Samsung LE19B455 Bedienungsanleitung

BN68-01980B-01

LCD TV

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com/register

Model Serial No.

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.

Country Customer Care Centre Web Site

AUSTRIA 0810 - SAMSUNG (7267864, € 0.07/min) www.samsung.com/at

BELGIUM 02 201 2418 www.samsung.com/be

www.samsung.com/be_fr

CZECH REPUBLIC

800 - SAMSUNG (800-726786) www.samsung.com/cz

Distributor pro Českou republiku:

Samsung Zrt., česká organizační složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8

DENMARK 8 - SAMSUNG (7267864) www.samsung.com/dk

EIRE 0818 717 100 www.samsung.com/ie

FINLAND 30 - 6227 515 www.samsung.com/

FRANCE 3260 dites 'SAMSUNG'(€ 0,15/Min)

0825 08 65 65 (€ 0.15/Min) www.samsung.com/fr

GERMANY 01805 - SAMSUNG (7267864, € 0.14/Min) www.samsung.de

HUNGARY 06 - 80 - SAMSUNG (7267864) www.samsung.com/hu

ITALIA 800 - SAMSUNG (7267864) www.samsung.com/it

LUXEMBURG 02 261 03 710 www.samsung.com/lu

NETHERLANDS 0900-SAMSUNG (0900-7267864) (€ 0,10/Min) www.samsung.com/nl

NORWAY 3 - SAMSUNG (7267864) www.samsung.com/no

POLAND 0 801 1SAMSUNG(172678)

022 - 607 - 93 - 33 www.samsung.com/pl

PORTUGAL 808 20 - SAMSUNG (7267864) www.samsung.com/pt

SLOVAKIA 0800 - SAMSUNG (7267864) www.samsung.com/sk

SPAIN 902 - 1 - SAMSUNG (902 172 678) www.samsung.com/es

SWEDEN 075 - SAMSUNG (726 78 64) www.samsung.com/se

SWITZERLAND 0848 - SAMSUNG (7267864, CHF 0.08/min) www.samsung.com/ch

U.K 0845 SAMSUNG (7267864) www.samsung.com/uk

TURKEY 444 77 11 www.samsung.com/tr

ESTONIA 800-7267 www.samsung.com/ee

LATVIA 8000-7267 www.samsung.com/lv

LITHUANIA 8-800-77777 www.samsung.com/lt

KAZAHSTAN 8-10-800-500-55-500 www.samsung.com/kz_ru

KYRGYZSTAN 00-800-500-55-500 -

RUSSIA 8-800-555-55-55 www.samsung.ru

TADJIKISTAN 8-10-800-500-55-500 -

UKRAINE 8-800-502-0000 www.samsung.ua

UZBEKISTAN 8-10-800-500-55-500 www.samsung.com/kz_ru

BN68-01980B-00Eng-Cover.indd 1 2009-03-20 �� 6:21:00

Digital TV (DVB-T) Notice

1. FUNCTIONALITIES RELATED TO DIGITAL TV (DVB) ARE ONLY AVAILABLE IN COUNTRIES OR AREAS WHERE DVB-T

(MPEG2 AND MPEG4 AVC) DIGITAL TERRESTRIAL SIGNALS ARE BROADCAST. DVB-T is the European consortium

standard for the broadcast transmission of digital terrestrial television. Please check with your local dealer about the

availability of DVB-T service in your area.

2. Although this TV set meets the current DVB-T standards as of [August, 2008], compatibility with future DVB-T digital terrestrial

broadcast cannot be guaranteed.

3. Some Digital TV functions may not be available or operate correctly in some countries or regions.

4. For more information, please contact your local SAMSUNG customer care centre.

Precautions When Displaying a Still Image

A still image may cause permanent damage to the TV screen

Do not display a still image and partially still on the LCD panel for more than 2 hours as it can cause screen image retention.

This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and

contrast of the screen when displaying a still image.

Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the

left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or

a game console may cause a similar effect to the screen. Damages caused by the above effect are not

covered by the Warranty.

Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images. To

prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.

