Schaefer Versa Mist PVM18 Bedienungsanleitung

Se f-Contained Power Mister

USER'S MANUAL

WARNING

IM ORTANT SAFETY INFORMATION INSIDE

VM18

• Read, understand and follow all safety information

and instructions in this manual before using or

servicing this product.

• Serious injury or death is possible.

• Retain these instructions for future reference.

VM18C

S ECIFICATIONS ......................................................................................................................2, 3

SET-U / O ERATION ..............................................................................................................4, 5

MAINTENANCE ............................................................................................................................6

RE LACEMENT ARTS................................................................................................................6

WARRANTY ..................................................................................................................................7

Index

Thank You!

Thank you for selecting our self-contained power misting equipment for your comfort conditioning needs. These products

have been engineered with the most reliable components and materials available, are are equipped with features to assure

ease of mobility, use and maintenance.

The cool air you will now enjoy when using this misting equipment is created through the process of evaporation. Heat is

required to change water from a liquid to a gas or "water vapor". Our self-contained power misting equipment creates a

"fog" by pumping water at a very low flow rate through small nozzles. When combined with the air added by a fan, this

fog is rapidly evaporated. The heat required to evaporate the fog is extracted from the air causing a reduced air temperature.

This cooler air is then distributed to people or animals creating a direct cooling effect.

The performance of your misting system can be affected by local conditions. For best results, it may be necessary to

experiment with the number of nozzles operating to achieve the cooling performance you desire.

Thank you again and stay cool!

Specifications

Our self-contained power misting equipment is configured into three separate models:

• One 18" fan head and pump assembly PVM18 C

• One 18" fan head, pump assembly and 10 gallon tank PVM18

• One 18" fan head, pump assembly and 14 gallon tank PVM18C

with integrated wheels and handle

FAN S ECIFICATIONS

Voltage (VAC) 120

Frequency (Hz) 60

Amps 1.45

HP 168 watts

Speeds 3

ALL MODELS

Voltage (VAC) 120

Frequency (Hz) 60

Total amps 2.15

Pump output 1 GPM

Mist hub 4 nozzles installed

Water supply POTAB E ON Y

Specifications (continued)

VM18LC

• One 18" fan head with powder-coated guard

mounted on a yoke attached to the pump enclosure.

• An integral ground fault circuit interruptor (GFCI) is

attached to the power cord.

• Equipped with a power cutoff tip switch.

• Includes one extra nozzle and two plugs.

• Shipped in a single carton, ready to assemble on your

existing 10 gallon Igloo cooler.

VM18

• One 18" fan head with powder-coated guard

mounted on a yoke attached to the pump enclosure.

• An integral ground fault circuit interruptor (GFCI) is

attached to the power cord.

• Equipped with a power cutoff tip switch.

• Includes one extra nozzle and two plugs.

• A 10 gallon tank is included for use as water reservoir.

• Shipped in two cartons, ready to assemble.

VM18C

• One 18" fan head with powder-coated guard

mounted on a yoke attached to the pump enclosure.

• An integral ground fault circuit interruptor (GFCI) is

attached to the power cord.

• Equipped with a power cutoff tip switch.

• Includes one extra nozzle and two plugs.

• A 14 gallon tank is included for use as water reservoir.

• The tank includes an integrated handle and 6" wheels.

• Shipped in two cartons, ready to assemble.

Set-Up / Operation

1. Always operate the power mister on a level surface. In the

event the unit is tipped over or tilted more than 35 degrees, a

built-in tip switch will shut off power to the pump and fan.

Power will be restored when unit is returned to the upright

position.

2. Fill cooler or tank with clean, fresh water (ice may be added)

each time the mister is used. Drain remaining water after

each use.

3. Aim the mister downwind for best results. If more than one

mister is used, arrange them in an arc around the area to be

misted.

4. To energize, plug the GFCI safety plug into any 120 VAC

60 Hz grounded outlet. Test GFCI per instructions below.

Turn the mister on using the toggle switch located on the top

of the pump enclosure. Place the switch in the FAN position

for air movement only, or FAN/MIST for air and mist.

5. Use the pull chain located on the back of the fan to choose

fan speed (OFF, OW, MEDIUM, HIGH). If fan does not

operate when rocker switch is in the FAN or FAN/MIST

position, the pull chain may be OFF.

6. The mist hub located in the center of the fan is equipped with

four nozzles. The output volume of water vapor can be reduced

by replacing one or two of the nozzles with the plugs provided.

