• OWNER’S MANUAL

• GUIDE DU PROPRIÉTAIRE

• MANUAL DEL USARIO

• RANGE HOOD

• HOTTE DE CUISINE

• CAMPANA DE COCINA

CAUTION

PRECAUTION

PRECAUCIÓN

Read and follow all safety rules and operating

instructions before rst use of this product.

Veuillez lire attentivement les consignes de

sécurité et les instructions d’utilisation avant

l’utilisation initiale de ce produit.

Lea y observe todas las reglas de seguridad y las

instrucciones de operación antes de usar esto

producto por primera vez.

Model • Modéle • Modelo

DWRH302SSST

Model Number:

Serial Number:

Date of Purchase:

Dealer:

PLEASE STAPLE YOUR SALES RECEIPT TO THE INSIDE FRONT

COVER

DWRH302SSST

TABLE OF CONTENTS

Instrucciones de Seguridad Importantes ...............

Ubicar el Conducto.................................................

Instalción................................................................

Operación...............................................................

Reemplazar la Bombilla ........................................

Limpieza y Mantenimiento ....................................

Resolución de Problemas .....................................

Garantía ...............................................................

ENGLISH

ESPAÑOL

Consignes importantes relatives à la sécurité......

Conduits ...............................................................

Installation ............................................................

Fonctionnement....................................................

Remplacement de l'ampoule ................................

Nettoyage et entretien ..........................................

Dépannage...........................................................

Garantie................................................................

FRANÇAIS

Important Safety Instructions ................................

Ducting...................................................................

Installation..............................................................

Operation ..............................................................

Lamp Replacement ...............................................

Cleaning and Maintenance ...................................

Troubleshooting ....................................................

Warranty ................................................................









TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS, OBSERVE THE FOLLOWING:

-











-











-

























TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:



















TO REDUCE THE RISK OF INJURY TO PERSONS IN THE

EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE

FOLLOWING:*















































































 !"#$%"!!!&#&%'

&#&%"()#"*)+&,"("$*"&-("&,(.'



















-





1) If it is necessary to use an extension cord, use only a

















DUCTING

Determine whether the hood will discharge vertically or

horizontally. For vertical or horizontal discharge, run ductwork

between the hood location and roof cap or wall cap.

A minimum 6” round duct must be used to maintain maximum

airow efciency.

Always use rigid type metal ducts only.

Whenever possible reduce the number of transitions and turns

in the ductwork. If a long duct run is required increase the duct

size from 6” to 7”.

If elbows or bends are required; install as far away from the

hood as possible.

Minimum mounting height between the range and the bottom

of the hood should be no less than 26”.

Maximum mounting height between the range and the bottom

of the hood should be no more than 34”.

WARNING!

FIRE HAZARD

NEVER implement ductwork in a space between walls, crawl

spaces, attics or garages. All exhaust must be vented outside.

Use metal ductwork only. Fasten all connections with sheet

metal screws and certied silver tape or duct tape.

2. Use the following diagram for placement of ductwork and

electrical cutout in cabinet. For a non-ducted installation, DO

NOT cut a duct access hole.

MOUNTING TO THE WALL

PREPARE THE HOOD

Unpack hood and check contents.

You should receive:

1 - Hood

2 - Decorative Flue Assembly

1 - Parts Bag containing:

2 - Flue Mounting Bracket

2 - Mounting Screws (M3 x 8mm Pan Head)

2 - Mounting Screws (M4 x 8mm Round Head)

2 - Mounting Screws (ST4 x 12mm Self Tapping)

2 - Mounting Screws (ST4 x 35mm Self Tapping)

4 - Drywall Anchors (Φ6 x 30mm & Φ8 x 35mm)

1 - Installation Instructions

1. Before mounting the hood, plug in and test all functions

for proper operation.

2. Remove the lters from the bottom of the hood to prevent

damage during the installation.

3. With assistance, hold the hood in position temporarily

ensuring the bottom is above the minimum clearance

for the cooking surface. Mark the location on the wall for the

holes for the two mounting screws.

4. Drill the holes (A) at the distances indicated. Use the

appropriate screws and screw anchors for your wall type (e.g.

reinforced concrete, drywall, etc.). If necessary, prepare back

wall with cross framing for secure installation.

5. Mount the hood on the wall screws. Align it in a horizon-

tal position relative to cabinets. When the hood has been

adjusted, secure unit by tightening screws (A).

6. Connect a 6” aluminum duct tube (not included) to

the exhaust piece using duct tape on all seals. (C).

Refer to diagram on following page.

8-5/16"

13/16"

CONNECT DUCTWORK

1. Carefully loosen but do not separate the telescopic chimney

duct pieces.

2. Install the electrical power supply within the parameters of the

decorative chimney duct.

3. Adjust the width of the support bracket to

match the upper duct. Attach it to the ceiling us-

ing the screws (B) so that it is centered in line with

your hood and at a distance from the ceiling indicated.

ROOF CAP

DECORATIVE

FLUE

6" ADAPTER

WALL CAP

26"~34"ABOVE

COOKING SURFACE

ROUND

DUCT

HOOD

ROUND ELBOW

Note: This range hood must be properly grounded.

The unit should be installed by a qualied electrician

in accordance with all applicable national and local

electrical codes.

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an

electrical short circuit, grounding reduces the risk of

electric shock by providing an escape wire for the

electric current. This appliance is equipped with a cord

containing a grounding wire and grounding plug. The

plug must be plugged into an outlet that is properly

installed and grounded.

