Sigma mobile X-style Tab A103 Bedienungsanleitung

Dear Client! Thank you for purchasing Sigma

mobile product!

Please read this manual before using the device to ensure safe and proper

use and prevent it from damages.

Software, design features and content of manual may be changed to

improve the product without a prior notice.

Manufactures and distributors are not liable for case damages as well as

the damages caused due to incorrect or improper exploitation.

Tablet PC Sigma mobile X-style Tab A103

Network charger

USB-cable

OTG-cable

Manual

Warranty Card

SIZE: 258*160*8.5 mm

The manufacturer reserves the right to change complement, specifications

and appearance.

Specifications

Android™ 7.0

Popular operating system for tablet Pcs, the

ability to install applications.

Screen

10,1” resolution 1280*800

CPU

МТК8321, four cores to 1,3GHz*.

Camera

5 Megapixel on the back and 2 Megapixel on

the front side of device to take photos and

record video.

Memory

Operational –2GB, built –16GB**. The

possible storage extension by micro-SD cards

up to 32 GB.

Dual SIM, 3G

2 SIM cards that support 3G technology –for

using Internet and to make calls.

WI-FI 802.11 B/G/N

Connection Interface to the wireless network

GPS

The ability to determine the location and to use

navigation programs.

Battery

9000 мAh.

OTG

USB On-The-Go. Ability to connect and use

some peripheral devices such mouse, USB

flash drive etc

*The frequency of the processor program may be limited to lower values.

** The actual memory size may be less due to the pre-installed operating

system and applications.

Table of contents

SAFETY AND SECURITY............................................................................................. 3

GETTING STARTED ................................................................................................... 4

Device Layout .................................................................................................... 4

Standby mode .................................................................................................... 5

Button to additional menu ................................................................................. 5

Connection to 3G networks................................................................................ 5

Indicator icons.................................................................................................... 6

Charging the battery .......................................................................................... 7

Installing a SIM-card........................................................................................... 8

Installing a memory card.................................................................................... 8

Touchscreen usage............................................................................................. 9

Rotating the screen .......................................................................................... 10

Notifications..................................................................................................... 10

Home screen .................................................................................................... 10

Managing objects ............................................................................................. 11

Creating folders................................................................................................ 11

Managing panels .............................................................................................. 11

Setting wallpaper ............................................................................................. 11

Widgets usage.................................................................................................. 12

Applications screen .......................................................................................... 12

Program installing ............................................................................................ 12

Program removing............................................................................................ 12

Account settings............................................................................................... 13

Files transferring .............................................................................................. 13

Securing the device .......................................................................................... 13

SETTINGS ............................................................................................................... 14

Wireless & networks ........................................................................................ 14

Data Usage ....................................................................................................... 15

More ................................................................................................................ 15

Device............................................................................................................... 16

Personal ........................................................................................................... 17

System.............................................................................................................. 19

Connection ............................................................................................................ 20

Phone ............................................................................................................... 20

Contacts ........................................................................................................... 21

Messaging ........................................................................................................ 22

Programs ............................................................................................................... 23

Internet ............................................................................................................ 23

Email ................................................................................................................ 23

Camera............................................................................................................. 24

Taking photos or recording videos ................................................................... 25

Gallery .............................................................................................................. 25

Google™ programs ........................................................................................... 26

Troubleshooting .................................................................................................... 27

SAFETY AND SECURITY

Do not disassemble device and do not repair it by yourself.

Permitted outside temperature operating mode: 0 to 35*C.

Storage temperature:-5 to +45*C.

Relative humidity: 5% to 90%, non-condensing (25 ° C).

Avoid the contact with fire to avoid explosion or fire.

Do not expose the device or the battery to very cold or very hot

temperatures.

Avoid the water penetration on the device.

Do not drop device and avoid its hitting by other objects.

Do not expose the tablet to the heavy mechanical impact.

Avoid contacts with sources of electromagnetic radiation.

For cleaning device do not use chemicals or cleaning means; always turn

the device off before cleaning.

Do not disconnect device from the PC while formatting and copying files.

When using the device as a removable disk always follow the instructions.

Any false step may lead to loss of files.

Create a backup copy of important data on the PC, as the device repair or

other causes may result the data loss.

Use only accessories recommended by the manufacturer.

To avoid of getting heavy metals, acids, lye in water or soil, causing

significant damage to the environment, utilize used battery according to the

law. The legal liability arises in case of infraction about the utilizationnorms.

HEADSET USAGE

For safety do not use headset while driving the car or bicycle.

Reduce the volume passing roadway.