❑

●

BN68-01980B-01L05.indb 1 2009-03-02 �� 5:54:43

English - 1

GENERAL INFORMATION

Viewing the Control Panel ................................................................. 2

Accessories ....................................................................................... 3

Viewing the Connection Panel........................................................... 4

Remote Control ................................................................................. 6

Installing Batteries in the Remote Control ......................................... 6

OPERATION

Viewing the menus ............................................................................ 7

Plug & Play Feature........................................................................... 8

CHANNEL CONTROL

Conguring the Channel Menu.......................................................... 9

Managing Channels .........................................................................11

PICTURE CONTROL

Conguring the Picture Menu .......................................................... 13

Using Your TV as a Computer (PC) Display.................................... 15

Setting up the TV with your PC........................................................ 16

SOUND CONTROL

Conguring the Sound Menu........................................................... 17

Selecting the Sound Mode .............................................................. 18

■

SETUP

Conguring the Setup Menu............................................................ 19

INPUT / SUPPORT

Conguring the Input Menu ............................................................. 21

Conguring the Support Menu......................................................... 22

RECOMMENDATIONS FOR USE

Teletext Feature............................................................................... 23

How to Adjust the Stand (19inch model only).................................. 24

How to Adjust the Angle of the TV (19inch model only)................... 24

Installing VESA Compliant Mounting Devices (19inch model only). 25

Using the Decoration Covers (19inch model only) .......................... 25

Installing the Stand .......................................................................... 26

Installing the Wall Mount Kit ............................................................ 26

Using the Anti-Theft Kensington Lock ............................................. 26

Securing the TV to the Wall ............................................................. 27

Troubleshooting: Before Contacting Service Personnel.................. 28

Specications .................................................................................. 28

■

CONTENTS

License

TruSurround HD, SRS and symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is

incorporated under license from SRS Labs, Inc.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

Symbol

N O T

Note One-Touch Button TOOL Button

❑

English

BN68-01980B-01L05.indb 1 2009-03-02 �� 5:54:44

English - 2

GENERAL INFORMATION

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.

Product design and specications may be changed without notice in order to enhance product performance.

Viewing the Control Panel

The product colour and shape may vary depending on the model.

You can use a button by pressing the side panel buttons.

SOURCE

: Toggles between all the available input sources. In the on-screen menu, use this button as you would use the

ENTER

button on the remote control.

MENU: Press to see an on-screen menu of your TV’s features.

: Press to increase or decrease the volume.

In the on-screen menu, use the

buttons as you would use the ◄ and ► buttons on the remote control.

: Press to change channels. In the on-screen menu, use the

buttons as you would use the ▼ and ▲

buttons on the remote control.

(POWER): Press to turn the TV on and off.

REMOTE CONTROL SENSOR: Aim the remote control towards this spot on the TV.

POWER INDICATOR: Blinks and turns off when the power is on and lights up in stand-by mode.

SPEAKERS

88 7

BN68-01980B-01L05.indb 2 2009-03-02 �� 5:54:44

English - 3

Accessories

Remote Control &

Batteries (AAA x 2) Power Cord Cover-Bottom

(22 inch model only)

Cleaning Cloth

(M4 X L16)

Wall Mount kit

(19 inch model only)

Decoration Cover

(19 inch model only)

Stand Screw X 4

(22 inch model only)

● Owner’s Instructions ● Warranty card ● Safety Guide

Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.

Warranty card / Safety Guide (Not available in all locations)

The items colour and shape may vary depending on the model.

BN68-01980B-01L05.indb 3 2009-03-02 �� 5:54:44

English - 4

Viewing the Connection Panel

The product colour and shape may vary depending on the model.

Whenever you connect an external device to your TV, make sure that power on the unit is turned off.

When connecting an external device, match the colour of the connection terminal to the cable.

DIGITAL AUDIO OUT (OPTICAL)

Connects to a Digital Audio component such as a Home theatre receiver.

When the HDMI IN jacks are connected, the DIGITAL AUDIO OUT (OPTICAL) jack on the TV outputs 2 channel audio

only. If you want to hear 5.1 channel audio, connect the Optical jack on the DVD / Blu-ray player or Cable / Satellite Box

directly to an Amplier or Home Theatre, not the TV.

SERVICE

Connector for software upgrades.

HDMI (DVI)

Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD / Blu-ray player)

No additional Audio connection is needed for an HDMI to HDMI connection.

The HDMI (DVI) jack can be used to connect a PC.

