Samsung SPHA820 Bedienungsanleitung

SPH-A820

User’s Guide

Draft

(2005. 1. 27)

Intellectual Property

All Intellectual Property, as defined below, owned by or

which is otherwise the property of Samsung or its

respective suppliers relating to the SAMSUNG Phone,

including but not limited to, accessories, parts, or

software relating there to (the “Phone System”), is

proprietary to Samsung and protected under federal

laws, state laws, and international treaty provisions.

Intellectual Property includes, but is not limited to,

inventions (patentable or unpatentable), patents, trade

secrets, copyrights, software, computer programs, and

related documentation and other works of authorship.

You may not infringe or otherwise violate the rights

secured by the Intellectual Property. Moreover, you

agree that you will not (and will not attempt to) modify,

prepare derivative works of, reverse engineer,

decompile, disassemble, or otherwise attempt to create

source code from the software. No title to or ownership

in the Intellectual Property is transferred to you. All

applicable rights of the Intellectual Property shall

remain with SAMSUNG and its suppliers.

Samsung Telecommunications

America (STA), Inc.

Headquarters:

1301 East Lookout Drive Suite 150 Richardson,

TX 75082

Tel: 972.761.7000

Customer Care Center:

1601 E. Plano Parkway, Suite 150 Plano, TX 75074

Toll Free Tel: 1.888.987.HELP (4357)

Fax: 972.801.6065

Internet Address: http://www.samsungusa.com

registered trademark of Samsung Electronics America,

Inc. and its related entities.

Licensed by Qualcomm Incorporated under one or more of

the following patents: U.S. Patent No. 4, 901, 307; 5, 056,

109; 5, 099, 204; 5,101, 501; 5, 103, 459; 5, 107, 225;

5, 109, 390.

Openwave® is a registered Trademark of Openwave, Inc.

RSA® is a registered TrademarSk RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY

CONTAINED ON THE WARRANTY PAGE ENCLOSED

WITH THE PRODUCT, THE PURCHASER TAKES THE

PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS

OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER

WITH RESPECT TO THE PRODUCT, INCLUDING BUT

NOT LIMITED TO THE MERCHANTABILITY OF THE

PRODUCT OR ITS FITNESS FOR ANY PARTICULAR

PURPOSE OR USE; THE DESIGN, CONDITION OR

QUALITY OF THE PRODUCT; THE PERFORMANCE OF

THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT

OR THE COMPONENTS CONTAINED THEREIN; OR

COMPLIANCE OF THE PRODUCT WITH THE

REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION

OR CONTRACT PERTAINING THERETO. NOTHING

CONTAINED IN THE INSTRUCTION MANUAL SHALL BE

CONSTRUED TO CREATE AN EXPRESS OR IMPLIED

WARRANTY OF ANY KIND WHATSOEVER WITH

RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG

SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY

KIND RESULTING FROM THE PURCHASE OR USE OF

THE PRODUCT OR ARISING FROM THE BREACH OF THE

EXPRESS WARRANTY, INCLUDING INCIDENTAL,

SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF

ANTICIPATED PROFITS OR BENEFITS.

Use road safety at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency call

Key in the emergency number for your present

location, then press [ ].

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 19.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

Contents

Unpack 3

Make sure you have each item

Your phone 3

Buttons, features, and locations

Get started 4

First steps to operate your phone

Menu functions 8

All menu options listed

Solve problems 17

Help and personal needs

Health and safety information 19

Unpack

Make sure you have each item

You can obtain the following accessories

for your phone from your local Samsung

dealer.

Phone Travel Adapter

Battery User’s Manual

• Standard battery • Extended battery

• Battery charger • Leather case

• Headset • Data link cable

• Car charger/

adapter •Travel chager/

adapte

• Portable hands free kit

Your phone

Buttons, features, and locations

Left soft key

Volume keys

Dial key

Special

function keys

Earpiece

Display

Power on/off/

Menu exit key

Alphanumeric

keys

Right soft key

Microphone

Navigation keys

(Up/Down/Left/

Right)

Menu access/

Confirm key

Cancel/

Correct key

Headset jack

External

speaker

External

display

Speaker

key

Service

LED

Ready link key

Get started

First steps to operate your phone

Install and charge the phone

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Install the battery:

To remove the battery,

slide the battery catch

toward the top of the

phone and hold it.

Plug the adapter into

the phone.

Plug the adapter into a standard AC wall outlet.

1 2

When the phone is completely charged (the

battery icon stops blinking), unplug the adapter

from the power outlet.

Remove the adapter from the phone.

Get started

Power on or off Keys and display

Power on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold

[]

to turn on

the phone.

3. If necessary, enter the PIN and

press <

Power off

1. Open the phone.

2. Press and hold

[]

Key(s) Description

Perform the function indicated on the bottom

line of the display.

In Idle mode, access menu options directly.

In Menu mode, scroll through the menu

options.

In Idle mode, enters Menu mode.

In Menu mode, selects the highlighted menu

option.

Sends or answers a call.

In Idle mode, retrieves the last number

dialled, missed, or received.

Deletes characters from the display.

In Menu mode, returns to the previous menu

level.

Get started

Key(s) Description

Ends a call. Hold down to switch the phone

on and off.

In Menu mode, cancels input and returns the

phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, hold

[1]

down to access your

voicemail.

Enter special characters.

Use for some special functions.

(on the left)

Accesses the Ready link list.

Makes and answers a R-Link call.

(on the left)

Adjusts the phone volume.

In Idle mode, with the phone open, adjusts

the keypad tone volume. With the phone

closed, hold down to turn on the backlight.

In Menu mode, scrolls through the menu

options.

(on the right)

Turns on the external speaker during a call.

In Idle mode, retrieves the last number

dialed, received, or missed.

Holde down to start the voice recognition.
