Sharp FU-A80J Bedienungsanleitung

ENGLISH

Device of this mark is a trademark of Sharp Corporation.

Plasmacluster is a registered trademark or a trademark

of Sharp Corporation.

AIR PURIFIER

OPERATION MANUAL

FU-A80J

Free standing type

H_FU-A80J-EN.indd 1 2011/09/05 11:40:27

Please read before operating your new Air Puri er

Some odour ingredients absorbed by the  lters may become separated and may be

discharged through the air outlet and result in additional odour. Depending on the

usage environment, especially when the product is used in a condition signi cantly

more severe than household use, this odour may become strong in a shorter period

than expected.

The air purifier is designed to remove air-suspended dust and odour, but not harmful gases

(for example, carbon monoxide contained in cigarette smoke). If the odour sources still exist, it

cannot completely remove the odour (for example, odours from construction materials and pet

odours).

It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.

In this case we recommend purchasing the optional replacement  lter.

HEPA  lter (white)

Deodorizing Pre  lter (black)

Dust

pollen, dust, particles of cigarette

smoke, pet dander

Odour

cigarette smoke odour,household

odour

H_FU-A80J-EN.indd 2 2011/09/05 11:40:29

E-1

ENGLISH

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

...E-2

PART NAMES.............................................E-4

FILTER INSTALLATION ........................... E-6

OPERATION ...............................................E-7

MAINTENANCE .........................................E-8

TROUBLESHOOTING ............................E-10

FOR CUSTOMER ASSISTANCE .......... E-11

SPECIFICATIONS....................................E-13

FEATURES

Exclusive Combination of Air Treatment

Technologies

Filtration System + Plasmacluster Ion

DECREASES ODOURS

Deodorizing Pre lter absorbs many com-

mon household odours.

REDUCES DUST, POLLEN, DANDER &

MOULD*

HEPA filter traps 99.97% of particles as

small as 0.3 microns.*

REFRESHES

Plasmacluster refreshes the air similar to

the way nature cleans the environment by

emitting a balance of positive and negative

ions.

*From the air that is drawn through the l-

ter system.

Room size : 62m2

Thank you for purchasing the SHARP Air

Purifier. Please read this manual carefully.

Before using this product, be sure to read

the section: “Important Safety Instructions.”

After reading this manual, keep it in a

convenient location for future reference.

H_FU-A80J-EN.indd 1 2011/09/05 11:40:29

E-2

Read all instructions before using the unit.

When using electrical appliances, basic safety precautions should be followed, including the

following:

WARNING - To reduce the risk of electrical shock, re or injury to persons:

•Connect the power plug to a dedicated electrical outlet for 230-240V ~ 50Hz.

• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet is

loosened.

•Periodically remove dust from the power plug.

•Do not use an extension cord.

• Do not insert ngers or any objects into the air inlet or air outlet.

•Do not unplug by pulling on cord. To unplug, grasp the plug.

• Do not handle plug or unit with wet hands.

•Unplug the electrical cord before performing any maintenance.

• Do not use the unit if the cord has been damaged. Please contact the nearest Service Center.

• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, a Sharp

authorized Service Centre or similarly qualied person in order to avoid a hazard.

• Do not use near ammable gases and material such as insecticides, fragrances, and lit cigarettes.

•Do not use in humid place such as bathrooms.

• Contact the nearest Sharp Approved Service Centre for any problems, adjustments, or repairs.

•This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure they do not play with the appliance.

NOTE - Radio or TV Interference

If this air purifier should cause interference to radio or television reception, try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the unit and radio/TV receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Contact the dealer or an experienced radio/TV technician for help.

IMPORTANT SAFETY INSTRUCTIONS

H_FU-A80J-EN.indd 2 2011/09/05 11:40:29

E-3

ENGLISH

CAUTIONS CONCERNING OPERATION

•Do not block any opening.

• Do not use the unit near or on hot objects, such as stoves or heaters or radiators.

•Do not use the unit with the wrong position.

• Always hold the handle on both sides of the unit when moving it.

Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting

in bodily injury.

• Do not use without lters inside the unit.

• Do not wash and reuse the lter.

Not only does it not improve lter performance, but also may cause electrical shock or malfunction.

• Clean the exterior with a soft cloth only.

Do not use corrosive cleansers, volatile uids and/or detergents when cleaning the unit.

The unit surface may be damaged or cracked.

In addition, the sensor may malfunction as a result.

INSTALLATION GUIDELINES

• Avoid locations where curtains, etc., come into contact with any opening.

