Samsung SM-M307F Bedienungsanleitung

SM-M307F/FN

Common

Mobile Device CONTENTS

1. Safety Precautions

2. Specification

3. Product Function

4. Exploded View and Parts list

5. MAIN Electrical Parts List

6. Level 1 Repair

7. Level 2 Repair

8. Level 3 Repair

9. Reference Abbreviation

Notice: All functionality, features, specifications,

and other product information provided in this

document, including but not limited to, benefits,

design, pricing, components, performance,

availability, and capabiliti-es of the product are

subject to change without notice. Samsung

reserves the right to alter this doc-ument or the

product described herein at anytime, without

obligation to provide notification of such

changes.

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

1. Safety Precautions

1-1. Repair Precaution

Before attempting any repair or detailed tuning, shield the device from RF noise or static

electricity discharges.

Use only demagnetized tools that are specifically designed for small electronic repairs,

as most electronic parts are sensitive to electromagnetic forces.

Use only high quality screwdrivers when servicing products. Low quality screwdrivers can

easily damage the heads of screws.

Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin

of error of most testing equipment.

We recommend 22-gauge twisted copper wire.

Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily

damaged, even with relatively low heat. Never use a soldering iron with a power rating of

more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).

Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.

Always use the replacement parts that are registered in the SEC system. Third-party replacement parts

may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

1. Safety Precautions

1-2. ESD(Electrostatically Sensitive Devices) Precaution

Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can

be easily damaged by it. We recommend protecting these components with conductive anti-static bags

when you store or transport them.

Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate

static electricity from your body before repairing ESDs.

Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly

connected.

Use only desoldering tools with plastic tips to prevent static discharge.

Properly shield the work environment from accidental electrostatic discharge before opening

packages containing ESDs.

The potential for static electricity discharge may be increased in low humidity environments,

such as air-conditioned rooms. Increase the airflow to the working area to decrease the

chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.

2. Specification

2-1. GSM General Specification

Item

GSM 850

EGSM 900

DCS1800

PCS1900

Freq. Band[MHz]

Uplink/Downlink

824~849

869~894

880~915

925~960

1710~1785

1805~1880

1850~1910

1930~1990

ARFCN range 128~251 0~124 & 975~1023 512~885 512~810

Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz

Mod. Bit rate/

Bit Period

270.833kbps

3.692us

270.833kbps

3.692us

270.833kbps

3.692us

270.833kbps

3.692us

Time Slot Period/

Frame Period

576.9us

4.615ms

576.9us

4.615ms

576.9us

4.615ms

576.9us

4.615ms

Modulation GSM/

EGPRS

GMSK/

8PSK

GMSK/

8PSK

GMSK/

8PSK

GMSK/

8PSK

MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm

Power Class 4(GMSK)

E2(8PSK)

4(GMSK)

E2(8PSK)

1(GMSK)

E2(8PSK)

1(GMSK)

E2(8PSK)

Sensitivity -102dBm -102dBm -100dBm -100dBm

TDMA Mux 8 8 8 8

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.

2. Specification

2-2. GSM Tx Power Class

TX Power

control level

GSM850

TX Power

control level

EGSM900

TX Power

control level

DCS1800

TX Power

control level

PCS1900

5 33±2 dBm 5 33±2 dBm

30±3 dBm

6 31±2 dBm 6 31±2 dBm 1 28±3 dBm 1 28±3 dBm

7 29±2 dBm 7 29±2 dBm 2 26±3 dBm 2 26±3 dBm

8 27±2 dBm 8 27±2 dBm 3 24±3 dBm 3 24±3 dBm

9 25±2 dBm 9 25±2 dBm 4 22±3 dBm 4 22±3 dBm

10 23±2 dBm 10 23±2 dBm 5 20±3 dBm 5 20±3 dBm

1 1 21±2 dBm 1 1 21±2 dBm 6 18±3 dBm 6 18±3 dBm

12 19±2 dBm 12 19±2 dBm 7 16±3 dBm 7 16±3 dBm

13 17±2 dBm 13 17±2 dBm 8 14±3 dBm 8 14±3 dBm

14 15±2 dBm 14 15±2 dBm 9 12±4 dBm 9 12±4 dBm

15 13±2 dBm 15 13±2 dBm 10 10±4 dBm 10 10±4 dBm

16 11±3 dBm 16 11±3 dBm 1 1 8±4 dBm 1 1 8±4 dBm

17 9±3 dBm 17 9±3 dBm 12 6±4 dBm 12 6±4 dBm

18 7±3 dBm 18 7±3 dBm 13 4±4 dBm 13 4±4 dBm

19 5±3 dBm 19 5±3 dBm 14 2±5 dBm 14 2±5 dBm

- - - - 15 0±5 dBm 15 0±5 dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.