What is HDMI?

‘High Denition Multimedia interface’ allows the transmission of high denition digital video data and multiple channels of

digital audio.

The HDMI / DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).

The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital

Copy Protection) coding feature installed, and supports multi - channel digital audio.

PC/DVI (HDMI) [AUDIO]

Connect to the audio output jack on your PC.

DVI audio outputs for external devices.

Connect to the video output jack on your PC.

–

790!

1 2 3 4 5

[TV Rear Panel]

Power Input

BN68-01980B-01L05.indb 4 2009-03-02 �� 5:54:45

English - 5

COMMON INTERFACE Slot

When not inserting ‘CI CARD’ in some channels, ‘Scrambled Signal’ is displayed on the screen.

The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in

about 2~3 minutes. If an error message is displayed, please contact your service provider.

When the channel information conguration has nished, the message ‘Updating Completed’ is displayed, indicating that

the channel list is now updated.

You must obtain a CI CARD from a local cable service provider. Remove the CI CARD by carefully pulling it out with your

hands since dropping the CI CARD may cause damage to it.

Insert the CI-Card in the direction marked on it.

The place of the COMMON INTERFACE Slot may be different depending on its model.

CAM is not supported in some countries and regions, check with your authorized dealer.

ANT IN

Connects to an antenna or cable TV system.

KENSINGTON LOCK (depending on the model)

The Kensington Lock (optional) is a device used to physically x the system when used in a public place. If you want to

use a locking device, contact the dealer where you purchased the TV.

The location of the Kensington Lock may be different depending on its model.

AV IN [R-AUDIO-L] / [VIDEO]

Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder.

Connect RCA audio cables to [R-AUDIO-L] on your set and the other ends to corresponding audio out connectors on the

A/V device.

Headphones jack

Headphone may be connected to the headphone output on your set. While the head phone is connected, the sound from

the built-in speakers will be disabled.

COMPONENT IN

Connect component video cables (optional) to component connector (PR, PB, Y) on the rear of your set and the other ends

to corresponding component video out connectors on the DTV or DVD.

If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box to the DTV (or DVD)

and connect the DTV (or DVD) to component connector (PR, PB, Y) on your set.

The PR, PB and Y connectors on your component devices (DTV or DVD) are sometimes labeled Y, B-Y and R-Y or Y, Cb

and Cr.

Connect RCA audio cables (optional) to [R-AUDIO-L] on the rear of your set and the other ends to corresponding audio

out connectors on the DTV or DVD.

EXT

Connector Input Output

Video Audio (L / R) RGB Video + Audio (L / R)

EXT O O O Only TV or DTV output is available.

Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.

–

BN68-01980B-01L05.indb 5 2009-03-02 �� 5:54:45

English - 6

Remote Control

You can use the remote control up to a distance of about 23 feet from the TV.

The performance of the remote control may be affected by bright light.

The product colour and shape may vary depending on the model.

POWER : Television Standby

button.

NUMERIC BUTTONS : Press to

change the channel.

:Performs the same function

as the ENTER

key of the

directional keys. When switching

channels with the numeric

buttons, and you press the

channel number and then the

ENTER

key, the channel is

immediately switched.

: Press to increase or

decrease the volume.

SOURCE: Press to display

and select the available video

sources.

CH LIST: Displays the Channel

List on screen

TOOLS: Use to quickly select

frequently used functions.

INFO: Press to display

information on the TV screen.

COLOURS BUTTONS: Use

these buttons in the Channel list

menus etc.

TV: Selects the TV mode directly.

PRE-CH: Enables you to return

to the previous channel you were

watching.

MUTE

: Press to temporarily

cut off the sound.

: Press to change

channels.

MENU: Displays the main on-

screen menu

FAV.CH: Press to switch to your

favourites channels.

RETURN: Returns to the

previous menu

 UP▲/DOWN▼/LEFT◄/

RIGHT►/ENTER

: Use to

select on-screen menu items and

change menu values.

(

EXIT: Press to exit the menu.

)

SUBT.: Digital subtitle display

GUIDE: Electronic Programme

Guide (EPG) display

Teletext Functions

: Teletext mode selection

(LIST / FLOF)

: Teletext store

: Teletext size selection

: Teletext reveal

Fastext topic selection

: Alternately select

Teletext, Double, or Mix.

