SCIWIL EN05-LCD Bedienungsanleitung

Changzhou Sciwil E-Mobility Techno

logy Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-

85600675

USERS GUIDE

EN05-LCD

Changzhou Sciwil E-Mobility Techno

logy Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-

85600675

Contents

Introduction .................................................................................................................................................. 1

1. Safety Notes ............................................................................................................................................ 2

2. Assembly .................................................................................................................................................. 2

3. Product Size .......................................................................................................................................... 3

4. Working Voltage and Connection ................................................................................................ 3

4.1 Working Voltage ........................................................................................................................ 4

4.2 Connection ................................................................................................................................... 4

5. Functions and Key Pad ...................................................................................................................... 4

5.1 Functions ....................................................................................................................................... 4

5.2 Control and Setting Items.......................................................................................................... 5

5.3 Display Area .................................................................................................................................. 5

5.4 Settings ........................................................................................................................................... 6

5.5 Communications Protocol ........................................................................................................ 7

5.6 Key Pad ............................................................................................................................................. 7

5.7 Error Code ...................................................................................................................................... 10

5.8 Serial Code ..................................................................................................................................... 10

6. Quality and Warranty .......................................................................................................................... 11

7. Version....................................................................................................................................................... 12

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

Introduction

Congratulations on purchasing your e-bike smart display. Before use, please read

through this manual. It is important to acknowledge all the

WARNINGS, SAFETY

NOTES AND INSTRUCTIONS

. This manual will walk you through assembly, settings

and operations of Sciwil display products in easy steps, to facilitate operations on

your e-bike.

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

1. Safety Notes

PLEASE TAKE CAUTION WHEN USE，DO NOT PLUG OR UNPLUG THE DISPLAY WHILE

YOUR E-BIKE IS POWERED ON.

AVOID CLASHES OR BUMPS TO THE DISPLAY.

DO NOT TEAR THE WATER-PROOF FILM ON THE SURFACE OF THE SCREEN,

OTHERWISE THE WATER-TIGHT PERFORMANCE OF THE PRODUCT MAY BE

DEGRADED.

DISPLAY WATER-PROOF RATE: IP6

UNAUTHORIZED ADJUSTMENT TO DEFAULT SETTINGS IS NOT SUGGESTED,

OTHERWISE NORMAL USE OF YOUR E-BIKE CAN NOT BE GUARANTEED.

WHEN THE DISPLAY PRODUCT DOES NOT WORK PROPERLY, PLEASE SEND THE

IT FOR AUTHORIZED REPAIR IN TIME.

2. Assembly

Fix the display on the handlebar, adjust it to a proper facing angle. Make sure your

e-bike is powered off, then plug the connector on the display to the connector on

the controller (bus) to finish standard assembly.

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

3. Product Size

Material

Shell Material: ABS

Screen Cover Material: High Hardness Acrylic (same hardness as tempered glass).

Working Temperature: -20°C~60°C.

Product Size

4. Working Voltage and Connection

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

4.1 Working Voltage

DC 24V-60V compatible (can be set on display)，other voltage level can be

customized.

4.2 Connection

Connector to Controller Display Cable Outlet Connector Display Cable Coupling Connector

Note: Some products may use waterproof connectors, in which case the internal

wire arrangements cannot be identified from outside.

5Functions and Key Pad

5.1 Functions

There are multiple items displayed on EN05 as follows:



Battery Level



Speed (average, maximum, current speed)



Distance (single Trip, total ODO)



PAS Level



Error Indication



Cruise



Brake



Headlight Indication

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

5.2 Control and Setting Items

Power Switch, Light Switch, Walk Mode, Real-time Cruise, Wheel Size Setting,

PAS Level PWM Setting, Speed Limit Setting, Auto-Off Setting.

5.3 Display Area

Overall Interface (displayed within 1s at start）

Introduction of Displayed Items:

1. Headlight

2. Battery Level

3. Versatile Area

Digital Voltage: VOL, Total Distance: ODO, Single Trip Distance: TRIP,

Riding Time: Time

4. Current Speed: CUR, Maximum Speed: MAX, Average Speed: AVG (km/h or mph)

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

The display calculates riding speed based on wheel size and signals (need to set

magnet numbers for Hall motors). ，

5. Error Indication Area

6. PAS Status Indication Area

5.4 Settings

P01: Backlight Brightness (1: darkest; 3: brightest)

P02: Mileage Unit (0: km; 1: mile)

P03: Voltage Class (24V / 36V / 48V / 60V / 72V )

P04: Auto-Off Time

(0: never, other value means time interval for display auto-off) Unit: minute

P05: Pedal Assist Level

0/3 Gear Mode: Gear 1-2V, Gear 2-3V, Gear 3-4V

1/5 Gear Mode: Gear 1-2V, Gear 2-2.5V, Gear 3-4V, Gear 4-3.5V, Gear 5-4V

P06: Wheel Size (Unit: inch Precision: 0.1)

P07: Motor Magnets Number (for Speed Test; Range: 1-100)

P08: Speed Limit Range: 0-50km/h, no speed limit if set to 50)

1. Communications status (controller-controlled)

The driving speed will be kept constant as the limited value.

Error Value: ±1km/h (applicable to both the PAS/throttle mode)

Note: The above-mentioned values are measured by metric unit (kilometers).

When the measuring unit is set to imperial unit (mile), the speed

displayed on the panel will be automatically switched to corresponding

imperial unit, however the speed limit value in the imperial unit interface

won’t change accordingly.

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

P09: Direct Start / Kick-to-Start Setting

0: Direct Start

1: Kick-to-Start

P10: Drive Mode Setting

0: Pedal Assist – The specific gear of the assist drive decides the assist power

value. In this status the throttle does not work.

1: Electric Drive – The vehicle is driven by the throttle. In this status the power

gear does not work.

2: Pedal Assist + Electric Drive – Electric drive does not work in direct-start status.

P11: Pedal Assist Sensitivity (Range: 1-24)

P12: Pedal Assist Starting Intensity (Range: 0-5)

P13: Magnets Number in Pedal Assist Sensor (5 / 8 / 12pcs)

P14: Current Limit Value (12A by default; Range: 1-20A)

P15: Unspecified

P16: ODO Clearance

Press and hold the up key for 5 seconds and ODO distance will be cleared.

5.5 Communications Protocol：UART

5.6 Key Pad

Key pad position:

Changzhou Sciwil E-

Mobility Technology Co., Ltd.

9th Huashan Road, Changzhou, Jiangsu, China- 213022

Fax: +86 519-85602675 Tel: +86 519-8560067

There are 3 keys on EN05 display. In following introductions:

is called “On/Off”,

is called “Info”,

Operations include short press, press and hold of a single key or two keys：

①During riding, press Plus or Minus to change PAS/throttle level.

②During riding, press On/Off to switch items displayed in versatile area.

Note：Press and hold of a single key is mainly used for switch mode/on/off

status. Press and hold of two keys is used for parameter settings.

(To avoid false operation, short press of two keys is not introduced.)

Operations:

·Switch On/Off Display

-Press and hold On/Off to switch on or off the display.

-When the display is on but the static current is under 1μA, the display will

automatically turn off after 10 minutes (or any set time by P04).

·Enter/Exit Walk Mode, Cruise Mode and Turn on Headlight:

- When your e-bike stops, press and hold Info to enter 6km/h walk mode.

- During riding, press and hold Info to enter real-time cruise. When in cruise

mode, press and hold Info to exit.

- When the display is on, press On/Off for 3s to turn on/off the headlight.
