Siemens OpenStage 60/80 Bedienungsanleitung

Communication for the open minded

Siemens Enterprise Communications

www.siemens.com/open

Documentation

HiPath 500, HiPath 2000, HiPath 3000, HiPath 5000

HiPath 4000, HiPath OpenOffice ME

OpenStage 60/80

OpenStage 60/80 T

Quick Reference Guide

oi.book Seite 1 Dienstag, 12. Februar 2008 4:54 16

Using Your Telephone

Function Keys and Audio Keys

Mode keys and TouchSlider

Shining blue: mode is active

Shining white:

for call lists: new entry in call list

for voicemails: new voicemail

TouchGuide

Programmable sensor keys on the display

qStart voice dialing

rActivate/deactivate forwarding

sEnd (disconnect) call

pTurn microphone on/off

oTurn headset on/off

nTurn speaker on/off

tTelephony interface

uPhonebooks

wCall lists

xVoicemails

vService/Applications menu

yHelp function

Run finger over TouchSlider:

Depending on situation, set

volumes for ringer or

speaker

Press mkey:

- Scroll upwards

Hold down:

- Scroll to beginning of list

Press lkey:

- Scroll downwards

Hold down:

- Scroll to end of list

Press gkey:

- Call up the context menu

- Go down a level

Press hkey:

- Cancel function

- Delete character

left of cursor

- Go up a level

Press ikey:

- Confirm input

- Perform action

Run finger over inner edge of ring W:

- Scroll through lists and menus

- Adjust volume

Keys

Label

S inactive

R lit

T flashing

oi.book Seite 2 Dienstag, 12. Februar 2008 4:54 16

Using Your Telephone

Display

Components

Entering Phone Numbers and Text

Keypad

In situations where text entry is possible, you can use the dial keys to enter text, punctua-

tion and special characters. To do this, press the numerical keys repeatedly.

Extra asterisk and pound key functions:

Display keyboard

Depending on the context, the display keyboard is displayed with different elements.

Using the display keyboard:

WShift focus to another element

gShift focus to "OK"

iSelect element

Key Function during text input Function when held down

*Write special characters Deactivate the ring tone.

#Switch between upper/lower case and digit entry. Activate telephone lock.

Status bar

Ta b ( a c t ive )

Selected entry

(e.g. call lists)

Context menu

Selected entry

in context menu

Missed Dialed

10:23 Mon 10/23/06 54321

Dial

Details

Delete

List options

Marie Curie

Einstein, A

Joseph von Fr.

Element in focus

Letters, digits, punctuation or special characters

Changes

Switch to number input

Switch to upper/lower case

Copy content of active field to the clipboard

Move cursor left/right

Switch to punctuation and special characters

Insert clipboard contents at cursor position

oi.book Seite 3 Dienstag, 12. Februar 2008 4:54 16

Important Operating Procedures HiPath 4000

Important Operating Procedures

HiPath 4000

In Idle State

Answering a call with the handset

ZZ^

Answering a call in speakerphone mode

ZZn

Dialing from the caller list

w("Missed" tab, press repeatedly for "Dialed", "Received", "Forwarded")

