Sensor SFR 8200SS Reparaturanleitung

03/2020

- 1 -

EN Deep fryer

Translation of the original manual

SFR 8200SS

03/2020

- 2 -

EN Deep fryer

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

General warnings

■This appliance must not be used by children 0 to 8 years of

age.This appliance may be used by children 8 years old and

older when under continuous supervision. This appliance

may be used by persons with physical, sensory or mental

impairments or by persons with insufficient experience and

knowledge, if they are properly supervised or have been

informed about how to use the appliance in a safe manner

and understand the potential dangers.

■Children must not play with the appliance.

■Cleaning and maintenance performed by the user must

not be performed by unsupervised children.

■Keep the appliance and its power cord out of reach of

children younger than 8 years of age.

■In the event that the power cord is damaged, have it

repaired at a professional service centre to prevent causing

a dangerous situation. It is forbidden to use the appliance

if it has a damaged power cord.

■The surfaces of the appliance that come into contact with

food must always be cleaned according to the instructions

in this user's manual.

■This appliance is not designed to be controlled using a

programmed device, external timer switch or remote

control.

■This appliance is designed for domestic use and similar

locations such as:

03/2020

- 3 -

–kitchens in stores; offices and other workplaces;

–in agriculture;

–for guests of hotels, motels and other similar locations;

–in bed and breakfast establishments.

■The appliance must be located in a stable position with the

handles positioned in such a way as to prevent spilling hot

liquids.

■The outer body of the appliance, the frying pot, the frying

basket and the inside parts of the lid become very hot

during use!

Electrical safety

■ Before connecting this appliance to a power socket, make sure that the voltage stated on its rating label corresponds to the voltage in your power socket.

■ Connect the appliance only to a properly grounded socket. Do not use an extension cord.

■ Do not connect and disconnect the power cord to and from the power socket with wet hands.

■ Ensure that the power plug contacts do not come into contact with water or moisture.

■ Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket. Disconnect the

cord from the power socket by gently pulling the plug of the power cord.

■ Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of a table and that it is not touching a hot surface or

sharp objects.

■ To avoid the danger of injury by electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments of the

appliance performed at an authorised service centre. Tampering with the appliance during the warranty period may void the warranty.

■ To prevent the risk of injury by electrical shock, never submerge the slow cooker unit, the power cord or the power plug in water or any other liquid.

■ Always turn off the appliance and disconnect it from the power socket when you have finished using it.

Correct use of the appliance

■ This appliance is used for frying food. It is not intended for bringing liquids to a boil. Do not use it for any other purpose than for which it was designed.

■ This appliance is designed for use in indoor areas only. Never use it in an outdoor or industrial environment.

■ This appliance must be used only in accordance with the instructions contained in this user's manual.

■ Only use the appliance with the original accessories that came with it.

Attention:

Using non-original accessories may result in a dangerous situation arising.

■ Do not use the appliance for indoor heating purposes!

■ Always turn off and disconnect the appliance from the mains power socket when not using it, when leaving it without supervision, before cleaning,

maintenance or moving it. Never move the appliance during operation.

■ Do not use the appliance when it is not functioning correctly or after it has fallen on the floor, been submerged in water or is damaged in any other way. Hand

it over to an authorised service centre for inspection or repair.

■ Do not turn on the appliance without the frying pot being filled with the frying medium.

■ Do not place any items into the frying pot except for the frying basket.

■ It is forbidden to modify the surface of the appliance in any way, e.g. using self-adhesive wallpaper, foil, etc.

Installation location of the appliance

■ Only use the appliance on an even, dry, clean, stable surface and heat resistant surface.

■ Do not use the appliance near flammable materials such as curtains, kitchen towels, etc.

■ Do not place the appliance on the edge of a table, on a drainboard, on unstable, inclining or uneven surfaces, on an electric or gas stove and other sources

of heat, or in their vicinity.

■ To ensure sufficient air circulation during operation, there must be a clearance of at least 15 cm on all sides of the appliance. Do not place any items on to the

appliance and do not cover the ventilation openings.

