USER MANUAL

English. 11/2019. Rev.1.0

XYZ

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

FCC ID : A3LSMG980F

Model : SM-G980F/DS, SM-G980F

Table of Contents

Basics

4 Read me first

7 Device overheating situations and

solutions

11 Device layout and functions

21 Battery

27 SIM or USIM card (nano-SIM card)

34 Memory card (microSD card) (Galaxy

37 Turning the device on and off

38 Initial setup

40 Samsung account

41 Transferring data from your previous

device (Smart Switch)

44 Understanding the screen

57 Notification panel

59 Entering text

Apps and features

62 Installing or uninstalling apps

64 Bixby

68 Bixby Vision

71 Bixby Home

74 Reminder

78 Phone

84 Contacts

88 Messages

91 Internet

93 Email

94 Camera

118 Gallery

124 AR EMOJI

131 Always On Display

134 Edge screen

138 Multi window

141 Samsung Pay

144 Samsung Health

150 Quick measure (Galaxy S5G)

151 Galaxy Wearable

151 Samsung Members

152 Samsung Notes

153 Calendar

154 Voice Recorder

157 My Files

157 Clock

159 Calculator

160 Game Launcher

162 Game Booster

163 Kids Home

165 SmartThings

169 Sharing content

170 Samsung DeX

177 Google apps

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Table of Contents

219 Accounts and backup

220 Samsung Cloud

221 Google

222 Advanced features

223 Bixby Routines

226 Motions and gestures

227 Dual Messenger

228 Digital wellbeing and parental controls

228 Digital Wellbeing

230 Device care

230 Optimising your device

231 Battery

232 Storage

232 Memory

233 Security

233 Apps

233 General management

234 Accessibility

235 Software update

235 About phone

Appendix

236 Accessibility

253 Troubleshooting

260 Removing the battery

Settings

179 Introduction

179 Connections

180 Wi-Fi

182 Bluetooth

183 NFC and payment

186 Data saver

186 Mobile data only apps

187 SIM card manager (dual SIM

models)

187 Mobile Hotspot and Tethering

188 More connection settings

192 Sounds and vibration

192 Dolby Atmos (surround sound)

193 Separate app sound

193 Notifications

194 Display

195 Blue light filter

196 Dark mode

196 Changing the screen mode or

adjusting the display colour

197 Screen resolution (Galaxy S5G,

)

198 Screensaver

198 Themes

199 Lock screen

200 Smart Lock

200 Biometrics and security

202 Face recognition

205 Fingerprint recognition

210 Samsung Pass

214 Secure Folder

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customise the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licensed for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and

downloading, auto-syncing, or using location services depending on your data plan. For

large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Centre. For user-installed apps, contact service

providers.

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

•

Modifying the device’s operating system or installing softwares from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

•

Your device comes with a screen protector attached. If you replace it, it is recommended

to use a Samsung product for better fingerprint recognition. (Galaxy S;

Whether a screen protector is attached may vary by region.)

•

Depending on the region or service provider, a screen protector is attached for protection

during production and distribution. Damage to the attached screen protector is not

covered by the warranty.

•

You can see the touchscreen clearly even in strong outdoor sunlight by automatically

adjusting the contrast range based on the surrounding environment. Due to the nature

of the product, displaying fixed graphics for extended periods may result in afterimages

(screen burn-in) or ghosting.

–

It is recommended not to use fixed graphics on part or all of the touchscreen for

extended periods and turn off the touchscreen when not using the device.

–

You can set the touchscreen to turn off automatically when you are not using it.

Launch the

Settings

app, tap

Display

→

Screen timeout

, and then select the length

of time you want the device to wait before turning off the touchscreen.

–

To set the touchscreen to automatically adjust its brightness based on the

surrounding environment, launch the

Settings

app, tap

Display

, and then tap the

Adaptive brightness

switch to activate it.

•

Depending on the region or model, some devices are required to receive approval from

the Federal Communications Commission (FCC). If your device is approved by the FCC,

you can view the FCC ID of the device. To view the FCC ID, launch the

Settings

app and

tap

About phone

→

Status

•

Depending on the region, you can view the regulatory information on the device. To

view the information, launch the

Settings

app and tap

About phone

→

Regulatory

information

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

Maintaining water and dust resistance

Your device supports water- and dust-resistance. Follow these tips carefully to maintain the

water- and dust-resistance of your device. Failure to do so may result in damage to your

device.

•

Do not immerse the device in fresh water deeper than 1.5 m or keep it submerged for

more than 30 minutes. If you immerse the device in any liquid other than fresh water,

such as salt water, ionised water, or alcoholic beverage, liquid will enter the device faster.

•

Do not expose the device to water moving with force.

•

If the device is exposed to fresh water, dry it thoroughly with a clean, soft cloth. If the

device is exposed to other liquids, such as salt water, swimming pool water, soapy water,

oil, perfume, sunscreen, hand cleaner, or chemical products such as cosmetics, rinse it

with fresh water and dry it thoroughly with a clean, soft cloth. If you do not follow these

instructions, the device’s performance and appearance may be affected.

•

If the device has been immersed in water or the microphone or speaker is wet, sound

may not be heard clearly during a call. After wiping the device with a dry cloth, dry it

thoroughly before using it.

•

The touchscreen and other features may not work properly if the device is used in water.

•

If the device is dropped or receives an impact, the water- and dust-resistant features of

the device may be damaged.

