English

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.

Product design and speciﬁcations may be changed without notice.

User Instructions

• Screen Image retention

Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma monitor panel for more than 2 hours

as it can cause screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of

brightness and contrast of the screen when displaying a still image.

• Heat on the top of the Plasma TV

The top side of the product may be hot after long period of use as heat dissipates from the panel through the vent hole in the upper part of the

product. This is normal and does not indicate any defect or operation failure of the product. However, children should be prevented from touching the

upper part of the product.

• The product is making a “cracking” noise.

A “cracking” noise may occur when the product contracts or expands due to a change in the surrounding environment such as temperature or

humidity. This is normal and not a defect of the unit.

• Cell Defects

The PDP uses a panel consisting of 2,360,000(HD-level) to 6,221,000(FHD-level) pixels which require sophisticated technology to produce. However,

there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.

• Avoid operating the TV at temperatures below 41°F (5°C)

• A still image displayed too long may cause permanent damage to the PDP Panel.

Watching the Plasma TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of

the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause similar effects to

the screen.

Damages caused by the above effect are not covered by the Warranty.

• After-images on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.

To prevent this effect, reduce the “brightness” and “contrast” when displaying still images for a long time.

• Warranty

Warranty does not cover any damage caused by image retention.

Burn-in is not covered by the warranty.

Securing the Installation Space

Keep the required distance between the product and other objects (e.g. walls) to ensure proper ventilation.

Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

✎

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.

✎

The appearance may differ depending on the product.

Installation with a stand. Installation with a wall-mount.

10 cm

10 cm 10 cm

10 cm

BN68-03167A-00Eng.indd 2 2010-07-06 오전 9:36:18

English

Contents

Getting Started

4 Accessories

4 Viewing the Control Panel

5 Viewing the Remote Control

6 Connecting to an Antenna

6 Plug & Play (Initial Setup)

Connections

7 Connecting to an AV Device

8 Connecting to an Audio Device

8 Changing the Input Source

Basic Features

9 How to Navigate Menus

9 Using the INFO button (Now & Next guide)

9 Planning Your Viewing

11 Channel Menu

12 Picture Menu

17 Sound Menu

19 Setup Menu

21 Support Menu

Advanced Features

22 Connecting to a PC

23 Media Play

29 Anynet+

Other Information

32 Analogue Channel Teletext Feature

33 Installing the Wall Mount

34 Securing the TV to the wall

35 Troubleshooting

38 Speciﬁcations

39 Index

Check the Symbol!

This function can be used by pressing the

TOOLS button on the remote control.

Note One -Touch Button

Indicates additional information. Check here for instructions on how to open

the relevant submenu within the OSD (on

screen display).

BN68-03167A-00Eng.indd 3 2010-07-06 오전 9:36:18

English

Accessories

✎

Please make sure the following items are included with your PDP TV. If any items are missing, contact your dealer.

✎

The items’ colours and shapes may vary depending on the models.

yRemote Control & Batteries (AAA x 2)

yOwner’s Instructions

yCleaning Cloth

yPower Cord

yWarranty Card / Safety Guide (Not available in some locations)

yBlanking Bracket yFerrite Core 2EA

(depending on the country)

✎

Ferrite Core for Power Cord: The ferrite cores are used to shield the cables from interference. When connecting a cable,

open the ferrite core and clip it around the cable near the plug as shown in the figure.

Distance between the ferrite core and one end of the cord put into the TV set

yA: below 50 mm

yB : below 20 mm

Viewing the Control Panel

✎

The product colour and shape may vary depending on the model.

SOURCE

Toggles between all the available input sources. In the on-screen menu, use this

button as you would use the ENTER

button on the remote control.

MENU Displays an on-screen menu, the OSD (on screen display) of your TV’s features.

Adjusts the volume. In the OSD, use the

buttons as you would use the

◄and ►buttons on the remote control.

Changes the channels. In the OSD, use the

buttons as you would use the

▼and ▲buttons on the remote control.

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

(Power) Turns the TV on or off.

Remote control sensor Aim the remote control towards this spot on the TV.

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount

of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

Getting Started

Speakers

Power Indicator

Remote control sensor

BN68-03167A-00Eng.indd 4 2010-08-02 오전 9:35:48

01 Getting Started

English

Viewing the Remote Control

Installing batteries (Battery size: AAA)

✎

NOTE

Use the remote control within 23 feet from TV.

Bright light may affect the performance of the remote

control. Avoid to use nearby special fluorescent light or neon

sign.

