ASSEMBLY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE YOU BEGIN. DO NOT JUMP AHEAD OF ANY STEP.
shopPOPdisplays makes no claim that these assembly instructions cover all details, conditions or variations, or that they cover all possible contingencies in connection with the assembly or installation of
this product. It is the Purchaser's responsibility to ensure that all components of this product are properly assembled and installed in accordance with these instructions. shopPOPdisplays assumes no
obligation or liability on account of any third-party recommendations, opinions or advice as to the assembly or installation of this product.
page
1
of
2
Teachers Desk Shield
PARTS LIST:
*NO TOOLS REQUIRED
*TWO PERSON ASSEMBLY RECOMMENDED
Front Panel
(1 pc)
STEP 2:
Stand Front
Panel up on
its long
edge and
push one of
the Flexible
connectors
onto one of
the shorter
side edges.
Side Panel
(4 pcs)
STEP 1:
Peel off the protective plastic film from both sides of Front Panel and Side Panels.
STEP 3:
Connect one of the Side Panels to open end of Flexible connector.
When connecting panels
together, make sure the hinge portion of the Connectors is to the outside as shown in image below.
Also ensure top edges of Side Panel and Front Panel are flush with each other.
NOTE:
Start
Connector
about 1/2"
down from
top edge
of Front
Panel in
order to
center it
on Panel.
Flexible
Connector
(4 pcs)
T Shaped
Gripper
Connector
(6 pcs)
HINGE ON OUTSIDE
1/2" down
ASSEMBLY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE YOU BEGIN. DO NOT JUMP AHEAD OF ANY STEP.
shopPOPdisplays makes no claim that these assembly instructions cover all details, conditions or variations, or that they cover all possible contingencies in connection with the assembly or installation of
this product. It is the Purchaser's responsibility to ensure that all components of this product are properly assembled and installed in accordance with these instructions. shopPOPdisplays assumes no
obligation or liability on account of any third-party recommendations, opinions or advice as to the assembly or installation of this product.
page
2
of
2
Teachers Desk Shield
ASSEMBLY COMPLETED
13901 / 13902
Use the adhesive-backed T Shaped Gripper
Connectors (included) to attach barrier securely
to desktop. Install one on the bottom edge of
each side panel and two additional ones evenly
spaced on the bottom edge of the Front Panel.
NOTE: Flexible connectors allow for multiple set-up options of your Desk Shield. Adjust the angle of all four hinge
joints to accomodate the shape of your workspace.
STEP 5:
Repeat
STEPS 2 - 4
to install
remaining
Flexible
Connectors
and Side
Panels on
opposite
side of
Desk Shield.
STEP 4:
Attach another Flexible connector to the open end of installed Side Panel, again starting it
about 1/2" down from top edge of Panel. Once fully installed, connect a second Side Panel to the
open end of Connector.
T Shaped
Grippers
NOTE: To ensure proper adhesion of T Grippers to mounting
surface, clean the area where the tape will be applied and
make sure it is dry prior to mounting Shield.
