Samsung UN46D7900XF Bedienungsanleitung

2011 Samsung TV

F/W Upgrade Guide

Samsung Electronics

Step1. How to prepare the USB Memory Drive

2. Connect the USB Memory Drive to the USB port of your PC.

Copy the file onto the USB Memory Drive.

3. Go to the USB Memory Drive, and then double click the file.

1. Download the firmware file from Samsung.com to your computer.

File Name : T-GAPAKUC.exe

4. Click the “Unzip” button.

5. The file unzips.

6. After the file unzips completely,

click the “OK” and “Close” buttons.

7. Confirm that a folder containing the

firmware files has been added to the USB

memory drive.

Folder name : T-GAPAKUC

8. Safely disconnect the USB memory drive

by right clicking the green check mark

on the taskbar, and then left clicking

“Safely Remove”.

O K

1. Turn on the TV.

2. Insert the USB Memory Drive

containing the firmware into the USB

port of TV.

3. Press the MENU button, select

„Support‟, „Software Upgrade‟, and then

„By USB‟.

8. When the firmware upgrade

is complete, the TV turns off and

then back on by itself.

4. The message “Scanning for USB.

This may take more 1 min.” is displayed.

6. Press OK. The TV turns off

automatically after displaying the

message below.

Step2. How to upgrade the Firmware

Scanning for USB.

This may take more than 1 min.

5. If the TV finds a valid firmware version,

it displays the message below.

Valid version found in the My USB device.

Upgrade version 000000 to version 001007?

The system will be reset after upgrade.

OK Cancel

TV will restart automatically for software

upgrade.

7. After the TV turns on again, the

upgrade starts.

Upgrading...

Please do not disconnect the USB until upgrade is

completed. TV will automatically restart after

completing upgrade.

80%

Upgrade is completed.

Cautions

While upgrading,

Do not pull the USB Memory drive out.

Do not unplug the power cable.

Do not turn off the TV.

※Warning

Pulling the USB Memory drive out or unplugging the power cable will cause a

firmware error or main board failure. Firmware errors and main board failures are

not covered by Samsung warranty policy.
