Samsung RB1844SL Bedienungsanleitung

DA68-00998A REV(0.0)

REFRIGERATOR

RB1844SW / RB1844SL

RB2044SW / RB2044SL

OWNER’S MANUAL

DA99-00191F REV(0.0)

In the U.S.for questions about features,

operation/performance, parts, accesories or service, call:

1-800-726-7864 (1-800-SAMSUNG)

www.samsungusa.com

DA99-00191F(0.0).q 2003.2.2 1:38 PM 1

FEATURES

High-energy efficiency with twin cooling system

• Optimized power consumption with twin cooling

system when using R134a and cyclopentane.

Humidity controled drawers

• This is suitable for storing dry or wrapped food

(e.g. fresh salads, vegetables and fruit).

Fridge at the top, drawer-type freezer at the

bottom

• The highly ergonomic humidity controlled drawers

are placed at waist height for frequent use.

• The drawer-type freezer minimizes temperature

variations and stores food cleanly and conveniently.

Digital temperature control display

• The display shows all functions of the appliance,

allowing easy control.

• Refrigerator and freezer temperatures can be

adjusted separately.

Power Freeze

• Speeds up the freezing process in the freezer.

Power Cool

• Speeds up the cooling process in the refrigerator.

Door alarm

• When the refrigerator door is left open for more

than two minutes, a musical alarm is automatically

triggered. This feature helps you save electricity

and preserve stored foods as a reminder to close

the door.

Automatic defrosting in refrigerator/freezer CONTENTS

FEATURES

WARNINGS / SAFETY PRECAUTIONS

INSTALLING THE REFRIGERATOR / FREEZER

PREPARING THE REFRIGERATOR / FREEZER

VIEW OF YOUR REFRIGERATOR / FREEZER

USING THE CONTROL FEATURES

CONTROLLING THE FREEZER AND

REFRIGERATOR TEMPERATURES

STORING FOOD IN THE REFRIGERATOR

OR FREEZER

MAKING ICE

REMOVING AND CLEANING ACCESSORIES

REPLACING INTERIOR LIGHTS

PROBLEMS AND SOLUTIONS

USAGE PRECAUTIONS

These operating instructions cover various models.

The characteristics of your appliance may differ

slightly from those described in this manual.

DA99-00191F(0.0).q 2003.2.2 1:38 PM 1

WARNINGS / SAFETY PRECAUTIONS

Warning

To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to observe the

following safety precautions. (After reading these owner’s instructions, please keep them in a safe place for

reference.) Remember to hand them over to any subsequent owner.

Indicates that a danger of death or

serious injury exists. Caution

Indicates that a risk of personal

injury or material damage exists.

Warning

Do not plug several appliances into the same socket.

• This could cause overheating and the risk of fire.

Keep the power plug away from the rear of the

refrigerator/freezer.

• A damaged power plug may cause fire due to overheating.

Do not directly spray water inside or outside the

refrigerator/freezer.

• There is a risk of fire or electric shock.

Do not spray inflammable gas near the

refrigerator/freezer.

• There is a risk of explosion or fire.

Do not bend the power cord excessively or place heavy

articles on it.

This constitutes a fire hazard. If the power cord is

damaged, have it replaced immediately by the

manufacturer or its service agent.

Do not insert the power plug with wet hands.

• You may receive an electric shock.

Do not put a container filled with liquid on top of the

appliance.

• If the water spills on to any electrical parts, it may lead to

fire or electric shock.

Do not install the refrigerator/freezer in a damp place,

where it may come into contact with water.

• Incorrect insulation of the electrical parts may cause an

electric shock or fire.

Do not store volatile and inflammable substances in the

refrigerator.

• The storage of benzene, thinner, alcohol, ether, LP gas or

other such substances may cause an explosion.

Do not disassemble, repair or alter the appliance.

• It may cause fire or abnormal operation, which may lead to

injury.

Pull the power plug out of the socket before replacing

the interior light in the refrigerator.

• Otherwise, there is a risk of electric shock.

Be sure to ground the appliance.

• Otherwise, it may cause material damage or electric shock.

If you wish to dispose of the refrigerator/freezer, throw it

away after removing the door or its seals.

• In this way, it is not possible for a child to remain trapped

inside it.

• Keep ventilation openings in the appliance enclosure or

mounting structure clear of obstruction.

• Do not use mechanical devices or any other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the

refrigerator/freezer, unless they are of a type

recommended by the manufacturer.

