Samsung DV331AE Series Bedienungsanleitung

* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and

Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of

consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.

Signature Features

Sensor Dry

For the perfect dry every time

Detects the moisture level in the load

and adjusts the drying time to save

time and money.

Available Colors

Wrinkle Prevent Option

To reduce ironing time

Intermittently tumbles clothes at the

end of the drying cycle to help prevent

wrinkles from setting in.

Steam Drying Technology

Refresh and Wrinkle-Care

These cycles infuse clothes with steam

to reduce wrinkles, remove odors, and

refresh clothing.

Neat White

DV331AER

7.3 cu. ft. Capacity Electric Steam Dryer

Features

∙Steam Drying Technology:

-Steam Refresh: Freshens up

clothes and removes odors

-Steam Wrinkle-Care: Relaxes

wrinkles to reduce ironing

∙7.3 cu. ft. Capacity

∙9 Preset Drying Cycles

∙3 Options

∙4 Temperature Settings

∙ 4 Way Venting

Convenience

∙Sensor Dry – Detects Moisture and

Adjusts Drying Time

∙Reversable See Through Door

∙ Dryer Drum Light

∙Child Lock

∙Lint Filter Indicator

∙Remaining Time Display

∙Adjustable End of Cycle Signal

∙Optional Pedestals or Stacking

Kit Available

Ranked “Highest in Customer

Satisfaction with Clothes

Dryers” by J.D. Power and

Associates.*

(Shown with optional pedestal) 3 Options

9 Cycles

Tango Red

(shown)

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Fabric Care

9 Preset Dry Cycles

Steam Refresh, Steam Wrinkle-Care, Normal,

Heavy Duty, Permanent Press, Delicates, Sanitize,

Time Dry, Quick Dry

3 Options

Mixed Load Bell, Wrinkle Prevent, Adjust Time

4 Temperature Settings

High, Medium, Low, Extra Low

4 Dry Levels

More Dry, Normal Dry, Less Dry, Damp Dry

3 Signal Sound Levels

Louder, Soft, Off

Accessories:

Stacking Kit: SK-3A1, SK-4A, SK-5A

Vent Kit: DV-1A

Pedestal: WE357A0R, WE357A0W

Warranty

One (1) Year All Parts and Labor

Two (2) Years Control Board

Product Dimensions + Weight

Dimensions: (WxHxD) 27" x 38 5⁄8" x 30 7⁄8"

Weight: 121.1 lbs / 55 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD) 29 3⁄4" x 43 3⁄4" x 33 1⁄8"

Weight: 143.2 lbs / 65 kg

Color Model # UPC Code

Tango Red DV331AER 036725560796

Neat White DV331AEW 036725560802

Matching Washer

Tango Red WF331ANR 036725560772

Neat White WF331ANW 036725560789

Installing your dryer

Required Dimensions for Installation With Pedestal Required Dimensions for Installation

With Stacking Kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 In.(2.5 cm)

Top - 17 In.(43.2 cm)

Rear - 4 In. (10.2 cm)

Closet Front - 2 In. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in²

(465cm²) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

1 in.1 in. 27 in.

Recessed Area

2 in. 4 in.

17 in.

Side View Conﬁned

27 in.

53 in.

Closet or Door

48 in.² *

24 in.² *

3 in.

1 in. 5.5 in.**

2.5 in.

1 in. 27 in.

77.25

in.

6 in. *

4 in.

50.8 in. (129 cm) to clear open door

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

Installation Options:

Stacked Side by Side On Pedestals Stacked Depth

(38 2⁄8”)

DV331AER

7.3 cu. ft. Capacity Electric Steam Dryer

30.875 in.

38.625

in.

30.875 in.

30.875

in.

* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and

Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of

consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.

Available Colors

(Shown with optional pedestal) 3 Options

9 Cycles

Signature Features

Sensor Dry

For the perfect dry every time

Detects the moisture level in the load

and adjusts the drying time to save

time and money.

Wrinkle Prevent Option

To reduce ironing time

Intermittently tumbles clothes at the

end of the drying cycle to help prevent

wrinkles from setting in.

Neat White

DV331AGR

7.3 cu. ft. Capacity Gas Steam Dryer

Tango Red

(shown)

Steam Drying Technology

Refresh and Wrinkle-Care

These cycles infuse clothes with steam

to reduce wrinkles, remove odors, and

refresh clothing.

Features

∙Steam Drying Technology:

-Steam Refresh: Freshens up

clothes and removes odors

-Steam Wrinkle-Care: Relaxes

wrinkles to reduce ironing

∙7.3 cu. ft. Capacity

∙9 Preset Drying Cycles

∙3 Options

∙4 Temperature Settings

∙ 3 Way Venting

Convenience

∙Sensor Dry – Detects Moisture and

Adjusts Drying Time

∙Reversable See Through Door

∙ Dryer Drum Light

∙Child Lock

∙Lint Filter Indicator

∙Remaining Time Display

∙Adjustable End of Cycle Signal

∙Optional Pedestals or Stacking

Kit Available

Ranked “Highest in Customer

Satisfaction with Clothes

Dryers” by J.D. Power and

Associates.*

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Fabric Care

9 Preset Dry Cycles

Steam Refresh, Steam Wrinkle-Care, Normal,

Heavy Duty, Permanent Press, Delicates, Sanitize,

Time Dry, Quick Dry

3 Options

Mixed Load Bell, Wrinkle Prevent, Adjust Time

4 Temperature Settings

High, Medium, Low, Extra Low

4 Dry Levels

More Dry, Normal Dry, Less Dry, Damp Dry

3 Signal Sound Levels

Louder, Soft, Off

Accessories:

Stacking Kit: SK-3A1, SK-4A, SK-5A

Vent Kit: DV-1A

Pedestal: WE357A0R, WE357A0W

Warranty

One (1) Year All Parts and Labor

Two (2) Years Control Board

Product Dimensions + Weight

Dimensions: (WxHxD) 27" x 38 5⁄8" x 30 7⁄8"

Weight: 121.1 lbs / 55 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD) 29 3⁄4" x 43 3⁄4" x 33

1⁄8"

Weight: 143.2 lbs / 65 kg

Installing your dryer

Required Dimensions for Installation With Pedestal Required Dimensions for Installation

With Stacking Kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 In.(2.5 cm)

Top - 17 In.(43.2 cm)

Rear - 4 In. (10.2 cm)

Closet Front - 2 In. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in²

(465cm²) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

1 in.1 in. 27 in.

Recessed Area

2 in. 4 in.

30.875 in.

17 in.

Side View Conﬁned

27 in.

38.625

in.

53 in.

Closet or Door

48 in.² *

24 in.² *

3 in.

1 in. 5.5 in.**

2.5 in.

1 in. 27 in.

6 in. *

4 in.

30.875 in.

30.875

in.

50.8 in. (129 cm) to clear open door

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

Installation Options:

Stacked Side by Side On Pedestals Stacked Depth

(38 2⁄8”)

DV331AGR

7.3 cu. ft. Capacity Electric Steam Dryer

Color Model # UPC Code

Tango Red DV331AGR 036725560819

Neat White DV331AGW 036725560826

Matching Washer

Tango Red WF331ANR 036725560772

Neat White WF331ANW 036725560789

77.25

in.
