VLW60T
Manual display unit and conguration for MODBUS level meters.
technical documentation ENG Rev. A
Page 2 of 24 www.sgm-lektra.com
VLW60T - index
INDEX
1-WARRANTY
2-PRODUCT
3-TECHNICAL SPECIFICATIONS
4-DIMENSIONS
5-INSTALLATION
6-ELECTRICAL CONNECTIONS
7-DISPLAY
8-CONFIGURATIONS
9-TESTING/QUALITY CERTIFICATE
page. 3
page. 4
page. 5
page. 6
page. 7
page. 9
page. 13
page. 14
page. 24
Page 3 of 24
www.sgm-lektra.eu
Products supplied by SGM LEKTRA are guaranteed for a period of 12 (twelve) months from delivery date
according to the conditions specied in our sale conditions document.
SGM LEKTRA can choose to repair or replace the Product.
If the Product is repaired it will maintain the original warranty terms, whereas if the Product is replaced it will have
12 (twelve) months of warranty. The warranty will be null if the Client modies, repairs or uses the Products for
other purposes than the normal conditions foreseen by instructions or Contract.
In no circumstances shall SGM LEKTRA be liable for direct, indirect or consequential or other loss or damage
whether caused by negligence on the part of the company or its employees or otherwise howsoever arising out of
defective goods.
1-WARRANTY
VLW60T - warranty
Page 4 of 24 www.sgm-lektra.com
VLW60T - product
2- PRODUCT
2.1 IDENTIFICATION
Each instrument has an adhesive identication plate on which the main instrument data are reported.
The following image describes the information and data on the plate.
2
Model: VLW60T
Input power: 24 Vdc ±20%
Max: 400mA @ 24Vdc,Class2
Serial number: MA0111803398
1. Model
2. Power supply
3. Serial number
12 3 4
5
1. Ethernet
2. USB Host
3. COM1 RS-232, RS-485 2W/4W
COM3 RS-485 2W
4. Power Connector - Morsetto estraibile
5. Skintop M20x1.5
1
2
3
VERSION “A” VERSION “B”
Page 5 of 24
www.sgm-lektra.eu
3-TECHNICAL FEATURES
Display
4.3 “TFT colour resistive touch LCD, 480 x 272 resolution, LED backlight (Life Time> 30000h)
Digital ports
COM Ports: COM1 RS485 (A, B)
RTC Battery
Integrated
Power supply
Version “A” 24Vdc ±20%
Version “B” 85-230Vac (50/60Hz) / 24Vdc/ac
Consumption
Max 15W
Casing material
Version “A” Plastic
Version “B” ABS - Polycarbonate
Dimensions l x h x d (mm)
Version “A” 128x102x32
Version “B” 183.5x250x126
Recess dimensions (mm)
119x93
Assembly
Version “A” panel-type
Version “B” wall mounted, on pole or on DIN bar, with ABS enclosure and clear cover
Front protection
Version “A” IP65 / NEMA4
Version “B” IP66
Storage temperature
-20°÷60°C
Operating temperature
0÷50°C
Relative humidity
10÷90% (senza condensa)
Certied
CE
VLW60T - technical features
Page 6 of 24 www.sgm-lektra.com
VLW60T - dimensions
4-DIMENSIONS
4.1 MECHANICAL DIMENSIONS VERSION “A”
102mm
128mm
92mm
118mm
32mm
126mm 183.5mm
250mm
4.2 MECHANICAL DIMENSIONS VERSION “B”
Page 7 of 24
www.sgm-lektra.eu
VLW60T - installation
5.1 ASSEMBLY OF PANEL FRONT VERSION “A”
Place the instrument in the prepared slot (119x93mm) and fasten the xing supports.
(tightening torque: 0.3÷0.45 Nm to guarantee the seal of the gasket without deforming the panel).
5-INSTALLATION
Page 8 of 24 www.sgm-lektra.com
VLW60T - installation
5.2 WALL MOUNTING OR ON DIN BAR VERSION “B”
• Installation must only be performed by qualied personnel and in compliance with current regulations.
• Install the unit in an environment compatible with the physical characteristics and construction materials of the
enclosure; for outdoor installations, protect the unit from rain and sun with a protective roof.
• Incorrect use of the device could cause serious damage to persons, the product and the equipment connected to it.
125mm
183.5mm
35mm
149mm
Page 9 of 24
www.sgm-lektra.eu
VLW60T - electrical connections
6.1 ELECTRICAL CONNECTIONS VERSION “A” (FRONT PANEL ASSEMBLY)
MODBUS PORT CONNECTION TO THE METER PROBES/KTU5/MTU/PTU/RPL75
The MODBUS connection for connection to the probes must be made to the COM1 [RS485] with 2 wires:
• Pin 1 > B
• Pin 2 > A
6-ELECTRICAL CONNECTIONS
24Vdc
0V
SCH
1 2 34
5678 9
6.2 POWER SUPPLY VOLTAGE CONNECTION 24VDC
The supply voltage must be connected to the removable terminal.
Ground
0V
+24Vdc
Power supply unit 24Vdc – min. 500mA
METER / MTU / RPL75
COM1 [RS485] PTU5x
KTU5
PIN 1 BLUE
PIN 2 GREEN
24Vdc BLACK
0V RED
MAX 5
SENSORS
Page 10 of 24 www.sgm-lektra.com
VLW60T - electrical connections
6.3 CONNECTION TERMINALS VERSION “B”
1) Separate the motor or power control cables from the VLW60T connection cables
2) Remove the caps from the cable glands and open the cover by loosening the appropriate screws.
3) Insert the cables into the transmitter through the cable glands.
4) Close the cover and tighten the cable glands.
6.4 INFILTRATIONS OF HUMIDITY
To avoid moisture inltration inside the enclosure, the following are recommended:
- For the electrical connections use a cable with an external diameter of 6÷12mm and fully tighten the M20 cable gland.
- Close the lid tightly.
- Position the cable in such a way as to form a downward curve in the output of the M20 cable gland; in this way
condensation and/or rainwater will tend to drip from the bottom of the curve.
