ShowPro X-Blinder Bedienungsanleitung

LED audience blinder

with a modern design and advanced features

designed to reproduce the look and feel

of the classic incandescent effect

www.showtech.com.au

TABLE OF CONTENTS

SAFETY / GENERAL INSTRUCTIONS

INTRODUCTION

Features

OVERVIEW

Rear view

Front view

DIMENSIONS

CONTROL MENU OVERVIEW

Control Panel

Function Menu

DMX FUNCTION CHART

9-channel mode

1-channel mode

3-channel mode

4-channel mode

MAINTENANCE

- X-Blinder

- Power cord

- User manual

- Warranty Card

PACKING CONTENT

211

www.showtech.com.au

WARNING! Before carrying out any operations with the unit, carefully read this instruction

manual and keep it with cure for future reference. It contains important information about

the installation, usage and maintenance of the unit.

SAFETY

General instruction

•The products referred to in this manual conform to the European Community Directives and are there-

fore marked with .

•The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.

Never make

risk an electric shock.

•

cording to standard EN 60598-1). It is, moreover, recommended to protect the supply lines of the units

from indirect contact and/or shorting to earth by using appropriately sized residual current devices.

installer. Check that the main frequency and voltage correspond to those for which the unit is designed

as given on the electrical data label.

•This unit is not for home use, only professional applications.

- in places subject to vibrations or bumps;

- in places with a temperature of over 45 °C.

an inspection or contact the manufacturer directly.

plant for a disposal which is not harmful to the environment.

Warnings and installation precautions

damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like

short circuit, burns, electric shock, etc.

•Always additionally secure the projector with the safety rope.When carrying out any work, always com-

ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country

•Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent

•The lamp (LED) shall be changed if it has become damaged or thermally deformed.

trigger epileptic seizures in photosensitive persons or persons with epilepsy.

•Do not touch the product’s housing when operating because it may be very hot.

www.showtech.com.au

INTRODUCTION

The X-Blinder is a warm white LED audience blinder with a modern design and advanced

FEATURES

- 4 x 100W warm white LEDs

- Flicker-free output with selectable PWM frequencies for worry-free video

- Smooth 16-bit dimming curves accurately mimic conventional fades

- Unique rugged die-cast body designed for mounting versatility

- Individual heads swivel independently in 24° range

- Power linking (PowerCon In/Out)

- DMX control

SPECIFICATIONS

Light Source: 100W White LED (3000K, 4500K or 5000K)

Beam Angle: 50°

Field Angle: 80°

Output: 1246 LUX @ 5 meters

Strobe: 0-30 Hz

Dimming: 4 dimming curve modes

Control: DMX, Auto (stand-alone)

DMX Channels: 1 / 3 / 4 / 9

Display: OLED function menu with 4 touch buttons

Mains: 100 - 240 VAC, 50/60 Hz (auto-ranging)

Consumption: 300W

Power connections: Neutrik PowerCon In/Out

Power linking: Up to 10 units @ 230V (up to 5 units @ 110V)

Data connections: XLR In/Out for DMX (3-pin or 5-pin)

Housing Material: Diecast aluminum

Finish: Matte black

IP rating: IP20

Cooling: Active (variable speed fan)

Dimensions: 364 x 364 x 163 mm

Weight: 8.7 KG

T5A 250V

ø5*20

www.showtech.com.au

DMX FUNCTION CHART

Channel Function Value Percent/Setting

9-CHANNEL MODE

1-CHANNEL MODE

1 Dimmer H 000 - 255 0–100%

2 Dimmer L 000 - 255 0–100%

3 Strobe 000 - 010

011 - 132

133 - 255

No function

0–20 Hz (All pods)

0–20 Hz (Random strobe macros)

4 White 1

000 - 255

0–100%

5 White 2

000 - 255

0–100%

6 White 3

000 - 255

0–100%

7 White 4

000 - 255

0–100%

8 Auto Programs

000 - 010

011 - 040

041 - 080

081 - 120

121 - 160

161 - 200

201 - 240

241 - 255

No function

Auto 1

Auto 2

Auto 3

Auto 4

Auto 5

Auto 6

No function

9 Dimmer Speed

000 - 010

011 - 040

041 - 080

081 - 120

121 - 255

Preset dimmer speed from display menu

Nonlinear dimming curve 1 (fastest)

Nonlinear dimming curve 2

Nonlinear dimming curve 3 (slowest)

Preset dimmer speed from display menu

1 Dimmer H 000 - 255 0–100%

2 Dimmer L 000 - 255 0–100%

3 Strobe 000 - 010

011 - 132

133 - 255

No function

0–20 Hz (All heads)

0–20 Hz (Random strobe macros)

1 White 1 000 - 255 0–100%

2 White 2 000 - 255 0–100%

3 White 3 000 - 255 0–100%

4 White 4 000 - 255 0–100%

4-CHANNEL MODE

3-CHANNEL MODE

OVERVIEW

Display

DMX In

Power Out

Buttons

Rear View

Power In

DMX Out

Mounting bracket

Safety cable

attachment point

Front View

DMX Programming

note:

