UA-PF40E

Operation Manual

Air Purifier

EN ESDE PT FR PL NL

ENGLISH

UA-PF40E

AIR PURIFIER

OPERATION MANUAL

Free standing type

“Plasmacluster” and “Device of a cluster of grapes” are

trademarks of Sharp Corporation.

*The number in this technology mark indicates an

approximate number of ions supplied into air of 1 cm3,

which is measured around the centre of a room with

the “high-density plasmacluster 7000” applicable ﬂ oor

area (at 1.2 m height above the ﬂ oor) at the medium

wind volume in air purifying mode, when an air puriﬁ er

using the high-density plasmacluster ion evolving

device is placed close to a wall. This product is

equipped with a device corresponding to this capacity.

NOTE

The air puriﬁ er draws in room air from the air intake, passes the air through a Pre-

Filter, a Deodorizing Filter and a HEPA Filter inside of the unit, then discharges the air

through the air outlet. The HEPA Filter can remove 99.97% of dust particles as small

as 0.3 microns that pass through the ﬁ lter.

The Deodorizing Filter gradually absorbs odours as they pass through the ﬁ lter.

Some odours absorbed by the ﬁ lters may break down over time, resulting in additional

odour. Depending on the usage environment, especially when the product is used in

extreme environments (significantly more severe than normal household use), this

odour may become strong in a shorter period than expected. If the odour persists, the

ﬁ lters should be replaced.

• The air puriﬁ er is designed to remove air-suspended dust and odour, but not harmful gases

(for example, carbon monoxide contained in cigarette smoke).

Please read before operating your new Air Puriﬁ er

HEPA Filter

Deodorizing Filter

Back Panel

(Pre-Filter)

ENGLISH

E-1

ENGLISH

Thank you for purchasing the SHARP

Air Puriﬁ er. Please read this manual carefully.

Before using this product, be sure to read the

section: “Important Safety Instructions.”

After reading this manual, keep it in a

convenient location for future reference.

For your reference, we recommend to keep

this manual in the place where you can read

at any time.

IMPORTANT SAFETY INSTRUCTIONS

.....E-2

PARTS NAME...............................................E-4

FILTER INSTALLATION .............................E-5

OPERATION .................................................E-6

CARE AND MAINTENANCE .....................E-8

TROUBLESHOOTING ..............................E-10

SPECIFICATIONS...................................... E-11

CONTENTS

FEATURES

Unique Combination of Air Treatment

Technologies

Triple Filtration System + Plasmacluster

Ions

TRAPS DUST*

Pre-ﬁ lter traps dust and other large

airborne particles.

REDUCES ODOURS

Deodorizing ﬁ lter absorbs many common

household odours.

REDUCES POLLEN & MOLD*

HEPA ﬁ lter traps 99.97% of particles as

small as 0.3 microns.

FRESHENS

Plasmacluster treats the air similar to the

way nature cleans the environment by

emitting a balance of positive and negative

ions.

*When air is drawn through the ﬁ lter

system.

Sensor Technology continuously monitors

air quality, and automatically adjusting

airﬂ ow based on detected air purity.

E-2

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should be followed,

including the following:

WARNING - To reduce the risk of electric shock, ﬁ re or injury to persons:

• Read all instructions before using the unit.

• Use only a 220-240 volt outlet.

• Do not use the unit if the power cord or plug is damaged or the connection

to the wall outlet is loosened.

• Periodically remove dust from the power plug.

• Do not insert ﬁ ngers or foreign objects into the intake or air outlet.

• When removing the power plug, always hold the plug and never pull the

cord.

Electric shock and/or ﬁ re from short circuit may occur as a result.

• Be careful not to damage the power cord, it may cause electric shock, excess heat

or ﬁ res.

• Do not remove the plug when your hands are wet.

• Do not use this unit near gas appliances or ﬁ replaces.

• Remove the power plug from the wall outlet before cleaning the unit and

when not using the unit.

Electric shock from bad insulation and/or ﬁ re from short circuit may occur as a

result.

•When cleaning the unit, or when the unit is not in use, be sure to unplug the unit.

Electric shock and/or ﬁ re from a short circuit may result.