Warning

DA99-00191F(0.0).q 2003.2.2 1:38 PM 2

WARNINGS / SAFETY PRECAUTIONS

Do not store too much food in the appliance.

• When you open the door, an item may fall out and cause

personal injury or material damage.

Do not put bottles or any kinds of glass in the freezer.

• The container may break and cause personal injury.

If the wall socket is loose, do not insert the power plug.

• It could be cause electric shock or fire.

Do not disconnect the power cord by pulling on it.

• You may disconnect a wire and cause a short circuit.

Do not store articles on top of the appliance.

• When you open or close the door, the articles may fall and

cause personal injury or material damage.

Do not store pharmaceutical products, scientific

materials or other temperature-sensitive products in the

refrigerator.

• Products that require strict temperature controls must not

be stored in the refrigerator.

Do not let a child hang from the door.

Allow an adequate space and install the

refrigerator/freezer on a firm, level floor.

• If the appliance is not level, there may be unusual noises

and poor cooling.

• Wait for at least one hour before plugging the appliance in.

Clean the refrigerator/freezer.

• Wipe and clean the appliance inside and outside with a

damp cloth and dry completely.

Plug the refrigerator/freezer into a wall socket used

exclusively by this appliance.

• This appliance must be properly grounded.

Caution Do not store pharmaceutical products, scientific

materials or other temperature-sensitive products in the

refrigerator.

• Products that require strict temperature controls must not

be stored in the refrigerator.

Do not let a child hang from the door.Do not touch any

containers or food in the freezer with wet hands.

• It may cause frostbite.

Remove any foreign matter or dust from the power plug

pins.

• Otherwise there is a risk of fire.

Do not insert your hand into the bottom area of the

appliance.

• Any sharp edges may cause personal injury.

After unplugging the appliance, wait for at least five

minutes before plugging it in again to the wall socket.

• Abnormal operation of the freezer may cause material

damage.

If the appliance is not to be used for a long period of

time, pull out the power plug.

• Any deterioration in the insulation may cause fire.

Do not let children touch or play with the control panel

on the front of the appliance.

• Do not allow children to play with this appliance.

• Do not stand or lean on the base panel, pull-out parts,

doors and so on.

• Repairs and maintenance of the appliance should only be

performed by a qualified technician. Incorrect repairs by an

unqualified person are a potential source of danger that

may have critical consequences for the user of the

appliance.

• Never put ice cubes or ice pops straight from the freezer

into your mouth. (The low temperature may cause “freezer

burns”.)

DA99-00191F(0.0).q 2003.2.2 1:38 PM 3

INSTALLING THE REFRIGERATOR/FREEZER

Allow an adequate space and install the

refrigerator/freezer on a firm, level floor.

• If the appliance is not level, there may be

unusual noises and poor cooling.

• Wait for at least one hour before plugging

the appliance in.

Clean the refrigerator/freezer.

• Wipe and clean the appliance inside and

outside with a damp cloth and dry completely.

Plug the refrigerator/freezer into a wall

socket used exclusively by this

appliance.

• This appliance must be properly

grounded.

Use of a grounded socket exclusively for the appliance:

• If you are using a socket with a grounded terminal, you do not

require a separate grounding connection.

Use of a non-grounded socket:

• Connect the “grounding wire” to the copper plate and bury

it at a depth of at least 10 inches in the ground.

The appliance must be positioned so that the plug is

accessible after installation.

If the front of the appliance is slightly higher than the rear, the door can be opened and closed more easily.

Place the food in the refrigerator/freezer.

• It is recommended that you wait for the

appliance to cool for 2-3 hours before

storing food in it.

LEVELLING

The appliance tilts down to the left.

Turn the left adjusting leg in the direction of

the arrow with a flat head screwdriver until

the appliance is level.

The appliance tilts down to the right.

Turn the right adjusting leg in the direction of

the arrow with a flat head screwdriver until

the appliance is level.

10 inch

Warning

DA99-00191F(0.0).q 2003.2.2 1:38 PM 4

PREPARING THE REFRIGERATOR /FREEZER

Install all shelves and compartments

removed during transport and place them in

the correct position.

You are advised to clean the appliance and

accessories before switching the appliance

on for the first time to remove any dust that

accumulated during packing and shipping.

Please clean the water dispenser (select

models only) with an detergent, especially if

there is an odor.

Switch on the appliance for approximately 2

hours before loading it with frozen food for

the first time. Do not load with frozen food

until the freezer temperature is at least 0°F.

If you want to store frozen food as rapidly

as possible, set the temperature control to

the coldest temperature (-14°F) and let the

appliance operate for one hour.

