Samsung RF22R7351SG Bedienungsanleitung

Refrigerator

User manual

Free Standing Appliance

Untitled-1 1 2021-06-22  4:44:19

English2

Contents

Safety information 4

What you need to know about the safety instructions 4

Important safety symbols and precautions: 5

State of California Proposition 65 Warning 5

Important safety precautions 5

Severe warning signs for transportation and site 7

Critical installation warnings 8

Installation cautions 9

Critical usage warnings 10

Usage cautions 12

Cleaning cautions 13

Critical disposal warnings 14

Installation 15

Refrigerator at a glance 15

Step-by-step installation 18

Operations 38

Main panel 38

SmartThings 47

SMART GRID Function (Demand Response) 50

Dispenser panel 53

Special features 54

Maintenance 60

Handling and care 60

Cleaning 69

Replacement 70

Troubleshooting 72

General 72

Do you hear abnormal sounds from the refrigerator? 76

SmartThings 78

Smart Grid (applicable models only) 79

LIMITED WARRANTY (U.S.A.) 80

SAMSUNG REFRIGERATOR 80

Untitled-1 2 2021-06-22  4:44:19

English 3

Contents

Warranty Information (CANADA) 83

If your refrigerator needs service 83

Limited Warranty for Original Purchaser 83

Obligation to the Original Owner 84

Exclusions of the Warranty 84

Regulatory Notice 85

FCC Notice 85

IC Notice 86

Open Source Announcement 87

Untitled-1 3 2021-06-22  4:44:19

English4

Safety information

Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure

that you know how to operate the features and functions that your new appliance offers

safely and efciently.

What you need to know about the safety instructions

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised to ensure that they

do not play with the appliance.

• Because the following instructions cover various models, the characteristics of your

refrigerator may differ slightly from the refrigerator described in this manual.

• If you have any question, contact us at 1-800-SAMSUNG or nd help and information

online at www.samsung.com.

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When

refrigerant leaks from the pipe, avoid any naked ames and move anything ammable

away from the product and ventilate the room immediately.

- Failing to do so may result in re or explosion.

• Improper use of the grounding plug can result in a risk of electric shock. If it is

necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade

grounding plug and a 3-slot receptacle that will accept the plug on the appliance.

The marked rating of the extension cord should be AC 115-120 V, 10 A, or more. If a

grounding adapter is used, make sure the receptacle box is fully grounded.

Safety information

Untitled-1 4 2021-06-22  4:44:19

English 5

Safety information

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This manual uses the following safety

symbols.

WARNING

Hazards or unsafe practices that may result in severe personal injury, property damage,

and/or death.

CAUTION

Hazards or unsafe practices that may result in severe personal injury and/or property

damage.

NOTE

Useful information that helps users understand or benet from the refrigerator.

These warning signs are here to prevent injury to you and others.

Please follow them carefully.

After reading this section, keep it in a safe place for future reference.

State of California Proposition 65 Warning

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Important safety precautions

Warning; Risk of re / ammable materials

WARNING

• R-600a is used as a refrigerant. This product contains ammable gas (Refrigerant

R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture if a leak in the

refrigerating circuit occurs, the size of the room in which the appliance may be sited

depends on the amount of refrigerant used. The room must be 35.3 ft³ in size for every

8 g of R-600a refrigerant inside the appliance.

• The installation location should not be exposed to direct sunlight and not placed near

any electric appliance or heat source, e.g. stove, oven or hob, radiator, etc.

Untitled-1 5 2021-06-22  4:44:20

Safety information

English6

Safety information

• If you use two products side by side, for safety reason, be sure to use certied products

in explosive gas atmospheres.

• Never start up an appliance showing any signs of damage. If in doubt, consult your

dealer.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent

or similarly qualied persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance can be quickly disconnected

from the supply in an emergency. It must be outside the area of the rear of the

appliance.

• Do not store explosive substances such as aerosol cans with a ammable propellant in

this appliance.

• New hose-sets supplied with the appliance are to be used and that old hose-sets should

not be reused.

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power supplies at the rear of

the appliance.

WARNING

• Fill with potable water only.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of

obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process,

other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage compartments of The appliance,

unless they are of the type recommended by the manufacturer.