2. Specification

2-3. WCDMA General Specification

Item

WCDMA2100(B1)

WCDMA1900(B2)

WCDMA850(B5)

WCDMA900(B8)

Freq. Band[MHz]

Uplink/Downlink

1920~1980

2110~2170

1850~1910

1930~1990

824~849

869~894

880~915

925~960

ARFCN range

UL：9612~9888

DL：10562~10838

UL：9262~9538

DL：9662~9938

UL：4132~4233

DL：4357~4458

UL：2712~2868

DL：2937~3088

Tx/Rx spacing 190MHz 80MHz 45MHz 45MHz

Mod. Bit rate/

Bit Period

42.2Mbps(DL)

5.42Mbps(UL) 42.2Mbps(DL)

5.42Mbps(UL)

Time Slot Period/

Frame Period

WCDMA

10ms/0.667ms

HSPA

2ms/0.667ms

WCDMA

10ms/0.667ms

HSPA

2ms/0.667ms

WCDMA

10ms/0.667ms

HSPA

2ms/0.667ms

WCDMA

10ms/0.667ms

HSPA

2ms/0.667ms

Modulation QPSK

16QAM

64QAM

QPSK

16QAM

64QAM

QPSK

16QAM

64QAM

QPSK

16QAM

64QAM

MS Power

(dBm) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓)

Power Class 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)

Sensitivity -106dBm -104dBm -104dBm -103dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.

2. Specification

2-4. L T E General Specification

Item

LTE Band1

LTE Band3

LTE Band5

LTE Band7

LTE Band8

Freq. Band[MHz]

Uplink/Downlink

1920~1980

2110~2170

1710~1785

1805~1880

824~849

869~894

2500~2570

2620~2690

880~915

925~960

ARFCN range UL:18000~18599

DL:0~599

UL:19200~19949

DL:1200~1949

UL:20400~20649

DL:2400~2649

UL:20750~21449

DL:2750~3449

UL:21450-21799

DL:3450-3799

Tx/Rx spacing

(MHz) 190 95 45 120 45

Channel Bandwidth

(MHz) 5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 5/10/15/20 1.4/3/5/10

Modulation QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)

Sensitivity (QPSK,

BW 10MHz) (dBm) -96.3 -93.3 -94.3 -94.3 -93.3

Item

LTE Band20

LTE Band28

LTE Band38

LTE Band40

LTE Band41

Freq. Band[MHz]

Uplink/Downlink

832~862

791~821

703~748

758~803 2570~2620 2300~2400 2496~2690

ARFCN range UL:24150~24449

DL:6150~6449

UL:27210~27659

DL:9210~9659

UL/DL:37750 ~

38249

UL/DL:38650 ~

39649

UL/DL:39650 ~

41589

Tx/Rx spacing (MHz) -41 55

Channel Bandwidth

(MHz) 5/10/15/20 3/5/10/15/20 5/10/15/20 5/10/15/20 5/10/15/20

Modulation QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

QPSK,16/64QAM

256QAM(DL only)

MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)

Sensitivity(QPSK,

BW 10MHz) (dBm) -93.3 -94.8 -96.3 -96.3 -94.3

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of anycontentordatafrom thisdocument without Samsung’swritten authorization isstrictlyprohibited.

