100835984, Rev. D

Gen 2 - March 2021

Standard 512E model

ST10000NE0008

SATA Product Manual

Publication number: 100835984, Rev. D March 2021

Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. IronWolf Pro, PowerChoice and

SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a cer-

tification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments. All other trademarks or registered trademarks are the property of their

respective owners.

No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.

Call 877-PUB-TEK1 (877-782-8351) to request permission.

When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different

standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage.

Actual quantities will vary based on various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating environment

and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for

Document Revision History

Revision Date Pages affected and Description of changes

Rev. A 05/17/2018 Initial release.

Rev. B 06/18/2018 7-8 & 14: Added cross reference to rated MTBF device operating condition requirements

21: Revised Table 7: Taiwan - Restricted Substances to latest BSMI requirements

Rev. C 04/09/2020

4: Updated Seagate Technology Support Services page

8: Corrected temperature & Humidity gradients

8 & 14-15: Updated environmental specifications

8 & 17: Added “command controlled to L/UL

18: Replaced Regulatory Compliance and Safety information with URL and instructions

bc: Updated address to new US HQ.

Rev. D 03/12/2021

fc, 5, 7, 9, 26-27 & 39: Removed 14TB & 12TB models & specifications.

7: Updated Spin-up current to 2.0A

7-8 &14: Revised operating temperature range statements & notes

18: Updated Section 1.2.10 HDD and SSD Regulatory Compliance and Safety

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 2

Contents

Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 About the Serial ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.1 Specification summary tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.2 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.2.1 LBA mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.4 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.5 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.5.1 Power consumption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.5.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.5.4 Extended Power Conditions - PowerChoice™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.6 Environmental limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.6.1 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.6.2 Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.6.3 Shock and Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.7 Acoustics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.8 Test for Prominent Discrete Tones (PDTs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.9 Electromagnetic immunity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.10 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.10.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF) . . . . . . . . . . . . . 17

2.11 HDD and SSD Regulatory Compliance and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.11.1 Regulatory Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.12 Corrosive environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.13 Reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.14 Product warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 3

Contents

3.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.1 Handling and static-discharge precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.3 Serial ATA cables and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.4 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.4.1 Mechanical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.0 Serial ATA (SATA) interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.1 Hot-Plug compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.2 Serial ATA device plug connector pin definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.3 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.3.2 Identify Device Data log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.3.3 Device Statistics log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

4.3.4 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

4.3.5 S.M.A.R.T. commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 4

For Seagate Product Support, visit: www.seagate.com/support

For Seagate Compliance, Safety, and Disposal, visit: www.seagate.com/support

For Firmware Download and Tools Download for Secure Erase, visit: www.seagate.com/support/downloads/

For information regarding online support and services, visit: www.seagate.com/contacts/

For information regarding Warranty Support, visit: www.seagate.com/support/warranty-and-replacements/

For information regarding data recovery services, visit: www.seagate.com/services-software/recover/

For Seagate OEM and Distribution partner and Seagate reseller portal, visit: www.seagate.com/partners

Seagate® Technology Support Services

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 5

www.seagate.com Introduction

1.1 Introduction

This manual describes the functional, mechanical and interface specifications for the following:

Seagate® IronWolf® Pro Serial ATA drive models.

These drives provide the following key features:

256 MB data buffer.

7200 RPM spindle speed.

Full-track multiple-sector transfer capability without local processor intervention.

High instantaneous (burst) data-transfer rates (up to 600MB per second).

Native Command Queuing with command ordering to increase performance in demanding applications.

PowerChoice™ for selectable power savings

Perpendicular recording technology provides the drives with increased areal density.

SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.

State-of-the-art cache and on-the-fly error-correction algorithms.

Support for S.M.A.R.T. drive monitoring and reporting.

Supports latching SATA cables and connectors.

Top Cover Attached motor for excellent vibration tolerance

Worldwide Name (WWN) capability uniquely identifies the drive.

NOTE Seagate recommends validating the configuration with the selected HBA/RAID

controller manufacturer to ensure use of full capacity is supported.

Table 1: Models

Standard 512E models

ST10000NE0008

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 6

www.seagate.com Introduction

1.1.1 About the Serial ATA interface

The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary

advantages include:

Easy installation and configuration with true plug-and-play connectivity.

It is not necessary to set any jumpers or other configuration options.

Thinner and more flexible cabling for improved enclosure airflow and ease of installation.

