SATO CX400 Bedienungsanleitung

PN: 9001124A

CX400

DESKTOP PRINTER

PARTS LIST

Warning: This equipment complies with the requirements in Part 15 of FCC rules for a Class A

computing device. Operation of this equipment in a residential area may cause unacceptable

interference to radio and television reception requiring the operator to take whatever steps nec-

essary to correct the interference.

in any form without the express permission of SATO America, Inc. The material in this document

is provided for general information only and is subject to change without notice. SATO America,

Inc. does not assume responsibility for any errors or omissions.

06 Nov 03

SATO GROUP OF COMPANIES

BARCODE SATO

INTERNATIONAL PTE LTD

438A Alexandra Road #05-01/ 02,

Alexandra Technopark,

Singapore 119967

Tel: 65-6271-2122

Fax: 65-6271-2151

Website: www.barcodesato.com

Email: [email protected]

SATO AMERICA INC.

10350 Nations Ford Road Suite A,

Charlotte, NC 28273

Tel: 1-704-644-1650

Fax: 1-704-644-1662

Website: www.satoamerica.com

Email: [email protected]

SATO UK LTD

Valley Road, Harwich, Essex England

Co12 4RR, United Kingdom

Tel: 44-1255-240000

Fax: 44-1255-240111

Website: www.satouk.com

Email: enquiries@satouk.com

SATO EUROPE NV

Leuvensesteenweg 369, 1932 Sint- Stevens-Woluwe, Brussels, Belgium

Tel: 32 (0)-2-788-80-00

Fax: 32 (0)-2-788-80-80

Website: www.sato-europe.com

Email: [email protected]

SATO DEUTSCHLAND GMBH

Schaberweg 28, 61348

Bad Homburg, Germany

Tel: 49 (0)-6-1726-8180

Fax: 49 (0)-6-1726-818-199

Website: www.sato-europe.com

Email: [email protected]

SATO POLSKA SP Z O.O.

Ul Okolna 2, 50-422 Wroclaw

Tel: 48-71-335-23-20

Fax: 48-71-335-23-25

Website: www.sato-europe.com

Email: [email protected]

SATO SHANGHAI CO, LTD

11 Floor, D, Pudong South Road 1111,

Pudong New Area, Shanghai,

China 200120

Tel: 86 (0)-21-58307080

Fax: 86 (0)-21-58307978

Website: www.barcodesato.com

Email: [email protected]

BAR CODE SATO ELECTRONICS (S) PTE LTD

438A Alexandra Road #05-01/02,

Alexandra Technopark, Singapore 119967

Tel: 65-6271-5300

Fax: 65-6273-6011

Website: www.barcodesato.com

www.satosingapore.com

Email: sales@satosingapore.com

SATO BAR CODE & LABELLING

SDN BHD

Suite B-08-11&12, Block B Plaza Mont' Kiara, No.2, Jalan Kiara Mont'

Kiara,

50480 Kuala Lumpur, Malaysia

Tel: 60-3-6203-5950

Fax: 60-3-6203-1209

Website: www.barcodesato.com

Email: [email protected]