•

Your device has been tested in a controlled environment and certified to be water-

and dust-resistant in specific situations (meets requirements of classification IP68 as

described by the international standard IEC 60529-Degrees of Protection provided by

Enclosures [IP Code]; test conditions: 15-35 °C, 86-106 kPa, fresh water, 1.5 metre, 30

minutes). Despite this classification, it is still possible for your device to be damaged in

certain situations.

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

Device overheating situations and solutions

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast

charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or

performance and is in the device’s normal range of operation. If the battery becomes too hot,

the charger may stop charging.

Do the following when the device heats up:

•

Disconnect the charger from the device and close any running apps. Wait for the

device to cool down and then begin charging the device again.

•

If the lower part of the device overheats, it could be because the connected USB

cable is damaged. Replace the damaged USB cable with a new Samsung-approved

one.

•

When using a wireless charger, do not place foreign materials, such as metal objects,

magnets, and magnetic stripe cards, between the device and the wireless charger.

The wireless charging or fast charging feature is only available on supported models.

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

When the device heats up during use

When you use features or apps that require more power or use them for extended periods,

your device may temporarily heat up due to increased battery consumption. Close any

running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat. Depending on

the functions and apps you use, these examples may not apply to your model.

•

During the initial setup after purchase or when restoring data

•

When downloading large files

•

When using apps that require more power or using apps for extended periods

–

When playing high-quality games for extended periods

–

When recording videos for extended periods

–

When streaming videos while using the maximum brightness setting

–

When connecting to a TV

•

While multitasking (or, when running many apps in the background)

–

When using Multi window

–

When updating or installing apps while recording videos

–

When downloading large files during a video call

–

When recording videos while using a navigation app

•

When using large amount of data for syncing with the cloud, email, or other accounts

•

When using a navigation app in a car while the device is placed in direct sunlight

•

When using the mobile hotspot and tethering feature

•

When using the device in areas with weak signals or no reception

•

When charging the battery with a damaged USB cable

•

When the device’s multipurpose jack is damaged or exposed to foreign materials, such as

liquid, dust, metal powder, and pencil lead

•

When you are roaming

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

Do the following when the device heats up:

•

Keep the device updated with the latest software.

•

Conflicts between running apps may cause the device to heat up. Restart the device.

•

Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

•

Close apps that increase battery consumption or that run in the background when

not in use.

•

Delete unnecessary files or unused apps.

•

Decrease the screen brightness.

•

If the device overheats or feels hot for a prolonged period, do not use it for a while. If

the device continues to overheat, contact a Samsung Service Centre.

Precautions for device overheating

If you begin to feel uncomfortable due to the device overheating, stop using the device.

When the device heats up, the features and performance may be limited or the device may

turn off to cool down. The feature is only available on supported models.

•

If the device overheats and reaches a certain temperature, a warning massage will appear

to prevent device failure, skin irritations and damages, and battery leakage. To lower the

device’s temperature, the screen brightness and the performance speed will be limited

and battery charging will stop. Running apps will be closed and all calling and other

features will be limited, except for emergency calls, until the device cools down.

•

If the second message appears due to a further increase of the device’s temperature, the

device will turn off. Do not use the device until the device’s temperature drops below the

specified level. If the second warning message appears during an emergency call, the call

will not be disconnected by a forced shut down.

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Basics

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to

avoid shortening the battery’s lifespan, damaging the device, or causing a fire.

•

Do not store your device in very cold or very hot temperatures.

•

Do not expose your device to direct sunlight for extended periods.

•

Do not use or store your device for extended periods in very hot areas, such as inside a

car in the summertime.

•

Do not place the device in any areas that may overheat, such as on an electric heating

mat.

•

Do not store your device near or in heaters, microwaves, hot cooking equipment, or high

pressure containers.

•

Do not use a cable whose covering is peeled off or damaged, and do not use any charger

or battery that is damaged or malfunctioning.

SAMSUNG CONFIDENTIAL

FCC 규격용_전략제품개발3그룹

Andere Handbücher für SM-G980F

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Handy Handbücher

Samsung

Samsung SGH-T659 Series Bedienungsanleitung

Samsung

Samsung Galaxy light Bedienungsanleitung

Samsung

Samsung GT-C3332 Bedienungsanleitung

Samsung

Samsung Giorgio Armani SGH-P520 Bedienungsanleitung

Samsung

Samsung GALAXY S5 Bedienungsanleitung

Samsung

Samsung SM-M317F/DSN Bedienungsanleitung

Samsung

Samsung SPH-W5200 Bedienungsanleitung

Samsung

Samsung i8910 Bedienungsanleitung

Samsung

Samsung GT-B7702C Bedienungsanleitung

Samsung

Samsung SM-A525F/DS Bedienungsanleitung

Samsung

Samsung SM-G998B Montageanleitung

Samsung

Samsung SCH-N191 Bedienungsanleitung

Samsung

Samsung SGH-X481 Bedienungsanleitung

Samsung

Samsung SGH-P100 Bedienungsanleitung

Samsung

Samsung SGH-I607 - Hands-free Earbud Headset Bedienungsanleitung

Samsung

Samsung GT-M8910U Bedienungsanleitung

Samsung

Samsung Galaxy S III SCH-R530 Bedienungsanleitung

Samsung

Samsung SCH U900 Bedienungsanleitung

Samsung

Samsung SGH-G400 Bedienungsanleitung

Samsung

Samsung GT-E1080F Bedienungsanleitung

Samsung

Samsung Sprint SPH-a660 Bedienungsanleitung

Samsung

Samsung GT-S8000C Bedienungsanleitung

Samsung

Samsung SM-B360E Bedienungsanleitung

Samsung

Samsung Galaxy S9 Enterprise Edition Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
