SANBOT MAX

USER MANUAL

ROBOT USER MANUAL

Contents

Introduction ......................................................................................................... 1

Sanbot Max application scenario and main function ........................................................................ 2

Unpacking Instruction ...................................................................................................................................................................................... 3

Basic operation ................................................................................................................................................................................................. 6

Specifications & parameters ............................................................................................ 8

Specifications of Charging pile .......................................................................................... 9

Safety guide ........................................................................................................ 10

To Know Your Robot ................................................................................................. 13

1. Packing List ................................................................................................................................................................................................ 13

2. Robot Appearance....................................................................................................................................................................................... 14

3. Charging Pile Appearance........................................................................................................................................................................... 18

How to Operate the Robot ............................................................................. 错误!未定义书签。

1. Turn On\Off ................................................................................................................................................................................................ 19

2. System load................................................................................................................................................................................................. 19

3. Log-in ......................................................................................................................................................................................................... 20

4. Hover Button .............................................................................................................................................................................................. 20

5. Menu Operation .......................................................................................................................................................................................... 20

6. Voice interaction ......................................................................................................................................................................................... 33

To Operate Mobile APP............................................................................................... 36

ROBOT USER MANUAL

1. Download and Install.................................................................................................................................................................................. 36

2. Login........................................................................................................................................................................................................... 36

3. Add Robot /Friends..................................................................................................................................................................................... 36

4. Chats ........................................................................................................................................................................................................... 27

5. Contacts ...................................................................................................................................................................................................... 27

6. Life.............................................................................................................................................................................................................. 28

7. Me............................................................................................................................................................................................................... 30

Introduction

Thank you for purchasing our product. This manual is for Robot.

Please carefully read this Instruction before using the Sanbot Max robot (hereinafter referred to as Sanbot Max), so you can

operate this robot very easily as soon as possible.Please carefully read this Instruction before using the Sanbot Max robot

(hereinafter referred to as Sanbot Max), so you can operate this robot very easily as soon as possible.

Please refer to this instruction and other related guidelines to make sure safety installation and usage.

Please do not allow preschool children to use this product alone.

Juveniles should use this product under the guidance of adults.

If you allow juveniles to use this product, please be sure to instruct them all what can do and can not do as well as safe use of

electricity.

Please tell your children not to put their fingers into the gap between the robot’s wings and its body as well as the gap between

the robot’s head and its body to avoid being caught while the robot moves.

Our company will regularly improve and update the manual. Updated contents will be added into the new edition of this manual

without further notice.

This manual may have some inaccurate technical contents or operational contents not conforming to the product. If you

confront with problems that you can’t handle according to this manual, please contact our customer service or the technical

support department of our company.

Contents of this manual are only for reference and may not be in full accord with the real product. Statement in this manual

without any guarantee in any form. Please prevail in kind.

Sanbot Max application scenario and main function

Sanbot Max integrates the function of consultation, guidance, propaganda, entertainment. It provides music and dance, gesture propaganda, guidance, track inspection,

visitor reception, chat consultation for enterprise, mall, hotel, bank, hospital, government affair hall and other place. With powerful function, Sanbot Max can satisfy repeated

job post demand in service links of all kinds of enterprises and partial replace correspond post staff to save the cost of staff and management and increase service efficiency,

therefore reaching continuous profit.

1. There are 10 degrees of freedom on Sanbot Max’s two arms and 10 degrees of freedom on Sanbot Max’s two palms. With the rotation of 2 degrees of freedom on the head,

it can realize the display of diversified gesture and actions, like greeter and dance.

2. Sanbot Max has a comprehensive robot vision, equipped with HD color camera, HD camera, visual camera, for security protection, video call, visual positioning and

visual recognition etc., function.

3. Sanbot Max has 11 touch sensors, 2 OLED eye displays, 4 atmosphere lamps, and all of them can be triggered or flexible switch based on different scenario.

4. Sanbot Max adopts voice interaction solution with 6 microphones pickup, which can make voice localization, echo cancellation beam orientation, high frequency gain,

reverberation cancellation.

5. Sanbot Max can support 3D SLAM map building, trajectory planning, navigation. Combining 3D vision, Sanbot Max can realize the function of indoor space map

building and positioning.

6. Combining 3D laser vision, infrared and ultrasonic to fuse obstacle avoidance mode, Sanbot Max can realize the function of emergency braking in case of unexpected

situation and moving on bypass obstacle.

