Convenience

mobile unit 2000C

for Hicom 300E

Hicom cordless E

Operating

instructions

Contents

Safety notes 6

Notes on mobile unit use........................................................................6

Notes on battery use ..............................................................................6

Meaning of symbols: ..............................................................................6

General 7

Operating elements, unit parts ...............................................................7

Explanation of display, display keys.......................................................8

Hicom cordless E ...................................................................................9

Features .................................................................................................9

Environmental conditions.....................................................................10

General notes on operation..................................................................10

Radio range.......................................................................................... 11

Leaving the radio network ....................................................................11

Fitting the attachment clip.................................................................... 11

Cleaning your mobile unit ....................................................................12

Lending/disposing ................................................................................12

User guidance, selecting functions.......................................................12

Putting into service 13

Inserting batteries in the mobile unit ....................................................13

Charging the batteries ..........................................................................14

Logging mobile units onto a telephone system ....................................15

Activating/deactivating mobile units.....................................................15

Activating/deactivating keypad protection............................................15

Telephone functions 16

Internal dialling.....................................................................................16

Dialling the Switchboard.......................................................................16

External dialling ...................................................................................17

Answering calls ....................................................................................18

Call Pickup ...........................................................................................19

Contents

Second Call Waiting.............................................................................20

Timed Reminder ..................................................................................21

Number redial - last 5 numbers............................................................22

System Abbreviated Dialling................................................................22

Night service ........................................................................................23

Switching functions 24

Automatic callback ...............................................................................24

Transfer................................................................................................24

Consultation during a call.....................................................................25

Toggle - switching between 2 users......................................................25

Conference...........................................................................................26

Call forwarding .....................................................................................28

Service menu .......................................................................................30

Telephone book 31

Saving numbers ...................................................................................31

Entering letters/characters and digits ...................................................32

Dialling a number from the telephone book .........................................33

Storing numbers from redial.................................................................33

Deleting / Editing an entry....................................................................34

Deleting the telephone book ................................................................35

PIN Features 36

Electronic Telephone Lock ...................................................................36

Mobile Class of Service .......................................................................37

Saving/modifying the mobile unit PIN..................................................38

Settings 39

Overview - settings ..............................................................................39

Setting the language ............................................................................40

Settings - handset, tone ringing... ........................................................40

Setting the station ................................................................................42

Contents

Tones - keys, battery, range... ..............................................................43

Overview - Tones .................................................................................44

Appendix 45

Fault clearance.....................................................................................45

Add-ons ................................................................................................46

Safety notes

Notes on mobile unit use

lDo not use mobile units in damp environments (bathroom/shower). The

units are not splash proof.

lDo not use the mobile unit in environments where there is danger of

explosion.

lMake sure that the telephone is at least one meter away from any

medical equipment.

lThe mobile unit is not suitable for people with hearing aids since the

radio signals interfere with hearing aids, producing a very unpleasant

humming sound if the volume is turned up high enough.

Recommendation: Gigaset 2000C headset,

see page 46.

Notes on battery use

lOnly use approved nickel-cadmium batteries (NiCad batteries), see

page 13.

lNever use other batteries or normal (non-rechargeable) batteries.These

batteries can cause short-circuit and may be subject to damage

(dangerous). Read the labels in the mobile unit and charging shell

battery compartments.

Meaning of symbols:

lWarning! Please read safety note

in the instructions.

lUse rechargeable batteries only

and observe polarity.

lAvoid contact with water and fire.

lDo not use non-Siemens charging devices. This could damage the

batteries.

lSuitable add-on charging shells are available from Siemens.

General

Operating elements, unit parts

3 11 13

Front Rear

1 Receiver inset 8 Recall key

2 Display (illuminated) 9 Microphone

3 Display keys 10 On/Off/Protect key

4 Menu key 11 Ringer loudspeaker

5 End call key 12 Battery compartment/lid

6 Talk key 13 Attachment clip

7 Alphanumeric keypad

Figure 1: Operating elements, unit parts

General

Explanation of display, display keys

The mobile unit features a 4-line display with 16 characters per line. Depend-

ing on the situation, the display shows:

ldigits, e.g. dialled numbers

ltext, e.g. the current station (system) or call options

lsymbols, e.g. ringing or battery symbol

land in the last line the current functions of the two display keys

Note:

The display texts are displayed in German (default setting), English,

French, Italian, Spanish or Dutch.

Setting the language, see page 40.

Display key functions

dCalls up the directory

SVC

Calls up T-Net services

INT

Sets up internal connections

zRedials number

{Cancels procedures

WCalls up supplementary menu

YZ Selects menu item or entry

<<<

>>>

Moves to left or right

XDeletes characters

Confirms actions

General

Hicom cordless E

The Hicom® cordless E DECT* telephone system comprises

lthe radio switching module for the Hicom 300E system

lbase stations (transmitter/receiver)

l2000C or 2000S mobile units (cordless telephones)

land the Gigaset 2000L charging shell (optional)

Features

Each mobile unit can log on to and be used by up to 4 DECT systems, e.g.

Hicom cordless E and Gigaset** 2000. This allows you to employ all the

features of the system in question. The features offered by Hicom cordless E

2000C include:

lmobile unit with 4-line, illuminated display, e.g. for displaying

– the dialled call number,

– the current applicable functions,

– the operating status and settings.

lStatus-dependent functions

lNumber redial for the last five numbers dialled

lTelephone book in the mobile unit for 100 entries

lInternal and external calls in the entire Hicom cordless E radio network

lRoaming (the user can roam throughout the entire radio network and

still receive all internal and external calls under one call number)

lAutomatic call transfer from base station to base station (handover)

lEnhanced user guidance with displays in German, English, French,

Italian, Spanish or Dutch (can be set)

lAutomatic callback for internal calls

lCall transfer to internal users

lConsultation during a call

lUse of all important Hicom functions that do not require a system-

specific telephone

lProtection against inadvertent key activation

lLong-lasting batteries:(NiCd 600ma, NiMH 1100ma, NiMH 1300ma)

– between 70 and 130 hours in stand-by mode

– between 7 and 13 hours when phone is in use

General

Environmental conditions

lPlease read the safety notes on page 6.

lMake sure that the mobile unit is at least one meter away from medical

equipment, fire alarm equipment and other radio equipment (e.g. radio

telephones or radio pagers), otherwise its performance may be im-

paired, e.g. by interference.

lThe mobile unit and charging shell should not be placed near other

electronic devices, such as Hi-fi, office or microwave devices, as this

may adversely affect operation of your telephone and/or the electronic

equipment.

lDo not expose the mobile unit or charging shell to direct sunlight or

other sources of heat.

lUse the mobile unit at temperatures between 0°C and +45°C.

lDo not expose the mobile unit to damp environments.

lAvoid using the mobile unit and charging shell in rooms where there is

a lot of dust.

General notes on operation

lWhen operating the mobile unit a basic distinction is made between

– telephone/switching functions, e.g. when a call is in progress

and

– local functions, display when mobile unit is on.

lAn incoming call cancels the local functions.

lLocal functions can be cancelled before saving with the function key

.or the end call key.

lLocal functions can also be performed in the charging shell.

lDisplay texts from the system are shown without muted vowels and

special characters.

lThe display of call charges at the mobile unit depends on the Hicom

setting.

lYour telephone book entries, all settings and your PIN are not lost,

even if you remove the batteries.

lThe mobile unit can be used as a second executive telephone with

limited functions.
