Samsung QA55Q70TAJ Leitfaden

E-MANUAL

Thank you for purchasing this Samsung product.

To receive more complete service, please register your

product at

www.samsung.com

Model Serial No.

To directly go to the page that provides instructions on

how to use the manual for visually impaired users, select

the Menu Learning Screen link below.

“Menu Learning Screen” Link

Contents

Guide

Connections

5Connection Guide

6 Connecting an Antenna (Aerial)

7Connecting to the Internet

10 Screen Sharing (Smart View) with your Mobile Device

13 Connection Cables for External Devices

15 Switching between external devices connected to the TV

17 Connection Notes

Remote Control and Peripherals

20 About the Samsung Smart Remote

23 About the Samsung Smart Remote (The Frame)

26 About the Samsung Smart Remote (The Sero)

29 Connecting the Samsung Smart Remote to the TV

30 Controlling External Devices with a Samsung Remote

Control - Using the Universal Remote

31 Using Anynet+ (HDMI-CEC)

32 Controlling the TV with a Keyboard, Mouse or Gamepad

34 Entering Text using the On-Screen Virtual Keyboard

Smart Features

36 Using Smart Hub

44 Using a Samsung account

46 Using the Ambient Mode

51 Using Remote Access

54 Using the Apps Service

58 Using the Gallery App

59 Using the SmartThings App

60 Using the e-Manual

63 Using the Internet

64 Playing pictures/video/music

70 Using Bixby

TV Viewing

74 Using the Guide

76 Recording Programmes

78 Setting Up a Schedule Viewing

80 Using Timeshift

80 Buttons and functions available while recording a

programme or Timeshift

82 Using the Channel List

83 Editing channels

84 Using a Personal Favourites List

85 TV-Viewing Support Functions

Picture and Sound

90 Using the Intelligent Mode

92 Adjusting the Picture Quality

94 Setting the Viewing Environment for External Devices

96 Picture Support Functions

97 Conguring a Sound Mode and Expert Settings

99 Using the Sound Support Functions

System and Support

101 Using the Time Functions and the Timers

104 Using the Auto Protection Time and Energy Saving

Functions

105 Updating the TV's Software

106 Audio and Video Functions for the Visually or Hearing

Impaired

111 Using Other Functions

Precautions and Notes

113 Before Using the Recording and Timeshift Functions

114 Supported broadcasting audio options

115 Read Before Using Apps

116 Read Before Using the Internet Function

118 Read Before Playing Photo, Video or Music Files

126 Read After Installing the TV

127 Supported Resolutions for UHD Input Signals

128 Resolutions for Input Signals supported by Q700T series or

higher

129 Supported Resolutions for FreeSync(VRR)

130 Read Before Connecting a Computer (Supported

Resolutions)

133 Supported Resolutions for Video Signals

135 Read Before Using Bluetooth Devices

136 Licences

Troubleshooting

Picture Issues

137 Testing the picture

Sound and Noise Issues

141 Testing the sound

Channel and Broadcast Issues

External Device Connectivity Issues

Network Issues

Anynet+ (HDMI-CEC) Issues

Remote Control Issues

Recording Issues

Apps

Media Files

Voice Recognition Issues

Other issues

Diagnosing TV operational issues

Getting Support

157 Getting support through Remote Management

157 Finding the contact information for service

157 Requesting service

FAQ

The TV Screen does not Display Properly

158 When the TV screen does not display properly

The TV does not Turn On

165 When your TV does not turn on

The Picture is Distorted or No Sound Comes Out of the

Sound Bar

171 When the TV does not connect with an external device

properly

Internet Access is not Available

176 When the TV can't connect to the Internet

There is No Sound or the Speakers are Making an Odd Sound

181 When no sound comes out of the TV, or the sound is

breaking up

The Remote Control does not Work

188 When the remote control does not work

Updating the Software

193 Updating to the latest TV software

Accessibility Guidance

Menu Learning Screen

200 Using the Remote control

202 Using the accessibility menu

206 Using the TV with Voice Guide on

208 Using the guide

211 Using Schedule Viewing

212 Using the Channel List

214 Recording

217 Using Smart Hub

220 Launching the e-Manual

221 Using Bixby

Guide

Learn how to use various features.

Connections

You can watch live broadcasts by connecting an antenna cable to your TV and can get access to the Internet by

using a LAN cable or wireless access point. Using various connectors, you can also connect external devices.

Connection Guide

You can view detailed information about external devices that can be connected to the TV.

Source Connection Guide Try Now

It shows you how to connect various external devices such as video devices, game consoles and PCs using pictures.

If you select the connection method and an external device, the connection details appear.