• Connect to potable water supply only.

WARNING

• Risk of child entrapment. Before you throw away your old refrigerator or freezer:

- Take off the doors.

- Leave the shelves in place so that children may not easily climb inside.

Untitled-1 6 2021-06-22  4:44:20

English 7

Safety information

CAUTION

• Risk Of Fire Or Explosion. Flammable Refrigerant Used. Do Not Use Mechanical Devices

To Defrost Refrigerator. Do Not Puncture Refrigerant Tubing.

• Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be Repaired Only By Trained

Service Personnel. Do Not Puncture Refrigerant Tubing.

• Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair Manual/Owner’s

Guide Before Attempting to Service This Product. All Safety Precautions Must Be

Followed.

• Risk Of Fire Or Explosion. Dispose Of Properly In Accordance With Federal Or Local

Regulations. Flammable Refrigerant Used.

• Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling

Instructions Carefully. Flammable Refrigerant Used.

• To Prevent A Child From Being Entrapped, Keep Out Of Reach Of Children And Not In

The Vicinity Of Freezer Or Refrigerator.

This appliance is intended to be used in household and similar applications such

• staff kitchen areas in shops, ofces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications.

Severe warning signs for transportation and site

WARNING

• When transporting and installing the appliance, care should be taken to ensure that no

parts of the refrigerating circuit are damaged.

- Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak

is detected, avoid any naked ames or potential sources of ignition and air the room

in which the appliance is standing for several minutes.

- This appliance contains a small amount of isobutane refrigerant (R-600a), a natural

gas with high environmental compatibility that is, however, also ammable.

Untitled-1 7 2021-06-22  4:44:20

Safety information

English8

Safety information

Critical installation warnings

WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact

with water.

- Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves,

room heaters, or other appliances.

• Do not plug several appliances and the refrigerator into the same multiple power strip.

The refrigerator should always be plugged into its own individual electrical outlet which

has a voltage rating that matches the voltage listed on the refrigerator’s rating plate.

- This provides the best performance and also prevents overloading of house wiring

circuits, which could overheat the wires and cause a re hazard.

• If the wall socket is loose, do not insert the power plug.

- There is a risk of electric shock or re.

• Do not use a power cord that has cracks or abrasion damage along its length or at

either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power

cord, insert the power cord between objects, or push the power cord into the space

behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord.

- This may result in an electric shock or re.

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug

rmly and pull straight out from the outlet.

- Damage to the cord may cause a short-circuit, re, and/or electric shock.

• Do not install this appliance near a heater or ammable material.

• Do not install this appliance in a location where gas may leak.

- This may result in an electric shock or re.

• This refrigerator must be properly located and installed in accordance with the

instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down.

- If you connect the power plug upside down, the wire can get cut off and cause a re

or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the

refrigerator.

• Keep the packing materials out of reach of children.

- There is a risk of death from suffocation if a child puts the packing materials on his

or her head.

• The appliance must be positioned so that the plug is accessible after installation.

- Failing to do so may result in an electric shock or re due to electric leakage.

• Do not install this appliance in a humid, oily or dusty location, or in a location exposed

to direct sunlight or to water (rain drops).

- Deteriorated insulation on electrical parts may cause an electric shock or re.

Untitled-1 8 2021-06-22  4:44:20

English 9

Safety information

• If large amounts of dust or water enter the refrigerator, disconnect the power plug and

contact a Samsung Electronics service center.

- Otherwise there is a risk of re.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product

in.

• Children should be supervised to ensure that they do not play with the snap rings used

for door adjustment or the water tube clips.

- There is risk of death by suffocation if a child swallows a snap ring or water tube

clip. Keep the snap rings and water tube clips out of children's reach.

• The refrigerator must be safely grounded.

- Always make sure that you have grounded the refrigerator before attempting to

investigate or repair any part of the appliance. Power leakages can cause severe

electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an

electrical ground.

- You must ground the refrigerator to prevent any power leakages or electric shocks

caused by current leakage from the refrigerator.

- Current leakage may result in an electric shock, re, explosion, or problems with the

product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug,

damaged power cord, or loose wall socket.