7. The unit will mist for approximately five hours on 10 gallons

of water.

GFCI TEST

The ground fault circuit interruptor (GFCI) mentioned above

provides protection from electric shock by examining the product's

electrical circuit for current leakage. It must be tested before each

use to assure safe operation. Follow these steps:

1. Plug into outlet - the indicator will show if power is available.

2. Press the TEST button - indicator will turn off.

3. Press the RESET button. Use product only if GFCI resets.

** DO NOT USE IF TEST FAILS. **

WARNING

ELECTRICAL SHOCK

HAZARD

INCH HAZARD

TRI HAZARD

• Serious injury or death is possible.

• Plug these units into properly

grounded receptacles only.

• Disconnect from electric supply

before filling, servicing, or

moving this equipment.

• Test GFCI before using. See

instructions at left.

• Do not carry the unit by the motor,

electric cords, hose line, fan guard

or bracket.

• Do not touch fan motor during use

or directly after; it may be hot.

• Do not operate fan without

guards in place.

• Do not insert anything into fan

guard while fan is operating.

• Unplug unit and dry any wet areas

before resetting a unit that has

tipped over.

• Position all electric cords to lie

flat on the ground or floor.

• Never use during rain, sleet, hail,

snow or any other inclement

weather conditions.

TEST

Fan

RESET

OFF

Fan &

Mist

ull chain

Nozzle (spare)

lugs

Set-Up / Operation (continued)

To prepare for operation:

1. Remove all items from cartons, remove packing

material and place on a level surface. The fan is

mounted on the bracket and the pump assembly is

contained in the lid, so please remove carefully.

2. Place empty cooler/tank in approximate location to be

misted. Carrying a full cooler/tank will be difficult as

it will weigh approximately 80 pounds.and is likely to

spill out if tank is tilted back. This can also make the

unit unstable and hazardous to move.

3. Fill cooler/tank with water (and ice, if desired).

DO NOT FILL ABOVE HANDLE RECESS!

4. Place the fan/pump enclosure on the cooler/tank. Be

sure the intake line and filter are in the bottom of

the cooler/tank.

5. Twist the fan/pump enclosure to engage slots in tank.

* Model PVM18 C does not include a tank. Since the

pump enclosure is specifically made to fit a 10 gallon Igloo

cooler, it must be used only with this type of cooler,

supplied by the user. DO NOT USE THE PVM18LC

WITH ANY OTHER WATER RESERVOIR!

WARNING

TI HAZARD

• Serious injury is possible.

• Support weight of fan with free hand when moving

tank with wheels.

• Do not fill tank before moving.

• Never operate pump without water supply.

• If leaks are observed, turn pump off and tighten fittings by hand.

• Excessively hard water (high solids) can plug nozzles.

• A plugged filter caused by poor water quality can restrict flow to pump and cause permanent damage.

• Never allow "fog" from the nozzles to come in contact with surfaces. This can cause condensation and water will form

on those surfaces; redirect the fan to prevent this circumstance.

CAUTION

Intake line

(filter lays in

bottom of tank)

Maintenance

WARNING

ELECTRICAL SHOCK

HAZARD

• Serious injury or death is possible.

• Disconnect from electrical supply

before performing any maintenance

operations.

NOZZLES

The fog or spray pattern exiting from the nozzles should

have an even cone shape. If this is not the case, the nozzle

should be cleaned or replaced. Nozzle function should be

checked regularly to assure best misting and evaporation

performance.

To clean or replace a nozzle:

1. Disconnect the unit from electrical supply.

2. Unscrew and remove the nozzle.

3. Soak in vinegar, rinse in water OR replace with new

nozzle.

4. Flush the water line to the mist hub before replacing

nozzle.

5. Screw the nozzle into the mist hub by hand.

NO TOOLS SHOULD BE USED TO TIGHTEN

THE NOZZLE.

FILTER

Filter maintenance requirements will vary with changing

water conditions. The filter should be inspected frequently

and changed as needed. A dirty filter will restrict water

flow to the pump and can cause permanent damage.

SYSTEM DRAIN / STORAGE

When it is time to store the VersaMist® or take it out of

use for more than a few days, it is strongly recommended

that the water be drained from the system to prevent

calcification problems and the formation of algae. Be sure

to empty the cooler or tank and allow it to air dry.

Clean the unit with a mild anti-bacterial solution regularly.