Using the headset, do not listen to music at a high volume for a long time

–reversely, it may lead to the hearing problems.

Stop using the headset or reduce the volume if you hear the ringing inears.

GETTING STARTED

Turn on: Press and hold a few seconds power button. Wait for the download

process and lock screen appearance.

Turn off: Press and hold for four seconds power button until the switching off

interface appears. Choose the button, which confirms the switching off. The

device turns off.

Device Layout

(1) Screen

(2) Front camera

(3) Back camera

(4) Speaker

(5) USB-connector

(6) Headset connector

(7) Power: long press –turn on/off the device; short press - sleep mode on/off

(turn on the screen)

(8) Volume button:

Loudness +: volume up

Loudness -: volume down

(9) Micro SD slot (under case)

(10) SIM-cards slot (under case)

Standby mode

In operation mode theshort pressing on the power button leads the device to

the standby mode, the screen goes dark.

The repeated short pressing on the power button leads the device out from

the standby mode; the lock screen is showed on the display.

To unlock the screen, you may swipe from the bottom in any part of the

screen.

It is possible to protect yourself from unauthorized access in several ways:

- Locking by the graphical key;

- Locking by the password or PIN;

- Locking by voice.

Button to additional menu

On the main screen and in the different programs might be the icon .

By pressing on it, the additional menu is opened for additional configuration

and management.

Connection to 3G networks

To activate 3G* insert SIM-card of mobile operator in specialslot on the tablet

(only for the tablet models with built-in 3G). Only after these actions turn on

the tablet, search 3G signal appears automatically.

* Turn off the connection toWi-Fi before running the 3G function (if the tablet

was connected via Wi-Fi).

Attention: To avoid SIM-card damages turn off the tablet before changing

and removing SIM-card. Use standard SIM-cards accurately (SIM/Micro-

SIM). It is not recommended to use SIM-cards adapter. Insert and remove

the SIM-card without effort. Mechanical damage is not a guarantee case.

Indicator icons

The icons displayed at the top of the screen provide information about the

status of the device. The icons listed in the table below are most common.

No signal

Signal strength

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

HSPA+ network connected

Wi-Fi connected

Bluetooth feature activated

GPS activated

Call in progress

Missed call

Synced with the web

New text or multimedia message

Alarm activated

Mute mode activated

Vibration mode activated

Flight mode activated

Error occurred or caution required

Battery power level

Charging the battery

Charge the battery before using it for the first time.

Use only Sigma mobile approved chargers, batteries, and cables.

Unapproved chargers or cables can cause the battery to explode or damage

the device.

When the battery power is low, the battery icon appears empty.

If the battery is completely discharged, the device cannot be turned on

immediately when the charger is connected. Allow a depleted battery to

charge for a few minutes before turning on the device.

If you use multiple apps at once, network apps, or apps that need a

connection to another device, the battery will drain quickly. To avoid losing

power during a data transfer, always use these apps after fully charging the

battery.

Charging with the charger

Connect the USB cable to the USB power adaptor, and then plug the end of

the USB cable into the multipurpose jack.

Connecting the charger improperly may cause serious damage to the device.

Any damage caused by misuse is not covered by the warranty.

The device may be used while charging; in that case charging time is

prolonged.

If the device receives an unstable power supply while charging, the

touchscreen may not function. If this happens, unplug the charger from the

device.

While charging, the device and the charger may heat up. This is normal and

should not affect the device’s lifespan or performance. If the battery gets

hotter than usual, the charger may stop charging.

If the device is not charging properly, take the device and the charger to a

Sigma mobile Service Centre.

After fully charging, disconnect the device from the charger. First unplug the

charger from the device, and then unplug it from the electric socket.

To save energy, unplug the charger when not in use. The charger does not

have a powerswitch, so you mustunplug the charger from the electric socket

when not in use to avoid wasting power. The charger should remain close to

the electric socket and easily accessible while charging.

Installing a SIM-card

Insert the SIM or USIM card provided by the mobile telephone service

provider.

1. Open the cover of the SIM-card.

2. Insert SIM-card with contacts facing down as shown in the picture.

3. Push on the SIM-card into the slot to fix it. Attention!

Do not

insert the

memory

card in slot

for the SIM-

card. If the

memory card stuck in the slot for SIM-card, take the device to service center

Sigma mobile for its safe removal. Be careful not to lose the SIM-card and do

not let others use it. Sigma mobile is not liable for any damages or

inconvenience caused by lost or stolen cards.

