Samsung SM-G920F Bedienungsanleitung

www.samsung.com

User Manual

English (EU). 03/2015. Rev.1.0

SM-G920F

SM-G920FQ

SM-G920I

Table of Contents

Basics

4 Read me first

5 Package contents

6 Device layout

8 SIM or USIM card

10 Battery

14 Turning the device on and off

15 Touchscreen

18 Home screen

24 Lock screen

25 Notification panel

28 Entering text

31 Screen capture

31 Opening apps

32 Multi window

37 Device and data management

41 Connecting to a TV

43 Sharing files with contacts

44 Emergency mode

Applications

45 Installing or uninstalling apps

46 Phone

49 Contacts

51 Messages

53 Internet

54 Email

55 Camera

71 Gallery

73 Smart Manager

75 S Planner

76 S Health

79 S Voice

81 Music

82 Video

83 Voice Recorder

85 My Files

86 Memo

86 Clock

88 Calculator

89 Google apps

Settings

91 Introduction

91 Wi-Fi

93 Bluetooth

95 Flight mode

95 Mobile hotspot and tethering

96 Data usage

97 Mobile networks

97 NFC and payment

100 More connection settings

102 Sounds and notifications

103 Display

103 Motions and gestures

Table of Contents

104 Applications

104 Wallpaper

105 Themes

105 Lock screen and security

110 Privacy and safety

113 Easy mode

113 Accessibility

114 Accounts

115 Backup and reset

115 Language and input

116 Battery

116 Storage

117 Date and time

117 User manual

117 About device

Appendix

118 Accessibility

133 Troubleshooting

138 Removing the battery (non-removable

type)

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customise the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licensed for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and

downloading, auto-syncing, or using location services depending on your data plan. For

large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Centre. For user-installed apps, contact service

providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

Basics

•

Depending on the region or model, some devices are required to receive approval from

the Federal Communications Commission (FCC). If your device is approved by the FCC,

you can view the FCC ID of the device. To view the FCC ID, tap

Apps

→

Settings

→

About device

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Package contents

Check the product box for the following items:

•

Device

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

Basics

Device layout

Microphone

Loud speaker

Back key

Multipurpose jack

Front camera

Speaker

SIM card tray

Power key

Touchscreen

Recents key

Headset jack

Home key (Fingerprint

recognition sensor)

LED indicator

Proximity/Light sensor

Main antenna

Infrared port

Flash

Volume key

NFC antenna/Wireless

charging coil

Rear camera

Microphone

GPS antenna

Basics

•

Do not cover the antenna area with your hands or other objects. This may cause

connectivity problems or drain the battery.

•

Using a Samsung-approved screen protector is recommended. Unapproved screen

protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touchscreen. The touchscreen may malfunction

in humid conditions or when exposed to water.

Keys

Key Function

Power

•

Press and hold to turn the device on or off.

•

Press to turn on or lock the screen.

Recents

•

Tap to open the list of recent apps.

•

Tap and hold to launch the split screen view.

Home

•

Press to turn on the screen while the screen is locked.

•

Press to return to the Home screen.

•

Press and hold to launch

Google

Back

•

Tap to return to the previous screen.

Volume

•

Press to adjust the device volume.

Basics

SIM or USIM card

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

•

Only nano-SIM cards work with the device.

•

Some LTE services may not be available depending on the service provider. For

more information about service availability, contact your service provider.

1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may

be damaged.

Basics

2 Pull out the SIM card tray gently from the SIM card tray slot.

3 Place the SIM or USIM card on the SIM card tray with the gold-coloured contacts facing

downwards.

Use caution not to lose or let others use the SIM or USIM card. Samsung is not

responsible for any damages or inconveniences caused by lost or stolen cards.

4 Insert the SIM card tray back into the SIM card tray slot.

Removing the SIM or USIM card

1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

2 Pull out the SIM card tray gently from the SIM card tray slot.

3 Remove the SIM or USIM card.

4 Insert the SIM card tray back into the SIM card tray slot.

Basics

Battery

Charging the battery

Charge the battery before using it for the first time or when it has been unused for extended

periods.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or

cables can cause the battery to explode or damage the device.

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on

immediately when the charger is connected. Allow a depleted battery to charge for

a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection

to another device, the battery will drain quickly. To avoid disconnecting from the

network or losing power during a data transfer, always use these apps after fully

charging the battery.

•

Using a power source other than the USB power adaptor, such as a computer, may

result in a slower charging speed due to a lower electric current.

Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable

into the multipurpose jack.