•Audio Device: HDMI (ARC), Optical, Bluetooth, Wi-Fi, Wi-Fi Speaker Surround Setup

HDMI (ARC) is supported by some models. Check the HDMI port name of the purchased product's model.

•Video Device: HDMI

•Smartphone: Screen Sharing (Smart View), SmartThings, Apple AirPlay, NFC on TV, Tap View

•PC: HDMI, Screen Sharing (Wireless), Apple AirPlay

•Input Device: Remote control, Keyboard, Mouse, USB Gamepad, Bluetooth Device

•Game Console: HDMI

•External Storage: USB Flash Drive, Hard Disk Drive (HDD)

Using HDMI Troubleshooting, you can check the connection to HDMI cable and external devices (takes approximately 2

minutes).

The connection method and available external devices may differ depending on the model.

Connection Guide

Audio Device

Video Device

Smartphone

Input Device

Game Console

External Storage

HDMI (ARC)

Optical

Bluetooth

Wi-Fi

Wi-Fi Speaker Surround Setup

HDMI Troubleshooting

Connect audio devices, such as speakers, sound bars,

headphones, or home theatres, to your TV.

The image on your TV may differ from the image above depending on the model and geographical area.

- 5 -

Connecting an Antenna (Aerial)

You can connect an antenna cable to your TV.

An antenna connection is not necessary if you connect a cable box or satellite box.

A connection method may differ with the models.

The image on your TV may differ from the image above depending on the model and geographical area.

- 6 -

Connecting to the Internet

You can get access to the Internet through your TV.

Settings General Network Open Network Settings Try Now

Congure network settings to connect to an available network.

Establishing a wired Internet connection

Settings General Network Open Network Settings Wired

If you connect a LAN cable, the TV automatically accesses the Internet.

If the TV does not automatically connect to the network, refer to "Network Issues" in "Troubleshooting".

Use a CAT 7 (*STP type) cable for the connection.

* Shielded Twisted Pair

The TV will not be able to connect to the Internet if your network speed is below 10 Mbps.

This function may not be supported depending on the model.

- 7 -

Establishing a wireless Internet connection

Settings General Network Open Network Settings Wireless

Make sure that you have the wireless access point's SSID (name) and password settings before attempting to

connect. The network name (SSID) and security key are available on the wireless access point's conguration

screen. See the wireless access point's user manual for more information.

Wireless Connection

Select your wireless network.

Refresh

Manage Saved Networks

The image on your TV may differ from the image above depending on the model and geographical area.

If no wireless access point is found, select Add Network at the bottom of the list and enter the network name (SSID).

If your wireless access point has a WPS or PBC button, select Use WPS at the bottom of the list, and then push the WPS or

PBC button on your access point within 2 minutes. The TV will connect automatically.

To view or delete previously connected network names (SSIDs), move the focus to Manage Saved Networks, and then press

the Select button.

- 8 -

Checking the Internet connection status

Settings General Network Network Status Try Now

View the current network and Internet status.

Resetting Your Network

Settings General Network Reset Network Try Now

Restore the network settings to the factory default.

Turning on the TV with a mobile device

Settings General Network Expert Settings Power On with Mobile

You can turn on the TV using a mobile device connected to the same network as the TV.

This function may not be supported depending on the model or geographical area.

This function is available with a mobile device connected to the TV through the SmartThings app or the Apple AirPlay

function.

Connecting an IP control device to the TV

Settings General Network Expert Settings IP Remote

You can connect an IP control device to the TV remotely to manage your IP device.

To use this function, Power On with Mobile must be turned on.

Turning this feature on may allow other IP control devices to control your TV. We recommend turning this feature on only if

an authorised third-party custom controller is installed and congured specically for a Samsung TV and if your Wi-Fi

network is password protected.

This function may not be supported depending on the model or geographical area.

Changing the name of the TV

Settings General System Manager Device Name Try Now

You can change the name of the TV on the network. Select User Input at the bottom of the list and change the

name.

- 9 -

Screen Sharing (Smart View) with your Mobile Device

You can watch the screen of your mobile device on the TV screen through Smart View or Tap View.

For information on how to share the screen with your mobile device, refer to Source Connection Guide

Smartphone Screen Sharing (Smart View).

• To turn off Screen Sharing (Smart View), disconnect the mobile device or press the button on the remote

control.

• Using the Smart View menu on your mobile device, you can change the settings such as aspect ratio.

• Use AirPlay if you are an iPhone or iPad user. For more information, refer to Source Connection Guide

Smartphone Apple AirPlay.

This function may not be supported depending on the model.

• The screen sharing function (Smart View/Apple AirPlay) on your mobile device appears on Multi View of the TV

(or the screen on your mobile device).

- 10 -
