Samsung RF261BEAESR Bedienerhandbuch

*25.5 cu. ft. measured as per Department of Energy

Signature Features

Available Colors

RF261BEAESR

26 cu.ft. French Door with Internal Filtered Water Dispenser

Features

· Large Storage Capacity – 26 cu. ft.*

· Internal Filtered Water Dispenser

· Additional Filtered Ice Maker

in the Freezer

· High Efficiency LED Lighting

· Twin Cooling Plus System®

· Cool Select Pantry™ with

Temperature Control

· Power Freeze and Power Cool Options

· Two Humidity Controlled Crispers

· Tempered Glass Spill Proof Shelves

· Gallon Door Bins

· EZ-Open Handle™ on Freezer Door

· Auto Out Upper Freezer Drawer

Convenience

∙ Cool Tight Door

∙ Door Alarm

∙ Water Filter Indicator

∙ Removable Ice Caddy

Energy Star Rated

Rated CEE Tier 2: More Efﬁcient

449 kWh / year

French Door design provides easy access to fresh food

and ﬂexible storage options.

Stainless

Steel

(shown)

Black

White

Stainless

Platinum

Internal Water Dispenser

Fresh, Filtered Water from Your Fridge

Filter inside the refrigerator removes

impurities from drinking water before

dispensing.

Twin Cooling Plus®Helps

Produce Stay Fresher

Refrigerator air is kept at higher,

near-commercial grade humidity

levels to keep perishable fruits and

vegetables from spoiling.

High-Efciency LED Lighting

Illuminates Virtually Every Corner.

Samsung's new high-efﬁciency LED

lighting gently brightens the interior of

your beautifully organized refrigerator.

Cool Select Pantry™

Some hinges cannot be removed, please refer to the dimensions with hinges for product install and delivery dimensions

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

Dimensions

Installing your Refrigerator

1. Measure the height, width and depth of the opening, making sure to include baseboards,

molding tile, countertop overhang, etc. Check to be sure there is enough room to open the

door (consider walls, islands or other obstacles when measuring).

2. Refer to chart B below to determine dimensions.

3. Allow 2” of clearance on hinge side of refrigerator when installing next to a wall wherehandle

may make contact.

4. Allow 1” minimum clearance at rear for proper air circulation and water/electrical connections.

Allow a 3/8” minimum clearance at sides and top for ease of installation.

5. Ensure each door and entry way in the home is wide enough for the refrigerator to be moved

through easily.

Please note: The following dimension and cutout information is for planning purposes only. For

complete installation details consult manual packed with product, or download manual on-line

at samsung.com.

Measure Height

including ooring.

Be sure to allow

for hinge clearance

height if needed

Measure Width

including

countertop

overhang

Measure Depth

including

molding or trim

RF261BEAESR

26 cu.ft. French Door with Internal Filtered Water Dispenser

Total Capacity: 25.5 cu. ft.

Refrigerator: 17.6 cu. ft.

· Internal Filtered Water Dispenser

· High Efﬁciency LED Lighting

· Cool Select Pantry™ with Temperature Control

· 2 Humidity Controlled Crispers

· 5 Tempered Glass Spill Proof Shelves

– 3 Slide Out

– 1 Slide In

– 1 Full Width

6 Clear Door Bins

– Right Door: 3 Gallon Bins

– Left Door: 3 Gallon Bins

Freezer: 7.9 cu. ft.

· 1 Large Opaque Freezer Bin with Divider

· Auto Pull Out Upper Drawer Bin

· Filtered Ice Maker – Cubed

· High Efﬁciency LED Lighting

Accessories:

Water Filter: HAF-CIN

Warranty

One (1) Year All Parts and Labor

Ten (10) Years Sealed System Parts and Labor

Product Dimensions + Weight

Dimensions: (WxHxD)

(Without Hinges): 35 6⁄8" x 68 5⁄8" x 33 1⁄4"

(With Hinges): 35 6⁄8" x 70" x 33 1⁄4"

(With Hinges + Door Handles): 35 6⁄8" x 70" x 35 5⁄8"

Weight: 306.4 lbs / 139 kg

Shipping Dimensions + Weight

Dimensions: (WxHxD)

38 5⁄8" x 75 6⁄8" x 36 2⁄8"

Weight: 332.9 lbs / 151 kg

21 1/2"

3 3/8"

35 3/4"

52 1/8"

29 1⁄ 4"

33 2/8"

35 5/8"

3 1/4"

24 1/4"

5⁄ 8"

41 3/4"

70"

1 1/4"

Color Model # UPC Code

Stainless Steel RF261BEAESR 036725590137

White RF261BEAEWW 036725590168

Black RF261BEAEBC 036725590151

Stainless Platinum RF261BEAESP 036725590144
