Samsung SM-J510F Bedienungsanleitung
2
Table of Contents
Basics
4 Read me first
5 Package contents
6 Device layout
8 Battery
13 SIM or USIM card
18 Memory card (microSD card)
19 Turning the device on and off
20 Touchscreen
23 Home screen
29 Lock screen
30 Notification panel
32 Entering text
33 Screen capture
34 Opening apps
34 Samsung account
36 Transferring data from your previous
device
38 Device and data management
41 Sharing features
42 Emergency mode
Applications
43 Installing or uninstalling apps
45 Phone
49 Contacts
51 Messages
54 Internet
56 Email
57 Camera
66 Gallery
68 S Planner
70 S Health
73 Voice Recorder
74 My Files
74 Memo
75 Clock
76 Calculator
77 Radio
78 Google apps
Table of Contents
3
98 Easy mode
98 Accessibility
99 Accounts
100 Backup and reset
100 Language and input
101 Battery
101 Storage
101 Accessories
102 Date and time
102 User manual
102 About device
Appendix
103 Troubleshooting
Settings
80 Introduction
80 Wi-Fi
82 Bluetooth
83 Flight mode
84 Mobile hotspot and tethering
85 Data usage
85 SIM card manager (dual SIM models)
86 Mobile networks
86 NFC and payment (NFC-enabled
models)
89 More connection settings
90 Smart Manager
92 Applications
92 Sounds and vibrations
93 Notifications
93 Do not disturb
94 Display
94 Advanced features
95 Wallpaper
95 Themes
95 Home screen
95 Lock screen and security
97 Privacy and safety
4
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
•
Depending on the region, you can view the regulatory information on the device. To view
the information, tap
Apps
→
Settings
→
About device
→
Regulatory information
.
Basics
5
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
Package contents
Check the product box for the following items:
•
Device
•
Battery
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
Basics
6
Device layout
Front camera
Microphone
Back key
Flash
Proximity sensor
Receiver
Power key
Multipurpose jack
Headset jack
Touchscreen
Recents key
Home key
Volume key
Back cover
Rear camera
Loud speaker
Main antenna
NFC antenna
(NFC-enabled models)
Flash
GPS antenna
Basics
7
•
Connectivity problems and battery drain may occur in the following situations:
–
If you attach metallic stickers on the antenna area of the device
–
If you attach a device cover made with metallic material to the device
–
If you cover the device’s antenna area with your hands or other objects while
using certain features, such as calls or the mobile data connection
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touchscreen. The touchscreen may malfunction
in humid conditions or when exposed to water.
Keys
Key Function
Power
•
Press and hold to turn the device on or off.
•
Press to turn on or lock the screen.
Recents
•
Tap to open the list of recent apps.
Home
•
Press to turn on the screen while the screen is locked.
•
Press to return to the Home screen.
•
Press and hold to launch
Google
.
Back
•
Tap to return to the previous screen.
Volume
•
Press to adjust the device volume.
Basics
8
Battery
Installing the battery
1 Remove the back cover.
Be careful not to damage your fingernails when you remove the back cover.
Do not bend or twist the back cover excessively. Doing so may damage the cover.
2 Insert the battery with the battery’s gold-coloured contacts properly aligned with the
device’s contacts.
2
1
Basics
9
3 Replace the back cover.
Removing the battery
1 Remove the back cover.
2 Pull out the battery.
Basics
10
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
1 Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable
into the multipurpose jack.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
2 Plug the USB power adaptor into an electric socket.
