Shehds Spark Machine Bedienungsanleitung
1
1.Introduction:
Thank you for choosing the spark machine
We recommend that you carefully read these operating instructions before
commissioning the unit. Please follow the instructions in this manual. This is the
only way to ensure safe operation, proper use and long service life.
1.1-Feature:
Environmental protection,safety:no gunpowder and noirritant
Support wireless control and DMX, operate is more easy and convenient.
Maintenance：
Please clean the machine regularly. It will reduce the replacement and repair cost
of spare parts.
Do not use for a long time, to clean the machine and make extra powder out.
500W Spark Machine
2
1.2-Product description：
1. Fuse
2. on/off switch
3. USB
4.DMX-512
5..Power out
6. power in
7.Display board
8.wire control plug
9. handle
10.Powder entrance
11. Spark nozzle
2.Safety instructions
Keep away from humidity, water and dust!Avoid placing the device in a location
with high humidity or excessive dust.
Place the device on a firm ground!
To avoid vibrations always place the device on a firm ground.
Do not use chemicals for cleaning!
Use a clean and dry cleaning rag to remove dust. Metal parts can be cleaned with
a damped cleaning rag. Before cleaning always unplug the device from the power
supply.
If the device is not working properly!
If problems occur unplug the device from the power supply. The user should not
try to service the device independently. All repairs and service must be
performed by a qualified technician.
Eye Protection
The eye protection warning icon is Shown to indicate that you must be protect
your eyes when close to the machine during machine operation.
The safety distance to the audience must be 2meter
Never aim the nozzle on people and keep a distance from 1 meter to the
nozzle.Don't spray on the food.
ATTENTION!
Damages caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any consequent secondary failures. Only
skilled workers are allowed to carry out the electrical connections. All electrical
and mechanical connections have to be carried out according to the European
safety standards.
3
Outdoor powder cannot be used indoors!When using outdoor powder, there
should be no carpet around the spark machine, and other inflammable articles!
The powder should not be exposed to the air. If a bag of powder is not used up, it
should be kept in a sealed condition and not exposed to open fire.
NOTE: Machine must be vertical if has powder in the tank. Must take out all
powder when machine shipped.
3.Technical data
Wireless RF Controllers N-1 Receiver/Dip
Switch +W-9 Usage Instructions：
When the heating is complete, the indicator light is green ; when the heating is not
finished, the indicator light is red . The machine is not effective until the heating is
complete. The amount and height of the spark is controlled by the remote control.
Specification :
Rated voltage
AC220V/50Hz/AC120V/60Hz
Rated power
500 W
Fuse
2.2 A 4.2 A
Pre-heating time
<8 min
Spark max height
2-5M
Spark height change
support
Wireless controller
W-9
Display screen
Digital display board
DMX
support
DMX channel
2
DMX range
1-512
Net weight
6.6 Kg
Gross weight
7.8 Kg
Machine size
210*218*260mm
Carton size
300*300*320mm
Stop:
Close or stop
Clean:
Clear powder
On:
Heating
Off:
Stop heating
Time:
Control continuous spark time 5/10/20/30S
Height:
Control spark height
Low,middle,high
4
4. Operation
4.1 Before using：
Never stand directly below the device when it is being mounted, removed or
serviced.Have a qualifiedtechnician
check the device annually and additionally before placing into service if stored
for an extended period of time.
Install the device in a secure location that is inaccessible to unauthorized
persons.This machine can only be used by adults.
Make sure there is no flammable material within a 10ft radius of the device.There
can be no objects blocking the use of the machine.
Be sure that the local power outlet match that or the required voltage for your
machine.
Can not join any flammable liquid, such as oil andgas.
Be sure the lid is well covered before use the machine,or the spark will splash out.
4.2 Usage method：
Place the unit on a flat,dry surface. The machine can not be sidelong,please pay
attention to keep upright. Otherwise the spark will not be vertical and probably
make the machine damaged.
fill the powder reservoir with our powder only then tighten the cap .
The device starts to heat up. This process needs 5 minutes, meanwhile the display
shows “UP”.
The heating process is finished. The display shows “READ“
OFF :
Indicates that the machine is ready to work
FFF:
The green light indicates that the machine is ready to Work.
HEAT:
Indicates that the machine is ready to heat.
DMX:
Red light flashes to indicate a successful DMX
connection and displays the current address code.
FAUL:
Red light indicate error alarm.
5
5. DMX CHANNELS
When using the DMX mode, two channels are occupied.
DMX Channel
CH1
1-255
Fountain on
CH2
0-20
Pre-heat off，And the first channel is invalid
50-100
Pre-heat on，And the first channel is valid
150-200
Clear Materical，And the first channel is invalid
Notes:Clean consumables when press button 2 for more than 15 seconds. Work stops
automatically in 15 seconds.
6.Warranty Instructions
◆ Warranty period：one year(the date of purchase)
◆ IF the buyers do not user the same supplier’s powder,the machine warranty period
will b e 3 month. The buyer will pay for the expenses if there are any components
changes.
◆ In such In the following cases, the product will not be guaranteed:
A: the product has been incorrectly operated and used inadvertently, for example, over
load, over pressure, and firing;
B: the product was broken because of careless handling;
C: due to poor use of environmental factors and sound quality problems, such as:
humidity, voltage instability, etc.;
D: products have been modified by non factory personnel.
◆ products comply with the warranty provisions, the factory will not charge
maintenance fees and accessories costs, for more than the warranty period of the
product, only the corresponding parts, finished goods costs.
◆ the contents of this warranty card, the company has the right to interpret, if the
user is unknown, please contact the local distributors.
◆ not covered by the warranty include: packing box, packaging, product shell and
hanger, remote control transmitter battery.