■ Do not place the appliance in the vicinity of items, surfaces or under items that may become damaged, for example walls, kitchen cabinets, cupboards,

paintings, curtains. The escaping steam could damage them.

Safety during use

■ Prior to pouring the frying medium into the appliance, ensure that all its parts are completely dry. With the same level of care, dry all foods prior to placing

them into the deep fryer. Otherwise, the hot frying medium will start splashing.

■ Be especially careful when handling frozen foods. Remove all pieces of ice. The more ice that remains on the food, the more the frying medium will splash.

■ An old, especially dirty, frying medium may ignite spontaneously when overheated. Replace the frying medium in a timely manner. In the event of a fire,

unplug the power plug and smother out the burning frying medium with a blanket.

03/2020

- 4 -

Warning:

Never use water for extinguishing a deep fryer fire.

■ Never add more frying medium into the frying pot than up to the MAX mark and never less than to the MIN mark. Whenever turning on the deep fryer, ensure

that there is a sufficient amount of frying medium inside.

■ Never turn on the appliance when there is no frying medium inside the frying pot. Otherwise, it may overheat.

■ Never melt pieces of shortening fat in the deep fryer. If the shortening fat does not cover the hotplate, the resulting high temperature may result in damage

to the appliance or a fire! Dissolve the shortening fat in another pot or similar container prior to using it.

■ The appliance must not be left without supervision when it is in operation.

■ When operating the appliance, the lid must be properly closed. Do not place any items on to the lid (e.g. protective gloves, wiping cloths) that could cover

the steam outlet.

■ During operation there needs to be sufficient area for air circulation above the appliance and around it. Do not cover the appliance or block its vent.

■ Make sure that the steam exhaust outlet does not point towards heat sensitive materials or you or other people. Hot steam may cause serious scalding.

■ While deep frying, do not touch places where hot steam is being emitted as this may cause burns or scalding.

■ Be careful when opening the lid; ensure that the steam escapes away from your body.

■ Do not place your hands into the internal area of the appliance while it is running.

■ Avoid contact with hot steam, which is released from the vents while the appliance is running.

■ When the appliance is in operation, the temperature of accessible surfaces may be higher. Do not touch the hot surface. Otherwise, this could cause burns.

Use the handle to remove and carry the hot frying basket.

■ Make sure that no water or any other liquid splashes on the power plug or the power socket, and that the hot steam emitted from the appliance is also kept

away. If this, nevertheless, occurs, disengage the circuit breaker of the power socket and then carefully dry the power socket and the power plug before

further use.

■ Do not place the hot frying basket on heat sensitive surfaces.

Handling the appliance and its parts

■ When you have finished using the appliance, always handle it in such a way as not to touch its outer surface or other parts that may still be hot as a result of

residual heat.

■ Do not touch the hot surfaces of the appliance. After turning off and disconnecting the appliance from the power socket, use the appliance's carry handles to

lift and carry it. For reasons of increased safety, we recommend using oven mitts.

■ It is necessary to pay exceptional care when moving the frying basket when it is filled with hot food.

Safety during maintenance

■ Allow the appliance to always fully cool down before cleaning it.

■ Regularly clean the appliance after each use according to the instructions in chapter Maintenance and cleaning. Do not perform any maintenance on the

appliance apart from the maintenance procedure described in chapter Maintenance and cleaning.

■ The outer body of the appliance is not intended to be washed in a dishwasher.

■ Never wash the appliance under running water or submerge it in water or another liquid.

03/2020

- 5 -

SFR 8200SS

MAX

MIN

03/2020

- 6 -

88:88

ON/OFF TIMEMODE TEMP

17min

25min

36min

46min

55min

03/2020

- 7 -

- 8 - 03/2020

EN Deep fryer

User's manual

■ Prior to using this appliance, please read the user's manual thoroughly, even in

cases, when one has already familiarised themselves with previous use of similar

types of appliances. Only use the appliance in the manner described in this user’s

manual. Keep this user's manual in a safe place where it can be easily retrieved for

future use. In the event that you hand this appliance over to somebody else, make

sure to also include this user's manual.

