Seagate Exos E 2U12 Series Bedienungsanleitung

Exos® E 2U12, 2U24, 5U84 Series Getting Started

Part Number 204936700-00, A • December 2022

Thank you for purchasing a Seagate storage product. This document provides an overview of product setup tasks and identifies

locations for information you need to accomplish each task in product documentation.

WARNING! Non-compliance could void your warranty. To safely mount the storage enclosure in a rack cabinet, you must

follow all directions exactly as specified in the identified hardware documentation. Retain original packaging materials for use with

returns. For storage enclosure returns, the master container must ship on a pallet.

Product setup

Seagate requires the person using these instructions to be a qualified technician, trained to perform installation and maintenance

of Seagate storage products. Use the Rackmount Guide and the video to direct you during initial installation.

For help, contact Technical Support at 1-800-SEAGATE or email [email protected]. You must provide the following data:

lIssue subject and detailed issue

description

lProduct type and serial number

lPart number of product or FRU experiencing a fault

condition

lSystem logs related to the fault condition

Shipkit item Quantity

Storage enclosure with or without drive modules 1

Accessory kit * 1

Railkit box 1

Optional SFP packs 2

*All power cords, included or obtained, must comply with applicable Seagate standards and requirements.

Installation checklist

Read this entire section before you begin. You must adhere to all safety requirements prior to and during installation.

WARNING! Do not attempt to install the 5U expansion enclosure into the rack cabinet with drive modules preloaded in the

slots. Serious injury and damage could result. Unload any drive modules in enclosure slots to a static-protected area. Do not

further lighten the enclosure by removing other components.

Installation prerequisites and safety guidance

1. Clear the site for installation and secure a static-protected area for unpacking the enclosure in that area.

2. Move the enclosure onto a suitable mechanical lift with two (2U) or three people (5U, using included belt straps).

3. Use a mechanical lift for positioning the enclosure and mounting it into the rack cabinet. Do not use a vacuum lift. To maintain

personal and equipment safety, do not use any other method to support the weight of the enclosure.

4. Maintain adequate enclosure clearances, both front and back.

5. Prior to handling all drive modules in carriers (DDICs), make sure you are static-compliant.

Use this checklist, performing each task only in the sequence presented after successful completion of the prior step.

Step Task Reference Location*

1 Complete all installation prerequisites Identified above GS

2 Unpack the enclosure Unpack and prepare the 2U or 5U enclosure topic RG

3 Prepare the site for installation into the rack cabinet Unpack and prepare the 2U or 5U enclosure topic RG

4 For rackmount installation, temporarily move any drive

modules not installed in the enclosure to a static-

protected area

For rackmount installation, temporarily move to a static-

protected area any drive modules not installed in the

enclosure

5 Install the rackmount kit in the rack cabinet Install the 2U or 5U enclosure rackmount rail kit topic RG

6 Mount the enclosure into the rack cabinet Mount the 2U or 5U enclosure into the rack cabinet topic RG

7 Install drive modules in carriers (DDICs) in the enclosure Populate the 2U or 5U enclosure topic RG

8 (Optional) Install any additional expansion enclosures Follow same process for chassis installation to this step RG

9 Test for safety electrical earth connection Test enclosure electrical earth connection topic HIMG

10 Connect all host and any expansion data cables Route 2U or 5U enclosure power cords and data cables

topic

HIMG

11 Connect all power cords

*See the Product documentation and support section for a complete list of all related documentation.

Product documentation and support

To obtain documentation, videos, and product information, visit www.seagate.com/support/data-storage-systems/.

Content description Document Seagate QR codes

Enhancements, known issues, and updates Release Notes Documentation,

Support

2U documentation,

support

5U documentation,

support

Installation of the rail kit and enclosure into a rack Rackmount Guide*

Initial installation of hardware and component replacement Hardware Installation and Maintenance Guide

Regulatory compliance, safety, and disposal information Compliance, Safety, and Disposal Guide

*Printed document included in the shipkit

Technology LLC in the United States and/or other countries. Exos is either a trademark or a registered trademark of Seagate Technology LLC or one of its affiliated

companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. Seagate reserves the

right to change, without notice, product offerings or specifications.