7. Sanbot Max chassis adopts structural design of four-wheel outer hub motor plus Mecanum wheel, so it can realize the rotation of 360 degrees, speed of movement up to

5m/s.

8. Sanbot Max with plenty of interfaces, such as USB, HDMI, RJ45, Audio IN, which can access to many kinds of external devices.

9. Sanbot Max has precise auto-charging strategy and charging safety strategy.

10. Sanbot Max with open system, can satisfy custom development or self-development of diversified industry customer.

Unpacking Instruction

Tools needed：Cutting knife, small hammer, cloth gloves;

Unpacking environment: As the size of container is too large, if you wanna keep the carton well, please make sure that the unpacking environment height is more than 3.5

meters.

Unpacking procedure: (Picture just for your information, please prevail in kind)

1. Please remove the outer packing case from bottom to top, and remove the plastic tape covered on the polyfoam.

2. Please remove the two pieces of foam from the front and back of the Sanbot Max, and remove the plastic film covered on the Sanbot Max.

3. Unscrew the butterfly nuts (4 in total) on the left and right sides of wooden pallet, then force out screws (4 in total) with hammer or by hand.

4. Take out of the two fixed wood blocks which are fixed by butterfly nuts and screw, and place them on the side of pallet behind Sanbot Max to make a slope (Please notice

the position of hole)

5. Two staffs stand in front of and behind of the Sanbot Max and hold on the torso of Sanbot Max to slowly push the Sanbot Max down the pallet along slope.

Basic operation

1. Transport Sanbot Max

At least 3 staffs are required to transport Sanbot Max at the same time, and the liftable part is the handle of chassis (the specific position please referred to “know about

Sanbot Max”--Bottom) and force is forbidden in other parts.

2. Turn on Sanbot Max

Before turning on Sanbot Max, please make sure that:

Sanbot Max is on a flat level ground;

There are no any other obstacles within 90 centimeters of Sanbot Max;

Press the power switch at bottom of robot to turn on the power supply (The specific position please referred to “Know about Sanbot Max”--bottom).

The first time turning on robot, please follow the instruction on the screen panel to finish start wizard.

3. Charging method

Method①: Auto-charging

Please connect the power adapter of charging pile to power socket and make sure that Sanbot Max’s auto-charging function is enable. During the use of robot, when the

power is lower than the set value, Sanbot Max will automatically remind the need for charging. User also can turn on charging mode by voice command or system control.

Method②:Manual charging

Please connect the power adapter of charging pile to power socket and move the robot to make the charging metal sheet on the back of robot contact metal charging sheet

of charging pile. It’s ok when you see the indicator flash on the charging pile or the charging status shows on the robot screen.

Method③: Charging by power adapter

Please remove the back cover screw of charging pile with screwdriver (the specific position please referred to “know about Sanbot Max”- back of charging pile) and open

back cover to remove the screw of power adapter (the specific position please refer to “know about your Sanbot Max” – inner of charging pile), then loosen the screw nut of the

power adapter charging port. After taking out the power adapter, one end of the power adapter connects to charging port on the back of robot, and the other end of power

adapter connects to power socket. It’s ok when you see the indicator flash on the charging pile or the charging status shows on the robot screen.

4. Control Sanbot Max

There are one red button and one green button respectively on left shoulder and right shoulder of Sanbot Max.

Red button is stop/pause button, and green button is working/recover button. Turn on or Turn off this function is selectable.

There are a set of buttons under the back and neck of Sanbot Max.

Up, down, left, right button can manually control robot to move forward, backward, left and right.

Press down reset button can let robot reset.

Press down stop button can stop robot’s commands and actions.

Press down option button and then press left or right button can control robot left and right lateral movement.

Press down option button and then press up or down button can control the back and front tilt of the robot’s waist.

Please do not exert force on arms, fingers, head when push robot move manually.

5. Open and recover mode of forward/backward compartment and bracket

Forward compartment of Sanbot Max adopts press type spring switch. There is a press type spring switch at the upper and lower ends of the forward compartment

respectively. Press the medium position of the upper end and the lower end of forward compartment down respectively, then you can open the forward compartment. After

aligning compartment, press it again to close the compartment.

Backward compartment of Sanbot Max can be opened by software control or inserting a hexagonal wrench into mechanical switch hole. Aligning the backward