Zf desired entry i

Activating callback

j destination phone number iZif no answer or busy: f"Callback" i

Saving a phone number to a key

SHold down programmable key Zf"Assign function" iZf"Change?" i

Zf"Selected dialing?" iZf"Save?" iZDZIn "Settings" tab f"User" i

Zf"Service menu" iZf"Destinations?" iZf"Selected dialing?" i

ZSpress programmable key Z"Enter new number?" iZj phone number

Z"Completed?" iZ"Use Destination Number?" iZ"Save?" i

Dialing a saved number

Ssaved phone number Z^

^Lift handset jEnter text or number

\Replace handset fSelect entry

[Conduct call gOpen context menu

ZRing tone/call waiting tone ZNext step in procedure

oi.book Seite 4 Dienstag, 12. Februar 2008 4:54 16

HiPath 4000 Important Operating Procedures

Saving a function to a key

SHold down programmable key Zf"Assign function" iZf"Change?" i

Zfselect function iZf"Save?" i

Redialing a number

^or nZf"Last number redial?" iZ^

Programming call forwarding

rZf"Edit call forwarding" iZfselect desired forwarding type (all calls, busy, no

reply, fixed, internal calls, external calls, busy/no reply) iZf"Destination" i

Zjphone number iZfselected forwarding, e.g. "all calls" iZf"On" i

Zf"Save & exit" i

Turning fixed call forwarding on/off for all calls

oi.book Seite 5 Dienstag, 12. Februar 2008 4:54 16

Important Operating Procedures HiPath 4000

During Calls with a Party A

Switching to speakerphone mode

Hold down nZ\(US only: nZ\)

Consultation

gZ"Consultation?" iZ

phone number for party B

iZ[party B Zg

Z"Release and return?" iZ[party A

Accepting call waiting

Zcall waiting tone Zf"Answer camp-on?" iZ[party B Zfparty B Zg

Zf"Release and return?" iZ[party A

Start conference

gZ"Consultation" iZ

phone number for party B

iZ[party B Zg

Zf"Conference?" iZ[party A and B

Start conference on call waiting

Zcall waiting tone Zf"Answer camp-on?" iZ[party B Zg

Zf"Conference?" iZ[party A and B

Blind transfer

gZf"Consultation?" iZjdestination phone number Z\

Transfer after consultation

gZ"Consultation?" iZ

phone number for party B

Z[party B Z\

oi.book Seite 6 Dienstag, 12. Februar 2008 4:54 16

HiPath 500/2000/3000/5000, HiPath OpenOffice ME Important Operating Procedures

HiPath 500/2000/3000/5000,

HiPath OpenOffice ME

In Idle State

Answering a call with the handset

ZZ^

Answering a call in speakerphone mode

ZZn

Rejecting a call

ZZf"Reject call" i

Dialing from the caller list

w("Missed" tab, press repeatedly for "Dialed", "Received", "Forwarded")

Zf desired entry i

Activating callback

j destination phone number iZif no answer or busy: f"Callback" i

Saving a phone number to a key

SHold down programmable key Zf"Assign function" iZf"Change key?" i

Zf"Destinations" iZf"Station no." iZStn number: jphone number i

Z"Save" iZ"Exit" i

Dialing a saved number

Ssaved phone number Z^

Saving a function to a key

SHold down programmable key Zf"Assign function" iZf"Change?" i

Zfselect function iZf"Exit" i

Programming call forwarding

rZf"Edit call forwarding" i

Zfselecting forwarding type (all calls, internal calls, external calls) i

Zf"Destination" iZjphone number iZfselected forwarding, e.g. "all calls" i

ZgZf"On" iZf"Save & exit“ i

Turning call forwarding on/off for all calls

oi.book Seite 7 Dienstag, 12. Februar 2008 4:54 16

Important Operating Procedures HiPath 500/2000/3000/5000, HiPath OpenOffice ME

During Calls with a Party A

Consultation

gZ"Consultation" iZ

phone number for party B

iZ[party B Zfparty B Z

gZ"Release and return" iZ[party A

Start conference

gZ"Start conference" iZ

phone number for party B

iZ[party B Zg

Zf"Conference" iZ[party A and B

Blind transfer

gZf"Consultation?" iZjdestination phone number Z\

Transfer after consultation

gZ"Consultation?" iZ

phone number for party B

Z[party B Z\

oi.book Seite 8 Dienstag, 12. Februar 2008 4:54 16

Communications GmbH & Co. KG

Hofmannstr. 51,

D-81359 München

The information provided in this document

contains merely general descriptions or char-

acteristics of performance which in case of

actual use do not always apply as described

or which may change as a result of further

development of the products. An obligation

to provide the respective characteristics shall

only exist if expressly agreed in the terms of

contract. Subject to availability. Right of

modification reserved. The trademarks used

are owned by Siemens Enterprise

Communications GmbH & Co. KG or their re-

spective owners.

Siemens Enterprise Communications

www.siemens.com/open

Communication for the open minded

Reference No.:

A31003-S2000-U116-1-7619