BARCODE SATO (THAILAND) CO., LTD

370/8 Supattra Building, 5th Floor, Rama9 Road, Bangkapi, Huay Kwang

Bangkok 10320, Thailand

Tel: 662-719-7780-3

Fax: 662-719-7784

Website: www.barcodesato.com

Email: sales@satothailand.co.th

SATO CX400 Parts List PN 9001124A Page 1

Printer Assembly, PL1

C54

15 C

910

Page 2 PN 9001124A SATO CX400 Parts List

Chassis Assembly, PL2

Base and Options Assemblies, PL3

37 K

J33

62 64

B66

59 42

27 26

46 60

50 42

83 Optional 40

75 Optional 80

SATO CX400 Parts List PN 9001124A Page 3

Housing Assembly, PL4

Page 4 PN 9001124A SATO CX400 Parts List

Item Part Number Part Description Qty

1 14SC00150 THUMBWHEEL 1

2 14SC00151 CLAMP, L2 2

3 14SC00152 WASHER 2

4 14SC00153 CLAMP SPRING 2

6 14SC00155 PRINT ASSEMBLY BRACKET 1

7 14SC00156 PRINT ASSEMBLY BUTTON 2

8 14SC00157 SHAFT, RIB2 2

9 14SC00158 WASHER, RIB 2

10 14SC00159 BUSH, RIB2 2

11 14SC00160 CHASSIS LOCK, LEFT 1

12 14SC00161 PRINT HEAD COVER 1

13 14SC00162 PRINT HEAD BRACKET 1

14 YCX405706 RIBBON SENSOR 1

15 YCX405701 THERMAL PRINT HEAD 1

16 14SC00163 CHASSIS SHAFT 1

17 14SC00164 ARM SPRING 1

18 14SC00165 RIB, ARM 1

19 14SC00166 PAPER GUIDE, LEFT 1

21 14SC00167 FILM GUIDE 1

20 YC3005762 LED 1

22 14SC00168 PAPER GUIDE, RIGHT 1

23 14SC00169 CONNECTOR BRACKET 1

24 14SC00170 SPACER, SUPPORT 2

25 YCX405703 EXTERNAL CONNECTOR BOARD 1

26 14SC00172 ROLLER BUSHING 3

27 YCX405708 PLATEN ROLLER, METAL/RUBBER 1

28 14SC00173 PEELER BAR 1

29 14SC00174 CABLE CLAMP 1

30 YC3005760 CHASSIS 1

31 14SC00175 PEELER SHAFT 2

32 14SC00176 GUIDE, LEFT 1

33 YCX405705 PAPER SENSOR 1

34 14SC00177 GUIDE, TOP BRACKET 1

35 14SC00178 GUIDE RACK, LEFT 1

36 14SC00179 GUIDE RACK, RIGHT 1

37 14SC00180 GEAR, MO. 5x27T 1

38 14SC00181 GUIDE, BOTTOM 1

39 YC3005757 BASE 1

40 14SC00182 RUBBER BOOT 4

42 14SC00184 GEAR, MO. 5x28T 4

43 14SC00185 SHAFT, RIB3 1

SATO CX400 Parts List PN 9001124A Page 5

44 14SC00186 CLAMP, LEFT 1

45 14SC00187 GEAR, ONE WAY, LEFT 1

46 14SC00188 WASHER, DIFF. 2

47 14SC00189 SHAFT, RIB1 1

48 14SC00190 CHASSIS LOCK, RIGHT 1

49 14SC00191 LOCK SPRING, RIGHT 1

50 14SC00192 BUSHING, DIFFERENTIAL 4

51 14SC00193 GEAR, MO. 5x54T 1

52 14SC00194 SPRING, THERMAL PRINT HEAD 1

53 14SC00195 HINGE PIN 2

54 14SC00196 LOCK SPRING, RIGHT 1

55 14SC00197 PIN, TOP DIFFERENTIAL 1

56 14SC00198 PIN, LOWER DIFFERENTIAL 1

57 14SC00199 SPRING, DIFFERENTIAL 1

58 14SC00200 SPRING HOLDER 2

59 YC3005761 UNWOVEN FABRIC 4

60 14SC00201 HOLDER, PUSH 2

61 14SC00202 SPRING, DIFFERENTIAL 1

62 14SC00203 GEAR 2

63 14SC00204 GEAR, ONE WAY, RIGHT 1

64 14SC00205 HOLDER, D 1

65 14SC00206 SPRING, RIB2 3

66 14SC00207 PLATEN SWITCH 1

67 14SC00208 GEAR, MO. 5x42T 1

68 14SC00209 GEAR, MO.5 17x44T 1

69 14SC00210 MOTOR BRACKET 1

70 YCX405707 MOTOR 1

75 YCX405200 DISPENSER ASSEMBLY (OPTIONAL) 1

77 14SC00211 COVER HINGE 1

79 14SC00212 HARNESS COVER 1

80 YCX405702 MAIN CIRCUIT BOARD, CX400 1

83 YCX405100 CUTTER ASSEMBLY (OPTIONAL) 1

84 14SC00213 FACE COVER 1

85 14SC00214 SWITCH, 2-POSITION 1

86 YCX405704 PANEL BOARD, CX400 1

87 14SC00215 FEED BUTTON 1

88 14SC00216 TRACK GEAR, PAPER 2

89 14SC00217 GEAR, MO. 5x20T 1

90 14SC00218 PAPER TRACK COVER 1

91 YC3005756 HOUSING COVER w/ WINDOW 1

93 14SC00219 PAPER HOLDER, LEFT 1

94 14SC00220 PAPER HOLDER, RIGHT 1

Item Part Number Part Description Qty

Page 6 PN 9001124A SATO CX400 Parts List

95 14SC00221 PAPER HOLDER LOCK 1

96 YC3005759 HOUSING 1

97 14SC00240 PRINT HEAD GUIDE 1

98 14SC00222 ROLLER BUSHING 2 1

A 14SC00223 SCREW, M13x6, PHILLIPS, BLACK 4

B 14SC00224 SCREW, T3x6, PHILLIPS, BLACK 26

C 14SC00225 SCREW, M3x4, PHILLIPS, BLACK 5

D 14SC00226 SCREW, T3x6, PHILLIPS, WASHERED, ZINC 2

E 14SC00227 SCREW, T3x8, PHILLIPS, BLACK 6

F 14SC00228 SCREW, T3x4, PHILLIPS, ZINC 3

G 14SC00229 SCREW, M2.6x6, PHILLIPS, ZINC 8

H 14SC00230 SCREW, T2.6x6, PHILLIPS, NICKEL 9

I 14SC00231 SCREW, T3x10, PHILLIPS, NICKEL 2

J 14SC00232 SCREW, T1.7x4, PHILLIPS, NICKEL 3

K 14SC00233 SCREW, T1.4x2, PHILLIPS 2

L 14SC00234 SCREW, M3x6, PHILLIPS, BLACK 4

M 14SC00235 SCREW, M3x4, PHILLIPS, NICKEL 2

N 14SC00236 SCREW, M2x2, PHILLIPS, NICKEL 2

O 14SC00241 SCREW, M2x3, PHILLIPS, BLACK 3

X 14SC00237 SNAP RING 7

Y 14SC00238 SNAP RING 7

Z 14SC00239 SNAP RING 2

Item Part Number Part Description Qty
