• Sturdy metal housing (transmitter & receiver)

• PC-supported frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Wireless microphone with programmable, easy-access MUTE switch

• Quick-change microphone head from the e 800 Series

• Large range of replaceable microphone heads from the successful evolution Series

• NEW: Ethernet port for connecting to the Wireless Systems Manager (WSM) software for control via computer –

this delivers a good overview of monitoring and professional data management for multi-channel systems

• NEW: Wireless synchronization of transmitters via infrared interface

• NEW: Enhanced frequency bank with up to 24 compatible frequencies

• NEW: 42 MHz bandwidth  1680 switchable frequencies

• NEW: Increased range for audio sensitivity

• NEW: Large, illuminated dot matrix display with warning indicator

• NEW: More control options (menu)

• NEW: Enhanced AF frequency range

• NEW: Contacts for recharging the BA 2015 accupack directly in the transmitter

• NEW: Soundcheck mode

• NEW: Integrated equalizer

• NEW: Switchable RF output power

• 2 AA batteries for more than 8 hours of use

• 4-level charge indicator for transmitter battery

• HDX compander for crystal-clear sound

• True diversity receiver for optimum reception

• Incl. installation kit for 19" rack mounting (1 U)

High-class design, brilliant sound – the

evolution wireless gvocal set enables

you to present speakers, singers, actors

and presenters perfectly.

The microphone not only transmits

strong voices clearly, it also picks up the

soft tones with a high degree of expertise.

A range of selectable microphone heads

makes the gvocal set a highly ﬂexible

device that can be used on any stage –

regardless of whether a professional or

an amateur is speaking.

You Know

You CanVocal Set

300 Series

Vocal

Set

• Sturdy metal housing (transmitter & receiver)

• PC-supported frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Wireless microphone with programmable, easy-access MUTE switch

• Various optional quick-change microphone heads available from

the e 800 and e 900 series

Technical Data

ew 300 g

Modulation wideband FM

Frequency ranges 516-558, 566-608, 626-668, 734-776, 780-822, 823-865

Transmission/Receiving frequencies 20 channel banks, 6 xed banks, 24 factory preset channels each

Switching bandwidth 42 MHz

Noise reduction system Sennheiser HDX

AF frequency response 25 – 18.000 Hz

S/N ratio (at 1mV and peak deviation) ≥ 115 dBA

THD (at nominal deviation and 1 kHz) ≤ 0,9 %

EM 300 g

SKM 300 g

Delivery includes

Receiver principle True Diversity

Sensitivity (with HDX, peak deviation) <2 µV at 52 dBAeff S/N

Adjacent channel rejection ≥ 75 dB

Intermodulation attenuation ≥ 70 dB

Blocking ≥ 75 dB

Pilot-tone squelch detachable

Antenna inputs 4 BNC sockets

AF output voltage (at peak deviation, 1kHz AF) ¼" (6.3 mm) jack socket, unbalanced: +12 dBu XLR socket,

balanced: +18 dBu

Power supply 12 V DC

Dimensions 202 x 212 x 43 mm (7.95" x 8.35" x 1.69")

Weight approx. 980 g (2.16 lbs)

RF output power at 50 O typ. 30/10mW, switchable

AF frequency response 25 – 18.000 Hz

Power supply 2 AA batteries, 1.5 V

Nominal voltage 2.4 V

Operating time typ. 8h

Dimensions Ø 50 x 265 mm (Ø 1.97" x 10.43")

Weight approx. 450 g (15.87 oz)

• EM 300 g rack-mount receiver

• SKM 300 g handheld transmitter

• MZQ 1 microphone clip

• GA 3 rackmount adapter

For recommended accessories please visit www.sennheiser.com
