Samsung DB32E Bedienungsanleitung

User Manual

The color and the appearance may differ depending on the

product, and the specifications are subject to change without

prior notice to improve the performance.

Recommended hours of use per day for the DBE models is less

than 16 hours.

If the product is used for longer than 16 hours a day, the

warranty may be void.

DB32E DB40E DB48E DB55E

DM32E DM40E DM48E DM55E DM65E DM75E

DH40E DH48E DH55E

Table of contents

Before Using the Product

Safety Precautions 8

Symbols 8

Cleaning 8

Storage 9

Electricity and Safety 9

Installation 10

Operation 12

Preparations

Checking the Components 16

Components 16

Parts 17

Control Panel 17

Reverse Side 19

Plug In Module (Sold separately) 21

Anti-theft Lock 21

Spacer logo 22

Remote Control 23

Connection Using an IR Stereo Cable

(sold separately) 25

Before Installing the Product

(Installation Guide) 26

Tilting Angle and Rotation 26

Ventilation 26

Dimensions 28

Using the COVER-JACK 29

Installing the Wall Mount 30

Installing the Wall Mount Kit 30

Wall Mount Kit Specifications (VESA) 30

Remote Control (RS232C) 32

Cable Connection 32

Connection 35

Control Codes 36

Connecting and Using a Source

Device

Before Connecting 45

Pre-connection Checkpoints 45

Connecting to a PC 45

Connection using the D-SUB cable

(Analog type) 45

Connection using a DVI cable (Digital type) 46

Connection Using an HDMI-DVI Cable 46

Connection Using an HDMI Cable 47

Connection Using an DP Cable 47

Connecting an External Monitor 48

Connecting to a Video Device 49

Connection Using the AV Cable 49

Connection Using the component Cable 49

Connection Using an HDMI-DVI Cable 50

Connection Using an HDMI Cable 51

Connecting to an Audio System 51

Connecting the antenna 52

Connecting the LAN Cable 52

Changing the Input source 53

Source 53

Using MDC

MDC Program Installation/Uninstallation 54

Installation 54

Uninstallation 54

Connecting to MDC 55

Using MDC via RS-232C

(serial data communications standards) 55

Using MDC via Ethernet 56

Home feature

Player 58

Approving a connected device from the server 59

Network Channel 63

Local Channel 63

Published Content 63

My Templates 63

Available features in the Player page 64

Player page Settings menu 65

When Content is Running 67

File Formats Compatible with Player 69

File Formats Compatible with Video Wall 74

Table of contents

Schedule 76

Available features in the Schedule page 76

Template 78

Clone Product 81

ID Settings 82

Device ID 82

PC Connection Cable 82

Device ID Auto Set 82

Video Wall 83

Apply to 83

Video Wall 84

Network Status 85

Picture Mode 86

On/Off Timer 87

On Timer 87

Off Timer 88

Holiday Management 88

Ticker 89

More settings 89

URL Launcher 90

Screen Adjustment

Picture Mode 91

Backlight / Contrast / Brightness / Sharpness /

Color / Tint (G/R) 92

Color Temperature 93

White Balance 94

2 Point 94

10 Point 94

Gamma 95

Calibrated Value 95

Advanced Settings 96

Dynamic Contrast 97

Black Tone 97

Flesh Tone 97

RGB Only Mode 97

Color Space 97

Motion Lighting 97

Picture Options 98

Color Tone 99

Digital Clean View 99

MPEG Noise Filter 99

HDMI Black Level 100

Film Mode 100

Auto Motion Plus 101

Dynamic Backlight 101

Picture Size 102

Position 103

Zoom/Position 103

Resolution 104

Auto Adjustment 105

PC Screen Adjustment 105

Picture Off 106

Reset Picture 106

OnScreen Display

PIP 107

PIP Settings 107

Display Orientation 109

Onscreen Menu Orientation 109

Source Content Orientation 109

Aspect Ratio 109

Screen Protection 110

Auto Protection Time 110

Screen Burn Protection 110

Message Display 113

Source Info 113

Multimedia Device Connection 113

No Signal Message 113

MDC Message 113

Download Status Message 113

Menu Language 114

Table of contents

Reset OnScreen Display 114

Sound Adjustment

Sound Mode 115

Sound Effect 116

Virtual Surround 116

Dialog Clarity 116

Equalizer 116

HDMI Sound 117

Sound on Video Call 117

Dolby Digital Comp 118

Speaker Settings 118

Sound Output 118

Auto Volume 119

Reset Sound 119

Broadcasting

Auto Program 120

Antenna 121

Channel List 122

Added Ch. 122

Favorites 1 ~ Favorites 5 122

Options 122

Edit Channel 123

Edit Favorites 125

Audio Options 128

Preferred Language 128

Multi-Track Sound 128

Program Rating Lock 129

Channel Settings 131

Fine Tune 131

Clear Scrambled Channel 131

Network

Network Status 132

Network Settings 132

Network type 132

Network Settings (Wired) 133

Network Setting (Wireless) 135

WPS(PBC) 137

Wi-Fi Direct 138

Multimedia Device Settings 138

Screen Mirroring 139

Server Network Settings 139

Connect to Server 139

MagicInfo Mode 139

Server Access 139

FTP Mode 139

Device Name 140

System

Accessibility 141

Voice Guide 141

Video Description 142

Caption 142

Menu Transparency 144

High Contrast 144

Enlarge 144

Setup 145

Initial settings (Setup) 145

