LED Spere & Cube Controller 30

ORDERCODE 41140

Congratulations!

You have bought a great, innovative product from Showtec.

The Showtec 19” LED Sphere & Cube Controller 30 brings excitement to any venue. Whether you want simple

plug-&-play action or a sophisticated DMX show, this product provides the effect you need.

You can rely on Showtec, for more excellent lighting products.

We design and manufacture professional light equipment for the entertainment industry.

New products are being launched regularly. We work hard to keep you, our customer, satisfied.

For more information: iwant@showtec.info

You can get some of the best quality, best priced products on the market from Showtec.

So next time, turn to Showtec for more great lighting equipment.

Always get the best -- with Showtec !

Thank you!

Showtec

Showtec 19“ LED Sphere & Cube Controller 30™Product Guide

Warning..…...................................................................................………………………………………………………..

Safety-instructions…………………………………………………………………………………………………………

Operating Determinations………………………………………………………………………………………………

Rigging……………………………………………………………………………………………………………………...

Description..…..............................................................................……….………………………………………………

Features and Overview ………………………………...….……………….………….……….……….……………..

Backside…………………………………………………...…...….……………….…………………...………………….

Installation...............................................................................…...………………………………………….………..….

Set Up and Operation.....................................................................……..………………………………………………

Menu Setting…..…..………………………………………………………………………..….……………………..……

Stand-alone………..………………………………………………………………………..….……………………..……

DMX-controlled………………………………………………………………………..….………….………………….…

Maintenance...................................................................................………..………….…….…………………………..

Troubleshooting............................................................................………………….………………….………………...

Product Specifications.................................................................……………….…….………………………………...

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

SAFETY INSTRUCTIONS

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should there

be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to follow

the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the device.

Never let the power-cord come into contact with other cables! Handle the power-cord and all

connections with the mains with particular caution!

Never remove warning or informative labels from the unit.

Never look directly into the light source.

Never leave any cables lying around.

Do not open the device and do not modify the device.

Do not connect this device to a dimmerpack.

Do not switch the device on and off in short intervals, as this would reduce the system’s life.

Only use device indoor, avoid contact with water or other liquids.

Avoid flames and do not put close to flammable liquids or gases.

Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power-cord by the plug. Never pull out the plug by tugging the power-cord.

Make sure that the device is not exposed to extreme heat, moisture or dust.

Make sure that the available voltage is not higher than stated on the rear panel.

Make sure that the power-cord is never crimped or damaged. Check the device and the power-

cord from time to time.

If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

CAUTION!

Keep this device away from rain and moisture!

Unplug mains lead before opening the housing!

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the

device switched off until it has reached room temperature.

If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

For replacement use fuses of same type and rating only.

Repairs, servicing and electric connection must be carried out by a qualified technician.

WARRANTY: Till one year after date of purchase.

OPERATING DETERMINATIONS

If this device is operated in any other way, than the one described in this manual, the product may suffer

damages and the warranty becomes void.

Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion, crash etc.

You endanger your own safety and the safety of others!

Rigging

Please follow the European and national guidelines concerning rigging, trussing and all other

safety issues.

Do not attempt the installation yourself !

Always let the installation be carried out by an authorized dealer !

Procedure:

If a LED Sphere/Cube is lowered from the ceiling or high joists, professional trussing systems have to be

used.

Mount the LED Sphere/Cube to the trussing system.

The LED Sphere/Cube must never be fixed swinging freely in the room.

The installation must always be secured with a safety attachment, e.g. an appropriate safety net or

safety-cable.

When rigging, derigging or servicing the LED Sphere/Cube, always make sure, that the area below

the installation place is blocked and staying in the area is forbidden.

Improper installation can cause serious damage to people and property !

CAUTION ! EYEDAMAGES !.

Avoid looking directly into the light source.

(meant especially for epileptics) !

Description of the device

Features

The 19” LED Sphere & Cube Controller 30 is designed for the more demanding user:

• 4/48 DMX Channels

• Controllable by DMX or Stand-alone controller.

• 12 Outputs for LED Sphere 30 or LED Cube 30

• DMX IN and DMX OUT.

