INSTRUCTION MANUAL FOR:

UNDER BONNET LAMP 30 SMD 12V

MODEL NO: LED032

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give

you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,

WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS

INTENDED. FAILURE TO DO SO MAYCAUSE DAMAGEAND/OR PERSONAL INJURYAND WILLINVALIDATE THE WARRANTY.

PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.

1.1. GENERAL

 WARNING! Disconnect lamp from power before performing any maintenance.

 DO NOT shine lamp directly into your, other person’s or animal’s eyes.

 DO NOT allow children to use the lamp.

Maintain the lamp in good condition.

 DO NOT use the lamp if the lamp if damaged.

 When not in use store the light in a safe, dry, childproof location.

 WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered

to when using this light.

Wear approved eye protection. A full range of safety equipment is available from your Sealey dealer.

Wear suitable clothing to avoid snagging.

DO NOT wear jewellery and tie back long hair.

Account for all tools being used and DO NOT leave them in or near the engine.

WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all

possible conditions and situations that may occur. It must be understood that common sense and caution

are factors which must be applied by the operator.

Original Language Version LED032 Issue: 1 - 29/01/13

2. INTRODUCTION

Robust design with built-in spring loaded telescopic mounting brackets. Soft padded hooks provide good protection

against bonnet. 30 SMD LEDs give complete engine bay illumination. Supplied with 5mtr cable and battery terminal

clips.

Model No:.............................LED032.

Voltage: ...................................12V.

Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7W.

Lamp Type: . . . . . . . . . . . . . . . . . . . . . . 30 x 3528 SMD.

Minimum/ Maximum Bonnet Width ...1230/1940mm.

1. SAFETY

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.

IMPORTANT: No liability is accepted for incorrect use of this product.

WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.

INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.

01284 757500

01284 703534

sales@sealey.co.uk

Sole UK Distributor, Sealey Group,

Kempson Way, Suffolk Business Park,

Bury St. Edmunds, Suffolk,

IP32 7AR

www.sealey.co.uk

Web

Original Language Version LED032 Issue: 1 - 29/01/13

4.1. Keep lamp clean and check for damage before every use. If damage is observed, remove from use until unit is

repaired.

4.2. If the lamp fails to operate, disconnect from the battery and check the fuse by pulling the lid of its cover (see

g.1). Replace if necessary, ret the fuse cover and reconnect to the battery.

4. MAINTENANCE

Fig.1

3.1. ATTACHING LAMP TO BONNET.

3.1.1. Place the padded hook at the end of the lamp, over one edge of the bonnet, and gently pull the lamp towards

the other side of the bonnet.

3.1.2. Steady the lamp with one hand, whilst extending the hook over the other side of the bonnet.

3.1.3. To use the lamp, connect the red (positive) clamp to the battery first, followed by the black (negative) clamp,

then turn on using the switch at the end.

3.1.4 When finished, disconnect the black (negative) clamp first, then the red (positive) one, and store the lamp in a

safe, dry and childproof location.

3. OPERATION INSTRUCTIONS

Environmental Protection.

Recycle unwanted materials instead of disposing of them as

waste. All tools, accessories and packaging should be sorted,

taken to a recycle centre and disposed of in a manner which

is compatible with the environment.

WEEE Regulations.

Dispose of this product at the end of its working life in compliance

with the EUDirective on Waste Electrical and Electronic Equipment.

When the product is no longer required, it must be disposed of in an

environmentally protective way. Contact your local solid waste

authority for recycling information.
