Sharkoon VAYA Bedienungsanleitung

www.sharkoon.com

Manual

VaYa EconomY

Table of contents page

1. Features 1

2. Package contents 2

3.The case at a glance 3

4. Mounting a mainboard 6

5. Mounting a power supply 8

6. Mounting a hard disk drive 9

7. Mounting an optical drive 10

8. Mounting a 3.5" device 12

9. Mounting an add-on card 13

10. Mounting additional fans / optimized airﬂow 13

Dear customer!

Congratulations for purchasing this premium quality SHARKOON product. For a long life time and to take full

advantage of this product we recommend you to read this manual completely.

Enjoy our product!

SHARKOONTechnologies

ECONOMY

VaYa EconomY

1. Features

 • ATXcase

 • 4x5.25"drivebays

 • 4x3.5"baysforHDDs(internal)

 • 1x3.5"mountingbay(external)

 • Front-I/O:

  2xUSB2.0,2xaudio

• Blackinteriorpainting

 • 7slotsforadd-oncards

 • Plasticfrontpanelwithmeshairinlet

 • QuickfastenersforopticaldrivesandHDDs,mainboardmountingpanelwithinstallation

opening for coolers

 • 2openingsforwatercooling

 • Cablemanagementsystem

 • Fanconguration:

 • Dimensions:465x185x440mm(LxWxH)

 • Weight:~5kg

Casefront 1x120mmLEDfan

(red/pre-installed)

Sidepanel 1x120mmor1x140mmfan

(optional)

Rear panel 1x80mm,92mmor120mmfan

(optional)



VaYa EconomY

2. Package contents

 • ATXcase“Vaya”

 • Accessorykit

9xstand-offsformainboard 25xscrewsformainboardand

drivemounting(3.5"and5.25")

4xscrewsforPSUmounting

16xscrewsforHDDmounting 1xlockattachmentand

corresponding screw

Note:

If you are missing any of the items listed above, please contact our customer service immediately:

[email protected] (Germany and Europe)

[email protected] (international).



VaYa EconomY

3.The case at a glance

ba a

A–5.25"mountingbays

B–3,5"mountingbay

C–FrontI/Owith:

 a–2xUSB2.0and

 b–2xaudioconnectors

D–behindtheMeshpanel:120mmLEDfan(pre-installed)

E–PowerbuttonandLED

F–ResetbuttonandLED

Front view

Sideview(closed/left)

A–Fanbracket(120or140mm)

B–Airinlet



VaYa EconomY

 Sideview(opened/left)

A–Mountingbaysfor5.25"devices

B–Mainboardmountingpanel

  featuring:

a–InstallationopeningforCPU

coolers and

b–Cablemanagementsystem

C–Quickfastenersforopticaldrives

D–Quickfastenersforharddisk

drives

Rear view

A–OpeningforI/Oshield

B–Openingsforwatercooling

C–Fanbracket(80,92or120mm)

D–Slotbezels

E–PSUbracket

F–Thumbscrews



VaYa EconomY

 Viewfrombelow

A A

A–Casefeet

B–Airinletforpowersupply

Connectorsfor:

A–HDD-LED

B–ResetSwitch

C–PowerSwitch

D–PowerLED+

E–PowerLED–

F–USBconnectoroftheUSBfronthub

G–Audioconnectors(HDAudioandAC’97)

The internal cables and connectors

Note:

For further information on how to install the intended devices, refer to their respective user

documentation.



VaYa EconomY

4. Mounting a mainboard

 1. Removethethumbscrewsonthecase’srearsideandtaketheleftsidepaneloffthecase.

  Laydownthecasesidewiseonanevensurface.

 2.Themountingpanelofthemainboardprovidesvariousdrillingsforstand-offs(g.1).

  g.1

  Themainboardcontainsspecialscrewopenings(g.2).

  g.2

Place the mainboard onto the mounting panel.You have to screw a stand-off into every drilling of the

  mountingpanelyoucanseethroughthemainboard’sscrewopenings.



VaYa EconomY

3. Remove the mainboard and screw the stand-offs into the respective drillings of the mounting panel

  (g.3).

  g.3

  (Stand-offs)

 4.PresstheI/Oshield(deliveredwiththemainboard)intotheI/Oshieldopeninginthecase’srearpanel.

5. Place the mainboard back onto the stand-offs and attach it to the mainboard using the screws for

  mainboardmounting(g.4).

  (Screwsformainboardmounting)

  g.4

 6.Connectthecase'sfrontI/Ocablestotherespectiveconnectorsofthemainboard(alsorefertoyour

  mainboard’smanualforfurtherinformation).



VaYa EconomY

5. Mounting a power supply

 1. SetupthecaseinfrontofyouandputthePSUagainstthePSUbracketonthecase’srearsidefromthe

  inside(g.5).

  g.5

2.AttachthePSUtothecasefromtheoutsideusingtheincludedscrewsforPSUmounting(g.6).

  g.6

   (ScrewsforPSUmounting)