• Accessories: Extension Cable for LED Sphere & Cube 3m. (41150)

Extension Cable for LED Sphere & Cube 6m. (41151)

Note: You can only connect the LED Sphere 30 and LED Cube 30 to the LED Sphere Controller 30

Overview

Fig. 1

1) Up: Increase the DMX address or program options.

2) Down: Decrease the DMX address or program options.

3) Menu: Change the pre-programmed modes.

4) Display: Change the settings of the pre-programmed modes (Speed, Flash, Colors)

5) ON / OFF

Backside

Fig. 2

6) IEC power connector + Fuse F2A 250V

7) Cooling Fan

8) 3 pin DMX OUT connector: XLR female socket used to send DMX signals.

9) 3 pin DMX IN connector: XLR male socket used to receive DMX signals.

10) 12X Output to LED Sphere 30cm (41120) or LED Cube 30 (41130).

Installation

Remove all packing materials from the LED Sphere & Cube Controller 30. Check that all foam and plastic

padding is removed. Connect all cables.

Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure proper

transmission on the DMX data link.

Do not supply power before the whole system is set up and connected properly.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

Set Up and Operation

Follow the directions below, as they pertain to your preferred operation mode.

Before plugging the unit in, always make sure that the power supply matches the product specification

voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

Menu Settings

Value

Description

COL

0-7

0-Blackout, 1-R, 2-G, 3-B, 4-Y,5-C, 6-M, 7-W

CHS

0-15

Built-in chases

SPD

1-16

Speed Control

CHA

0-511

DMX Address

4 or 48

Channel Control

SOU

ON / OFF

Sound-controlled

You can operate this device as:

1. Stand-alone unit

2. DMX-controllable

Stand-alone

1. Turn the power switch on. The device will start.

2. If you want to use the COL menu, be sure to set CHS to 0 and SPD to 1

If you want to use the CHS and SPD menu, be sure to set COL to 0.

3. You will find all the pre-programmed chases below.

CHASE 1

BEGIN

GB G RB B RG R

R GB G RB B RG

0 1 2 3 4 5 6 7 8 9 10 11 12

All lights operate synchronously with a fade effect.

CHASE 2:

L 255 COLOUR

R G R B G R RB

0 1 2 3 4 5 6 7 STEP

All lights operate synchronously with a fade effect.

CHASE 3:

L 255 COLOUR

R G B R G B

0 1 2 3 4 5 6 STEP

All lights operate synchronously with a fade effect.

L 255 COLOUR

STEP

CHASE 4:

L 255 COLOUR

B G R G R

GB R B G R

0 1 2 3 4 5 STEP

All lights operate synchronously with a fade effect.

CHASE 5:

BLOCK1 BLOCK2 BLOCK3

L 255

R R+B R+B+G G G+R G+R+B B B+G B+G+R

0 STEP1 STEP4 STEP7 STEP2 STEP5 STEP8 STEP3 STEP6 STEP9

Divide the 12 steps into 4 parts (BLOCK1、BLOCK2、BLOCK3); there is no fade effect.

CHASE 6:

L 255 COLOUR

R G B Y M C W

BLOCK1 BLOCK2 BLOCK3 BLOCK4 BLOCK5 BLOCK6

BLOCK12 BLOCK11 BLOCK10 BLOCK9 BLOCK8 BLOCK7 ALL

0 1 2 3 4 5 6 7 STEP

There is no fade effect.

CHASE 7:

The course for every unit showing is the same as chase 2.

12 units do not operate synchronously, this is a random chase.

CHASE 8:

WHITE COLOUR

R G B Y C M M C Y B G R

0 1 2 3 4 5 6 7 8 9 10 11 12 BLOCKS

With fade effect.

CHASE 9:

255 COLOUR

R R G G B B Y Y C C M M

0 1 2 3 4 5 6 7 8 9 10 11 12 STEP

All lights operate synchronously with a 7 color fade effect.

CHASE 10:

255 COLOUR

C R C R

0 1 2 3 4 STEP

CHASE 11:

255 COLOUR

M G M G

0 1 2 3 4 STEP
