Samsung SDC18809 Bedienungsanleitung

Condensing Dryer

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

SDC18809

SDC1A809

SDC3C801

SDC3K801

This manual is made with 100% recycled paper.

SDC18809X-02805K-02_EN.indd 1SDC18809X-02805K-02_EN.indd 1 2011-06-02  11:48:572011-06-02  11:48:57

2_ features

features

1. Super capacity

Ultra drying capabilities are at your ﬁngertips! Now you can dry extra-large loads. Our large

8kg capacity dryer circulates more air through your clothes, drying them faster, for a wrinkle-

free result.

2. Visible water tank indicator

For the ﬁrst time in the industry, users can see the water level of the water tank through the

transparent scale panel, without having to open the water tank.

3. Sensor drying (fully automatic drying)

By adopting humidity and temperature sensors, the operating time and energy usage is

controlled using digital technology.

4. Interior lamp

The interior lamp allows the easy viewing of the interior even when it is dark.

5. Rack drying

This is a low-temperature drying function developed to protect fragile fabrics from the

tumbling process and to dry items such as sports shoes that cannot be dried by the tumble

drying course.

6. Certiﬁcated wool course

The wool-mark certiﬁed course minimizes damage when drying wool clothes.

7. Reversible door for easier door opening at any location

Our dryers will ﬁt just about anywhere and without a door conﬂict. The direction of our easy

reversible door can be changed with simple handy work.

8. Diamond drum for fabric care

Samsung electronics’ proprietary diamond-shaped drum offers excellent protection to your

laundry.

9. High energy efﬁciency

Energy efﬁciency has been optimised to minimize unnecessary power consumption.

M1006(Woolmark approval number).

SDC18809X-02805K-02_EN.indd Sec9:2SDC18809X-02805K-02_EN.indd Sec9:2 2011-06-02  11:49:162011-06-02  11:49:16

safety information _3

safety information

Congratulations on your new Samsung Dryer. This manual contains important

information on the installation, use, and care of your appliance. Please take the

time to read this manual to take full advantage of your dryer’s many beneﬁts and

features.

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all possible conditions and

situations that may occur. It is your responsibility to use common sense, caution, and care when installing,

maintaining, or operating your dryer.

Always contact your manufacturer about problems or conditions you do not understand.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS

WARNING

Hazards or unsafe practices that may result in severe personal injury or

death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or

property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or personal injury when

using your washer, follow these basic safety precautions:

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicity.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric shock.

Call the service center for help.

Note

Read operator’s manual

• Clothes dryer installation must be performed by a qualiﬁed technician.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• To reduce the risk of severe injury or death, follow all installation instructions.

WARNING - Risk of Fire

SDC18809X-02805K-02_EN.indd Sec1:3SDC18809X-02805K-02_EN.indd Sec1:3 2011-06-02  11:49:172011-06-02  11:49:17

4_ safety information

This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and

spread out so that the heat is dissipated.

safety information

WARNING

SDC18809X-02805K-02_EN.indd Sec1:4SDC18809X-02805K-02_EN.indd Sec1:4 2011-06-02  11:49:172011-06-02  11:49:17

safety information _5

SEVERE WARNING SIGNS FOR INSTALLATION

The installation of this appliance must be performed by a qualiﬁed technician or service

company.

- Failure to do so may result in electric shock, ﬁre, an explosion, problems with the

product, or injury.

Plug the power cord into an AC 220~240V/50Hz wall socket or higher and use the socket

for this appliance only. In addition, do not use an extension cord.

- Sharing a wall socket with other appliances using a power strip or extending the power

cord may result in electric shock or ﬁre.

- Ensure that the power voltage, frequency and current are the same as those of the

product speciﬁcations. Failure to do so may result in electric shock or ﬁre. Failure Plug

the power plug into the wall socket ﬁrmly.

Remove all foreign substances such as dust or water from the power plug terminals and

contact points using a dry cloth on a regular basis.

- Unplug the power plug and clean it with a dry cloth.

