SeaLevel Relio R2 SYNC Bedienungsanleitung

Relio R2 SYNC

User Manual | RELIO R2 SYNC



2

 © Sealevel Systems, Inc. RELIO R2 SYNC Manual | SL9255 10/2021

Contents

CONTENTS....................................................................................................................................................................................................................................2
INTRODUCTION...........................................................................................................................................................................................................................3
FEATURES.....................................................................................................................................................................................................................................4
COM EXPRESS MODULE/RAM CONFIGURATION OPTIONS ..........................................................................................................4
BEFORE YOU GET STARTED .....................................................................................................................................................................................................5
WHAT’S INCLUDED ...............................................................................................................................................................5
ADVISORY CONVENTIONS.......................................................................................................................................................5
OPTIONAL ITEMS..................................................................................................................................................................6
SPECIFICATIONS ........................................................................................................................................................................................................................8
MECHANICAL DIMENSIONS ....................................................................................................................................................8
ENVIRONMENTAL SPECIFICATIONS ...........................................................................................................................................8
OPERATING TEMPERATURE RANGE ..........................................................................................................................................8
POWER SUPPLY....................................................................................................................................................................9
POWER INPUT .....................................................................................................................................................................9
MANUFACTURING ..............................................................................................................................................................10
SYSTEM OPERATION.................................................................................................................................................................................................................11
POWER BUTTON ................................................................................................................................................................11
POWER STATES..................................................................................................................................................................11
SYNCHRONOUS SERIAL COMMUNICATION PORTS .....................................................................................................................11
INTERNAL BAUD RATE GENERATOR........................................................................................................................................11
CONTROL AND STATUS REGISTERS DEFINITION.........................................................................................................................12
INTERFACE SELECTION .........................................................................................................................................................13
100-PIN CONNECTOR PIN OUT ............................................................................................................................................13
DB-25M CONNECTOR PIN OUTS..........................................................................................................................................15
CMOS BATTERY ................................................................................................................................................................20
SYSTEM DESCRIPTION............................................................................................................................................................................................................20
FRONT PANEL I/O CONNECTORS...........................................................................................................................................20
REAR PANEL I/O CONNECTORS.............................................................................................................................................21
MECHANICAL DRAWINGS.....................................................................................................................................................22
GETTING STARTED ................................................................................................................................................................................................................... 27
WHERE TO GET SOFTWARE ..................................................................................................................................................27
BIOS CONSIDERATIONS .........................................................................................................................................................................................................28
APPENDIX A –HANDLING INSTRUCTIONS ........................................................................................................................................................................29
APPENDIX B –ELECTRICAL INTERFACE..............................................................................................................................................................................30
APPENDIX C –ASYNCHRONOUS COMMUNICATIONS ....................................................................................................................................................31
WARRANTY................................................................................................................................................................................................................................32


Introduction

Overview

The Relio R2 SYNC is an exceptionally rugged embedded controller with integrated synchronous

communications ports for operating in harsh environments. The R2 SYNC’s fan less and cableless structure

ensures extensive durability for long-term usage. The R2 SYNC differs from traditional industrial computer

systems in that it is built using the PICMG COM Express architecture. Sealevel has partnered with the leading

COM Express module manufacturers to ensure our customers benefit from the best in the industry. This

manual will focus on the higher-level features of the R2 SYNC computer system.

The R2 SYNC is compatible with Basic and Compact form factor Type 6 pin out COM Express modules. COM

Express is a widely supported implementation of Computer on Module (COM) design. The COM Express

architecture reduces the complexity, cost and time required for custom computer system design by combining

the processing, memory, video, Ethernet, and USB functionality in a small, highly integrated module. COM

Express modules install on a carrier board that provides the application specific I/O and external connectors

best suited for the system requirements.

Sealevel COM Express carrier boards leverage the company’s years as a leader in I/O and communication

products to provide carrier board and full system solutions in the fastest time possible. Common I/O features

include serial, analog and digital I/O. Sealevel’s extensive library of proven I/O circuits can be included as

required to meet the specific I/O count, voltage ranges, and connector types.

The R2 SYNC is equipped with a four-port RS-232, RS-422, RS-485,EIA-530, EIA-530A, V.35 synchronous serial

interface. Designed using the popular Zilog Z85230 Enhanced Serial Communication Controller (ESCC), the

board is an ideal solution for military, satellite, radar, banking, and other applications that require robust

synchronous communications.