The appliance is preset for normal

operation. We recommend temperatures of

38°F in the refrigerator and -2°F in the

freezer.

The interior light of the appliance will light

up when the door is open.

This interior light will go out when the door

is closed

Your appliance is operated by a

compressor which switches “on and off” to

maintain the internal temperature. When

the compressor is new, it requires running

in for a period of up to five months. During

this period, it may be slightly noisy. This is

quite normal and does not represent a fault.

Store food once the temperature in the

refrigerator is sufficiently low. It takes a few

hours after starting the refrigerator to reach

the proper temperature.

If the appliance does not operate correctly,

check the electricity supply. If the problem

persists, contact your dealer.

To prepare your appliance for use and check that it is running correctly, take the following steps.

VIEW OF YOUR REFRIGERATOR / FREEZER

Refrigerator Light

Refrigerator

Refrigerator shelves

Humidity Controlled

Drawer

Twist Ice Maker and

Ice storage Bin

Freezer

Freezer Drawer

Multi-Purpose Door Bins

Bottle Bins

FREEZER LIGHT

Deli Drawer

DA99-00191F(0.0).q 2003.2.2 1:38 PM 5

USING THE CONTROL FEATURES

FREEZER TEMPERATURE BUTTON

Sets the freezer temperature.

Press the button repeatedly to change the

temperature in sequence between

-14°F and 8°F.

REFRIGERATOR TEMPERATURE BUTTON

Sets the refrigerator temperature.

Press the button repeatedly to change the

temperature in sequence between 34°F and

46°F

POWER COOL

BUTTON

• Speeds up the cooling process in the refrigerator.

POWER FREEZE BUTTON

Speeds up the freezing process in the freezer.

DA99-00191F(0.0).q 2003.2.2 1:38 PM 6

CONTROLLING THE FREEZER AND REFRIGERATOR TEMPERATURES

Temperature Display

Displays the current and selected freezer

temperatures.

Freezer Display

Indicates that you are setting the freezer

temperature or have opened the freezer door.

Temperature Display

Displays the current and selected refrigerator

temperatures.

Refrigerator Display

Indicates that you are setting the refrigerator

temperature or have opened the refrigerator door.

Freezer

•The freezer can be set to a temperature between

-14°F and 8°F.

•Press the FREEZER TEMP. button repeatedly until the

desired temperature is shown in the temperature display.

•The temperature display changes in sequence between -

14°F and 8°F. When the display reaches -14°F, it returns to

8°F.

•After five seconds, the display reverts to the average freezer

temperature, which changes as the freezer reaches the new

temperature.

Refrigerator

•The refrigerator can be set to a temperature between 34°F

and 46°F.

•Press the REFRIGERATOR TEMP. button

repeatedly until the desired temperature is shown in the

temperature display.

•The temperature display changes in sequence and reverts to

the average temperature in the same way as the freezer.

INDICATORS

Power Freeze

• This light is on when you press the POWER FREEZE button.

Press this button to quickly return the freezer to the set temperature.

This feature is useful if the freezer door has been left open for awhile.

• Press the button again to cancel the POWER FREEZE mode.

Temperature

display

• The temperatures displayed for the freezer and refrigerator are the actual

temperatures

of each compartment.

• There may be a slight difference between the set temperature and the actual

temperature.

Power Cool

• This light is on when you press the POWER COOL button.

Press this button to quickly return the refrigerator to the set temperature.

This feature is useful if the refrigerator door has been left open for awhile.

• Press the button again to cancel the POWER COOL mode.

DA99-00191F(0.0).q 2003.2.2 1:38 PM 7

STORING FOOD IN THE REFRIGERATOR OR FREEZER

When storing food in the appliance, follow the

recommendations below.

• Allow warm food and beverages to cool down before

storing them in the appliance.

• Ensure that food is well-wrapped or covered before it is

stored. This will prevent food from dehydrating,

deteriorating in color or losing flavor and will help

maintain freshness. Fruits and vegetables need not be

wrapped, provided that they are stored in the refrigerator

vegetable drawers.

You are advised not to wrap the food with paper and

store it in the refrigerator and freezer.

It could be the cause of odor generation.

• Never let any oil or grease come into contact with the

plastic fittings or door seals, as these materials easily

become porous.

• Never store any explosive substances inside the

appliance. High-proof alcohol should only be stored

upright in tightly sealed containers.

• Please keep the space between shelf and the rear wall

of the enclosed space of the cabinet 1/2inch apart for air

circulation.