- Failure to do so may result in electric shock or ﬁre.

Keep all packaging materials well out of the reach of children, as packaging materials can

be dangerous to children.

- If a child places a bag over its head, it may result in suffocation.

This appliance must be properly grounded.

Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- This may result in electric shock, ﬁre, an explosion, or problems with the product

- Never plug the power cord into a socket that is not grounded correctly and make sure

that it is in accordance with local and national codes.

Do not install or keep the product exposed to the outdoor elements.

Do not use a damaged power plug, damaged power cord or loose wall socket.

- This may result in electric shock or ﬁre.

If the plug (power supply cord) is damaged, it must be replaced by the manufacturer or its

service agent or a similar qualiﬁed technician in order to avoid a hazard.

This appliance should be positioned to be accessible to the power plug after installation.

Do not pull or excessively bend the power cord.

Do not twist or tie the power cord.

Do not hook the power cord over a metal object, place a heavy object on the power cord,

insert the power cord between objects, or push the power cord into the space behind the

appliance.

- This may result in electric shock or ﬁre.

Do not pull the power cord, when unplugging the power plug.

- Unplug the power plug by holding the plug.

- Failure to do so may result in electric shock or ﬁre.

This appliance must be properly grounded. Never plug the power cord into a receptacle

that is not grounded adequately and in accordance with local and national codes. See

installation instructions for grounding this appliance.

WARNING

SDC18809X-02805K-02_EN.indd Sec1:5SDC18809X-02805K-02_EN.indd Sec1:5 2011-06-02  11:49:172011-06-02  11:49:17

6_ safety information

SEVERE WARNING SIGNS FOR USING

Do not let children or pets on or into the product. In addition, when disposing of this

product, disassemble the door lock (lever).

- This may result in children falling and injuring themselves.

- If children become locked in the product, there is a danger of suffocation.

Do not try to access the inside of the product when the drum is rotating.

Do not sit on the product or lean against the door.

- This may result in the product turning over and resulting in injury.

Dry the laundry only after it was spun by an appropriate washing machine.

Do not dry unwashed items in the tumble dryer.

Do not drink the condensed water.

Never stop a tumble dryer before the end of the drying cycle unless all items are quickly

removed and spread out so that the heat is dissipated.

Do not dry laundry contaminated by inﬂammable materials such as gasoline, kerosene,

benzene, thinner, alcohol, etc.

- This may result in electric shock, ﬁre or explosion.

Do not let pets chew or play with the dryer.

- This may result in electric shock or injury.

When disposing of the product, separate the door and the power cord before disposing of

the product.

- Failing to do so may result in damage to the power code or an injury.

Do not touch the power plug with wet hands.

- This may result in electric shock.

Do not repair, replace, or attempt to service any part of the appliance unless speciﬁcally

recommended in the user-repair instructions. You must also have the skills necessary to

service this appliance.

Do not attempt to repair, disassemble, or modify the appliance yourself.

- Do not use any fuse(such as cooper, steel wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is required, contact your nearest service

center.

- Failure to do so may result in electric shock, ﬁre, problems with the product, or injury.

safety information

WARNING

SDC18809X-02805K-02_EN.indd Sec1:6SDC18809X-02805K-02_EN.indd Sec1:6 2011-06-02  11:49:172011-06-02  11:49:17

safety information _7

CAUTION SIGNS FOR USING

Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in electric shock, ﬁre, problems with the product, or injury.

Do not touch the glass door and inside of the drum during or just after drying as it is hot.

- This may result in burns.

Do not press the buttons using sharp objects such as pins, knifes, ﬁngernails, etc.

- This may result in electric shock or injury.

Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry

contaminated by dry cleaning detergent.

- This may result in spontaneous combustion or ignition due to the heat of the oxidation of

the oil.

Do not dry laundry containing forming rubber (latex) or similar rubber textures.

- If forming rubber is heated, it may start a ﬁre.

Do not dry laundry contaminated by vegetable oil or cooking oil as a large amount of the oil

will not be removed when washing the laundry. In addition, use the Cool Down cycle so that

the laundry is not heated.