For maximum flexibility, each of the serial ports can be individually configured for RS-232, RS-422, RS-485,EIA-

530, EIA-530A, V.35 communications. In RS-232 mode, all common modem control signals are implemented

for compatibility with a wide range of peripherals. A digital phase lock loop (DPLL) is included on each port,

and the board supports data rates up to 128K bps in burst mode. For easy implementation, a fan-out cable is

included that terminates the onboard 100-pin connector to four DB-25M connectors.

Software support, critical for successful synchronous communication development, is provided through

Sealevel’s SeaMAC driver. HDLC/SDLC protocols are supported as well as certain configurations of Monosync,

Bi-sync, and Raw modes.

The R2 SYNC also utilizes the Exar SP-506 multi-protocol electrical interface chip that allows it to be compliant

with EIA/TIA-530/530A, EIA/TIA-232E, EIA/TIA 485, and ITU V.35. Optional cables are available to connect RS-

449, RS-530, RS-530A, V.35 and X.21 interfaces.

Features

The following features are included and installed on the Relio R2 SYNC models.

▪4 Synchronous Serial ports individually configurable for RS-232, RS-422, RS-485, RS-530, RS-530A,

V.35 (DB100 + Cable for 4 DB25 connectors) using the Z85230 Enhanced Serial Communications

Controller (ESCC)

oData rates to 128K bps (Burst mode)

oAll modem control signals implemented

oCompatible with Sealevel 5402 and 5402e Synchronous cards

▪1 Display Port Compatible Video Output

▪2 Gigabit Ethernet Ports

▪2 USB 2.0 Ports

▪64GB mSATA Solid State Drive

▪Power Button with integrated LED

▪Supports Wake-on-LAN

▪18-36 VDC Input

COM Express Module/RAM Configuration options

Part Number

COM Express Module

COM Express Module Description

RAM

R23008-01

IBR-i3-3217UE

Type 6 Standard Module with Intel

Core i3 3217UE Ivy Bridge CPU

8GB DDR3 1333 ECC

R27008-01

IBR-i7-3517UE

Type 6 Standard Module with Intel

Core i7 3517UE Ivy Bridge CPU

8GB DDR3 1333 ECC

Before You Get Started

What’s Included

The R2 SYNC is shipped with the following items. If any of these items are missing or damaged, please

contact Sealevel at 864.843.4343 for a replacement.

•R2 SYNC Computer System

•BK1042 (Wall mount brackets)

•CA339 Molex 100-Pin to (4) DB25 Male Cable, 36-inch Length

•TR145-US AC/DC Power Supply –Desktop 90-264VAC/47-63Hz 21VDC regulated 3000mA

output with a KPPX-4P connector

Advisory Conventions

Warning

The highest level of importance used to stress a condition where damage could result to the product,

or the user could suffer serious injury.

Important

The middle level of importance used to highlight information that might not seem obvious or a

situation that could cause the product to fail.

Note

The lowest level of importance used to provide background information, additional tips, or other non-

critical facts that will not affect the use of the product.

Optional Items

Depending upon your application, you are likely to find one or more of the following items useful with the R2

SYNC. All items can be purchased from our website (www.sealevel.com)or by calling our sales team at

(864) 843-4343.

Cables

CAT5 Patch Cable, 7’ In Length (Part# CA246)

Standard 7' CAT5 Unshielded Twisted Ethernet Pair Patch Cable

(RJ45) with blue jacket.

CAT5 Patch Cable, 10' In Length (Part# CA247)

Standard 10’ CAT5 Unshielded Twisted Pair Ethernet Patch Cable

(RJ45) with blue jacket.

DB25 Female to DB25 Male Extension Cable, 72 inch Length (Item# CA104)

The CA104 is a standard DB25F to DB25M serial extension

cable. Extend a DB25 cable or locate a piece of hardware

where it is needed with this six foot (72 inch) cable. The

connectors are pinned one-to-one so the cable is compatible

with any device or cable with DB25 connectors. The cable is

fully shielded against interference and the connectors are

molded to provide strain relief. Dual metal thumbscrews

secure the cable connections and prevent accidental

disconnection. Recommended for applications with data

rates less than 1M bps.

DB25 Female (RS-530) to DB37 Male (RS-449 DTE) Cable, 10 inch Length (Item#

CA107)

DB25 Female (RS-530) to DB37 Male (RS-449 DTE) Cable, 10

inch Length. RS-530 was designed to replace the bulky DB37

RS-449 connector. The CA107 cable allows any Sealevel RS-

530 adapter to be used in an RS-449 application.