The colour and shape may vary depending on the model.

Turns the TV on and off.

Returns to the previous channel.

To mute all TV output sound

Displays channel lists on the screen

(p. 11).

Changes channels.

Displays and selects the available video

sources (p. 8).

Displays the EPG (Electronic Programme

Guide). (p. 9)

Displays information on the TV screen.

Exits the menu.

Selects the on-screen menu items and

changes the values seen on the menu.

P.MODE: Press to select the picture

mode (p. 12).

S.MODE: Press to select the sound

mode (p. 17).

DUAL f-g: Sound effect selection

(p. 18).

AD: Turns the audio description on

and off (not available in some locations)

(p. 18).

P.SIZE: Selects the picture size (p. 13).

SUBT.: Displays digital subtitles (p. 20).

Have direct access to channels.

Adjusts the volume.

Opens the OSD.

Quickly select frequently used functions.

Returns to the previous menu.

Alternately select Teletext ON, Double,

Mix or OFF.

Displays Media Play (USB) (p. 23).

Use these buttons in Media Play

(USB) and Anynet+ (HDMI-CEC)

modes (p. 23, 29).

(



: Controls recording for Samsung

recorders that have the Anynet+

feature)

These buttons are for the Channel

Manager, Media Play (USB) menu, etc.

BN68-03167A-00Eng.indd 5 2010-07-06 오전 9:36:19

Getting Started

English

Connecting to an Antenna

When the TV is initially powered on, basic settings proceed automatically.

✎

Preset: Connecting the power cord and antenna.

✎

The PDP device may interfere with an amateur radio or AM radio.

Plug & Play (Initial Setup)

When the TV is initially powered on, a sequence of on-screen prompts will assist in conﬁguring basic settings. Press the

POWER

button. Plug & Play is available only when the Input source is set to TV.

✎

To return to the previous step, press the Red button.

1Selecting Store Demo

or Home Use

Press the ◄or ►button, then press the ENTER

button.

ySelect the Home Use mode. Store Demo Mode is for retail

environments.

yTo return the unit’s settings from Store Demo to Home Use

(standard): Press the volume button on the TV. When you see the

volume OSD, press and hold MENU for 5 sec.

POWER

2Selecting a country Press the ▲or ▼button, then press the ENTER

button.

Select the appropriate country. If the desired country does not exist on

the menu, select Others.

3Selecting a channel

source

Press the ▲or ▼button, then press the ENTER

button. Select Digital & Analogue,

Digital or Analogue.

4Selecting a channel Press the ▲or ▼button, then press the ENTER

button.

Select the channel source to memorise. For more information, refer to Channel →

Auto Store (p. 11).

✎

Press the ENTER

button at any time to interrupt the memorisation process.

5Setting the Clock

Mode

Set the Clock Mode automatically or manually.

yAuto: Allows you to select time zone.

yManual: Allows you to manually set the current date and time.

6Time zone Press the ▲or ▼button to highlight the time zone for your local area.

Press the ENTER

button (Australia only).

7Viewing the HD

Connection Guide.

The connection method for the best HD screen quality is displayed.

8Enjoy your TV. Press the ENTER

button.

If You Want to Reset This Feature...

Select Setup - Plug & Play (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0.” If you want to

change the PIN number, use the Change PIN function.

ANT OUT

VHF/UHF Antenna

Cable

Power Input

BN68-03167A-00Eng.indd 6 2010-07-06 오전 9:36:19

English

02 Connections

Connections

Connecting to an AV Device

Using an HDMI or HDMI/DVI cable: HD connection (up to 720p/1080i)

Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, cable box, STB satellite receiver

✎

HDMI IN 1(DVI), 2, 3, PC/DVI AUDIO IN

When using an HDMI/DVI cable connection, you must use the HDMI IN 1(DVI) jack. For the DVI cable

connection, use a DVI to HDMI cable or DVI-HDMI (DVI to HDMI) adapter for video connection and the PC/DVI

AUDIO IN jacks for audio.

If an external device such as a DVD / Blu-ray player / cable box / STB satellite receiver supporting a HDMI

versions older than 1.3 is connected, the TV may operate abnormally (e.g. no screen display / no sound /

annoying flicker / abnormal colour).

If there is no sound after connecting an HDMI cable, check the HDMI version of the external device. If you

suspect the version is older than 1.3, contact the provider of the device to confirm the HDMI version and

request an upgrade.