- The oxidization heat of the oil may start a ﬁre.

Make sure that the pockets of all clothing to be washed are empty.

- Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause

extensive damage to the appliance.

Do not wash clothing with large buckles, buttons, or other heavy metal.

Do not use softener or a static electricity remover unless recommended by the

manufacturer.

- This may result in damage to the laundry.

Do not use the dryer near dangerous powders such as coal dust, wheat ﬂour, etc.

- This may result in electric shock, ﬁre or an explosion.

Do not place inﬂammable materials near the product.

- This may result in toxic gases from the product, damage to parts, electric shock, ﬁre or

an explosion.

- The appliance should not be placed behind lockable doors etc.

SEVERE WARNING SIGNS FOR CLEANING

Do not clean the appliance by spraying water directly onto it.

Do not use benzene, thinner or alcohol to clean the appliance.

- This may result in discolouration, deformation, damage, electric shock or ﬁre.

Before cleaning or performing maintenance, unplug the appliance from the wall socket.

- Failure to do so may result in electric shock or ﬁre.

Clean the ﬁlter case before and after using the dryer.

Clean the inside of the product on a regular basis by asking an authorized service engineer.

Clean the condenser with water once a month.

The interior of the dryer should be cleaned periodically by qualiﬁed service personnel.

CAUTION

WARNING

SDC18809X-02805K-02_EN.indd Sec1:7SDC18809X-02805K-02_EN.indd Sec1:7 2011-06-02  11:49:172011-06-02  11:49:17

8_ contents

contents

INSTALLING YOUR DRYER

9Tools needed for installation

9See Dryer Exterior

10 Check before installing

10 Before using the product

10 Important to installer

10 Location considerations

10 Alcove or closet installation

11 Electrical requirements

11 Grounding

12 Installation side by side

12 Final installation checklist

13 Draining water without using the water tank

13 Connecting the drain hose

15 Installation stacking

16 Door Reversal

OPERATING INSTRUCTIONS, TIPS

18 Overview of the control panel

20 Child lock

20 Signal off

21 My cycle

21 Delay End

21 Interior Lamp

22 Rack Dry

23 Load the dryer properly

23 Getting started

CARE AND CLEANING

24 Clean the ﬁlter case

24 Clean the condenser

24 Control Panel

24 Tumbler

24 Stainless Steel Tumbler

24 Dryer Exterior

25 Dumping condensed water( )

25 Cleaning the ﬁlter case( )

26 Cleaning the condenser assembly

SPECIAL LAUNDRY TIPS

27 Special laundry tips

TROUBLESHOOTING

28 Check these points if your dryer…

30 Information codes

APPENDIX

31 Fabric care chart

32 Protecting the environment

32 Declaration of conformity

32 Speciﬁcations

33 Cycle chart

34 Consumption data

SDC18809X-02805K-02_EN.indd Sec2:8SDC18809X-02805K-02_EN.indd Sec2:8 2011-06-02  11:49:172011-06-02  11:49:17

installing your dryer _9

installing your dryer

TOOLS NEEDED FOR INSTALLATION

Hire a professional to install this dryer properly. If there is a service call performed as a result of poor setup,

adjustment, and connection, it is considered the responsibility of the installer. If you install the dryer you are

responsible.

Make sure you have everything necessary for proper installation (AC 220~240V/50Hz).

1. A GROUNDED ELECTRICAL OUTLET is required. See Electrical Requirements (See page 11).

2. CONDENSING SYSTEM - Condenses, processes and circulates hot and humid air internally using an

internal heat condenser.

SEE DRYER EXTERIOR

Parts

Hose guide Cable tie Hose connector Long drain hose(2m) Manual book

01 INSTALLING YOUR DRYER

Water tank

Control panel

Door

Levelling feet

Work top

Plug

Filter case

Condenser

SDC18809X-02805K-02_EN.indd Sec3:9SDC18809X-02805K-02_EN.indd Sec3:9 2011-06-02  11:49:172011-06-02  11:49:17

10_ installing your dryer

CHECK BEFORE INSTALLING

• Do not plug the power cord into the wall outlet before completing the dryer installation.