■ Carefully unpack the appliance and take care not to throw away any part of

the packaging before you find all its parts. We recommend saving the original

cardboard box, packaging material, purchase receipt and responsibility statement

of the vendor or warranty card for at least the duration of the legal liability

for unsatisfactory performance or quality. In the event of transportation, we

recommend that you pack the appliance in the original box from the manufacturer.

DESCRIPTION OF THE APPLIANCE

A1 Lid

A2 Viewing window for inspecting the

frying process

A3 Frying basket from chrome-plated

steel

A4 Removable basket handle

A5 Fixed basket bracket for draining

the frying medium

A6 Heating element

A7 Frying pot

A8 Deep fryer body

A9 Lid handle

A10 Vents

A11 Control elements

A12 Heating module with a power cord

compartment

A13 Minimum and maximum frying

medium level marks

A14 Handles of the deep fryer unit

They are heat-resistant and prevent

any burns and enable the handling

of the appliance while it is operation

without the need for protective

gloves

B1 Handle wires B2 Wire holder

C1 Digital display

C2 ON/OFF button (start/stop)

Serves to start and stop deep frying

C3 MODE button

Enables the selection of one of five

preset deep frying programs

C4 TIME button

Enables the setting of a frying time

in the range from 1 to 99 minutes in

1-minute increments.

C5 TEMP button (temperature)

Enables the setting of a frying

temperature in the range from 110

to 190°C in 5°C increments.

D1 Cover plate

D2 Metal filter

D3 Transparent glass

INTENDED USE OF THE DEEP FRYER

■ This deep fryer is intended exclusively for deep frying food using suitable oil or

shortening fat. It is not intended for heating water or other liquids or for cooking

food directly in the frying pot without the use of a frying medium.

BEFORE FIRST USE

■ Before first use, wash the lid A1, frying basket A3 with handle A4 and frying pot

A7 in a hot detergent solution. Then rinse all these parts with clean water and dry

them thoroughly with a fine wiping cloth. The frying pot can also be washed in a

dishwasher.

■ Also clean out the inner and outer parts of the deep fryer unit unit using a lightly

dampened wiping cloth and then wipe it dry. Never submerge the deep fryer unit

in water or any other liquid!

OPERATION

PREPARING THE DEEP FRYER FOR FRYING

■ Place the deep fryer on a suitable even surface that is out of children's reach. Always

position the handles of the deep fryer so that nobody can brush against them and

knock or tilt the deep fryer over, or spill its hot contents.

■ If you wish to place the deep fryer on a cooktop underneath a range hood, ensure

that the cooktop is turned off.

■ Take out the frying basket and insert the handle A4 into the frying basket by

squeezing the basket wires B1 towards each other with your fingers and insert the

bent ends into the holes in the bracket B2 on the basket.Then apply gentle pressure

to secure the wires in the bracket. An audible click will be heard.

■ Insert the dry and empty frying pot A7 into the deep fryer unit. Insert the heating

module A12 with the heating element A6 into the frying pot.

■ Pour the frying medium (deep frying oil or shortening/fat) into the frying pot. Only

use oils and shortening fats that are explicitly marked as "non-frothing" and suitable

for deep frying. This information is provided on the packaging or label.

Warning:

Never pour more frying medium into the frying pot than up to the

MAX mark and never less than up to the MIN mark.

Never pour any liquid, for example water, into the frying pot.

Never combine various types of shortening fats or oils together.

They could overflow out of the deep fryer.

■ Clean the top edge of the frying pot and any other parts, which have been soiled

while the frying pot was being filled.

FOOD PREPARATION

■ As a rule, cut food into equal-sized pieces to ensure that it cooks evenly.

■ If the food intended for deep frying is damp, then dry it first. Always season food

with spices only after frying and do not apply the spices above the frying pot or

during the course of frying.

■ If you wish to deep fry coated/battered food, ensure that it is evenly coated/battered

and that any excess breadcrumbs are tapped off because loose breadcrumbs spoil

the quality of the frying medium.