- This may result in an electric shock or re.

• Only a qualied technician or service company should be allowed to change the fuse in

the refrigerator.

- Failing to do so may result in an electric shock or personal injury.

Installation cautions

CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface.

- Keep the ventilation space in the appliance enclosure or mounting structure clear of

obstructions.

• After you have installed the refrigerator and turned it on, allow the appliance to stand

for 2 hours before loading it with food.

• It is strongly recommended you have a qualied technician or service company install

the refrigerator.

- Failing to do so may result in an electric shock, re, explosion, problems with the

product, or injury.

• Overloading one door may make the refrigerator fall, causing physical injury.

Untitled-1 9 2021-06-22  4:44:20

Safety information

English10

Safety information

Critical usage warnings

WARNING

• Do not insert the power plug into a wall socket with wet hands.

- This may result in an electric shock.

• Do not store articles on the top of the appliance.

- When you open or close the door, the articles may fall and cause personal injury

and/or material damage.

• Do not insert hands, feet, or metal objects (such as chopsticks, etc.) into the bottom or

the back of the refrigerator.

- This may result in an electric shock or injury.

- Any sharp edges may cause a personal injury.

• Do not touch the inside walls of the freezer or products stored in the freezer with wet

hands.

- This may cause frostbite.

• Do not put a container lled with water on the refrigerator.

- If spilled, there is a risk of re or electric shock.

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas,

alcohol, ether, LP gas, and other such products) in the refrigerator.

- This refrigerator is for storing food only.

- This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance.

- Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet

are necessarily small. Be careful when you open the doors if children are in the area.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the area under the appliance.

- Any sharp edges may cause personal injury.

• Do not store pharmaceutical products, scientic materials, or temperature sensitive

products in the refrigerator.

- Products that require strict temperature controls must not be stored in the

refrigerator.

• Do not place or use electrical appliances inside the refrigerator/freezer, unless they are

of a type recommended by the manufacturer.

• If you smell smoke, pull out the power plug immediately, and then contact a Samsung

Electronics service center.

• If large amounts of dust or water enter the refrigerator, disconnect the power plug and

contact your Samsung Electronics service center.

- Otherwise there is a risk of re.

• Do not let children step on a drawer.

- The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and

do not let children enter the refrigerator.

• Do not allow babies or children to go into a drawer.

- It can cause death from suffocation by entrapment or personal injury.

Untitled-1 10 2021-06-22  4:44:20

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Kühlschrank Handbücher

Samsung

Samsung RS25H50 SERIES Bedienungsanleitung

Samsung

Samsung RFG297HD SERIES Bedienungsanleitung

Samsung

Samsung RF26HFEND series Bedienungsanleitung

Samsung

Samsung RL22FC Series Bedienungsanleitung

Samsung

Samsung RF59C701ES9/EU Bedienungsanleitung

Samsung

Samsung BRR7GR121 Series Bedienungsanleitung

Samsung

Samsung RF4287HABP Bedienungsanleitung

Samsung

Samsung RS22HDHPNSR Bedienungsanleitung

Samsung

Samsung RF28HM Bedienungsanleitung

Samsung

Samsung RSA1NHMH Bedienungsanleitung

Samsung

Samsung RL55VQBRS Premium 2m Fridge Freezer Bedienungsanleitung

Samsung

Samsung BRB30705EWW/EF Bedienungsanleitung

Samsung

Samsung RB195ACBP Bedienungsanleitung

Samsung

Samsung RF28HF Bedienungsanleitung

Samsung

Samsung RT22S Bedienungsanleitung

Samsung

Samsung RB34A7B5DCE/EF Bedienungsanleitung

Samsung

Samsung SR270MLS Bedienungsanleitung

Samsung

Samsung RS265LA series Sicherheitsleitfaden

Samsung

Samsung RS23NAMS Sicherheitsleitfaden

Samsung

Samsung RT18M SERIES Bedienungsanleitung

Samsung

Samsung RF23M8590SR/AA Bedienungsanleitung

Samsung

Samsung RT38CG6624S9 Bedienungsanleitung

Samsung

Samsung RF30HDEDTSR/AA Bedienungsanleitung

Samsung

Samsung DA68-01890C Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung
