Seneca Z-MODEM-3G Bedienungsanleitung

MI003781-E.DOCX ENGLISH 1/8

INSTALLATION

MANUAL

Manual language English

Series Z-PC

Product

MODEM

Description 2G and 3G modem, GSM850, EGSM900, DCS1800,

PCS1900, WCDMA900 and 2100 Frequency

Contents

1. PRELIMINARY WARNINGS 2

2. PRELIMINARY USE INSTRUCTIONS 2

3. GENERAL SPECIFICATIONS 2

4. TECHNICAL SPECIFICTIONS 3

Power Supply 3

Modem 3

SIM 3

USB 3

Antennas 3

Environmental Conditions 4

Case 4

Standards 4

Insulations 4

5. INSTALLATION RULES 5

6. ELECTRICAL CONNECTIONS 5

Power Supply 6

Micro USB 6

Antennas 7

7. LED INDICATIONS ON THE FRONTAL PANEL 7

LED meaning 7

8. PURCHASE ORDER CODE 7

9. MODULE LAYOUT 8

10. DECOMMISSIONING AND DISPOSAL 8

Manufacturer

Seneca srl

Registered office: Via Austria 26

35127 – Z.I. - Padua – I

Tel +39.049.8705355- 8705355

Fax +39 049.8706287

WEB www.seneca.it

Mail Technical support: supporto@seneca.it

Product information: commerciale@seneca.it

This document is the property of SENECA srl. Unauthorized duplication and reproduction

is strictly forbidden. The content of this document corresponds to the described products

and technologies. Stated data may be modified or supplemented for technical and/or

sales purposes.

Programming tools, manuals, templates, examples, etc. for the product can be

downloaded free of charge from www.seneca.it/products/z-modem-3g.

MI003781-E.DOCX ENGLISH 2/8

PRELIMINARY

WARNINGS

The full content of this manual must be read before performing any

operation. The module must only be used by qualified electricians. Specific

documentation is available from www.seneca.it/products/z-modem-3g

The module must be repaired and damaged parts replaced by the

Manufacturer. The product is sensitive to electrostatic discharges. Take

appropriate measures during any operation.

The warranty is null and void in the event the module or devices supplied by

the Manufacturer, necessary for its correct operation, are improperly used

or tampered with and, in any case, if the instructions contained in this

manual were not followed.

PRELIMINARY

USE

INSTRUCTIONS

Don’t obstruct ventilation slots with any objects.

Don’t place the module next to devices that generate heat.

GENERAL

SPECIFICATIONS

- Modem with HSDPA/UMTS/EDGE/GPRS protocol.

It can be connected to a wireless network with a SIM, that is without subscribing with

a physical provider using a cable connection such as a telephone network, ADSL, etc.

- 2 SMA connectors for the two antennas: MAIN and DIVERSITY.

For better performance we recommend to positioning the antennas at a 90° angle

between each other.

- The antenna supplied can be replaced with one with a higher gain.

- Removable terminals with section of 2.5 mm2.

- 5 frequency bands.

- Slot for push-push mini SIM.

- Micro USB 2.0 interface connector to exchange data with Z-TWS4 and Z-PASS1.

- The product can be installed on an IEC EN 60715 omega guide.

- LED front indications: Supply (PWR) and status (STAT).

MI003781-E.DOCX ENGLISH 3/8

TECHNICAL

SPECIFICTIONS

Power Supply

Power supply 11 −40 Vor 19 −28 V50/60Hz

Absorption 4.5 W max

Connections 0.2 – 2.5 mm

screw removable terminals (AWG 24-12)

Modem

Frequencies GSM / GPRS / EDGE

Quad-band: GSM850 GSM 900, DCS 1800, PCS 1900

UMTS / HSPA+

Dual-Band: WCDMA2100/900 2100/850, 1900/850

Transmitted power GSM/GPRS:

Class 4 (2W): GSM850, EGSM900

Class 1 (1W): DCS1800, PCS1900

EDGE:

Class E2 (0.5W): GSM850, EGSM900

Class E1 (0.4W): DCS1800, PCS1900

UMTS:

Class 3 (0.25W): WCDMA2100/900, 2100/850,1900/850

Connection speed GPRS Class B, multi-slot class 12,

Decoding: CS1-4,

Max download speed: 85.6kbps,

Max upload speed: 85.6kbps,

EDGE multi-slot class 12,

Decoding: MSC1-9,

Max download speed: 236.8kbps;

Max upload speed: 236.8kbps

UMTS R99 speed: 384 kbps Download/Upload

SIM5350L series: HSDPA category 10 - 14.4 Mbps+ HSUPA

category 6 - 5.76 Mbps

DRX Diversity receiver SIM

SIM type Mini SIM @ 3V

Introduction and removal Facilitated by the Push-push system

USB

Type Micro USB

Use Data transfer for Z-TWS4 and Z-PASS1

Antennas

"Main" antenna (mandatory) SMA female, 50 Ωimpedance

"Diversity" antenna (recommended)

SMA female, 50 Ωimpedance

MI003781-E.DOCX ENGLISH 4/8

Environmental Conditions

Protection rating IP20

Operating temperature -20 −+60 °C

Storage temperature -40 −+85 °C

Humidity 10 – 90% non condensing

Altitude up to 2000 m above sea level

Case

Weight 47g

Dimensions 41 x 44 x 26 mm (terminal excluded)

Case PA6, black

Standards

EN 301 511 Global System for Mobile communications (GSM);

Harmonized EN for mobile stations in the GSM 900

and GSM 1800 bands, article 3.2 of the R&TTE

Directive (1995/5/EC).