It is recommended you purchase an HDMI-certified cable. Otherwise, the screen may appear blank or a

connection error may occur.

Using a Component (up to 720p/1080i) or Audio/Video (480i only) Cable

Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR

✎

To obtain the best picture quality, the Component connection is recommended over the A/V connection.

HDMI OUT

DVI OUT



W R

AUDIO OUT

R-AUDIO-L

DVD /

Blu-ray player

DVD /

Blu-ray player

Red White

R

R  R  

RR  R



VCR

Red

Red White

White

Blue Green Yellow

DVD / Blu-ray player

BN68-03167A-00Eng.indd 7 2010-07-06 오전 9:36:20

English

Connections

Connecting to an Audio Device

Using an Optical (Digital) or Headphone Connection

Available devices: digital audio system, ampliﬁer, DVD home theatre

✎

DIGITAL AUDIO OUT (OPTICAL)

When a Digital Audio System is connected to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume

of both the TV and the system.

5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH.

When the receiver (amplifier or DVD home theatre) is set to on, you can hear sound output from the TV’s

optical jack. When the TV is receiving a DTV signal, the TV will send 5.1 CH sound to the amplifier or DVD

home theatre. When the source is a digital component such as a DVD / Blu-ray player / cable box / STB

(Set-Top-Box) satellite receiver and is connected to the TV via HDMI, only 2 CH audio will be heard from the

amplifier or DVD home theatre. If you want to hear 5.1 CH audio, connect the digital audio out jack from your

DVD / Blu-ray player / cable box / STB satellite receiver directly to an amplifier or home theatre.

✎

Headphones

: You can connect your headphones to the headphones output on your set. While the

headphones are connected, the sound from the built-in speakers will be disabled.

Sound function may be restricted when connecting headphones to the TV.

Headphone volume and TV volume are adjusted separately.

Input Cables (Sold Separately)

HDMI HDMI-DVI Component Composite (AV) Coaxial (RF) VGA

Changing the Input Source

Source List

Use to select TV or an external input sources

such as a DVD / Blu-ray player / cable box /

STB satellite receiver.

■TV / AV / Component1 / Component2

/ PC / HDMI1/DVI / HDMI2 / HDMI3 /

USB

✎

In the Source List, connected

inputs will be highlighted.

✎

PC always stay activated.

SOURCE

Edit Name

■VCR / DVD / Cable STB / Satellite STB / PVR STB /

AV Receiver / Game / Camcorder / PC / DVI PC /

DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA:

Name the device connected to the input jacks to make

your input source selection easier.

✎

When connecting an HDMI/DVI cable to the

HDMI IN 1(DVI) port, you should set to DVI PC or

DVI Devices mode under Edit Name.

✎

If an HDMI cable is connected to the

HDMI IN 1(DVI) port, the audio may not work. In

this case, connect to the PC/DVI AUDIO IN port.

OPTICAL

digital audio system

BN68-03167A-00Eng.indd 8 2010-07-06 오전 9:36:20

English

02 Connections

Basic Features

How to Navigate Menu

Before using the TV, follow the steps below to learn how to

navigate the menu and select and adjust different functions.

1 MENU button: Displays the main on-screen menu.

2 ENTER

/ Direction button: Move the cursor and

select an item. Conﬁrm the setting.

3 RETURN button: Returns to the previous menu.

4 EXIT button: Exits the on-screen menu.

How to Operate the OSD (On Screen Display)

The access step may differ depending on the selected menu.

1MENU

The main menu options appear on

the screen:

Picture, Sound, Channel, Setup,

Input, Application, Support.

2▲/ ▼Select an icon with the ▲or ▼

button.

3ENTER

Press ENTER

to access the

sub-menu.

4▲/ ▼Select the desired submenu with

the ▲or ▼button.

5◄/ ►Adjust the value of an item with the

◄or ►button. The adjustment in

the OSD may differ depending on

the selected menu.

6ENTER

Press ENTER

to complete the

conﬁguration.

7EXIT

Press EXIT.

Using the INFO button (Now & Next guide)

The display identiﬁes the current channel and

the status of certain audio-video settings.

The Now & Next guide shows daily TV

programme information for each channel

according to the broadcasting time.

yScroll ◄, ►to view information for a

desired programme while watching the

current channel.

yScroll ▲, ▼to view information for other channels. If you

want to move to the currently selected channel, press

the ENTER

button.

Planning Your Viewing

Guide

The EPG (Electronic Programme Guide)

information is provided by broadcasters.