• If the power cord is damaged, it must be replaced by the manufacturer, its

service agent, Sharp Authorized Service Centre or similarly qualiﬁ ed person

in order to avoid a hazard.

• Do not operate when using aerosol insecticides or in rooms where there is oily

residue, incense, sparks from lit cigarettes, chemical fumes in the air or in very

high humidity conditions, such as a bathroom.

• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.

• Only a Sharp Authorized Service Centre should service this air puriﬁ er. Contact the

nearest Service Centre for any problems, adjustments, or repairs.

• This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of

the appliance in a safe way and understand the hazards involved. Children shall

not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

NOTE - Radio or TV Interference

If this air puriﬁ er should cause interference to radio or television reception, try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the unit and radio/TV receiver.

• Connect the equipment into an outlet on a circuit diﬀ erent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

ENGLISH

E-3

CAUTIONS CONCERNING OPERATION

• Do not block the air intake and/or air outlet.

• Do not use the unit near or on hot objects, such as stoves or heaters or where it

may come into contact with steam.

• Do not lay the unit down when using.

• Always hold the handle on the back of the unit when moving it.

• Do not use without the ﬁ lters installed inside the unit.

• Do not wash and reuse the HEPA ﬁ lter and the Deodorizing ﬁ lter.

Not only does it not improve filter performance, it may cause electric shock or

malfunction.

INSTALLATION GUIDELINES

•When using the unit, place it away from equipment utilizing electric waves

such as televisions or radios to avoid electrical interference.

•Avoid using in locations where furniture, fabrics or other items may come in

contact with and restrict the air intake and/or air outlet.

•Avoid using in locations where the unit is exposed to condensation or

drastic temperature changes. Appropriate condition is at room temperature

0 – 35 ºC.

•Place on a stable surface with suﬃ cient air circulation.

When placing the unit on a heavily carpeted area, the unit may vibrate slightly.

•Avoid locations where grease or oily smoke is generated.

The unit surface may crack as a result.

• The dust collecting ability of the unit is eﬀ ective even when the unit is close

to the wall, the surrounding walls and ﬂ oor may get dirty. Please place the

unit at a distance from the wall. The wall directly behind the air outlet may

become dirty over time. When using the unit for an extended period of time

at the same location, periodically clean the walls adjacent to it.

FILTER GUIDELINES

•

Follow the instructions in this manual for correct care and maintenance of the ﬁ lter.

E-4

PARTS NAME

BACK

FRONT

PLASMACLUSTER SIGN

Blue Plasmacluster ON

Oﬀ Plasmacluster OFF

7DUST SIGN

Indicates the air purity of the room

in 3 levels with colour changes.

Clean

Impure

Red

Orange

Green

17 16

3 4 5 6

1Main Unit 9Handle

2Air Outlet 10 Dust Sensor /

Dust Sensor Filter

3OFF TIMER Button

(Press 3 sec.) LIGHT ON/OFF Button 11 HEPA Filter

4MODE Button, Indicator Light (green)

(Press 3 sec.)Plasmacluster Ion ON/OFF Button

12 Deodorizing Filter

13 Upper Tabs

5CLEAN ION SHOWER Button, Indicator Light (green) 14 Back Panel (Pre-Filter)

6POWER ON/OFF Button 15 Bottom Tabs

7DUST SIGN 16 Power Cord

8PLASMACLUSTER SIGN 17 Plug

ENGLISH

E-5

Remove the Back Panel.

2Remove the plastic bag and

take out the Filter.

FILTER INSTALLATION

To maintain the quality of the ﬁ lter, it is installed in the main unit and packed in plastic

bag. Be sure to remove the ﬁ lter from the plastic bag before using the unit.

Upper Tabs

Pull

Push

Be sure to remove the power plug

from the wall outlet.

Bottom Tabs

HEPA Filter

Deodorizing Filter

4Replace the Back Panel to the

main unit.

Place the Filter inside the main

unit.

Do not install the ﬁ lter backwards or the

unit will not operate properly.

When replacing the ﬁ lter, making a memo

of the start of use date is recommended.