• Check the appearance of the product for any damaged parts before starting the product installation.

• If there are any parts that appear to be damaged, please contact your nearest Samsung Customer

Service Center.

• When moving the product, do not move the product by yourself.

• Take care of the edges of the dryer as they can be sharp.

• Do not install the dryer in a location exposed to frost. Cold water may damage the product.

• Use the product indoors only.

• Do not place the dryer on one side when lifting it, and do not move the dryer in such a way that the

internal parts shake. This may result in damage to the internal parts of the product.

BEFORE USING THE PRODUCT

• Check if there are any accessories remaining inside the drum.

• Plug in the power cord just before operating the product.

• Do not block the air inlet hole of the cooling grill at the front of the dryer.

• Do not place inﬂammable objects near the dryer and keep the surroundings clean.

• Keep the dryer level with the ground.

• Do not remove the adjustable levelling feet of the dryer. They are necessary to keep the product level

with the ground.

IMPORTANT TO INSTALLER

Please read the following instructions carefully before installing the dryer. These instructions should be kept

for future reference.

REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES TO AVOID THE DANGER OF A CHILD

SUFFOCATING.

LOCATION CONSIDERATIONS

Because a condensing type has been adopted, which condenses and processes air inside the dryer,

external ventilation is not required.

Therefore, The dryer can be installed and used in any location where the temperature is between 5

and 35 degrees centigrade, unlike a conventional dryer that requires an external exhaust system.

ALCOVE OR CLOSET INSTALLATION

To operate safely and properly, your new Dryer requires minimum clearances of:

Sides – 25 mm Rear – 51 mm

Top – 25 mm Front – 465 mm

If both the washing machine and a dryer are installed together, the front of the alcove or closet must have at

least 465 mm unobstructed air opening.

installing your dryer

WARNING

SDC18809X-02805K-02_EN.indd Sec3:10SDC18809X-02805K-02_EN.indd Sec3:10 2011-06-02  11:49:182011-06-02  11:49:18

Andere Handbücher für SDC18809

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Trockner Handbücher

Samsung

Samsung DV339AE series Bedienungsanleitung

Samsung

Samsung DVE22N6850W Bedienungsanleitung

Samsung

Samsung DVE45R6300 Series Bedienungsanleitung

Samsung

Samsung DVG45T6005 Series Bedienungsanleitung

Samsung

Samsung DV456EWHDSU/AA Bedienungsanleitung

Samsung

Samsung FlexDry DVG55M9600W Bedienungsanleitung

Samsung

Samsung DVE54M8750 Series Bedienungsanleitung

Samsung

Samsung DV22K6800 series Bedienungsanleitung

Samsung

Samsung DV405 SERIES Bedienungsanleitung

Samsung

Samsung DV8 Series Bedienungsanleitung

Samsung

Samsung DV400GWHD Series Bedienungsanleitung

Samsung

Samsung FlexDry DVG55M9600W/A3 Bedienungsanleitung

Samsung

Samsung DVE45T3400P Bedienungsanleitung

Samsung

Samsung DV206LEW Bedienungsanleitung

Samsung

Samsung DV56H9100EG/AC Bedienungsanleitung

Samsung

Samsung DV45H6300EG Installations- und Betriebshandbuch

Samsung

Samsung DV42H5400EF Bedienungsanleitung

Samsung

Samsung DVG50R8500 Series Bedienungsanleitung

Samsung

Samsung DVEG53BB8900 Series Bedienungsanleitung

Samsung

Samsung DVE50T7455V/AC Bedienungsanleitung

Samsung

Samsung DV42H5200 Bedienungsanleitung

Samsung

Samsung DVG45T6200W/A3 Bedienungsanleitung

Samsung

Samsung DV218AEW Bedienungsanleitung

Samsung

Samsung DV665J Series Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
