Precautions
Electrical Safety
E1. Adhere to the specified operating voltage for the MiniMPL electronics at all times. The MiniMPL has
a power consumption of 100 W, and the default operating voltage is AC 110-240V, 50/60 Hz. The
voltage specification on custom configured units is labeled accordingly.
E2. Use grounded plugs and receptacles for power. It is recommended to use receptacles or power strips
equipped with surge suppressors to protect the electronics from damage.
E3. All electrical connections should be verified by qualified personnel prior to operating the instrument.
Incorrect or poor connections may cause damage to the equipment.
E4. Ground straps are recommended for handling connection cables of the MiniMPL to avoid damage
due to electrostatic discharge.
E5. Startup and shutdown procedures must be followed as described in Section 4 of this Operations
Manual. Do not attempt to open or move the MiniMPL while the instrument is in operation.
E6. The user should review all procedures listed in this Operations Manual.
E7. The MiniMPL does not have any user serviceable components. Refer any service requirements
directly to Sigma Space or an authorized representative.
Mechanical, Optical, and Environmental Safety
M1. The MiniMPL is not weatherproof, and must not be exposed to rain or excessive humidity levels
above 80%. The operating and storage temperature of the instrument should always be between 10C
(50F) and 35C (95F).
M2. The surface of the MiniMPL aperture should not be touched by hand or cleaned in a manner that is
outside of standard optical cleaning practices (gloves, acetone, lint free cotton wipes). The aperture
must remain covered when not in use to protect against dust and accidental damage. Any dust
accumulating on the aperture during normal operations should be periodically cleaned using filtered,
pressurized air. Care should be taken to avoid contact with the optical surfaces.
M3. Always use the attached handle to gently move the MiniMPL. Dropping or bumping the MiniMPL
may cause serious damage to the components inside.
Laser Safety
L1. Caution – Laser Radiation exposure may occur if the user modifies the controls or performance of
the instrument with procedures other than those specified herein.
L2. The MiniMPL System is a Class II Laser Product as defined by the US CDRH 21CFR1040.10/.11; Class II
Laser Product as defined by EN60825-1/2; and ANSI Z136.1 2000.
L3. All operators of the MiniMPL should be trained in Laser Safety prior to operating the MiniMPL. Laser
warnings should be observed at all times and direct viewing of the beam should be avoided.