Scalability to higher performance levels.

In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA

was designed to allow users to install a Serial ATA host adapter and Serial ATA disk drive in the current system and

expect all of the existing applications to work as normal.

The Serial ATA interface connects each disk drive in a point-to-point configuration with the Serial ATA host adapter.

There is no master/slave relationship with Serial ATA devices like there is with parallel ATA. If two drives are attached

on one Serial ATA host adapter, the host operating system views the two devices as if they were both “masters”on two

separate ports. This essentially means both drives behave as if they are Device 0 (master) devices.

NOTE The host adapter may, optionally, emulate a master/slave environment to host software

where two devices on separate Serial ATA ports are represented to host software as a

Device 0 (master) and Device 1 (slave) accessed at the same set of host bus addresses. A

host adapter that emulates a master/slave environment manages two sets of shadow

registers. This is not a typical Serial ATA environment.

The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide

backward compatibility with existing host systems and software. The Command and Control Block registers, PIO and

DMA data transfers, resets, and interrupts are all emulated.

The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers,

referred to as the Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional

information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment”

specification. The specification can be downloaded from www.serialata.org.

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 7

www.seagate.com Drive specifications

1.2 Drive specifications

Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For

convenience, the phrases the drive and this drive are used throughout this manual to indicate the IronWolf Pro Serial

ATA drive models.

1.2.1 Specification summary tables

The specifications listed in the following tables are for quick reference. For details on specification measurement or

definition, see the appropriate section of this manual.

Table 2 Drive specifications summary

Drive specification#ST10000NE0008

Formatted (512 bytes/sector)** 10TB

Guaranteed sectors (see Section 1.2.2)

Heads 13

Discs 8

Bytes per logical sector 512

Bytes per physical sector 4096

Recording density, KBPI (Kb/in max) 2426

Track density, KTPI (ktracks/in avg.) 436

Areal density, (Gb/in2 avg) 1058

Spindle speed (RPM) 7200

Internal data transfer rate (Mb/s max) 2833

Sustained data transfer rate OD (MiB/s max) 238 (250 MB/s max)

I/O data-transfer rate (MB/s max) 600

ATA data-transfer modes supported PIO modes 0–4

Multiword DMA modes 0–2

Ultra DMA modes 0–6

Cache buffer 256MB (262,144KB)

Weight: (maximum) 690g (1.521 lb)

Average latency 4.16ms

Power-on to ready (sec) (typ/max) 23/30

Standby to ready (sec) (typ/max) 23/30

Startup current (typical) 12V (peak) 2.0A

Voltage tolerance (including noise) 5V ± 5%

12V ± 10%

Operating ambient temperature (min °C)*0°C (Ambient)

Operating temperature (max °C)*65°C (Drive Reported Temperature) †

Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 1.2.6.1 and 1.2.14)

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 8

www.seagate.com Drive specifications

# All specifications above are based on native configurations.

* See Section 1.2.10, "Reliability" for rated MTBF device operating condition requirements.

** One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity.

Accessible capacity may vary depending on operating environment and formatting.

*** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.

specification, which may increase acoustic and power to operational levels.

†Seagate does not recommend operating at sustained drive temperatures above 60°C.

Operating at higher temperatures may affect drive health.

Temperature gradient (°C per hour max) 20°C (operating)

20°C (nonoperating)

Relative humidity*5% to 95% (operating)

5% to 95% (nonoperating)

Relative humidity gradient 20% per hour max

Altitude, operating –304.8 m to 3,048 m

(–1000 ft to 10,000+ ft)

Altitude, nonoperating (below mean sea level, max) –304.8 m to 12,192 m

(–1000 ft to 40,000+ ft)

Operational Shock (max at 2 ms - typical) Read 70 Gs / Write 40 Gs

Non-Operational Shock (max at 2 ms - typical) 250 Gs

Linear Random Operating Vibration 5–500 Hz: 0.70 Grms

Random Rotary Operating Vibration 20–1500Hz: 12.5 rads/s²

Linear Random Non-Operating Vibration 2–500 Hz: 2.27 Grms ref

Drive acoustics, sound power (bels)

Idle*** 1.8 (typical)

2.0 (max)

During periods of drive idle, some offline activity may occur according to the

SMART specification, which may increase acoustic and power to operational levels.