3. Product Function

Main Function

Item

Description

OS Android P OS V9.0

GSM850 / GSM900 / DCS1800 / PCS1900

WCDMA: B1/ B2/ B5/ B8

LTE: B1/B3/B5/B7/B8/B20/B38/B40/B41

Battery 6000mAh

Base Band 2.3Ghz Quad + 1.7GHz Quad

Other RF GPS, Glonass, Beidou, Galileo / BT5.0 / USB 2.0 / WIFI 802.11 a/b/g/n/ac / NFC(SM-M307FN Only)

Camera Triple Camera ( 48MP(F2.0) + 5MP(F2.2) + 8MP(F2.2)) with LED Flash / Front Camera 16MP(F2.0)

LCD 6.4", FHD+, 2400x1080

RAM 4GB / 6GB

Storage 64GB / 128GB

Sensor Accelerometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, Proximity Sensor, Grip

sensor

Accessory

Charger: 9V/1.67A and 5V/2.0A AFC charging

Data cable: 3.0pi, 0.8m(USB-C)

Ear phone: 3.5pi, 4pin

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

4. Exploded View and Parts List

4-1. Cellular phone Exploded View

QFR01

QAR01

QMO01

QME03

QCA02

QMP01

QCA01

QCR12

QAN02

QCR205

QKP01

QRE01

QSM01

QCR205

QAN01

QCB01

QME02

QME01

QIF01

QBA01

QSP01

※SVC REPAIR TAPE

QRT01

Confidential and proprietary-the contents in this service guide subject to change without prior notice

Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.

5. MAIN Electrical Parts List

Parts Code

Design LOC

Description

ZD5013 0401-001110 DIODE-SWITCHING

D5000 0404-001250 DIODE-SCHOTTKY

ZD6005,ZD6015 0406-001561 DIODE-TVS

ZD5012 0406-001592 DIODE-TVS

ZD5001 0406-001728 DIODE-TVS

ZD6013,ZD6014 0406-001781 DIODE-TVS

D5001 0406-001808 DIODE-TVS

ZD6011,ZD6012 0406-001809 DIODE-TVS

ZD1001 0406-001829 DIODE-TVS

LED5000 0601-003768 LED

U2006 1001-001911 IC

U2001 1001-001969 IC

U3004 1001-002065 IC

U3001 1001-002077 IC

U2020 1003-002802 IC

UCP400UP 1105-003012 IC

UME5000 1107-002536 IC

U3005 1201-003869 IC

U1001 1201-004029 IC

PAM1000 1201-004109 IC

PAM1001 1201-004209 IC

U1000,U1015 1201-004219 IC

U6001 1201-004240 IC

U3014 1203-008249 IC

U5006 1203-008251 IC

U7002 1203-008326 IC

U2000 1203-008693 IC

U5007 1203-008719 IC

U5003 1203-008729 IC

U3013,U7000 1203-008865 IC

U3000,U3003,U7003 1203-008867 IC

U7004 1203-008926 IC

U5001 1203-009113 IC

U7001 1203-009220 IC

U5000 1203-009224 IC

U5002 1203-009233 IC

U7038 1203-009245 IC

U6012 1205-005750 IC

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Handy Handbücher

Samsung

Samsung SGH-E870 Bedienungsanleitung

Samsung

Samsung GT-S8300 Bedienungsanleitung

Samsung

Samsung GT-C3200 Bedienungsanleitung

Samsung

Samsung SCH-R760 Bedienungsanleitung

Samsung

Samsung SGH-L878 Bedienungsanleitung

Samsung

Samsung SM-M307FN/DS Bedienungsanleitung

Samsung

Samsung SCH-2500 series Bedienungsanleitung

Samsung

Samsung SGH-D838 Bedienungsanleitung

Samsung

Samsung GH68-23488A Bedienungsanleitung

Samsung

Samsung GT-S5830D Bedienungsanleitung

Samsung

Samsung GT-I9118 Bedienungsanleitung

Samsung

Samsung SCH-R940 Bedienungsanleitung

Samsung

Samsung Z Flip4 5G Bedienungsanleitung

Samsung

Samsung SGH-t329 Series Bedienungsanleitung

Samsung

Samsung GALAXYS5 Bedienungsanleitung

Samsung

Samsung GT-S6500T Bedienungsanleitung

Samsung

Samsung GALAXY Note3 Bedienungsanleitung

Samsung

Samsung SM-G318ML/DS Bedienungsanleitung

Samsung

Samsung Galaxy Note 3 Docomo SC-01F Bedienungsanleitung

Samsung

Samsung A630 - SCH Cell Phone Bedienungsanleitung

Samsung

Samsung SM-G781W Bedienungsanleitung

Samsung

Samsung SGH-E250D Bedienungsanleitung

Samsung

Samsung GT-I9305T Bedienungsanleitung

Samsung

Samsung TracFone SGH-T155G Series Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