Head number

as shown

corresponds

to DMX address

sequence of

individual heads

www.showtech.com.au www.showtech.com.au

BUTTONFUNCTION

Menu Selects operating mode or exits submenus

Up Scrolls up through option lists or selects higher value

DownScrolls down through option lists or selects lower value

Enter Activates displayed menu option or selected value

CONTROL MENU OVERVIEW

CONTROL PANEL

DIMENSIONS

363

164

101

137

111

MODE OPTIONS / VALUES DESCRIPTION

FUNCTION MENU

Auto Show Auto 1 –6 Speed 0–100 Automatic programs

Static Dimmer 0-255

Sets the intensity of the light output

Strobe

Selects the strobe frequency

Dimmer Mode

No dimmer

Dimmer 1 –3 Select curves

Dimmer 1 (fast) ~ Dimmer 3 (slow)

Back Light

10S Turns o display backlight

after 10 seconds of inactivity

20S Turns o display backlight

after 20 seconds of inactivity

30S Turns o display backlight

after 30 seconds of inactivity

Display backlight always on

Information

Auto Test Turns on all LEDs in sequence for testing

Fixture Hours Shows total usage hours

Version Shows installed software version

DMX Address 001–512 Selects DMX address (upper channel

limit depends on personality chosen)

DMX Channel

1 Ch 1-channel: dimmer

3 Ch 3-channel: dimmer H, dimmer L, Strobe

4 Ch 4-channel: Heads 1 - 4

9 Ch 9-channel: Heads 1 - 4, auto programs,

dimmer speed, dimmer H, dimmer L,

strobe

Master/Slave Mode Master DMX mode (Master)

Slave Slave mode

Fan Mode Auto Fan control

High

Temperature

LED1

Individual head temperature

LED2

LED3

LED4

LED Frequency

600Hz

PWM frequency

1200 Hz

2000 Hz

4000 Hz

25KHz

www.showtech.com.au www.showtech.com.au

BUTTONFUNCTION

Menu Selects operating mode or exits submenus

Up Scrolls up through option lists or selects higher value

DownScrolls down through option lists or selects lower value

Enter Activates displayed menu option or selected value

CONTROL MENU OVERVIEW

CONTROL PANEL

DIMENSIONS

363

164

101

137

111

MODE OPTIONS / VALUES DESCRIPTION

FUNCTION MENU

Auto Show Auto 1 –6 Speed 0–100 Automatic programs

Static Dimmer 0-255

Sets the intensity of the light output

Strobe

Selects the strobe frequency

Dimmer Mode

No dimmer

Dimmer 1 –3 Select curves

Dimmer 1 (fast) ~ Dimmer 3 (slow)

Back Light

10S Turns o display backlight

after 10 seconds of inactivity

20S Turns o display backlight

after 20 seconds of inactivity

30S Turns o display backlight

after 30 seconds of inactivity

Display backlight always on

Information

Auto Test Turns on all LEDs in sequence for testing

Fixture Hours Shows total usage hours

Version Shows installed software version

DMX Address 001–512 Selects DMX address (upper channel

limit depends on personality chosen)

DMX Channel

1 Ch 1-channel: dimmer

3 Ch 3-channel: dimmer H, dimmer L, Strobe

4 Ch 4-channel: Heads 1 - 4

9 Ch 9-channel: Heads 1 - 4, auto programs,

dimmer speed, dimmer H, dimmer L,

strobe

Master/Slave Mode Master DMX mode (Master)

Slave Slave mode

Fan Mode Auto Fan control

High

Temperature

LED1

Individual head temperature

LED2

LED3

LED4

LED Frequency

600Hz

PWM frequency

1200 Hz

2000 Hz

4000 Hz

25KHz

www.showtech.com.au www.showtech.com.au

DMX FUNCTION CHART

Channel Function Value Percent/Setting

9-CHANNEL MODE

1-CHANNEL MODE

1 Dimmer H 000 - 255 0–100%

2 Dimmer L 000 - 255 0–100%

3 Strobe 000 - 010

011 - 132

133 - 255

No function

0–20 Hz (All pods)

0–20 Hz (Random strobe macros)

4 White 1

000 - 255

0–100%

5 White 2

000 - 255

0–100%

6 White 3

000 - 255

0–100%

7 White 4

000 - 255

0–100%

8 Auto Programs

000 - 010

011 - 040

041 - 080

081 - 120

121 - 160

161 - 200

201 - 240

241 - 255

No function

Auto 1

Auto 2

Auto 3

Auto 4

Auto 5

Auto 6

No function

9 Dimmer Speed

000 - 010

011 - 040

041 - 080

081 - 120

121 - 255

Preset dimmer speed from display menu

Nonlinear dimming curve 1 (fastest)