■ Certain types of food, such as doughnuts, can be deep fried directly in the frying pot

containing the frying medium without using the frying basket.

■ Cut large pieces of food, e.g. chickens, into smaller pieces. This will prevent

subsequent scalding when removing the food from the basket.

■ Do not place too many food pieces on top of each other, they could stick together.

■ Remove any excess ice from frozen foods since it could cause the oil to boil over.

■ Do not fill the basket more than halfway, otherwise the temperature of the frying

medium will fall and the frying result will not be optimal.

TURNING ON AND STAND-BY MODE

■ Connect the power cord plug to a power socket. The appliance will beep, button

C2 (ON/OFF) and button C3 (MODE) will be lit and P001 will appear on the display.

In this way the deep fryer enters the stand-by mode, meaning that it is ready for

operation.

USING THE PRESET PROGRAMS

■ The deep fryer has five preset programs enabling you to quickly and easily prepare

various types of meals without needing to set the time and temperature.

■ Repeatedly press button C3 (MODE) and select one of the programs from the table

below.

Program

number Icon Food Temperature

(°C)

Frying time

(mins)

P001 French fries 190 7

P002 Meat 180 5

P003 Prawns 170 6

P004 Chicken 160 6

P005 Mushrooms 150 5

■ Press button C2 (ON/ OFF). The display will show the current temperature of

the frying medium and the deep fryer will start preheating to the temperature

corresponding to the selected program. The preset time or target temperature

can be shown during the preheating process by pressing button C4 (TIME) or C5

(TEMP). After 5 seconds, the shown time/temperature will automatically switch back

to showing the current temperature of the frying medium.

Note:

If button C4 (TIME) or C5 (TEMP) is pressed more than once during the

preheating process, this will change the preset time or temperature. If

you wish to retain the initial program settings, then stop the preheating

process by pressing C2 (ON/OFF) and use button C3 (MODE) to again

select the same program and start it by pressing C2 (ON/OFF).

■ When the preheating process is finished, the appliance will beep and the display will

show the achieved temperature and the deep fryer will wait for your next action.

Continue according to chapter DEEP FRYING.

SETTING CUSTOM TEMPERATURE AND TIME

■ The deep fryer enables the setting of temperature and time according individual

preferences.

Note:

Information about the appropriate temperature is provided on

the labelling of the food or in the table in this user's manual, see

RECOMMENDED TIME AND TEMPERATURE TABLE.

■ To set a custom time, press button C4 (TIME). The button will be lit and the default

time of 07:00 minutes will start flashing on the display.Then repeatedly press button

C4 (TIME) to set the time in the range from 01:00 to 99:00 minutes in 1-minute

increments.

■ To set a custom temperature, press button 5 (TEMP). The button will be lit and the

default temperature of 190°C will start flashing on the display.

■ Then repeatedly press button C5 (TEMP) to set the time in the range from 110 to

190°C in 5°C increments.

■ Press button C2 (ON/ OFF). The display will show the current temperature of

the frying medium and the deep fryer will start preheating to the temperature

corresponding to the selected program. The preset time or target temperature

can be shown during the preheating process by pressing button C4 (TIME) or C5

(TEMP). After 5 seconds, the shown time/temperature will switch back to showing

the current temperature of the frying medium.

■ When the preheating process is finished, the appliance will beep and the display will

show the achieved temperature and the deep fryer will wait for your next action.

Continue according to chapter DEEP FRYING.

- 9 - 03/2020

DEEP FRYING

■ Carefully take off the lid, slowly insert the basket with the food into the frying pot

with the preheated frying medium and put the lid back on.

Attention:

When deep frying food that contains a large amount of water or

frozen foods, lower the basket into the frying medium slowly. This

will prevent it from overflowing.

■ Press button C2 (ON/ OFF). The countdown of the preset time will start and deep

frying will commence.

Note:

Steam may escape from underneath the lid during the deep frying

process. This is normal and does not constitute a fault.

■ While frying, we recommend to stir the food occasionally to prevent it from sticking

together. You can monitor the progress of deep frying through the viewing window

in the lid.

