Sandstrom S10DPF16 Bedienungsanleitung

Instruction Manual

10” Digital Photo

Frame

S10DPF16

Contents

Safety Warnings.............................................................................................. 4

Unpacking....................................................................................................... 6

Product Overview........................................................................................... 7

Front & Rear View .............................................................................................................7

Top View ..............................................................................................................................7

Preparations.................................................................................................... 8

Connecting to the Mains Power .................................................................................8

Inserting a Memory Card / USB Device .................................................................... 8

Selecting the Memory Device ..................................................................................... 9

Viewing Photos............................................................................................... 9

Viewing Thumbnails........................................................................................................9

Calendar View ............................................................................................... 10

Playing a Slideshow.......................................................................................................10

Setting ........................................................................................................... 11

Maintenance ................................................................................................. 13

Hints and Tips................................................................................................ 13

Specications................................................................................................ 14

Main Unit...........................................................................................................................14

Mains Adapter .................................................................................................................14

Safety Warnings

Read all the instructions carefully before using the unit and keep them for

future reference.

Retain the manual. If you pass the unit onto a third party make sure to include

this manual.

Check that the voltage marked on the rating label matches your mains

voltage.

Damage

• Please inspect the unit for damage after unpacking.

• Do not continue to operate the unit if you are in any doubt about it

working normally, or if it is damaged in any way - switch o, unplug from

the mains socket and consult your dealer.

Location of Unit

• The unit must be placed on a at stable surface and not subjected to

vibrations.

• Do not place the unit on sloped or unstable surfaces as the unit may fall o

or tip over.

• The mains socket must be located near the unit and should be easily

accessible.

• This unit is designed for indoor use only.

Temperature

• Avoid extreme degrees of temperature, either hot or cold. Place the unit

well away from heat sources such as radiators or gas / electric res.

• Avoid exposure to direct sunlight and other sources of heat.

Naked Flames

• Never place any type of candle or naked ame on the top of or near the

unit.

Moisture

• To reduce the risk of re, electric shock or product damage, do not expose

this unit to rain, moisture, dripping or splashing. No objects lled with

liquids, such as vases, should be placed on the unit.

• If you spill any liquid into the unit, it can cause serious damage. Switch it

o at the mains immediately. Withdraw the mains plug and consult your

dealer.

Mains Adapter

Use mains adapter listed

in the user manual only.

• The mains adapter will continue to draw electricity from the mains supply

when plugged in the mains socket. In the interests of safety and to avoid

unnecessary energy consumption, never leave the adapter plugged in the

mains socket while unattended for long periods of time. Disconnect the

adapter from the power supply.

• Make sure the unit or unit stand is not resting on top of the mains adapter

cable, as the weight of the unit may damage the cable and create a safety

hazard.

Interference

• Do not place the unit on or near appliances which may cause

electromagnetic interference. If you do, it may adversely aect the working

performance of the unit, and cause a distorted sound.

• Supervision

• Children should be supervised to ensure that they do not play with the

unit.

• Never let anyone especially children push anything into the holes, slots or

any other openings in the case - this could result in a fatal electric shock.

Service

• To reduce the risk of electric shock, do not remove screws. The unit does

not contain any user-serviceable parts. Please leave all maintenance work

to qualied personnel.

• Do not open any xed covers as this may expose dangerous voltages.

Maintenance

• Ensure to unplug the unit from the power supply before cleaning.

• Do not use any type of abrasive pad or abrasive cleaning solutions as these

may damage the unit’s surface.

• Do not use liquids to clean the unit.

Note about LCD screen

• The LCD screen is manufactured using high-precision technology. However,

some tiny black points and/or bright points (red, blue or green in colour)

may constantly appear on the LCD screen. These points are generated in

the manufacturing process and are normal.

Thank youfor purchasing your new product.

We recommend that you spend some time reading this instruction

manual in order that you fully understand all the operational

features it oers. You will also nd some hints and tips to help you

resolve any issues.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose

of it please do so according to local regulations.

The following items are included:

If items are missing or damaged, please contact Partmaster (UK

only).

Tel: 0344 800 3456 for assistance.

Main Unit Mains Adapter

Instruction Manual

Instruction

Manual

1. LCD Display

2. SD / SDHC / MMC card slot

1. Button

• To access the menu.

• Return to previous screen.

2. Button

• Return to main menu.

• Switch the unit on/o.

3. Button

Start/pause/resume playback.

3. USB Port

4. DC IN socket

4. Buttons

• Navigate Left/Right on the

menu screen and adjust

certain settings.

Buttons

• Navigate Up/Down on the

menu screen and adjust

certain settings.

Product Overview

Front & Rear View

Top View

21 3 4

1 2

Preparations

Connecting to the Mains Power

1. Connect the supplied mains adapter to

the unit, and then plug into the mains

socket.

2. Press to switch the unit on.

3. Press and hold to switch the unit o.

Inserting a Memory Card / USB Device

This frame can only play images (JPEG).

If les in other formats are played,

please use your computer to convert

the images to a readable format.

MMC

• The unit can only play image (JPEG le format) in USB or CARD

operation. All other type le will not be shown.

• If your USB device or memory card is not loaded with images,

the format of your USB device or memory card might not be

compatible with the unit.

• This unit supports USB versions 1.1, 2.0 and 3.0.

• The unit can support USB devices and memory cards with up to

32GB of memory.

• The unit may not be compatible with all USB devices and

memory cards, this is not an indication of a problem with the

unit.

Selecting the Memory Device

The unit can only display one memory device’s contents at a time. If more

than one memory device is connected, select the desired memory device

to be displayed by pressing in the memory device screen.

When a memory device is inserted into the unit, it

will be automatically enter thumbnails screen.

• Press to enter the main menu.

• Press to select the desired memory device,

then press to conrm.

Viewing Photos

Viewing Thumbnails

In Photo screen, the photos on the selected memory device can be

displayed on the screen as thumbnails.

1. Press to select Photo on the main menu

and press to enter thumbnails screen.

2. The les / folders are displayed on the screen

as playlist.

3. To navigate through the thumbnails or

move to the next or previous page of the

thumbnails, press .

4. Press or to exit.

Photo Calendar Setting



62.5 KB

800 x 600

USB

1/4

Playing a Slideshow

In thumbnails screen, select a photo and then press to start a slideshow

from the current photo.

• To pause the slideshow and view a single photo, press . To resume the

slideshow, press again.

• Press to exit the slideshow and view the photos in thumbnails.

While in pause mode:

• To skip to previous or next photo, press .

• Press to return or press to exit to the main menu.

Calendar View

1. Press to select Calendar on the main

menu and press to conrm.

2. Display will show time / calendar with photo

slideshow.

3. Press to select next/previous month.

4. Press to select next/previous photo.

5. Press or to exit.

Photo Calendar Setting

Sun

June

34 5 6 7 8 9

10 11 12 13 14 15 16

17 18 19 20 21 22 23

24 25 26 27 38 29 30

Mon Tue Wed Thu Fri Sat