Nonlinear dimming curve 2

Nonlinear dimming curve 3 (slowest)

Preset dimmer speed from display menu

1 Dimmer H 000 - 255 0–100%

2 Dimmer L 000 - 255 0–100%

3 Strobe 000 - 010

011 - 132

133 - 255

No function

0–20 Hz (All heads)

0–20 Hz (Random strobe macros)

1 White 1 000 - 255 0–100%

2 White 2 000 - 255 0–100%

3 White 3 000 - 255 0–100%

4 White 4 000 - 255 0–100%

4-CHANNEL MODE

3-CHANNEL MODE

OVERVIEW

Display

DMX In

Power Out

Buttons

Rear View

Power In

DMX Out

Mounting bracket

Safety cable

attachment point

Front View

DMX Programming

note:

Head number

as shown

corresponds

to DMX address

sequence of

individual heads

www.showtech.com.au www.showtech.com.au

INTRODUCTION

The X-Blinder is a warm white LED audience blinder with a modern design and advanced

FEATURES

- 4 x 100W warm white LEDs

- Flicker-free output with selectable PWM frequencies for worry-free video

- Smooth 16-bit dimming curves accurately mimic conventional fades

- Unique rugged die-cast body designed for mounting versatility

- Individual heads swivel independently in 24° range

- Power linking (PowerCon In/Out)

- DMX control

SPECIFICATIONS

Light Source: 100W White LED (3000K, 4500K or 5000K)

Beam Angle: 50°

Field Angle: 80°

Output: 1246 LUX @ 5 meters

Strobe: 0-30 Hz

Dimming: 4 dimming curve modes

Control: DMX, Auto (stand-alone)

DMX Channels: 1 / 3 / 4 / 9

Display: OLED function menu with 4 touch buttons

Mains: 100 - 240 VAC, 50/60 Hz (auto-ranging)

Consumption: 300W

Power connections: Neutrik PowerCon In/Out

Power linking: Up to 10 units @ 230V (up to 5 units @ 110V)

Data connections: XLR In/Out for DMX (3-pin or 5-pin)

Housing Material: Diecast aluminum

Finish: Matte black

IP rating: IP20

Cooling: Active (variable speed fan)

Dimensions: 364 x 364 x 163 mm

Weight: 8.7 KG

T5A 250V

ø5*20

www.showtech.com.au

WARNING! Before carrying out any operations with the unit, carefully read this instruction

manual and keep it with cure for future reference. It contains important information about

the installation, usage and maintenance of the unit.

SAFETY

General instruction

•The products referred to in this manual conform to the European Community Directives and are there-

fore marked with .

•The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.

Never make

risk an electric shock.

•

cording to standard EN 60598-1). It is, moreover, recommended to protect the supply lines of the units

from indirect contact and/or shorting to earth by using appropriately sized residual current devices.

installer. Check that the main frequency and voltage correspond to those for which the unit is designed

as given on the electrical data label.

•This unit is not for home use, only professional applications.

- in places subject to vibrations or bumps;

- in places with a temperature of over 45 °C.

an inspection or contact the manufacturer directly.

plant for a disposal which is not harmful to the environment.

Warnings and installation precautions

damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like

short circuit, burns, electric shock, etc.

•Always additionally secure the projector with the safety rope.When carrying out any work, always com-

ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country

•Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent

•The lamp (LED) shall be changed if it has become damaged or thermally deformed.

trigger epileptic seizures in photosensitive persons or persons with epilepsy.

•Do not touch the product’s housing when operating because it may be very hot.

www.showtech.com.au

Inhaltsverzeichnis

Andere ShowPro Beleuchtungsausrüstung Handbücher

ShowPro

ShowPro MoonLite 150 HEX Bedienungsanleitung

ShowPro

ShowPro MoonLite 80 HEX Bedienungsanleitung

ShowPro

ShowPro Venue Haze 1200 Bedienungsanleitung

ShowPro

ShowPro PLUTO 250 Bedienungsanleitung

ShowPro

ShowPro DIAMONDBACK LEDDIA100 Bedienungsanleitung

ShowPro

ShowPro K65 IP Bedienungsanleitung

ShowPro

ShowPro ProShop LED PAR Hex-7 Bedienungsanleitung

ShowPro

ShowPro LED UP Quad-4 Bedienungsanleitung

ShowPro

ShowPro Dreampix Driver 1800 IP Bedienungsanleitung

ShowPro

ShowPro Truss Mate II Bedienungsanleitung

ShowPro

ShowPro LED EPAR CW MULTI Bedienungsanleitung

ShowPro

ShowPro PLUTO 600 PROFILE Bedienungsanleitung

ShowPro

ShowPro NITEC photon multi LEDNIT141 Bedienungsanleitung

ShowPro

ShowPro UniFog DMX Bedienungsanleitung

ShowPro

ShowPro H1 PROFILE Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
