Serene HD 40P Bedienungsanleitung

HIGH DEFINITION AMPLIFIED TELEPHONE

Operating Guide

HD 40P

Manueldel’utilisateur

Important safety Instructions

Read all the instructions before using the appliance.1.

To reduce the risk of injury, close supervision is2. necessary when an appliance is used near children.

Do not contact moving parts or any exposed metal

3. surface.

Only use attachments recommended or sold by the

4. manufacturer.

Do not use outdoors. Do not use near water, for

5. example, near a bath tub, wash bowl, kitchen sink or

laundry tub, in a wet basement or near a swimming

pool.

To disconnect, turn all controls to the off position,

6. then remove plug from outlet.

Do not unplug by pulling on cord. To unplug, grasp

7. the plug, not the cord.

Unplug from outlet when not in use and before servicing or

8. cleaning.

Do not operate any appliance with a damaged cord or plug, or

9. after the appliance malfunctions or is dropped or damaged in

any manner. Return appliance to the nearest authorized service

facility for examination, repair, or electrical or mechanical

adjustment.

Use only the power cord and batteries indicated in the manual.

10. Do not dispose of batteries in ﬁre. They may explode. Check

local codes for possible special disposal instructions.

Plug any power adapter to the socket-outlet that near the

11. equipment and should be easily accessible.

Avoid using any telephone product during an electrical storm.

12. There may be a remote risk of electric shock from lightning.

Do not use the telephone to report a gas leak in the vicinity of

13. the leak.

“SAVETHESE INSTRUCTIONS”

WARNING – When using telephone equipment or electric appliances, basic precautions should always be followed to reduce the risk

of ﬁre, electrical shock and injury to persons, including the following:

Package Contents

Your package includes all the items as shown here. If there

is anything missing, please contact our Customer Care

Department immediately.

English

123 4 5 6 7

15 12 13 14

Handset hook (for wall mounting use only)1.

One-touch memory dialing buttons2.

Hold (press to put call on hold and to mute the handset, lift the3.

handset or a quick press of the hook switch releases the Hold)

Prog (press to program number into memory)4.

Amplify (press to turn on/off the powerful handset ampliﬁer5.

manually)

Flash (press to switch between current call and the call waiting)6.

Redial (This is a dual function button. It is a last number redial7.

button during normal usage. However, it becomes a PAUSE

button during memory programming. Press this button inserts

a 2-second pause into the phone number string. For example:

9 PAUSE 755 8222 dials 9 and then pauses for 2-second before

dialing out rest of the phone number.)

Tone/Pulse (This slide switch selects tone dialing or pulse8.

dialing. Tone dialing is faster).

Ringer Tone (to select a ring tone to suit your hearing)9.

Feature Identiﬁcation

Ringer Volume (to select a ringing volume level to suit your10.

hearing)

Speaker on/off with indicator (Press this button to turn11.

on / off the speakerphone for hands-free dialing or

conversation. Handset must be on its cradle in order for

this feature to work.)

Tone (to enhance speech clarity; move it until you hear the12.

best incoming speech clarity while on the phone. Positions

1 thru 4 enhance low, mid, mid-high, and high tone part of

the speech respectively)

Volume (to adjust the volume of the handset).13.

Amplify LED indicator14.

Call-on-hold visual indicator.15.

Ampliﬁer Auto On/Off (On: the ampliﬁer will come on16.

automatically and return to the previous level setting

every time you lift the handset. Off: the ampliﬁer will not

come on automatically; you must press Amplify to turn

on the ampliﬁer).

English

Connect your phone as shown. When

ﬁnished, lift handset to test. If you hear a

dial tone, your telephone is ready. If not,

check all connections again.

Connections

English

Slide out the handset hook, turn it upside down and reinsert. This hook keeps the

1. handset in place when wall mounted.

Fit the wall mount bracket into the base of the phone.

Connect the short phone cord. Align and put the mounting holes over the heads3. of the wall plate screws (make sure the screw head protrude enough, if not, use

a screw driver to adjust) and slide the phone downward slightly to lock the phone

in place.

Wall Mounting

Using the Speakerphone

Press the Speaker button to turn on the speakerphone. Or, if1.

you are on the phone, press the Speaker button then returns the

handset back to its cradle.

Adjust the Volume switch to reach a comfortable level.2.

Press the Speaker button again to end the call.3.

Press the HOLD button during a call mutes the microphone and4.

the call is placed on Music-On-Hold mode. Press it again releases

the hold and un-mutes the microphone.)

12 3

Amplifying incoming sounds Manually/Automatic

English

When you are on the phone, press the Amplify button to turn on1.

the ampliﬁer

Adjust the Volume switch to reach a comfortable sound level.2.

Adjust theTone switch until you can hear the incoming voice3.

clearly.This needs to be done the ﬁrst time you use the phone only

and you can leave this setting for all future calls.

If you want the ampliﬁer to come-on automatically every time4.

you use the phone, slide the Ampliﬁer Auto On/Off switch on the

underside to the On position.To turn off the ampliﬁer (for the non

hard-of-hearing user), press the Amplify button.To return to the

Auto-on mode, press

Ampliﬁer again.

Programming Number for One-Touch Memory Dialing

Lift the handset, press PROG.1.

Dial the phone number you wish to save (maximum of 15 digits).2.

Press PROG again.3.

Press the memory button you wish to store the phone4.

number, then hang up the phone.