Performance seek 2.6 (typical)

2.8 (max)

Nonrecoverable read errors 1 sector per 1015 bits read

Annualized Failure Rate (AFR)*0.73% based on 8760 POH

Maximum Rated Workload*Maximum rate of <300TB/year

Workloads exceeding the annualized rate may degrade the drive MTBF and impact prod-

uct reliability. The Annualized Workload Rate is in units of TB per year, or TB per 8760

power on hours. Workload Rate = TB transferred * (8760 / recorded power on hours).

Warranty To determine the warranty for a specific drive, use a web browser to access the following

web page: www.seagate.com/support/warranty-and-replacements/.

From this page, click on the “Is my Drive under Warranty” link. The following are required

to be provided: the drive serial number, model number (or part number) and country of

purchase.The system will display the warranty information for the drive.

Load-unload cycles (command controlled) 600,000

Supports Hotplug operation per

Serial ATA Revision 3.3 specification

Yes

Drive specification#ST10000NE0008

Seagate IronWolf Pro Serial ATA Product Manual, Rev. D 9

www.seagate.com Drive specifications

1.2.2 Formatted capacity

*One GB equals one billion bytes when referring to hard drive capacity.

Accessible capacity may vary depending on operating environment and formatting.

NOTE LBA Counts for drive capacities greater than 8TB are calculated based upon the

SFF-8447 standard publication. ftp://ftp.seagate.com/sff/SFF-8447.PDF

1.2.2.1 LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is

the number of guaranteed sectors as defined above.

See Section 1.4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit

addressing support of drives with capacities over 137GB.

1.2.3 Recording and interface technology

1.2.4 Start/stop times

ST models Formatted capacity* Guaranteed sectors Bytes per logical sector

ST10000NE0008 10TB 19,532,873,728 512E

Interface Serial ATA (SATA)

Recording method Perpendicular

Recording density, KBPI (Kb/in max) 2426

Track density, KTPI (ktracks/in avg) 436

Areal density (Gb/in2avg) 1058

Spindle speed (RPM) (± 0.2%) 7200

Internal data transfer rate (Mb/s max) 2833

Sustained data transfer rate (MiB/s max) 238

I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5)

Power-on to Ready (sec) (typ/max) 23/30

Standby to Ready (sec) (typ/max) 23/30

Ready to spindle stop (sec) (max) 20

Inhaltsverzeichnis

Andere Seagate Lagerung Handbücher

Seagate

Seagate BARRACUDA COMPUTE ST6000DMZ03 Bedienungsanleitung

Seagate

Seagate CHEETAH 73LP Bedienungsanleitung

Seagate

Seagate U Series 9 CE Bedienungsanleitung

Seagate

Seagate ST38421A - U4 8.4 GB Hard Drive Bedienungsanleitung

Seagate

Seagate ST31000525SV - 1.0TB 7200RPM Sata... Bedienungs- und Sicherheitshinweise

Seagate

Seagate BARRACUDA ST1000LM049 Bedienungsanleitung

Seagate

Seagate MOMENTUS ST9500325AS Bedienungsanleitung

Seagate

Seagate FreeAgent Go Bedienungsanleitung

Seagate

Seagate SKYHAWKLITE ST2000VX007 Bedienungsanleitung

Seagate

Seagate ST31000322CS - Pipeline HD 1 TB Hard Drive Bedienungsanleitung

Seagate

Seagate ST423451N Bedienungsanleitung

Seagate

Seagate EXOS ST14000NM0081 Bedienungsanleitung

Seagate

Seagate ST300MP0004 - 512N Bedienungsanleitung

Seagate

Seagate ST9500430SS - Constellation 7200 500 GB Hard... Bedienungsanleitung

Seagate

Seagate CHEETAH 18FC Bedienungsanleitung

Seagate

Seagate Elite 9 Bedienungsanleitung

Seagate

Seagate BARRACUDA ST5000LM000 Bedienungsanleitung

Seagate

Seagate ST905003BPA1E1-RK - Maxtor BlackArmor 500 GB External Hard... Bedienungsanleitung

Seagate

Seagate Momentus Thin ST500LT012 Bedienungsanleitung

Seagate

Seagate Momentus ST500LM021 Bedienungsanleitung

Seagate

Seagate FreeAgent Pro Bedienungsanleitung

Seagate

Seagate NAS ST4000VN000 Bedienungsanleitung

Seagate

Seagate ST3500071FC Bedienungsanleitung

Seagate

Seagate ST3000VX006 Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
