SIC SIC4340 Bedienungsanleitung
USER MANUAL
SIC4340
Development Kit
Rev 1.0 (Dec 2020)
This document describes how to get start with
SIC4340 Development kit board.
Revision History
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
2
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
Revision History
Revision
Date
Software
Version
Description
1.0
December 2020
1.0.2
1st Release
The information herein is for product information purposes. While the contents in this
publication have been carefully checked; no responsibility, however, is assumed for
inaccuracies. Silicon Craft Technology PLC. reserves the right to make changes to the products
contained in this publication to improve design, performance, or reliability.
Contents
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
3
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
Contents
SIC4340 Development Kit................................................................................................................................................ 1
Revision History................................................................................................................................................................... 2
Contents................................................................................................................................................................................. 3
List of Figures....................................................................................................................................................................... 4
1. Introduction ..................................................................................................................................................................... 5
2. Instruments ...................................................................................................................................................................... 5
3. Installation ........................................................................................................................................................................ 6
3.1 Installation on Android..................................................................................................................................................6
3.2 Installation on IOS ...........................................................................................................................................................7
4. Application Demonstration ......................................................................................................................................... 8
4.1 Setting ..................................................................................................................................................................................8
4.2 NFC Communication.......................................................................................................................................................9
4.3 Result Display ..................................................................................................................................................................12
4.4 Blank NDEF setting........................................................................................................................................................13
5. Legal Information .........................................................................................................................................................14
5.1 Disclaimer..........................................................................................................................................................................14
List of Figures
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
4
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
List of Figures
Figure 1: Detail of SIC4340 development kit board.........................................................................5
Figure 2: SIC4340 Tools app on Google Play Store..........................................................................6
Figure 3: SIC4340 Tools APP on IOS App Store................................................................................7
Figure 4: Setting page of SIC4340 Tools ...........................................................................................8
Figure 5: Bias current setting...............................................................................................................9
Figure 6: tap on 'PROCESS' to start NFC session..............................................................................9
Figure 7: Tap a tag status ..................................................................................................................10
Figure 8: Success status .....................................................................................................................10
Figure 9: Error status ..........................................................................................................................11
Figure 10: Result page .......................................................................................................................12
Figure 11: Write Blank NDEF feature................................................................................................13
Introduction and Instruments
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
5
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
1. Introduction
SIC4340 is NFC tag type 2 with built-in ADC for physical sensor measurement for 3-
channels selectable. These built-in ADC can drive the current from 1µA to 504µA and measure
the electrical value (e.g. voltage, resistance, and capacitance). The measured value is provided
with 10-bit resolution. SIC4340 Development kit board with SIC4340 Tools application is
developed to help the user learn how to use SIC4340 features with many sensors such as light
sensor, gas sensor or temperature sensor. In the app, the user can set the bias current for each
channel and measure the result from SIC4340 IC. The voltage and resistance result will be
displayed on the app after measurement.
Silicon Craft Technology PLC. (SIC) creates this document to describe how to get start
with SIC4340 development kit board and how to install and use SIC4340 Tools application on
both Android and IOS platform.
2. Instruments
To get start with SIC4340 development kit board, there are some instruments
required as below.
1. NFC mobile which can be a. or b.
a. Android mobile with Android operation version 4.1 (Jelly Bean) or above.
b. iPhone with IOS13 or above.
2. SIC4340 Development kit board as Figure 1
Figure 1: Detail of SIC4340 development kit board
Installation
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
6
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
3. Installation
There are SIC4340 Tools application available on both Android and IOS Platform.
3.1 Installation on Android
For SIC4340 Tools application on Android. It can be downloaded and installed from
Google Store link: https://play.google.com/store/apps/details?id=com.sic.sic4340rmeas or
search for ‘SIC4340 Tools’ in Google Play Store.
Figure 2: SIC4340 Tools app on Google Play Store
Installation
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
7
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
3.2 Installation on IOS
For SIC4340 Tools application on IOS, It can be downloaded and installed from App
Store link: https://apps.apple.com/us/app/sic4340-tools/id1518973827 or search for ‘SIC4340
Tools’ in IOS App Store.
Figure 3: SIC4340 Tools APP on IOS App Store
Application Demonstration
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
8
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
4. Application Demonstration
This part demonstrates how to use SIC4340 Development kit board with SIC4340 Tools
application. The content in this part includes setting, NFC communication, result display, and
blank NDEF setting.
4.1 Setting
In the setting page of SIC4340 Tools, user can enable or disable each pin and set the
bias current separately for each pin as shown in Figure 4
Figure 4: Setting page of SIC4340 Tools
Application Demonstration
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
9
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
The bias current can be set from slider bar or click the value on the top of slider bar to
manually type the value as shown in Figure 5
Figure 5: Bias current setting
4.2 NFC Communication
After finished the setting, push ‘PROCESS’ button to start the NFC session as shown in
Figure 6
Figure 6: tap on 'PROCESS' to start NFC session
Application Demonstration
SIC4340 USER MANUAL
SIC4340 Development Kit
PROPRIETARY AND CONFIDENTIAL
10
USER MANUAL SIC4340
DEC, 2020
V1.0
Copyright © 2020 Silicon Craft Technology PLC
After the NFC session has started, the NFC dialog will show the status as in Figure 7 (a)
for Android and Figure 7 (b) for iPhone.
Figure 7: Tap a tag status
After the status has shown as in Figure 7, user have to tap and hold the mobile on the
antenna of SIC4340 development kit board until the status changed to success as in Figure 8
(a) for Android and Figure 8 (b) for iPhone
Figure 8: Success status
(a)
(b)
(a)
(b)