Attention:

When deep frying food that contains a large amount of water or

frozen foods, lower the basket into the frying medium slowly. This

will prevent it from overflowing.

Note:

The thermostat will automatically turn on and off to maintain the correct

temperature of the frying medium. Based on this, the power indicator

light will intermittently turn on and off.

The deep frying process can be stopped at any time by pressing button

C2 (ON/OFF).

Warning:

The deep fryer and its lid are very hot during the deep frying

process. In the event that it is necessary to handle the deep fryer

during its operation, always use oven mitts and only handle it

using the handles on the deep fryer unit.

■ When the preset time has elapsed, the deep fryer will beep and switch to the stand-

by mode and P001 will appear on the display. In this way, the deep frying process

is finished.

FINISHING DEEP FRYING

■ When the deep frying process ends in any of the above-described modes, always

remove the lid in such a way as to avoid coming into contact with the hot steam, lift

the basket above the level of the frying medium and hang it on the fixed bracket A5

into the resting position on the deep fryer unit. Allow excess oil to drip off the food.

Warning:

Never touch the frying basket when you have finished deep

frying, it is very hot! Lift the frying basket out of the deep fryer

only by the basket handle.

■ Allow the deep fryer to cool down without the lid to prevent water from condensing.

■ After the oil drips off, put the deep fried food into a suitable container. We

recommend to line the container with a suitable kitchen paper towel.

RECOMMENDED TIME AND TEMPERATURE TABLE

■ Generally, it is recommended to use lower temperatures for brittle foods (vegetables,

fish) and higher temperatures for frozen foods (French fries, chicken, etc.).

Note:

The frying times and temperatures are only of informative character.

Food Temperature (°C)

Mushrooms 150

Onion rings 150

Zucchini 150

Chicken 160

Fondue from Parmesan 170

Cheese croquettes 170

Fish 170

Fish fingers 180

Fried prawns 180

Fried cheese 180

Doughnuts 190

French fries (frozen) Phase 1 170

Phase 2 190

Meat/fish/potato croquettes 190

DEEP FRYING TIPS

■ When frying lighter foods such as French fries, select a higher temperature. On the

other hand when frying bulkier foods such as chicken drumsticks or meat balls,

select lower temperatures to ensure the foods are evenly fried inside.

■ It is appropriate to fry French fries in two phases. In the first phase, fry them for 5-10

minutes at 170°C and then allow them to cool down. In the second phase, fry them

for 2-4 minutes at 190°C.

■ When frying several food types start with those that require the lower temperature.

■ When frying pre-fried foods, use a higher temperature and a shorter frying time

than for raw foods.

REMOVING UNPLEASANT ODOURS FROM THE FRYING

MEDIUM

■ Some foods, for example fish, may impart an unpleasant odour to the frying

medium. This odour can be neutralised using the following method:

– heat the frying medium to a temperature of 160 ˚C

– place a few shoots of parsley or two slices of bread into the frying medium,

– wait until "bubbles" stop forming, then using a suitable utensil, remove the

parsley or bread.

Overheating protection

■ The fryer is equipped with a safety fuse against overheating, which protects it

against damage. In the event of the fryer heating up excessively, e.g. due to long

use or accidentally starting it without the frying medium, the safety fuse against

overheating will be activated automatically. In such a case, the deep fryer will shut

off. Disconnect the deep fryer from the power socket and allow it to cool down.

Contact an authorised service centre to request a replacement of the safety fuse.

Under no circumstances should you replace the safety fuse yourself.

Attention:

Despite the fact that the deep fryer has overheating protection,

do not use it empty without the frying medium. The incorrect

use of the deep fryer may negatively affect its working order and

lifetime.

HANDLING THE FRYING MEDIUM

■ When not using the deep fryer regularly, it is recommended to pour the cooled

down frying medium into enclosed bottles or other deep frying containers and to

store it in a refrigerator or another cool place. Pour the frying medium into bottles

through a fine strainer to filter out food residues.

Warning:

Prior to transferring the frying medium, always allow it to cool

down sufficiently to prevent serious burns.

