Installation Instruction

Pressure Balanced Control

Please read the instructions completely before beginning the installation.

Pressure balanced control

Model Number: 4731SQ

Rev 11/2019

INSTALLATION INSTRUCTIONS

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

1/7

NOTE: Do not remove the plastic cover template until mounting the

trim.

- Determine where the finished wall will be. This

measurement is necessary to accurately plumb in the

valve.

- Install valve into the wall using min/max adjustment limits

on the plastic cover template. The backset measurement

from the center of the shower outlet to the outside of

finished wall is 3’’.

NOTE: It is critical to completely flush the lines of all dirt and debris

(metallic shavings, flux, etc.) prior to installing the pressure

balanced valve to the supply lines.

NOTE: When soldering connections do not use excessive heat as

this may cause damage to the cartridge or filter screens.

- Connect the HOT water supply to the left inlet of the valve

(RED) and COLD supply to the right inlet of the valve

(BLUE).

- Connect the outlet pipe to shower connections.

- Test for proper function before closing walls. Do this by

pressurizing both HOT and COLD lines.

Rough Installation

Pressure balanced control

Model Number: 4731SR

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

2/7

Shower Trim Installation

IMPORTANT: Do not turn control spindle. Accidentally turning the

control spindle will change the temperature setting, which is

pre-callibrated from the factory.

1 - Remove the plastic cover template.

2 - Loosen the two screws on the lock plate.

3 - Insert the stem key through the lock plate and onto the

broach of the valve.

4 - Retighten the screws on the lock plate.

5 - Completely screw in the proper end of the all thread into

the lock plate. The limited threaded end of the all thread is the

proper end which will screw into the lock plate.

6 - From the finished wall, measure the distance of 1” and

make a mark on the all thread.

7 - Remove the all thread from the lock plate and using a

hacksaw cut off the excess at the mark. Re-assemble the all

thread into the lock plate. Make a mark on the stem key 1/2”

from the end of the all thread. Remove the all thread and stem

key, cut the excess off the stem key, and then re-assemble to

the valve.

1 - Apply a ring of silicone caulking around the back of the

shower plate and slide plate over the all thread and stem key

until snug against the finish wall.

NOTE: Make sure that the horizontal axis of the shower plate is level.

2 - Make sure the valve is in the “off ” position by fully rotating

the stem key clockwise.

3 - To assemble the handle trim, place o-ring onto the all

thread shank then, make it flush to the plate. Screw the base

onto the all thread clockwise while keeping the lever in the 6

o’clock position (pointing straight down). Tighten to the shower

plate firmly.

Plate Cover

Sleeve

Bell

Set Screw

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

3/7

Santec Pressure Balanced Valve has a temperature limit stop. Below is the temperature stop set up:

1 - Remove all handle trim parts, including the trimplate.

2 - Remove all rough parts including the all thread, stem key and lock plate.

3 - Make sure the valve is fully turned clockwise. Install the mechanical stop with its left side

touching the stop.

4 - Install the limit stop over the mechanical stop as shown in. The limit stop should point

between the two S’s of the logo TEMPRESS. This is the manufacturers recommended

temperature limit. If the user desires a higher temperature than assemble the limit stop

counter-clockwise from the manufacturers recommended position.

5 - Reinstall the components of the valve and trim.

Temperature Stop Set Up

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

4/7

1 - Remove all handle trim parts, including the trimplate.

2 - Remove the all thread, stem key, lock plate, limit stop, and

mechanical stop.

3 - Remove the 4 screws holding the front valve plate to the

valve and remove the plate.

4 - Carefully pull out the valve cartridge from inside the valve.

5 - Use your fingernail to pry up the filter inserts on both sides of

the valve.

WARNING: Using a screwdriver or metallic object to remove the filter

inserts will scar the inside of the valve body which may lead to a water

leakage.

6 - All debris can now be easily removed from the filter screen by

running it under the water until clean.

7 - Replace the insert back into the valve body, making sure the

angled edge of the insert faces outward.

8 - Replace the cartridge back into the valve body, making sure

that the H is pointed toward the HOT inlet tube and C is facing

toward the COLD inlet tube. The H and C letters are stamped on

the side of the cartridge.

9 - Reverse the assembly steps 3, 2 and 1 above.