: Exit from the teletext display

: Teletext sub page

: Teletext next page

: Teletext previous page

: Teletext index

: Teletext hold

(

: Teletext cancel

Installing Batteries in the Remote Control

1. Lift the cover at the back of the remote control upward as shown in the gure.

2. Install two AAA size batteries.

Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the

compartment.

3. Replace the cover.

Remove the batteries and store them in a cool, dry place if you won’t be using the

remote control for a long time.

If the remote control doesn’t work, check the following:

Is the TV power on?

Are the plus and minus ends of the batteries reversed?

Are the batteries drained?

Is there a power outage or is the power cord unplugged?

Is there a special uorescent light or neon sign nearby?

–

(

)

BN68-01980B-01L05.indb 6 2009-03-02 �� 5:54:45

English - 7

OPERATION

Viewing the menus

Before using the TV, follow the steps below to learn how to navigate the menu in order to select

and adjust different functions.

1. Press the MENU button.

The main menu is displayed on the screen. Its left side has icons: Picture, Sound,

Channel , Setup, Input, Support.

2. Press the ▲ or ▼ button to select one of the icons.

Press the ◄ or ► button to access the icon’s sub-menu.

3. Press the ▲ or ▼ button to move to items in the menu.

Press the ENTER

button to enter items in the menu.

4. Press the ▲/▼/◄/► button to change the selected items.

Press the RETURN button to return to the previous menu.

5. Press the EXIT button to exit from the menu.

Using the remote control buttons

Button Operations Button Operations

MENU Display the main on-screen menu. ▲/▼/◄/►/

ENTER

Move the cursor and select an item.

Select the currently selected item.

Conrm the setting.

RETURN

Return to the previous menu.

EXIT

Exit the on-screen menu.

Example: Setting the TV’s Brightness in the Picture Menu

Adjusting the Brightness to 80

1. Press the MENU button to display the menu.

2. Press the ENTER

button to select Picture.

3. Press the ▲ or ▼ button to select Brightness.

4. Press the ENTER

button.

5. Press the ◄ or ► button until the brightness becomes 80.

6. Press the ENTER

button.

Press the EXIT button to exit from the menu.



Mode :Standard ►

Backlight : 8

Contrast : 95

Brightness : 45

Sharpness : 50

Colour : 50

Tint (G / R) : G50 / R50


Mode :Standard ►

Backlight : 8

Contrast : 95

Brightness : 45

Sharpness : 50

Color : 50

Tint (G/R) : G50/R50


Backlight : 8

Contrast : 95

Brightness :45  ►

Sharpness : 50

Color : 50

Tint (G/R) : G50/R50

Advanced Settings

Picture Options

Picture Reset


Mode : Standard

Backlight : 8

Contrast : 95

Brightness : 45

Sharpness : 50

Color : 50

Tint (G/R) : G50/R50


Brightness 45

Move

Adjust

Enter

Return

Brightness 80

Move

Adjust

Enter

Return

BN68-01980B-01L05.indb 7 2009-03-02 �� 5:54:46

English - 8

Plug & Play Feature

When the TV is initially powered on, basic settings proceed automatically and subsequently.

1. Press the POWER button on the remote control. The message You can set the menu

language. is displayed.

2. Select the appropriate language by pressing the ▲ or ▼ button. Press the ENTER

button to conrm your choice.

3. Press the ◄ or ► button to select Store Demo or Home Use, then the ENTER

button.

We recommend setting the TV to Home Use mode for the best picture in your home environment.

Store Demo mode is only intended for use in retail environments.

If the unit is accidentally set to Store Demo mode and you want to return to Home Use (Standard): Press the Volume

button on the TV. When the volume OSD is displayed, press and hold the MENU button on the TV for 5 seconds.

4. Press the ENTER

button. Select the appropriate country by pressing the ▲ or ▼ button. Press the ENTER

button to

conrm your choice.

5. Press the ▲ or ▼ button to select Air or Cable, then press the ENTER

button.

Air: Air antenna signal.

Cable: Cable antenna signal.

6. Press the ▲ or ▼ button to select the channel source to memorize. Press the ENTER

button to select Start.

Digital & Analogue: Digital and Analogue channels.

Digital: Digital channels.