EN 301 489-1 Common technical requirements

EN 301 489-1 Specific conditions for mobile and portable radio

and ancillary equipment of digital cellular radio

telecommunications systems (GSM and DCS)

EN61000-6-4 Emission, industrial environment

EN64000-6-2 Immunity, industrial environment

EN60950 Safety

Insulations

1500 Vinsulation between modem and power supply

MI003781-E.DOCX ENGLISH 5/8

INSTALLATION

RULES

The module has been designed for vertical installation on an IEC EN 60715 omega guide. For optimal

operation and long working life, adequate ventilation must be provided. Avoid positioning cable ducts or

other objects so that they obstruct the ventilation slots. Avoid mounting modules over equipment

generating heat. Installation in the bottom part of the distribution board is recommended

OMEGA IEC EN 60715 guide installation on and removal from.

Insertion on the IEC EN 60715 guide:

1) Move the four hooks on the back of the module

outwards as illustrated in fig. 1b.

2) Insert the module aligning the IDC10 rear connector

to the female of the Seneca support for the IEC EN

60715 guide.

3) To secure the module to the guide, tighten the four

hooks on the side of the IDC10 rear connector as shown

in fig. 1a.

Removal from the IEC EN 60715 guide:

As illustrated in figure 1b:

1) Move outwards the four hooks on the side

of the module, using a screwdriver.

2) Extract the module from the guide.

ELECTRICAL

CONNECTIONS

IDC10 rear connector (POWER AND PORT 1)

In the figure you can see the meaning of the IDC10

connector pins if you want to provide signals

through them.

Module power is available from the rear connector

or via terminals 2 and 3.

Potential Z-PC-DINAL2-17.5 use

If the Z-PC-DINAL1-17.5 accessory is used the

power supply

and communication signals may be provided by the

terminals block.

The illustration shows the meaning of the various

terminals and DIP-switch position, found in all

Seneca supports for the IEC EN 60715 guide (not

used for the Modbus network).

GNDSHLD: Connection cable signal protection

shield (recommended).

MI003781-E.DOCX ENGLISH 6/8

Power Supply

The power supply must be connected to the

IDC10 bus or to terminals 2 and 3.

The supply voltage must be between 10 and

40V(any polarity), or between 19 and 28 V.

The upper limits must not be exceeded in

order to avoid serious damage to the

module.

The power supply source must be protected

from any malfunctions using appropriately-sized

safety fuses.

Micro USB

The module has a microUSB connector, you can connect the Z-MODEM-3G to Z-TWS4

or to Z-PASS1 through it. The adaptor cables, supplied with the module, must be

connected as shown in the figure.

For further information, refer to the Z-TWS4 or Z-PASS1 user manuals.

MI003781-E.DOCX ENGLISH 7/8

Antennas

Z-MODEM-3G

STAT

USB

One antenna (ANTENNA-STILO-EA247) is

supplied with Z-MODEM-3G.

This antenna must be screwed into the SMA

MAIN connector.

An second "diversity" antenna can be

connected to the module in order to improve

the performance of the modem.

For more performance you can use an antenna

with a better gain (see accessories).

Warning: The modem don’t work properly if

only the "div" (diversity) antenna is connected.

LED

INDICATIONS

THE

FRONTAL

PANEL

LED meaning

LED STATUS LED meaning

PWR Green ON The module is switched ON

PWR Green OFF The module is switched OFF

STAT yellow Flashing Connected to the network

STAT yellow Fast flashing PPP connection established

STAT yellow ON Network search

PURCHASE

ORDER

CODE

ANTENNA-STILO-EA247 SMA connector, 90° (like the one supplied)

A-GSM 3m cable, with sheathed adhesive antenna

ANT-LINK1-MG 3m cable, with magnetic-base antenna

CAVO-USBA-MICROB-MP 1m cable, from male A-type to male microB-type

MI003781-E.DOCX ENGLISH 8/8

MODULE

LAYOUT

111210

8 97

111,0 mm

17.5 mm100 mm

MicroUSBOTG

fordatainput

fromZ-TWS4 orZ-PASS1

ET004892B

Z-MODEM-3G

3G Modem for

Z-TWS4 /Z-PASS1

MADEIN ITALY

DIVERSITY

Antenna

MAIN

Antenna

PowerSupply 2,3

11-40Vdc

19-28Vac(50-60Hz)

Max3W

Connector

Rearbus

SIMCard

Push-Push

connector

Z-MODEM-3G

STAT

USB

DIV

MAIN

10.

DECOMMISSIONING

AND

DISPOSAL

Electrical and electronic waste disposal (applicable in the European Union and

other countries with recycling). The symbol on the product or packaging indicates

that the product cannot be discarded as domestic waste. It should be taken to an

authorised recycling centre for electrical and electronic waste. Ensuring that the

product is suitably discarded will avoid potential negative impacts on the

environment and human health, that could be caused by non compliant product

disposal. Material recycling will contribute to the preservation of natural resources.

To receive further information, please contact your local waste disposal service

centre or product dealer.