Rep acement Parts

RE LACEMENT ARTS

P/N DESCRIPTION

TG18-3WX 18" circulation fan

MK-BRASSP UG Misting plug

BN12 Brass replacement nozzle 0.012

TS3P Three-position toggle switch

PVM-PUMP Shurflo pump

PVM-TIPSWITCH Tip switch

PVM18-KNOB Knob, metric

MISTHUB2 Mist disk

C2500GFCI 25 ft power cord with GFCI

0WHEE 6X134R Rubber wheel, 6" x 1-3/4" (for mobile tank)

All information, illustrations and specifications provided here are based on the latest product information

available at the time of printing. Product specifications subject to change.

Warranty

Schaefer Ventilation Equipment, LLC

Schaefer Limited Warranty olicy

Schaefer Ventilation Equipment, LLC (SVE) provides the following limited warranty from the date of invoice to

the initial purchaser of our products or to its customer with a dated proof of purchase:

I. Two-year coverage (unless otherwise indicated below) applies to all products, components and

assemblies provided by SVE that prove to be defective in material or workmanship. Any such defective

product will be repaired or replaced at SVE’s option, with the defective product or component returned,

upon approval, to SVE, F.O.B Sauk apids, Minnesota.

II. This warranty does not cover:

a. Failure, damage or malfunction as a result of:

i. Improper installation or installation not in accordance with installation instructions.

ii. Operating conditions that vary from SVE’s operating instructions.

iii. Misuse, abuse, negligence, alteration, or accident.

iv. Transporting the product.

v. Improper operation or lack of appropriate or regular maintenance of the product.

b. Loss of time, inconvenience, loss of use of the product or other consequential or incidental damages.

c. Parts that need replacement due to normal wear and tear.

d. Superficial or cosmetic rust or corrosion.

e. Any product whose name plate has been removed.

Products with warranty periods that differ from the standard 2-year warranty are as follows:

• Poly Housings 25 years

• Fiberglass Housings 15 years

• Low-intensity Tube Heater Exchange Tubes 5 years

• Heavy-Duty Industrial Wash-Down Fans (with VWD motors) 3 years

• K-Series, 2-Stage, Compact and Stainless Steel Tube Heaters 1 year

• Quartz and Zubri Heaters 1 year

• Big Dog™ Fans 1 year

• Shutter Motors and Aluminum iveted Fan Blades 1 year

• Epoxy Line Wash down fans (with EWD motors) 1 year

• Evaporative Cooling Pads 180 days

• HotZone® Electric Elements 120 days

• Quartz Bulbs 90 days

• Tuff & Gusty Fans 90 days

• Any product or part as noted as an exception to the standard

2-year warranty in the product’s operating manual.

SVE reserves the right to add or delete products from this exception list at any time.

THE E A E NO WA ANTIES OF ME CHANTABILITY O FITNESS OF USE.

SVE reserves the right to change product design and specification without prior notice or liability.

The above constitutes the sole warranty offered by Schaefer Ventilation Equipment, LLC.

Effective March 1, 2010.

800-779-3267

www.schaeferfan.com

2-11-11 / M-VMISTBLUE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Schaefer Luftbefeuchter Handbücher

Schaefer

Schaefer VersaMist PVM18 Series Bedienungsanleitung

Beliebte Luftbefeuchter Handbücher anderer Marken

Boneco

Boneco H300 Bedienungsanleitung

Bionaire

Bionaire CM1 Handbuch

Air-O-Swiss

Air-O-Swiss AOS 7131 Handbuch

KING

KING K 5002 Rainbow Bedienungsanleitung

Crane

Crane EE-6902 Bedienungsanleitung

Glaziar

Glaziar Ness Bedienungsanleitung

Philips

Philips DreamStation Go Abmessungen

Honeywell

Honeywell MISTMATE HUL520BC Bedienungsanleitung

Stadler Form

Stadler Form Hera Bedienungsanleitung

Hunter

Hunter 31206 Bedienungsanleitung

TaoTronics

TaoTronics TT-AH004 Bedienungsanleitung

adorini

adorini Cigar Heaven Bedienungsanleitung

Lanaform

Lanaform Aroma Bedienungsanleitung

Aprilaire

Aprilaire 800 Series Bedienungsanleitung

Pyle

Pyle SereneLife PHUMDIF8 Bedienungsanleitung

Trotec

Trotec B 200 Bedienungsanleitung

Pure Humidifier

Pure Humidifier EC Series Bedienungsanleitung

Crane

Crane EE-864 Bedienungsanleitung