Touch Control 147

Touch Control Lock 147

Admin Menu Lock 147

Time 148

Clock 148

DST 149

Sleep Timer 149

Power On Delay 149

Auto Source Switching 150

Primary Source Recovery 150

Primary Source 150

Secondary Source 150

Table of contents

Power Control 151

Auto Power On 151

PC Module Power 151

Max. Power Saving 151

Standby Control 152

Power Button 152

Network Standby 152

Eco Solution 153

Energy Saving 153

Eco Sensor 153

Screen Lamp Schedule 153

No Signal Power Off 154

Auto Power Off 154

Temperature Control 154

Device Manager 155

Keyboard Settings 155

Mouse Settings 156

Pointer Settings 157

Play via 158

Change PIN 158

Security 159

Safety Lock 159

Button Lock 159

USB Auto Play Lock 159

General 160

Smart Security 160

BD Wise 161

Anynet+ (HDMI-CEC) 162

Troubleshooting for Anynet+ 164

HDMI Hot Plug 166

DivX®Video On Demand 166

Game Mode 166

Reset System 167

Support

Software Update 168

Update now 168

Auto Update 168

Contact Samsung 168

Go to Home 169

Player 169

Schedule 169

Template 169

Clone Product 169

ID Settings 169

Video Wall 170

Network Status 170

Picture Mode 170

On/Off Timer 170

Ticker 170

More settings 170

Reset All 171

Playing photos, videos and music

(Media Play)

Read the following before using

media play with a USB device 172

Using a USB device 174

Playing media content from a PC/mobile device 175

Features provided in the media content list

page 176

Menu items in the media content list page 177

Available buttons and features during photo

playback 178

Available buttons and features during video

playback 179

Available buttons and features during music

playback 180

Supported Subtitle and Media play file

formats 181

Subtitle 181

Supported image resolutions 181

Supported music file formats 182

Supported Video Formats 182

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Center 184

Testing the Product 184

Checking the Resolution and Frequency 184

Check the followings. 185

Q & A 192

Specifications

General 194

PowerSaver 197

Preset Timing Modes 199

Appendix

Responsibility for the Pay Service

(Cost to Customers) 201

Not a product defect 201

A Product damage caused by customer's fault 201

Others 201

Optimum Picture Quality and Afterimage

Burn-in Prevention 202

Optimum Picture Quality 202

Prevention of Afterimage Burn-in 202

License 204

Terminology 205

Table of contents

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

Chapter 01

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-

colored stains on the product.

―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10 cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Andere Handbücher für DB32E

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung LCD-Fernseher Handbücher

Samsung

Samsung P R E L I M I N A R Y LN46B650 Bedienungsanleitung

Samsung

Samsung LT-P266W Bedienungsanleitung

Samsung

Samsung Series 4+ Bedienungsanleitung

Samsung

Samsung LE32A676A1M Bedienungsanleitung

Samsung

Samsung SMART TV Bedienungsanleitung

Samsung

Samsung LN19A450 - 19" LCD TV Bedienungsanleitung

Samsung

Samsung Series 4+ Bedienungsanleitung

Samsung

Samsung LN40A450 Bedienungsanleitung

Samsung

Samsung LN40C560J2F Bedienungsanleitung

Samsung

Samsung LN-S4052D Bedienungsanleitung

Samsung

Samsung LE19A656A1D Bedienungsanleitung

Samsung

Samsung LN37A530 Bedienungsanleitung

Samsung

Samsung 3 SERIES Bedienungsanleitung

Samsung

Samsung LN40B750 Bedienungsanleitung

Samsung

Samsung QE50Q60AAUXXH Bedienungsanleitung

Samsung

Samsung LN32C530F1FXZA Bedienungsanleitung

Samsung

Samsung LE32A446T1W Bedienungsanleitung

Samsung

Samsung UN32FH4003 Bedienungsanleitung

Samsung

Samsung SP43J6HDX/XEN Bedienungsanleitung

Samsung

Samsung LE40B550 Bedienungsanleitung

Samsung

Samsung LW22N23N Bedienungsanleitung

Samsung

Samsung BN68-02540A-04 BN68-02540A-04 Bedienungsanleitung

Samsung

Samsung LN-T4642H Bedienungsanleitung

Samsung

Samsung LE22A455C1C Bedienungsanleitung

Beliebte LCD-Fernseher Handbücher anderer Marken

LG 32LC4R* Bedienungsanleitung

ViewSonic

ViewSonic N4200w-1 VS10945-1M Bedienungsanleitung

Salora

Salora 22LED1600 Bedienungsanleitung

Dell

Dell W1900 19 Gebrauchsanweisung

Grundig

Grundig 40 VLE 8230 BP Bedienungsanleitung

Philips

Philips 43PFL4901/F7 Bedienungsanleitung

Sony

Sony Bravia XBR-43X830C Bedienungsanleitung

LG 32LS350 Bedienungsanleitung

VIORE

VIORE LED32VF60 Bedienungsanleitung

Toshiba

Toshiba Regza 42HL167 Bedienungsanleitung

JVC

JVC LT-32A220 Bedienungsanleitung

Philips

Philips 20TA1000/93 Bedienungsanleitung

Philips

Philips 32PFL3158T/12 Bedienungsanleitung

Sony

Sony Bravia KDL-V32XBR2 Bedienungsanleitung

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Bedienungsanleitung

Philips

Philips 40PFL7705D Bedienungsanleitung

Dynex

Dynex DX-40L261A12 Bedienungsanleitung

JVC

JVC LT-23C50BU Bedienungsanleitung