Using programme schedules provided by

broadcasters, you can specify programmes

you want to watch in advance so that the

channel automatically changes to the selected

programme channel at the speciﬁed time.

Programme entries may appear blank or out of date

depending on a channel status.

✎

In New Zealand, if Digital Text is set to Enable, the EPG

(Electronic Programme Guide) will work.

(refer to page 20)

Using Channel View

INFO

View Mode

+24 Hours Ch. Mode

Information

Page

Watch

2:10 Tue 1 Jun

Guide

Channel View - All

1 2 3 4 5 6

GUIDE

BN68-03167A-00Eng.indd 9 2010-07-06 오전 9:36:21

English

Basic Features

Using Scheduled View

1 Red (View Mode): View the list of programmes that

are playing now or coming up.

2 Yellow (+24 Hours): Viewing the list of programmes to

be broadcasted after 24 hours.

3 Blue (Ch. Mode): Select the type of channels you

want to display on the Channel View window. (All, TV,

Radio, Data/Other, My Channel 1~4)

4 Information: Displays details of the selected

programme.

(Page): Move to next or previous page.

6 ENTER

button

– When selecting the current programme, you can

watch the selected programme.

– When selecting the future programme, you can

reserve to watch the selected programme. To cancel

the schedule, press the ENTER

button again and

select Cancel Schedules.

¦Seeing Channels

Channel Manager

Delete or set favourite channels. Select a channel in the

Channels, My Channels or Scheduled screen.

■Channels: Shows the channel list according to

channel type.

■

My Channels: Shows the group of the channel.

■Scheduled: Shows all the currently reserved

programmes.

✎

Using the colour buttons with the Channel Manager

Green (Zoom): Enlarges or shrinks a channel

number.

Yellow (Select): Selects multiple channel lists.

Select desired channels and press the Yellow button

to set all the selected channels at the same time. The

mark appears to the left of the selected channels.

Blue (Sort): Change the list ordered by channel

name or channel number.

(Page): Move to next or previous page.

(Tools): Displays the Channel Manager option

menu. (The options menus may differ depending on

the situation.)

Channel Status Display Icons

Icons Operations

An analogue channel.

A channel selected.

A channel set as a Favourite.

(

A programme currently being broadcast.

A locked channel.

)

A reserved programme.

View Mode

Cancel

2:10 Tue 1 Jun

Guide

Scheduled View

1 6

358 ORF1

359 ORF2 0

360 ORF2 S

361 * BBC World

728 \bid-up.tv

c729 Boonerang

1 C1

2 C2

All

Radio

Data/Other

Analogue

Zoom Select Sort

Page

Tools

Channels

BN68-03167A-00Eng.indd 10 2010-07-06 오전 9:36:22

Andere Handbücher für Plasma TV

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Samsung Fernseher Handbücher

Samsung

Samsung CS21K3DX/BWT Bedienungsanleitung

Samsung

Samsung TXN2034F Bedienungsanleitung

Samsung

Samsung CL15K5MN Bedienungsanleitung

Samsung

Samsung DM65D Bedienungsanleitung

Samsung

Samsung CL21B501HLMXZS Bedienungsanleitung

Samsung

Samsung HPS5053X/XAA (HP-S5053) Bedienungsanleitung

Samsung

Samsung CS-29A10HW Bedienungsanleitung

Samsung

Samsung UA40JU6000K Bedienungsanleitung

Samsung

Samsung CL32A20HE Bedienungsanleitung

Samsung

Samsung PDP Display Leitfaden

Samsung

Samsung UN46ES8000 Leitfaden

Samsung

Samsung OfficeServ 7000 Series Bedienungsanleitung

Samsung

Samsung PN50C680G5F Bedienungsanleitung

Samsung

Samsung UN55D6400 Leitfaden

Samsung

Samsung QN65LST9TAFXZA Bedienungsanleitung

Samsung

Samsung EB40D Bedienungsanleitung

Samsung

Samsung Bauhn Tizen ATV65UHDT-0922 Bedienungsanleitung

Samsung

Samsung KS7D Bedienungsanleitung

Samsung

Samsung CS29Z4HF9X/BWT Bedienungsanleitung

Samsung

Samsung HL-T5075S - 50" Rear Projection TV Bedienungsanleitung

Samsung

Samsung PS50C430 Bedienungsanleitung

Samsung

Samsung ps64f8500ar Leitfaden

Samsung

Samsung T24D310ES Bedienungsanleitung

Samsung

Samsung CFT27908X/SMS Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung
