STARFISH WIFI SMART 6' INDOOR STRIP,

OPTIONAL 3' EXTENSION

Model: S11263, S11264

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

WARNING: Risk of Fire or Electric Shock

• This strip lighting is only intended to be used with the products provided in the kit,

or the S11264 extension strips.

• This product consumes a total of 20W (.167A) and is rated to control up to 8

additional S11264 extension strips. Each extension strip consumes 8.8W (.075A).

• Installation requires knowledge of luminaries electrical systems. If not qualied, do

not attempt installation. Contact a qualied electrician.

• To reduce risk of re and over-heating, secure all connections.

• TURN OFF the electrical power before proceeding.

• The electrical rating of this product is 120V/60Hz.

• The grounding and banding of the overall system shall be done in accordance with

National Electric Code (NEC) Article 600 and local codes.

• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet

metal or other sharp objects.

• Do not make or alter any open holes in an enclosure of wiring or electrical

components during kit installation.

• This device is not intended for use with emergency exits.

NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful interference; (2)

This device must accept any interference received, including interference that may

cause undesired operation. Visit www.Satco.com for

full warranty details and dimmer compatibility information.

Satco Products, Inc.

Brent wood, NY 11717© Copyright 2020 Satco Products, Inc. 10/20

Download the

STARFISH App

INSTALLATION

Before installation, select a location where you want to

install, measure the required length of strip light, and mark

it. Conrm that the adapter power cord will reach the

desired power outlet and the LED strip light. Clean the

mounting surface and keep it dry. It is important that the

surface is smooth and clean for proper adhesion.

STEP 1: Turn power OFF before

installing xture.

STEP 3: Connect the strip light to

another one (if you want extensions),

ensure that the polarity symbols

are aligned.

NOTE: Strip light can be

extended up to 10M.

STEP 4: Remove the paper liner

from the back of the strip light

and press against of the mounting

surface. Ensure minimal hand

contact to the adhesive.

DO NOT reposition strip light

once it is mounted.

STEP 6: Plug strip light into the nearest outlet.

Installation is complete. Turn power ON.

STEP 8: App Connection: To connect your device, download the free

“Starsh Smart Lighting” App from the app store. Please refer to our

Starsh User Guide for detailed instructions on how to pair your device.

STEP 5: If there is an LED chip in a corner

when placing the strip light, ensure the

angle of the bend is greater than 90

degrees to avoid damaging the LED chip.

STEP 2: Adjust strip light length.

It should only be cut in the

designated locations.

STEP 7: Connect the strip light to the

controller, ensure that the polarity symbols are

aligned. Connect power adapter to controller.

Via the control button on the driver, toggle

through the functions:

• Warm White – ON

• Cool White – ON

• Warm and Cool White – ON

• RGB – ON

• OFF

• Press and hold on for 5 seconds to connect APP