Filter Screen Removal & Cleaning

PARTS DRAWING

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

5/7

Pressure Balanced Shower Valve (PB-3600)

We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water

spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a

non-abrasive carnauba wax will add protection to the finish and should be used if the faucets will not be dried

after use. For clear coated finishes, it is recommended to clean your product weekly with a soft moist cloth.

WARNING: Do not clean your SANTEC product with ammonia (Window cleaner), bleach, soap, acids,

abrasives, harsh polish, harsh cleaners, a coarse surfaced cloth, coarse sponge, or any type of scouring pad.

Doing so may ruin your faucet finish and/or void the warranty.

Thank you for making SANTEC a part of your lifestyle and luxury spa experience. Our products have been

created as works of enduring quality and sophisticated design.

Luxurious finishes need proper care and attention, so in order to understand how to properly clean your

distinctive luxury finish, please refer to the finish care information below:

Your SANTEC product can be identified in one of two categories: clear coated finishes or non-clear coated

finishes. Clear coated finishes are more scratch-sensitive and are more reactant to harsh cleaning chemicals

than non-clear coated finishes. Once you have identified the specific luxury finish of your SANTEC product,

please follow the important corresponding care instructions.

We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water

spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a

non-abrasive carnauba wax is occasionally required and will add protection to the finish if the faucets will not

be dried after use.

FINISH CARE INFORMATION

CLEAR COATED FINISHES

NON-CLEAR COATED FINISHES

TO OBTAIN WARRANTY SERVICE

Please read ‘WHAT IS COVERED BY OUR WARRANTY’ and ‘EXCLUSIONS AND LIMITATIONS OF

WARRANTY’ sections to understand what is and what is not covered. Please have ready the proof of

purchase (original sales receipt), description of the problem, and carefully package the product or defective

part with postage prepaid. Then, please contact your local SANTEC Showroom or write to SANTEC Technical

Services.

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

6/7

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

LIFETIME LIMITED WARRANTY

SANTEC is committed to enhancing your bathroom experience by creating luxury products that will provide

enduring satisfaction. Every effort has been made to satisfy the highest standards of design and production,

to create lasting peace of mind for our customers. We provide the following limited warranties on our products:

LENGTH OF WARRANTY & WHO IS COVERED BY OUR WARRANTY

This warranty extends to the original consumer purchaser only and extends for as long as the original

purchaser owns the product and the home in which the product is installed.

WHAT IS COVERED BY OUR WARRANTY

FINISHES: SANTEC Polished Chrome, Polished Nickel and Satin Nickel finishes carry a Lifetime Limited

warranty against manufacturing defects and tarnish to the original purchaser. All other finishes carry a ten

(10) year limited warranty against manufacturing defects and tarnish to the original puchaser only.

CARTRIDGES: Santec cartridges carry a lifetime limited warranty, with the exception of thermostatic and

pressure balanced cartridges, which carry a three (3) year limited warranty against manufacturing defects

to the original purchaser.

PARTS: Santec parts carry a 10-year limited warranty against manufacturing defects, to the original

purchaser.

EXCLUSIONS & LIMITATIONS OF WARRANTY

Damage due to negligence, accident, abuse, improper installation, or improper maintenance such as, but

not limited to: heat from soldering during installation, the use of plumber’s putty, damage from tools used

during installation, the use or exposure to chemicals or cleaning products either abrasive or non-abrasive,

or the use of any cleaning tool or product other than a soft, clean cloth. Reverse osmosis may also shorten

the life of the finish.

Changes in the finish or in the product due to normal wear or aging does not cover any products or parts

which have been altered or used in a manner not typical for the product.

Loss, damages, or expense, incidental or consequential whatsoever, originating from the purchase,

installation, use, repair, failure, or replacement of any SANTEC product or part, allowed by law.

This warranty does not cover:

Commercial and/or Industrial installations and use of the product.

This warranty does not include labor, travel charges, or any costs incurred for repair, removal, installation,

servicing, diagnosing, or handling of either defective or replacement parts.

SANTEC reserves the product components of the covered product will be repaired, refinished, or replaced

at the sole discretion of SANTEC. SANTEC reserves the right to examine any product claimed defective prior

to any warranty claim being accepted or processed, at its sole discretion. This warranty gives you specific

legal rights and you may have other rights which may vary from state to state.

Damage or deterioration caused by environmental impacts.

The measurements shown are for reference only. Products and specifications shown are subject to change without notice.

www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681

7/7
