Seiko 8V36 Bedienungsanleitung

You are now the proud owner of a SEIKO Analogue Quartz Watch

Cal. 8V36. For best results, please read the instructions in this booklet

carefully before using your SEIKO Analogue Quartz Watch. Please

keep this manual handy for ready reference.

Usted es ahora un honrado poseedor del reloj SEIKO analógico de cuarzo

Cal. 8V36. Para obtener de él los mejores resultados, lea las instrucciones

del presente folleto con cuidado antes del uso de su reloj SEIKO

analógico de cuarzo. Guarde este manual para fácil referencia.

English

ENGLISH

CONTENTS

Page

TIME SETTING ......................................................................................................... 4

ULTRASONIC ALARM ............................................................................................. 5

NOTES ON ULTRASONIC ALARM .......................................................................... 7

BATTERY LIFE INDICATOR ..................................................................................... 7

BATTERY CHANGE.................................................................................................. 7

SPECIFICATIONS..................................................................................................... 9

✩

For the care of your watch, see “TO PRESERVE THE QUALITY OF YOUR

WATCH” in the attached Warranty Booklet.

English

CAL. 8V36

Time indicated by hour, minute,

second and 24-hour hands

Alarm indicator

Shows the alarm engagement/

disengagement.

Ultrasonic alarm

Ultrasonic motor runs at a high

speed to vibrate the watch at the

designated time.

English

TIME SETTING

●

Pull out CROWN when the second hand is at the 12

o’clock position and push it back in accordance with a

time signal.

●

Check that the 24-hour hand is correctly set.

Pull out and turn to set the

time. Then, push in.

When setting the minute hand, first advance it 4 to 5 minutes ahead of the desired time and then turn it

back to the exact minute.

➠

English

ULTRASONIC ALARM

●

To set the alarm time more precisely, turn the alarm hand

counterclockwise.

Turn to set the alarm

hand to the desired

alarm time.

Then pull out.

To set the alarm time less than 2 hours ahead of the current time, first advance the alarm hand more than

2 hours ahead of the current time and then turn it back to the exact alarm time.

English

●To engage the alarm ●To disengage the alarm

Pull out.

●

Indicating the alarm is engaged.

Push in.

●

Indicating the alarm is disengaged.

At the designated time, the watch vibrates for 20

seconds.

➠

English

NOTES ON ULTRASONIC ALARM

BATTERY LIFE INDICATOR

●The alarm can be set on a 12-hour basis.

●When using the ultrasonic alarm, make sure that the watch bracelet fits snugly on your wrist so that

the vibration of the watch can be perceived clearly.

●Please note that, while you are engaged in an active sport or work requiring arm movement, the

vibration of the watch may not be perceived clearly.

●The alarm time scale may be graduated differently depending on the model. When reading the current

time, take care not to mistake the alarm time scale for the current time scale.

When the battery nears its end, the second hand moves at two-second intervals instead of normal one-

second intervals to indicate that the battery needs to be replaced with a new one.

BATTERY CHANGE

The miniature battery which powers your watch should last approximately

2 years. However, because the battery is inserted at the factory to check

the function and performance of the watch, its actual life once in your

possession may be less than the specified period. When the battery expires,

be sure to replace it as soon as possible to prevent any malfunction. For

battery replacement, we recommend that you contact an AUTHORIZED

SEIKO DEALER and request SEIKO SR43W battery.

* The battery life may be less than 2 years if the ultrasonic alarm is used more

than 10 seconds a day.

* When the battery nears its end, the ultrasonic motor runs slowly. In that case,

replace the battery with a new one. (The time accuracy is not affected)

Years

English

WARNING

●Do not remove the battery from the watch.

●If it is necessary to take out the battery, keep it out of the reach of children. If

a child swallows it, consult a doctor immediately.

●Never short-circuit, heat or otherwise tamper with the battery, and never

expose it to fire. The battery may burst, become very hot or catch fire.

●The battery is not rechargeable. Never attempt to recharge it, as this may cause

battery leakage or damage to the battery.

CAUTION

English

SPECIFICATIONS

1 Frequency of crystal oscillator .......................... 32,768 Hz (Hz = Hertz … Cycles per second)

2 Loss/gain (Monthly rate) ................................... Less than 15 seconds at normal temperature range (5°

C ~ 35°C) (41°F ~ 95°F)

Accuracy of the alarm ....................................... ±5 minutes

3 Operational temperature range ......................... –10°C ~ +60°C (14°F ~ 140°F)

4 Duration of watch vibration ............................... 20 seconds for each time

5 Display system

Time ............................................................. 24-hour, hour, minute and second hands

Ultrasonic alarm ........................................... Designated alarm time and indication of alarm

engagement/disengagement

6 Driving system

For the watch ............................................... Step motor, 1 piece

For the ultrasonic alarm ............................... Ultrasonic motor, 1 piece

7 Battery .............................................................. Miniature silver oxide battery SR43W, 1 piece

8 Battery life ......................................................... Approx. 2 years

9 IC (Integrated Circuit) ........................................ C-MOS-IC, 2 pieces

* The specifications are subject to change without prior notice for product improvement.