Analogue: Analogue channels.

When setting the antenna source to Cable, a step appears allowing you to set a value for the digital channel search. For

more information, refer to Channel → Auto Store.

The channel search will start and end automatically.

Press the ENTER

button at any time to interrupt the memorization process.

After all the available channels are stored, the message Set the Clock Mode. is displayed.

7. Press the ENTER

button. Press the ▲ or ▼ button to select Auto, then Press the ENTER

button.

If you select Manual, Set current date and time is displayed.

If you have received a digital signal, the time will be set automatically. If not, select Manual to set the clock. (refer to page

19)

8. The connection method to provide the best quality HD is offered. After conrming the method, press the ENTER

button.

9. The message Enjoy your viewing is displayed. When you have nished, press the ENTER

button.

If you want to reset this feature...

1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER

button.

2. Press the ENTER

button again to select Plug & Play.

3. Enter your 4 digit PIN number. The default PIN number of a new TV set is ‘0-0-0-0’. (refer to page 20)

If you want to change PIN number, use the Change PIN function.

The Plug & Play feature is only available in the TV mode.

Plug & Play

You can set the menu language.

Menu Language : English ►

Enter

BN68-01980B-01L05.indb 8 2009-03-02 �� 5:54:46

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Samsung LCD-Fernseher Handbücher

Samsung

Samsung LN40D550 Bedienungsanleitung

Samsung

Samsung 5 Series Bedienungsanleitung

Samsung

Samsung UD6400 Installationsanleitung

Samsung

Samsung UN46B7000 - 46" LCD TV Bedienungsanleitung

Samsung

Samsung LE32B530P7W Bedienungsanleitung

Samsung

Samsung LA22B350F2 Bedienungsanleitung

Samsung

Samsung LN-S2341W Bedienungsanleitung

Samsung

Samsung LW24R15W Bedienungsanleitung

Samsung

Samsung LNT3253H - 32" LCD TV Bedienungsanleitung

Samsung

Samsung UN55D6500 Bedienungsanleitung

Samsung

Samsung UA65KS9000 Bedienungsanleitung

Samsung

Samsung LN32A32B Bedienungsanleitung

Samsung

Samsung LCD TV Bedienungsanleitung

Samsung

Samsung S23C550H Bedienungsanleitung

Samsung

Samsung LN-S4096D Bedienungsanleitung

Samsung

Samsung LTN 1735 Bedienungsanleitung

Samsung

Samsung LN-T1953H Gebrauchs- und Pflegehandbuch

Samsung

Samsung LE32C650L1K Bedienungsanleitung

Samsung

Samsung UE50TU8070 Bedienungsanleitung

Samsung

Samsung 6 series Bedienungsanleitung

Samsung

Samsung LN-S4095D Bedienungsanleitung

Samsung

Samsung LN32C530F1F Bedienungsanleitung

Samsung

Samsung LN-R238W Bedienungsanleitung

Samsung

Samsung UN32H5203 Bedienungsanleitung

Beliebte LCD-Fernseher Handbücher anderer Marken

LG 32LC4R* Bedienungsanleitung

ViewSonic

ViewSonic N4200w-1 VS10945-1M Bedienungsanleitung

Salora

Salora 22LED1600 Bedienungsanleitung

Dell

Dell W1900 19 Gebrauchsanweisung

Grundig

Grundig 40 VLE 8230 BP Bedienungsanleitung

Philips

Philips 43PFL4901/F7 Bedienungsanleitung

Sony

Sony Bravia XBR-43X830C Bedienungsanleitung

LG 32LS350 Bedienungsanleitung

VIORE

VIORE LED32VF60 Bedienungsanleitung

Toshiba

Toshiba Regza 42HL167 Bedienungsanleitung

JVC

JVC LT-32A220 Bedienungsanleitung

Philips

Philips 20TA1000/93 Bedienungsanleitung

Philips

Philips 32PFL3158T/12 Bedienungsanleitung

Sony

Sony Bravia KDL-V32XBR2 Bedienungsanleitung

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Bedienungsanleitung

Philips

Philips 40PFL7705D Bedienungsanleitung

Dynex

Dynex DX-40L261A12 Bedienungsanleitung

JVC

JVC LT-23C50BU Bedienungsanleitung