■ It is not necessary to replace the frying medium after every use. If you fry mainly

potatoes and filter the frying medium, it is possible is reuse it 8 to 10×. Do not use

the same frying medium for more than 6 months.

■ Always replace the frying medium when:

– it has a brown colour or from the very beginning stinks or smokes

– there is too much water in it. A high water concentration in the oil or shortening/

fat is indicated by bubbles and water drops, water steam and a rapidly rising

oil or shortening/fat. If the water concentration in the deep fryer is too high, it

may happen that the oil or shortening fat may explode out, which can be very

dangerous to both the people using the deep fryer as well as those in its vicinity.

If you wish to replace the frying medium, proceed as follows:

– prepare a container with an appropriate volume

– disconnect the deep fryer from the power grid

– tilt open the lid, take out the frying basket, hold the deep fryer unit by its handles

and pour out the frying medium into the prepared container

Warning:

Replace the frying medium only after it has cooled down

completely. In the event that shortening fat was used, it must still

be partially liquid for it to be poured out.

- 10 - 03/2020

■ Never pour used frying medium into standard household waste. Every municipality

has different regulations for the disposal of table oils and fats. Request information

about your disposal options at the municipal or town council office.

■ If you wish to only filter out the frying medium, proceed as follows:

– disconnect the deep fryer from the power grid

– pour the completely cooled down frying medium from the frying pot into

another container with a suitable volume capacity.

– wash the frying pot and dry it thoroughly

– pour the frying medium back through an appropriate filtration paper

CLEANING AND MAINTENANCE

Attention:

Prior to any cleaning or maintenance, always disconnect the deep

fryer from the power grid and allow it to cool down completely.

Attention:

The deep fryer unit, power cord and the heating element are not

intended for washing in a dishwasher.

Do not spray these parts with water or any other liquid or

submerge them in water or any another liquid.

■ We recommend cleaning the deep fryer immediately after it cools down to prevent

food scraps from drying on. These are harder to remove later.

■ After every use, wipe the deep fryer unit and the heating module with heating

element using a soft damp cloth; wipe the power cord using a dry cloth.

■ Wash the lid, frying basket including the handle, the frying pot in hot water with

detergent, rinse and dry thoroughly with a fine wiping cloth. The frying pot can also

be washed in a dishwasher.

■ Wipe out the inside of the deep fryer unit using paper towels, tougher soils can be

cleaned using a soft sponge and then wipe it dry.

■ In the event that the filter D2 or the viewing window glass D3 are very dirty, screw

out the cover plate D1 from the underside of the lid, wash the filter and the glass

in hot water with detergent, rinse and dry thoroughly with a fine cloth. Return both

parts to their place and screw the cover plate back on.

Attention:

To clean the deep fryer unit or the frying pot, never use chemicals,

dishwashing abrasive wool, steel wool or cleaning products with

abrasive component since these can damage them.

■ After pouring out the frying medium, always remove any dripped frying medium

and remains from prior deep frying.

STORAGE

■ Before storing it, the deep fryer must be completely cool and disconnected from the

power supply, clean and dry.

■ Assemble the deep fryer in the same way as for frying and put on the lid.

■ Then store the deep fryer in a clean, dry and well-ventilated place out of children's

reach.

Attention:

Keep the stored deep fryer away from extreme temperatures,

direct sunlight and excessive humidity and do not store it in an

overly dusty environment. Do not place any items on the stored

deep fryer.

TROUBLESHOOTING

■ If the appliance does not work as described in the user's manual, check the list of

most frequent problems below in order to remedy the problem. In the event that

your problem is not listed or if the problem persists, turn off the appliance, pull the

power plug out of the power socket and contact an authorised service centre. Under

no circumstances should you attempt to repair the appliance yourself.

Problem Possible cause Solution

The fryer is not

working

The fryer is not connected to

a power socket.

Check that the power plug is

connected to a power socket.

You did not turn on the

fryer, you did not set the

temperature.

Turn on the deep fryer and set

it to one of the temperatures.

The deep fryer overheated

and protection was activated.