It may become dirty or a malfunction may occur.

• Avoid locations where the unit is exposed to condensation, due to rapid temperature changes.

(If it is unavoidable please allow unit to stand for 1 hour before switching on.)

(Use under appropriate conditions between 0 - 35˚C room temperature.)

• Place on a stable surface with sufcient air circulation.

When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.

• Avoid use in locations where greasy or oily smoke is generated (such as in a kitchen, etc.).

The unit surface may crack or the sensor may malfunction as a result.

FILTER GUIDELINES

• Follow the instructions to handle carefully and keep maintenance.

Do not install any other type of lters.

H_FU-A80J-EN.indd 3 2011/09/05 11:40:29

E-4

PART NAMES

ILLUSTRATIVE DIAGRAM

INCLUDED

• Operation manual

BACK

1 Air Outlet

2 Air Inlet

3 Handle

4 Main Unit

5 HEPA Filter

6 Deodorizing Pre Filter

7Dust Sensor

8 Date Label

9 Power Cord

10 Plug

H_FU-A80J-EN.indd 4 2011/09/05 11:40:32

E-5

ENGLISH

MAIN UNIT DISPLAY

11 12 13 14 15 16 17

11 QUICK CLEAN Button / Quick Clean Indicator Light (green)

12 (Plasmacluster) ON / OFF Button /

(Plasmacluster) ON / OFF Indicator Light (green)

13 CLEAN SIGN

The color changes according to the air condition.

14 (Plasmacluster) Sign (blue)

15 FAN SPEED Indicator Light (green)

16 FAN SPEED Button

17 POWER Button

Green Yellow Red

Clean Very Impure

H_FU-A80J-EN.indd 5 2011/09/05 11:40:32

E-6

FILTER INSTALLATION

Unplug the electrical cord before

performing any maintenance.

To maintain the quality of the  lters, they are installed in the main unit and packed in plas-

tic bags. Be sure to remove the  lters from the plastic bags before using the unit.

Remove the front Panel.

Gently grip the bottom of the front panel

and remove it by pulling the bottom gently

toward you.

Remove the plastic bags.

Place the  lters accordingly.

Keep the order of  lters.

Fix the Front Panel.

Fix the Front Panel by hooking it into

the top of the unit. Swing panel in by

pushing gently until the panel snaps

into place.

Record the date when you

start or replace the  lters.

HEPA  lter (white)

Deodorizing Pre  lter (black)

H_FU-A80J-EN.indd 6 2011/09/05 11:40:39

E-7

ENGLISH

OPERATION

Press to start / stop.

Unless the power cord has been unplugged,

the operation starts in the previous mode it

was operated in.

FP-A80U

Press to select fan speed.

Press to turn Plasmacluster

Ion Mode ON and OFF.

Press to start Quick Clean Mode..

The unit will operate at HIGH fan speed for

15 minutes, then will return to the prior operation.

"QUICK CLEAN" mode is effective when you

would like to clean quickly.

CLEAN SIGN

The Dust Sensor automatically moni-

tors dust pollution level and adjusts

fan speed accordingly.

Green Yellow Red

Clean Very Impure

ON OFF

3 2 1

QUICK CLEAN Operation

Light Control

Press for 3 seconds to select

ON/OFF of the Plasmacluster

SIGN and the CLEAN SIGN.

FP-A60U

AUTO mode

*The air puri er operates the air ow speed

automatically according to the interior

pollution level detected by the sensor.

H_FU-A80J-EN.indd 7 2011/09/05 11:40:41

E-8

CLEANING THE FILTERS

Turn off the unit, and unplug the

power cord.

Remove the Front Panel.

(Refer to E-6)

Clean the lter and Dust sensor.

Gently remove dust from the lter, using a

vacuum cleaner with attachment or similar tool.

Dust Sensor

Remove the Sensor cover, and remove the

dust on the Sensor lter.

If it is very dirty, wash it with water and dry it

thoroughly.

CLEANING THE UNIT

Dust sensor

Deodorizing Pre lter

Sensor cover

Sensor lter

MAINTENANCE

Wipe with a dry, soft cloth.

For stubborn stains or dirt, use a soft cloth

dampened with warm water.

Do not use volatile uids and

detergents.

Benzine, paint thinner, polishing powder,

detergent ingredients etc., may damage

the unit.

Care Cycle :

Whenever dust accumulates on the unit or every 1 month.

H_FU-A80J-EN.indd 8 2011/09/05 11:40:43
