Seagate STT320000A Technisches Handbuch

Seagate Travan 40GB User Guide 29

Internal Storage System

Click here

to continue

Seagate

40GB

Online User Guide

Trr

ravanavan

avanavan

avan

Tr40ig.p65 01/21/2002, 10:23 AM29

Seagate Travan 40GB User Guide 1

Contents

Page

3 Introduction

5 Installing the drive

15 Operation and maintenance

22 Troubleshooting

25 Technical Support

Seagate Travan 40GB — Online User Guide

TR40IG.P65 01/07/2002, 8:41 AM1

Seagate Travan 40GB User Guide 2

be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording or otherwise, without prior written permission from Seagate Removable Storage Solutions.

Product features and specifications described in this guide are subject to change without notification.

Seagate and the Seagate Logo are registered trademarks of Seagate Technology, LLC. All other trademarks are the

property of their respective owners.

Publication Number T-013, Rev. A, January, 2002

FCC Notice

This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with

the manufacturer’s instructions, may cause interference to radio and television reception which could void the

user’s authority to operate the equipment. It has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of FCC Rules, which are designed to provide reasonable protection against such

interference in a residential installation. However, there is no guarantee that interference will not occur in a

particular installation.

If interference does occur, try to correct it by taking one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the computer and the receiver.

• Connect the computer into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

Further, this equipment complies with the limits for a Class B digital apparatus in accordance with Canadian Radio

Interference Regulations ICES-003.

Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canda.

TR40IG.P65 01/07/2002, 8:41 AM2

Seagate Travan 40GB User Guide 3

About this manual

This manual describes how to install and oper-

ate your new Seagate Travan 40GB tape drive.

The manual also contains information on

troubleshooting and technical support for your

new drive.

Note. Wherever a page number is referenced in

this online manual, you can click on the

page number to jump to that page. You

can return to the original page by clicking

the back button in your viewer soft-

ware.

Introduction

TR40IG.P65 01/07/2002, 8:41 AM3

Seagate Travan 40GB User Guide 4

About your Travan tape drive

The Seagate Travan 40GB can store up to 40

Gbytes on a single Travan 40 cartridge, and

features a data transfer rate of up to 240

Mbytes per minute.

Note. These values are based on 2:1 data

compression. Uncompressed values are

one half as high. Capacities, backup

speeds and transfer rates will vary with

file type and system configuration.

This drive also includes Seagate FastSense(TM)

technology for optimizing drive and host data

transfer rates.

The Seagate Travan 40GB can read and write

Travan 40 cartridges. It can read but

not

write

Travan 20 or NS20 (TR-5) cartridges.

Note. This drive cannot use TR-1, TR-2, TR-3,

TR-4, or QIC-80 cartridges.

TR40IG.P65 01/07/2002, 8:41 AM4

Seagate Travan 40GB User Guide 5

This chapter describes how to install the

Seagate Travan 40GB ATAPI tape drive in your

computer.

What you will need

• You will need a standard flat-bladed screwdriver

and a Phillips screwdriver to install the tape

drive in your computer.

•This tape drive must be attached to a second-

ary IDE port. If your computer has two IDE

ports, and the secondary port is not being

used, you may need to obtain a 40-pin IDE

interface cable for your tape drive. See page

8 for details.

If your computer has only a single IDE port,

you will need to obtain a new ATAPI host

adapter that provides a secondary IDE port for

the tape drive. You will also need a second

40-pin IDE interface cable for your tape drive.

See page 9 for details.

Installing the drive

TR40IG.P65 01/07/2002, 8:41 AM5

Seagate Travan 40GB User Guide 6

Important precautions

To protect your computer and drive from electro-

static damage, follow these guidelines:

• Before you open your computer or remove the

drive from its antistatic bag, ground yourself

by touching the metal chassis of your com-

puter or some other grounded object. For

optimal protection, use an electrostatic

grounding strap.

Note. To be properly grounded, your computer

must be plugged into a grounded electri-

cal outlet.

• Do not touch any printed circuit boards or

electronic chips on your drive or in your

computer.

TR40IG.P65 01/07/2002, 8:41 AM6

Seagate Travan 40GB User Guide 7

Installation Procedure

Follow the steps below to install the Travan

40GB drive in your computer

Note. We recommend that you install your

backup software

before

you install your

tape drive. For more information, see the

instructions that came with the backup

software.

1. Decide where to attach the tape drive.

Before you install your tape drive, you should

determine how many IDE ports your computer

has. You may find this information in the manual

for your computer. You can also look inside your

computer and compare your system with the

illustrations on pages 8 and 9.

If your computer has two IDE ports, continue to

page 8. If your computer has only one IDE port,

see page 9.

TR40IG.P65 01/07/2002, 8:41 AM7

Seagate Travan 40GB User Guide 8

If your computer has two IDE ports:

Most modern computers have two IDE ports.

Each port can support up to two devices (on a

single IDE cable). A hard disk is usually at-

tached to the

primary

IDE port, as shown in

Figure 1. However, the Travan 40 should not be

attached to an IDE port that is being used by a

hard disc or a sound card. Thus, you must use

the secondary IDE port for your tape drive.

If no devices or cables are attached to the

secondary IDE port (as shown in Figure 1), you

will need to obtain a second IDE cable for your

tape drive.

If a CD-ROM or other compatible device is

attached to the secondary IDE port (as shown in

Figure 2) you can install the tape drive on the

same cable as the CD-ROM.

Continue to page 10 for instructions on setting

the master-slave jumpers.

Figure 1

Figure 2

Computer

Motherboard

Primary

IDE port

Secondary

IDE port

Hard

Disc

Hard

Disc

Attach tape drive and cable here

(tape drive must be configured

as "Master")

Computer

Motherboard

Primary

IDE port

Secondary

IDE port CD-ROM

configured as "Master"

Attach tape drive here

configured as "Slave"

CD-ROM

Hard

Disc

Hard

Disc

EXAMPLE 1: Existing computer with two IDE ports

(hard disc attached to the primary IDE port)

EXAMPLE 2: Existing computer with two IDE ports

(ATAPI devices on both primary and secondary IDE Ports)

TR40IG.P65 01/07/2002, 8:41 AM8

Seagate Travan 40GB User Guide 9

If your computer has only one IDE port:

• If your computer has only a single IDE port,

as shown in Figure 3, it is probably being

used by the hard disc drive. You should not

attach your tape drive to an IDE port that is

being used by a hard disc or a sound card.

In this situation, before you can install the

tape drive, you must purchase an ATAPI host

adapter that provides a second IDE port. You

will also need a second IDE cable for the

tape drive. After installing the host adapter,

set the master/slave jumpers as described on

page 10.

Figure 3

Computer

Motherboard

Primary

IDE port

Hard

Disc

Hard

Disc

Since there is no secondary IDE

port, you must purchase an ATAPI

host adapter that provides two ports

EXAMPLE 3: Existing computer with only one

IDE port

(hard disc attached to primary port)

TR40IG.P65 01/07/2002, 8:41 AM9