Wait several minutes for the

deep fryer to cool down

and try turning it on again.

If necessary, contact an

authorised service centre.

Food is insufficiently

cooked.

You set a temperature that

is too low. Increase the temperature

Too much food in the frying

basket. Remove some of the food.

The food contains remains of

ice or too much moisture.

Before frying, remove the ice

remains and thoroughly dry

the food.

Fresh French fries

are not crispy.

The crispiness of fresh Fresh

fries depends on the amount

of oil and water content.

Thoroughly dry French fries

before frying them. Slice

them up

into smaller pieces and add

more oil if necessary.

The frying medium

foams excessively

during the deep

frying process.

The food contains remains of

ice or too much moisture.

Before frying, remove the ice

remains and thoroughly dry

the food.

The frying medium is not

suitable for frying.

Use oil or shortening fat

suitable for frying.

The frying medium has been

used for too

long.

Replace the frying medium.

The deep fryer

is emitting an

unpleasant odour.

The frying medium is no

longer fresh. Replace the frying medium.

The frying medium is not

suitable for frying.

Use oil or shortening fat

recommended for frying. Do

not combine various types of

oil and shortening fat.

The text EEE is

shown on the

display.

Faulty temperature sensor.

Immediately stop using the

deep fryer and contact an

authorised service centre.

TECHNICAL SPECIFICATIONS

Rated voltage range ...............................................................................................................230 V AC

Rated frequency........................................................................................................................50/60 Hz

Rated power input.....................................................................................................................2,400 W

Frying pot capacity......................................................................3.2 litres / 1.4 kg of French fries

Dimensions (height × width × depth)....................................195 mm × 215 mm × 364 mm

Weight...................................................................................................................................................3 kg

Changes to text and technical parameters are reserved.

INSTRUCTIONS AND INFORMATION REGARDING THE

DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at a site designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC

EQUIPMENT

This symbol on products or original documents means that used

electric or electronic products must not be added to ordinary

municipal waste. For proper disposal, renewal and recycling, hand

these products over to determined collection points. Alternatively, in

some European Union states or other European countries you may

return your appliances to the local retailer when buying an equivalent

new appliance.

Correct disposal of this product helps save valuable natural resources

and prevents potential negative effects on the environment and human health, which

could result from improper waste disposal. Ask your local authorities or collection

facility for more details.

In accordance with national regulations penalties may be imposed for the incorrect

disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic devices, ask your retailer or supplier for

the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product,

request the necessary information about the correct disposal method from the local

council or from your retailer.

This product meets all the basic requirements of EU directives related to

it.

Inhaltsverzeichnis

Andere Sensor Fritteuse Handbücher

Sensor

Sensor SFR 7200SS Reparaturanleitung

Beliebte Fritteuse Handbücher anderer Marken

Innsky

Innsky 55SA1US Bedienungsanleitung

Falcon

Falcon G350/11 Benutzerhandbuch

GoWISE USA

GoWISE USA GW22612 Bedienungsanleitung

Wolf

Wolf IF15/S Bedienungsanleitung

Electrolux

Electrolux Thermetic 9CHG583284 Kurzanleitung

Gourmia

Gourmia GAF799 Bedienungsanleitung

DeLonghi

DeLonghi D677UX Bedienungsanleitung

SEVERIN

SEVERIN DEEP FRYER - Benutzerhandbuch

Toastmaster

Toastmaster TMFG18-NAT Bedienungsanleitung

Domo

Domo DO465FR Bedienungsanleitung

Henny Penny

Henny Penny PFG-691 Bedienungsanleitung

Farberware

Farberware FBW FT 43721 B Bedienungsanleitung

GERMANICA

GERMANICA GEAF5L3LD Bedienungsanleitung

Roller Grill

Roller Grill MF 120 R Bedienungsanleitung

Philips

Philips HD9211 Bedienungsanleitung

Linea 2000

Linea 2000 Domo DO536FR Bedienungsanleitung

Lakeland

Lakeland 31796 Bedienungsanleitung

Dash

Dash Tasti-Crisp DFAF755 Bedienungsanleitung