NOTE

E-6

OPERATION

AUTO SLEEP MED MAX

CLEAN AIR

START

• Select the desired fan speed.

• Unless the power cord has been unplugged,

the operation starts in the previous mode it

was operated in.

STOP

FAN SPEED

SLEEP

• The unit will operate very quietly, and the fan speed

is automatically switched depending on the amount of

impurities in the air.

DUST /PLASMACLUSTER SIGN go oﬀ automatically.

Even though the indicator is oﬀ , Plasmacluster Ion is

released into air unless Plasmacluster Ion is turned oﬀ by

NOTE

AUTO

• The fan speed is automatically switched depending on the

amount of impurities in the air. The sensors detect impurities

for efﬁcient air purﬁcation.

Releases high-density Plasmacluster ions and discharges strong air ﬂ ow for 60 minutes.

CLEAN ION SHOWER

START

• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be

released.

• When the operation ﬁ nishes, the unit will return to the prior

operation mode.

It is able to change the other mode or turn oﬀ during this

mode.

NOTE

● 2h ● 4h ● 8h CANCEL

OFF TIMER

Select the time turning oﬀ the unit during operation. The unit automatically stops once the selected

time is reached.

Inhaltsverzeichnis

Sprachen:

Andere Sharp Luftreiniger Handbücher

Sharp

Sharp FU-S25E Bedienungsanleitung

Sharp

Sharp FP-A80M Bedienungsanleitung

Sharp

Sharp Plasmacluster FP-P30U Bedienungsanleitung

Sharp

Sharp Plasmacluster IG-GC2E Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-830U Bedienungsanleitung

Sharp

Sharp FZ-S63MF Bedienungsanleitung

Sharp

Sharp Plasmacluster IG-A10EU Bedienungsanleitung

Sharp

Sharp FP-R65CX Bedienungsanleitung

Sharp

Sharp KC-A60E Bedienungsanleitung

Sharp

Sharp FU-425E Bedienungsanleitung

Sharp

Sharp Plasmacluster IG-A10EU Bedienungsanleitung

Sharp

Sharp KC-G60Y Bedienungsanleitung

Sharp

Sharp IG-CH2E Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-860U Bedienungsanleitung

Sharp

Sharp KC-G51R Bedienungsanleitung

Sharp

Sharp Plasmacluster KC-C70U Bedienungsanleitung

Sharp

Sharp QNET ZENsational KC-G60M-W Bedienungsanleitung

Sharp

Sharp FP-A80U Bedienungsanleitung

Sharp

Sharp KI-N50A Bedienungsanleitung

Sharp

Sharp Plasmacluster FP-JM40E Bedienungsanleitung

Sharp

Sharp KC-G50E Bedienungsanleitung

Sharp

Sharp FU-A80Y Bedienungsanleitung

Sharp

Sharp FU-40SE-J Bedienungsanleitung

Sharp

Sharp FP-K50U Bedienungsanleitung

Beliebte Luftreiniger Handbücher anderer Marken

IKEA

IKEA UPPÅTVIND Bedienungsanleitung

Nash

Nash AP-1 PureSmart Bedienungsanleitung

LG PH-U450 Series Bedienungsanleitung

DeLonghi

DeLonghi DDSX 220WFA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Bedienungsanleitung

Philips

Philips AC2721 Bedienungsanleitung

Hitachi

Hitachi EP-A3000 Bedienungsanleitung

TruSens

TruSens Z-2000 Bedienungsanleitung

Motorola

Motorola MBP87SN Bedienungsanleitung

Beko

Beko ATP 7100I Bedienungsanleitung

Carrier

Carrier INFINITY 1620 Bedienungsanleitung

AtmosAir

AtmosAir P2002 Bedienungsanleitung

Winix

Winix NK300 Bedienungsanleitung

Friedrich

Friedrich C-90A Bedienungs- und Montageanleitung

Surgically Clean Air

Surgically Clean Air JADE2.0 Bedienungsanleitung

Base aire

Base aire 555 Pro Bedienungsanleitung

Champion

Champion CP25 Bedienungsanleitung

vollara

vollara Air & Surface Pro+ Bedienungsanleitung
