Seiko Y187 Bedienungsanleitung

You are now the proud owner of a SEIKO Analogue Quartz Watch Cal.

Y187. For best results, please read the instructions in this booklet

carefully before using your SEIKO Analogue Quartz Watch. Please keep

this manual handy for ready reference.

Siete ora in possesso di un orologio SEIKO Analogico al Quarzo Cal. Y187.

Per ottenere i migliori possibili risultati dal vostro orologio, leggere

attentamente le istruzioni di questo manuale prima di utilizzare il vostro

orologio SEIKO analogico al quarzo. Conservare poi il manuale stesso per

ogni qualsiasi eventuale futuro riferimento.

English

CONTENTS

Page

DATE SETTING ........................................................................................................... 4

TIME SETTING ............................................................................................................ 4

STOPWATCH .............................................................................................................. 5

ADJUSTING THE HAND POSITION ............................................................................ 7

NOTES ON USING THE WATCH ................................................................................ 8

BATTERY LIFE INDICATOR ........................................................................................ 9

BATTERY CHANGE ..................................................................................................... 9

SPECIFICATIONS........................................................................................................ 10

✩

For the care of your watch, see “TO PRESERVE THE QUALITY OF YOUR

WATCH” in the attached Worldwide Guarantee and Instruction Booklet.

ENGLISH

English

CAL. Y187

STOPWATCH

●STOPWATCH minute and 1/5-second

hands

●Measures up to 30 minutes in 1/5 second

increments.

●Split time measurement

●Hour and minute hands with small

second and 24-hour hands

●Date displayed in numerals

TIME/CALENDAR

English

DATE SETTING

CROWN

Pull out to first click and turn clockwise

until the previous day’s date appears.

▼

Pull out to second click and turn until the

desired date appears.

▼

Push back in to normal position.

CROWN

Pull out to second click when Small sec-

ond hand is at the 12 o’clock position.

▼

Turn to set 24-hour, Hour and Minute

hands.

▼

Push back in to normal position in accor-

dance with a time signal.

TIME SETTING

Small second hand

Hour hand

Date

➠➠

➠

24-hour hand

Minute hand

➠

English

STOPWATCH

●The stopwatch can measure up to 30 minutes in 1/5 second increments.

●After 30 minutes, it will start counting again from “0” repeatedly up to 6 hours.

STOPWATCH OPERATION

AStart / Stop / Restart

Reset / Split / Split release

STOPWATCH 1/5-second hand

●Before using the stopwatch:

• Check that the crown is set at the normal position.

• Press button B to reset the STOPWATCH hands to “0” position.

STOPWATCH minute hand

English

Standard measurement

START

STOP

▼

RESET

Accumulated elapsed time measurement

START

STOP

▼

RESTART

RESET

▼

STOP

▼

• • • •

Split time measurement

START

SPLIT

▼

SPLIT

RELEASE

RESET

▼

STOP

▼

• • • •

* Restart and stop of

the stopwatch can

be repeated by

pressing button A.

* Measurement and

release of split

time can be

repeated by

pressing button B.

Measurement of two competitors

START

▼

FINISH TIME

OF 1ST

COMPETITOR

2ND

COMPETITOR

FINISHES

▼

FINISH TIME

OF 2ND

COMPETITOR

▼

RESET

English

ADJUSTING THE HAND POSITION

●If the STOPWATCH hands do not return to “0” position when the stopwatch is reset or when

the battery is replaced with a new one, follow the procedure below.

CROWN Pull out to second click.

▼

APress repeatedly to reset STOP-

WATCH minute hand to “0” posi-

tion.

▼

Press repeatedly to reset STOP-

WATCH 1/5-second hand to “0”

position.

▼

CROWN Push back in to normal position.

* Hands move quickly if the respective buttons are

kept pressed.

* After adjusting the STOPWATCH hand position, be

sure to set the time following the procedure in

“TIME SETTING”.

➠

STOPWATCH

minute hand

STOPWATCH

1/5-second hand

English

NOTES ON USING THE WATCH

DATE SETTING

●Do not set the date between 9:00 p.m. and 3:00 a.m. Otherwise, the date may not change properly. If

it is necessary to set the date during that time period, first change the time to any time outside it, set the

date and then reset the correct time.

TIME SETTING

●The 24-hour hand moves correspondingly with the hour hand. When setting the hour hand, check the 24-

hour hand to see that AM/PM is correctly set.

●When setting the minute hand, advance it 4 to 5 minutes ahead of the desired time and then turn it back

to the exact time.

STOPWATCH

●When the stopwatch has been reset and button A is pressed before the STOPWATCH hands reach “0”

position, the stopwatch starts counting time as button A is pressed.

●Note on crown operation while the stopwatch is in use:

Even if the crown is pulled out to the first click, the stopwatch continues measuring. However, if it is pulled

out to the second click, the STOPWATCH hands are reset to “0” position.

HOW TO OPERATE THE SCREW LOCK TYPE CROWN

(for models with screw lock type crown)

●To unscrew the crown:

Turn the crown counterclockwise. Then, pull it out for time/calendar setting or for adjusting the

STOPWATCH hand position.

●To screw in the crown:

With the crown at the normal position, turn it clockwise while pressing it.

English

BATTERY LIFE INDICATOR

●When the battery nears its end, the small second hand moves at two-second intervals instead

of normal one-second intervals to indicate that the battery needs to be replaced with a new

one.

BATTERY CHANGE

Years

The miniature battery which powers your watch should last approximately

2 years. However, because the battery is inserted at the factory to check

the function and performance of the watch, its actual life once in your

possession may be less than the specified period. When the battery expires,

be sure to replace it as soon as possible to prevent any malfunction. For

battery replacement, we recommend that you contact an AUTHORIZED

SEIKO DEALER and request SEIKO SR927SW battery.

* If the stopwatch is used to measure up to 30 minutes more than twice a day, the

battery life may be less than the specified period.

WARNING

●Do not remove the battery from the watch.

●If it is necessary to take out the battery, keep it out of the reach of children. If

a child swallows it, consult a doctor immediately.

English

CAUTION

●Never short-circuit, heat or otherwise tamper with the battery, and never

expose it to fire. The battery may burst, become very hot or catch fire.

●The battery is not rechargeable. Never attempt to recharge it, as this may cause

battery leakage or damage to the battery.

SPECIFICATIONS

1 Frequency of crystal oscillator ...... 32,768 Hz (Hz = Hertz ... Cycles per second)

2 Loss/gain (monthly rate) ................ Less than 20 seconds at normal temperature range (5°C ~ 35°

C) (41°F ~ 95°F)

3 Operational temperature range ..... –5°C ~ +50°C (23°F ~ 122°F)

4 Driving system .............................. Step motor, 3 pieces

5 Display system

Time ....................................... Hour, minute, second and 24-hour hands

Date ........................................ Displayed in numerals.

Stopwatch .............................. Minute and 1/5-second hands

The stopwatch measures up to 30 minutes in 1/5 second increments.

6 Battery .......................................... SEIKO SR927SW, 1 piece

7 Battery life indicator

8 IC (Integrated Circuit) .................... C-MOS-LSI, 1 piece

* The specifications are subject to change without prior notice for product improvement.