4. Close cover of the SIM-card.

Installing a memory card

Your device accepts memory cards with maximum capacities of 32 GB.

Depending on the memory card manufacturer and type, some memory cards

may not be compatible with your device.

Some memory cards may not be fully compatible with the device. Using an

incompatible card may damage the device or the memory card, or corrupt

the data stored in it.

Use caution to insert the memory card right-side up.

The device supports the FAT and the exFAT file systemsfor memory cards.

When inserting a card formatted in a different file system, the device asks

to reformat the memory card.

Frequent writing and erasing of data shortens the lifespanof memory cards.

When inserting a memory card into the device, the memory card’s file

directory appears in the My Files.

1. Open the cover of the memory card.

2. Insert memory card with contacts facing down as shown in the picture.

3. Push on the memory card into the slot to fix it.

4. Close cover of the memory card.

Touchscreen usage

It is recommended to use fingers when you use the touchscreen.

Attention! Do not allow the touchscreen to come into contact with other electrical devices.

Electrostatic discharges can cause the touchscreen to malfunction. To avoid damaging the

touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

The device may not recognize touch inputs close to the edges of the screen, which are outside of the

touch input area. Leaving the touchscreen idle for extended periods may result in afterimages (screen

burn-in) or ghosting. Turn off the touchscreen when you do not use the device.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to

enter a character using the keyboard on the screen, tap it with your finger.

Tapping and holding

Tap and hold an item or the screen for more than 2 seconds to access

available options.

Dragging

To move an item, tap and hold it and drag it to the target position.

Double-tapping

Double - tap on a webpage or image to zoom in. Double –tap again to return.

Swiping

Swipe to the left or right on the Home screen or the Apps screen to view other

panels. You may swipe upwards or downwards to scroll through a webpage

or a list of items such as contacts.

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part.

Pinch to zoom out.

Rotating the screen

Many programs support the interface displaying in landscape or portrait

format. If the device turns, the display turns automatically according to the

new screen position.

Open notification panel and cancel the option Screen turning if you do not

want the screen to turn.

Attention! Some programs do not support the Screen turning option. Some

programs display different screen positions depends on the device position.

Notifications

When you receive new notifications, such as messages or missed calls,

indicator icons appear on the status bar. To see more information about the

icons, open the notification panel and view the details. To open the

notification panel, drag the status bar downwards. To close the notification

panel, swipe upwards on the screen. Scroll down to see additional

notifications.

On the notifications panel you may view current device settings. Drag the

status bar downwards to use the following options:

Settings : switch to device settings

Wi-Fi: Wi-Fi function on/off

Connection data: on/off mobile data

Battery

Do not disturb function switch

Bluetooth: on/off Bluetooth

Flight mode: on/off Flight mode

Screen Rotation: on/off automatically screen rotation

Torch: on/off Torch

Location: on/off GPS function

Adjust the screen brightness

Home screen

Home screen is the starting point for accessing all of the device’s features. It

displays widgets, shortcuts to apps, and more. To view other panels, swipe

to the left or right.

Inhaltsverzeichnis

Andere Sigma mobile Tablette Handbücher

Sigma mobile

Sigma mobile AB A1010 Bedienungsanleitung

Sigma mobile

Sigma mobile Tab A1015 Bedienungsanleitung

Sigma mobile

Sigma mobile X-style Tab A104 Bedienungsanleitung

Beliebte Tablette Handbücher anderer Marken

Laser

Laser MID-1060 Benutzerhandbuch

MUNBYN

MUNBYN IRT09J Kurzanleitung

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Bedienungsanleitung

Dell

Dell Latitude ST Betriebsanleitung

Lenovo

Lenovo IdeaTab S6000L Betriebsanleitung

Venturer

Venturer WT9L11 Bedienungsanleitung

EDUGEAR

EDUGEAR UnoBook Bedienungsanleitung

Philips

Philips PI3210G/58 Bedienungsanleitung

ADLINK Technology

ADLINK Technology IMT-BT Bedienungsanleitung

TwinMOS

TwinMOS TwinTAB-T102D1 Bedienungsanleitung

Archos

Archos 9.7 xenon Bedienungsanleitung

Getac

Getac E100 Bedienungsanleitung

HANNspree

HANNspree HANNspad SN70T3 Bedienungsanleitung

Philips

Philips PI3105W2/55 Bedienungsanleitung

LG LG-V935 Bedienungsanleitung

Zeki

Zeki TBDB763B Bedienungsanleitung

Ricoh

Ricoh eQuill Bedienungsanleitung

DT Research

DT Research DT365CT Montageanleitung