OPTIONAL ITEMS, CONTINUED

DB25 Female (RS-530) to DB15 Male (X.21) Cable, 72 inch Length (Item# CA159)

DB25 Female (RS-530) to DB15 Male (X.21) Cable, 72 inch

Length. Converts the Standard DB25 implementation of RS-

530 or RS-422 to the ITU-T X.21 standard pinout.

DB25 Female to DB25 Male (RS-530) Twisted Pair Serial Cable, 72 inch Length (Item#

CA174)

DB25 Female to DB25 Male Twisted Pair Serial Cable, 72

inch Length. Twisted Pairs provide increased data integrity in

high-speed serial applications. Recommended for RS-530

applications with data rates greater than 1M bps.

DB25 Female (V.35) to ITU-T ISO-2593 Style Connector (V.35) Cable, 72 inch Length

(Item# CA178)

DB25 Female (V.35) to ITU-T ISO-2593 Style Connector

(V.35) Cable, 72 inch Length. The CA178 converts the

Sealevel DB25 implementation of V.35 to the ITU-T V.35

mechanical standard.

Specifications

Mechanical Dimensions

Package Length

7.820 inches (19.86 cm)

Package Width1

4.744 inches (12.04 cm)

Package Height

2.672 inches (6.90 cm)

Environmental Specifications

Specification

Operating

Storage

Temperature Range

0º to 50º C (32 º to 122 ºF)1

-40 to 85 ºC (-40 to 185 ºF)

Humidity Range

10 to 90% R.H. Non-Condensing

Operating Temperature Range

The R2 SYNC7008 can operate with no airflow at 50C as long as the steady-state CPU usage does not exceed

50%. If CPU usage is sustained at a workload greater than 50%, the CPU will throttle itself back to keep its

internal temperature in a safe range.

If the application environment requires the computer to operate at 50C with steady state CPU usage greater

than 50%, some additional cooling must be used to ensure safe operation of the electronics.

The R2 SYNC computer system is a fan-less, solid state computer that relies on thermal conduction to move

heat from internal components to the outside of the enclosure. The lid is designed as a finned heat sink to

increase overall surface area. Three main cooling methods can be used to optimize removal of heat from the

system.

1. Airflow

2. Thermal conduction through mounting

3. Computer orientation

Width listed is for computer without mounting brackets. Total width with brackets is shown in drawings.

2 Operating temperature is dependent on particular model. See the Operating Temperature Range section for model

capabilities.

Part Number

COM Express Module

Operating Temperature

Range

Comment

R23008-01

IBR-i3-3217UE

0 - 50 °C

Requires Industrial Temperature SSD

R27008-01

IBR-i7-3517UE

0 - 50 °C

Requires Industrial Temperature SSD

SPECIFICATIONS, CONTINUED

Airflow over the lid provides the most effective heat removal of these three options. It is optimal to mount the

computer in an area that has either natural or forced airflow to constantly remove heat from the enclosure.

Mounting the computer to a large thermally conductive surface (such as an I-Beam, steel cabinet or other large

metal surface) allows heat to travel through the enclosure and be dissipated into the large structure.

Power Supply

The power supply provided has a universal AC input. It provides 21 VDC @ 3.0 A max output to the R2 SYNC

system. Typical power consumption varies depending on COM Express Module, memory capacity,

OS/software activity and peripheral devices. AC current draw will never exceed 1.4 A.

All necessary system voltages are generated from a single DC input capable of accepting 18 VDC to 36 VDC

(fed by above DC power supply).

Acceptable System Input Voltage

18 VDC-36 VDC

DC Current Rating (Dependent on COM Express

Module , input voltage and load)

375 mA-2150 mA

Power Input

The 12003 carrier board is designed to operate from 18VDC up to 36VDC. The current draw varies across this

range and is heavily dependent on the COM Express module, peripheral devices, and installed software. The

connector at J9 is Kycon KPJX-4S. Use Kycon KPPX-4P as the mate if creating your own power cable.

Figure 1 - Power Connector

SPECIFICATION, CONTINUED

Pin #

Signal

Name

Positive DC Power

Negative DC Power (GND)

Positive DC Power

Manufacturing

All Sealevel Systems printed circuit boards are built to UL 94V0 rating and are 100% electrically tested.

These printed circuit boards are solder mask over electroless Ni / Immersion gold.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere SeaLevel Controller Handbücher

SeaLevel

SeaLevel Relio R2 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