A. Refrigerator

Transparent, unbreakable shelves

• Place food in storage containers and lay the items out at suitable

intervals.

• The storage shelf is made from an unbreakable, transparent material,

so that you can use it safely.

Humidity controlled drawers

• Fruit and Vegetables can be stored in these compartments.

• The drawer can be removed if you need more space to store fruit and

vegetables.

• To maintain the high humidity, slide the humidity control lever to

“HIGH”side.

Multi-purpose door guard and egg bin

• The refrigerator is warmest at the front, at the top and in the door.

• Store small packaged foods, like milk, yogurt and beverages here.

Bottle door guard

• Store small bottles and cartons of beer, milk and juice in the upper area

and large bottles and gallon cartons in the lower area.

DA99-00191F(0.0).q 2003.2.2 1:38 PM 8

STORING FOOD IN THE REFRIGERATOR OR FREEZER

Upper freezer drawer

• Store packed frozen foods, like ice cream and bacon.

Middle/lower freezer drawer

• Store fresh meat and fish or dried foods divided into

suitably sized portions.

B. Freezer

Wrapping food

Pack the food in suitably sized portions for your household.

Vegetable and fruit portions should be no heavier than 2 pounds, while meat portions can be up to 5.5 lbs.

Smaller portions freeze through more quickly and the quality is better maintained when defrosting and preparing the food.

It is important to seal food in airtight bags or containers before freezing to prevent it from losing its taste or dehydrating.

Wrap the food, press out any air and seal it airtight.

Suitable wrapping materials:

Plastic bags, cling-film, aluminium foil and freezer containers. These items are available from any dealer.

Unsuitable wrapping materials:

Wrapping paper, wax paper, cellophane, bin bags or used carrier bags.

These can cause odors to be generated.

Suitable sealing materials:

Rubber bands, plastic clips, string, freezer tape or similar.

Plastic film and bags may be heat-sealed using a special sealing iron or press.

Before placing a package in the freezer, it should be clearly labelled with the contents and date of freezing.

Note

Upper freezer drawer

Middle/lower freezer drawer

MAKING ICE

Pull out the ice-cube trays.

Fill trays up to the water

level mark (arrow).

Put the ice-cube trays

back in position.

Close the freezer door.

Making ice quickly

To speed up the time it takes to make ice, press the “POWER FREEZE” button to select the fast

freeze function.

Danger of explosion

• The coldest parts of the refrigerator are the rear panels and the lowest shelf. This is the best place to

store delicate food.

• Glass bottles containing liquids that can freeze should never be stored in the freezer as the glass will explode.

Warning

Note

Twist Ice System

Once the water has

become frozen, turn the

dials on the ice cube

trays to empty ice cubes

into the storage bin.

DA99-00191F(0.0).q 2003.2.2 1:38 PM 9

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Kühlschrank Handbücher

Samsung

Samsung RB3 T Series Bedienungsanleitung

Samsung

Samsung RF220NCTA Bedienungsanleitung

Samsung

Samsung RF266AEBP Bedienungsanleitung

Samsung

Samsung RL40 Series Bedienungsanleitung

Samsung

Samsung RL37J Series Bedienungsanleitung

Samsung

Samsung RF195 series Bedienungsanleitung

Samsung

Samsung RM25JWSH Sicherheitsleitfaden

Samsung

Samsung RT62K7057BS Bedienungsanleitung

Samsung

Samsung RF267ABBP/XAA Bedienungsanleitung

Samsung

Samsung RF265ABPN Bedienungsanleitung

Samsung

Samsung SR-L677EV Bedienungsanleitung

Samsung

Samsung RB28F Series Bedienungsanleitung

Samsung

Samsung RFG237AAPN - 23 cu. ft. Refrigerator Bedienungsanleitung

Samsung

Samsung RT41HSSW1/XTR Bedienungsanleitung

Samsung

Samsung RS257BAWW Sicherheitsleitfaden

Samsung

Samsung RS20 series Sicherheitsleitfaden

Samsung

Samsung RR35H61657F Bedienungsanleitung

Samsung

Samsung Refrigerator Bedienungsanleitung

Samsung

Samsung RF30BB69006MAA Bedienungsanleitung

Samsung

Samsung RF23BB8900 Bedienungsanleitung

Samsung

Samsung RT18 Series Bedienungsanleitung

Samsung

Samsung RF28HF Bedienungsanleitung

Samsung

Samsung RF50 Series Bedienungsanleitung

Samsung

Samsung RF28JBEDBSG/AA Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
