SIGLENT TECHNOLOGIES SDG2000X Series Bedienungsanleitung
Quick Start
SDG2000X Series Function/Arbitrary Waveform Generator
QS0202X-E01A
2015 SIGLENT TECHNOLOGIES CO., LTD
SIGLENT
SDG2000X Quick Start I
Copyright
○
CSIGLENT TECHNOLOGIES CO., LTD. All rights reserved.
Information in this publication replaces all previous
corresponding material.
SIGLENT reserves the rights to change the specifications and
the price.
Without permission, contents in this manual are not allowed to
be copied, extracted or translated.
SIGLENT
II SDG2000X Quick Start
General Safety Summary
Carefully read the following safety precautions to avoid any personal injuries or damages
to the instrument and any product connected to it. To avoid potential hazards, please use
the instrument as specified.
Only the qualified technician can service the instrument.
Avoid fire or personal Injure.
Use proper power line.
Use only the special power line which approved by local state.
Ground the Instrument.
The instrument is grounded through the protective terra conductor of the power line. To
avoid electric shock, the ground conductor must be connected to the earth. Make sure the
instrument is grounded correctly before connecting its input or output terminals.
Connect the signal wire correctly.
The potential of the signal wire ground is equal to the earth, so do not connect the signal
wire to a high voltage. Do not touch the exposed contacts or components.
Observe all terminal ratings.
To avoid fire or electric shock, please observe all ratings and sign instruction on the
instrument. Before connecting the instrument, please read the manual carefully to gain
more information about the ratings.
Do not operate with suspected failures.
If you suspect that the product is damaged, please let a qualified service personnel check
it.
Avoid circuit or wire exposure.
Do not touch exposed contacts or components when the power is on.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep the surface of the instrument clean and dry.
Safety Terms and Symbols
Terms used on the instrument. Terms may appear on the instrument:
DANGER: Indicates an injury or hazard that may immediately happen.
WARNING: Indicates an injury or hazard that may not immediately happen.
CAUTION: Indicates that a potential damage to the instrument or other property might
occur.
Symbols used on the instrument. Symbols may appear on the instrument:
Hazardous Protective Warning Chassis Power
Voltage Earth Ground Ground Switch
SIGLENT
SDG2000X Quick Start III
Content
General Safety Summary.............................................................. II
Adjust the Handle ......................................................................... 1
The Front Panel............................................................................ 2
The Rear Panel .......................................................................... 11
Touch Screen Display ................................................................. 14
Use Built-In Help System ............................................................ 18
Introduction of EasyWave ........................................................... 19
Contact SIGLENT ....................................................................... 20
SIGLENT
SDG2000X Quick Start 1
Adjust the Handle
When using the instrument, users can adjust the handle to a
needed position which makes it easier to operate and observe.
Horizontal Position Carrying Position
Figure 1 Adjust the Handle
SIGLENT
2SDG2000X Quick Start
The Front Panel
The figure below shows SDG2000X’s front panel composition:
Figure 2 SDG2000X Front Panel
1. Power Key
This key is used to turn on/off the SDG2000X. When the power
key is off, SDG2000X is in the power off state.
2. USB Host
SDG2000X supports U-Disk using FAT format. It’s used to read
waveforms or state files from a U-Disk or store the current state
3. Touch Screen Display
10.Waveform Option
Area
4. Numeric Keyboard
5. Knob
1. Power Key
电源键
11. Menu Keys
2. USB Host
6. Arrow Keys
7. CH1/CH2 Control/Output Port
9. Function Keys
8. Channel Select Key
SIGLENT
SDG2000X Quick Start 3
of the instrument to the U-Disk.
Users can update the firmware through U-Disk.
3. Touch Screen Display
SDG2000X has a 4.3 inch TFT-LCD touch screen, which
displays current function menu, parameter settings, system
state, prompts, etc. It is the most important display and control
center of the instrument. For detailed information, please refer
to “Touch Screen Display”.
4. Numeric Keyboard
Consists of numbers from 0 to 9, radix points “.” and symbol
keys “+/-”, which are used to input parameters.
Note：To enter a negative number, you need to enter a symbol
“-”at first.
5. Knob
It is used to increase (clockwise) or decrease (counterclockwise)
the current numerical value when setting parameters.
It is also used to switch characters in the soft keyboard when
inputting a file name.
When saving or reading files, rotate the knob to choose a
SIGLENT
4SDG2000X Quick Start
position to save a file or choose a file to be read; press the knob
to open a selected folder or file.
When choosing Waveforms →Page 1/2 →Arb →Arb Type
rotate the knob to select a desired built-in or stored waveform.
6. Arrow Keys
When using knob to set parameters, they are used to select the
digit to be modified.
When using numeric keyboard to set parameters, the left arrow
key is used as a Backspace function.
When inputting a file name, they are used to move the position
of cursor.
7. Channel Control Area
CH1 Control/Output Key
The Output key on the left is used to turn on/off CH1 output.
The nominal output impedance of the BNC connector is 50Ω.
When pressing Output (the key backlight turns on), the
connector outputs waveform according to the current
configuration of CH1.
CH2 Control/Output Key
