Satson IR-EXT-050C Bedienungsanleitung

IR-EXT-050C

IR over CAT5 Extender

User Manual

Made in Taiwan

Safety and Notice

The IR-EXT-050C IR over CAT5 Extender has been tested for conformance to safety regulations and

requirements, and has been certified for international use. However, like all electronic equipments, the

IR-EXT-050C should be used with care. Please read and follow the safety instructions to protect yourself from

possible injury and to minimize the risk of damage to the unit.

zFollow all instructions and warnings marked on this unit.

zDo not attempt to service this unit yourself, except where explained in this manual.

zProvide proper ventilation and air circulation and do not use near water.

zKeep objects that might damage the device and assure that the placement of this unit is on a stable surface.

zUse only the power adapter and power cords and connection cables designed for this unit.

zDo not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

The IR-EXT-050C IR over CAT5 Extender boosts up your IR control distance at least 100m (330ft). With

single cost effective CAT-5 cable, users can readily extend and duplicate IR access to IR controllable devices such

as Blue-ray disc players and TV to increase application flexibility. Typical applications include digital signage,

education and demonstration system, and home theater. IR-EXT-050C includes two units: transmitting

(IR-EXT-050C [Tx]) and receiving (IR-EXT-050C [Rx]) units.

Features

zSupport full bandwidth of IR signal, 20KHz ~ 60KHz

zBuilt-in IR splitter on TX and RX unit

zBi-directional IR path

zSuper long extension distance

zSingle power supply on either TX or RX unit

zEasy to install

zWall mounting housing design for easy and robust installation

The length depends on the characteristics and quality of the cables. Higher resolutions and longer

transmission distances require low skew cables (<25ns/100m) for best performance. Unshielded CAT6

with metal RJ-45 connectors is recommended.

ntroduction

Specifications & Package Contents

Model Name

R-

XT-050C

Technical

XRX

Role of usage Transmitter and Splitter

eceiver and Splitter

IR bandwidth 20 ~ 60 KHz

ESD protection Human body model

—

±19kV [air-gap discharge]

& ±12kV [contact discharge]

Input 1x 3.5mm 1x RJ-45 + 1 x 3.5mm

Output 1x RJ-45 + 2x 3.5mm 2 x 3.5mm

RJ-45 connector WE/SS 8P8C with 2 LED indicators

3.5mm connector Earphone jack for IR

ransmitter or Receiver cable

IR remote control Electro-optical characteristics: τ= 25°

Carrier frequency: 20-60kHz

Mechanical

Housing Metal enclosure

Dimensions

(L x W x H)

Model [TX/RX] 75 x 55 x 25mm [3.0”x2.2”x1”]

Package 270 x 175 x 80mm [10.6” x 6.9” x 3.1”]

Carton 450 x 370 x 300mm [1’6” x 1’3” x 1’]

Weight Model 270g [9.5oz]

Package 670g [1.5 lbs]

Fixedness Wall-mounting case with screws upon request

Power supply

nter-locked 5V 2A DC

Power consumption 1 Watts [max]

Operation temperature 0~40°C [32~104°F]

Storage temperature -20~60°C [-4~140°F]

Relative humidity 20~90% RH [no condensation]

Package Contents

R-

XT-050C

1x User Manual

1x 5V 2A interlocked wall wart power adapter

In fact, there is no diffference between TX and RX. Therefore customer can take any as TX or RX without

any limitation.

IR-EXT-050C-TX/RX Front Panel

1. IR receiver: Connect to a IR receiver cable

2. IR local output1: Connect to a IR transmitter cable

3. IR local output2: Connect to a IR transmitter cable

4. +5V power input: Connect to the +5V power adaptor

IR-EXT-050C-TX/RX Rear Panel

5. RJ-45 output: Plug in a CAT-5/5e/6 cable that needs to be linked to the RJ-45 connector of another unit.

1. Connect the IR receiver cables to both TX and RX units.

2. Connect the IR transmitter cables to both TX and RX units.

3. Connect one Cat-5/5e/6 cable between TX and RX unit.

4. Make sure your Cat-5/5e/6 cables are tightly connected and not loose.

5. Plug the +5V power supply to the power jack on either TX or RX unit.

Hardware Installation

Panel Descriptions

IR Extenders

IRBlaster IRReceiver

IR Sockets

IR Blaster: Plug in the IR blaster here to emit all IR command signals received from the IR receiver to control the

source devices.

IR Receiver: Plug in the IR receiver here to receive all IR command signals from the IR remote controls of the

source devices.

CAUTION!

Wrongly insert IR blaster and IR receiver to wrong 3.5mm infrared sockets may result in the failure of

the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets.

Definition of IR Earphone Jack

IR Blaster IRReceiver

You can buy any IR extension cables in the market that are compatible to the definition of the IR sockets for

the matrix if necessary for replacement use. However, IR cables longer than 2m (6-ft) may not work.

R Pass-through

1. The transmission length is largely affected by the type of Cat-5/5e/6 cables. The testing result shows solid

UTP cables (usually in bulk cable 300m/1000ft form) can transmit a lot longer signals than stranded UTP

cables (usually in patch cord form). Shielded STP cables are better suited than unshielded UTP cables. A solid

UTP Cat-5e cable shows longer transmission range than stranded STP Cat-6 cable. For long extension

applications, solid UTP/STP cables are the only viable choice.

2. EIA/TIA-568-B termination (T568B) for LAN cables is recommended for better performance.

3. To reduce the interference among the unshielded twisted pairs of wires in Cat-5/5e/6 cable, one can use

shielded STP cables to improve EMI problems, which is worsen in long transmission.

4. Because the quality of the Cat-5/5e/6 cables has the major effect on how long the transmission limit can

achieve and how good is the received picture quality, the actual transmission range is subject to one’s choice

of Cat-5/5e/6 cables.

Performance Guide for HDMI over CAT5/6 Cable Transmission

Performance rating Type of CAT5/6 cable

Wiring Shielding CAT5 CAT5e CAT6

Solid Unshielded (UTP)   

Shielded (STP)   

Stranded Unshielded (UTP)  

Shielded (STP) 

Termination Please use EIA/TIA-568-B termination (T568B) at any time

Notice