WARNING - Improper grounding can result in a risk of

electric shock.

Consult a qualied electrician if the grounding instructions

are not completely understood, or if doubt exists as to whether

the appliance is properly grounded.

Do not use an extension cord. If the power supply cord is too

short, have a qualied electrician install an outlet near the

appliance.

Set up the electrical power supply within the space covered by

the decorative ues.

Position the power socket at a maximum distance of 33-7/16”

(85 cm) from where the lead exits from the hood

(see illustration alongside).

Make sure this does not interfere with the decorative ues

(where the ue touches the wall.)

Insert the plug into the power socket.

The rangehood can be installed in the following ways:

Circulating indoor air (A)

Outdoor venting (B)

INSTALLATION ALTERNATIVES

WARNING

LEVELING DEVICE

When mounting hood on the wall, the level can be adjusted

by turning the two screws on the motor housing.

REMEMBER!

If turns or transitions are required: Install as far away from

duct opening and as far apart between the two transitions

as possible.

Minimum mount height between range top to hood bottom

should be no less than 26”.

Maximum mount height should be no higher than 34”.

It is important to install the hood at the proper mounting

height . Being mounted too low could result in heat damage

and re hazard; while hoods mounted too heigh will be

hard to reach and will affect performance and efciency.

If a two-part connection tube is used, the lower section must

sit outside the upper section.

Do not connect the rangehood exhaust to a duct used to

circulate hot air or vent steam from another appliance.

Always use protective gloves when installing the appliance.

OPERATION

Always turn the hood ON before cooking in order to establish

an air ow in the kitchen. After turning off the range, let the

hood run for a few minutes to clear the air.

Heat Sensor:

The hood is equipped with a heat sensing thermostat. If the

safety device detects heat in excess of 158°F (70°C) above the

cooking surface, it will turn on or speed up the fan. If the fan is

not on or running at a low speed, the heat sensor will override

the normal fan control and run the fan on high speed. When

the temperature level drops below 158°F (70°C) the fan speed

will revert back to its original setting.

Operate the hood as follows:

To activate the rangehood, press the power button. Once

activated, the buttons and LED light up.

Power

The Silhouette Select™rangehood are equipped with 3 light

settings High, Low and Off. Press the light icon once and the

20w halogen bulbs turn on providing full task lighting. Press

the icon again and this reduces the illumination to 50%. Press

the icon a third time to turn the lights off.

Light

After 100 hours, the lter icon lights up and the user must re-

move the lter, clean it and replace it in order to reset the icon.

Press and hold the power button for 3 seconds to reset after

cleaning the lter.

Filter

Silhouette Select™rangehoods include a convenient feature

that allows the range hood to continue to run for an additional

5 minutes to expel residual vapors and odours after cooking.

When the timer button is pressed once the current fan speed

will continue to run for a duration of 5 minutes and the timer

icon appears on the LED display. Push the timer button a

second time to cancel the timer and remove the icon from the

LED display.

Timer

Your Silhouette Select TM rangehood offers 3 fans settings

low, medium and high. To activate the fan press the fan button

and the fan starts at the low setting and the corresponding icon

appears on the LED display. Press the fan button again and

the blower increases to the medium speed. Press a third time

for the highest speed and a fourth time to turn the fan off.

Fan

Icon for low speed

Icon for medium speed

Icon for high speed

CONNECT THE WIRING

Connect house power cable to rangehood wiring,

Ground Wire: GREEN

Fire Wire : BLACK

Zero Line : WHITE

LAMP REPLACEMENT

1. Remove Filters.

Remove tap holding lters in place. Pull down on lter tabs and

lift lters out. Set lters aside.

2. Lamp Replacement.

1. Pull out lamp from inside, release the connecter.

2. Install a new lamp, then connect the wire again.

3. Re-install the lter.

LPOWER CABLE

6" VERTICAL DUCT

KNOCKOUT

33-7/16“

(85cm)

max

The mesh lters are intended to trap residue and grease

produced in the cooking process. To ensure optimal perfor-

mance, appearance, and a sanitary cooking environment,

clean the lters, fan and grease laden surfaces regularly. Use

only a clean cloth and mild detergent solution on stainless

steel and painted surfaces. Do not use corrosive or abrasive

cleaning agents or steel wool or scouring pads as these will

scratch the surface. Do not use cleaning products that use

chlorine bleach or orange cleaners.

The grease lters, bottom panel surrounding the grease lters,

and the blower should be cleaned frequently. When washing

by hand use warm soapy (mild detergent) water. The grease

lter and blower wheels are dishwasher safe.

The motor is permanently lubricated and never needs oiling. If

the motor bearings make unusual or excessive noise, call for

service at 1-800-263-2629.

Hood Cleaning

Stainless steel is one of the easiest materials to keep

clean. Occasional care will help preserve its ne appearance.

Cleaning tips:

Hot water with soap or detergent is all that is usually needed.

Follow all cleaning with rinsing with clear water. Wipe dry with

a clean, soft cloth to avoid water marks.

For discolorations or deposits that persist, use a

non-scratching household cleanser or stainless steel polishing

powder with a little water and a soft cloth.

For stubborn cases, use a plastic scouring pad or soft bristle

brush together with cleaning solution and water. Rub lightly

in direction of polishing lines or “grain” of the stainless nish.

Avoid using too much pressure which may alter the surface.

DO NOT allow deposits to remain for long periods of time.

DO NOT use ordinary steel wool or steel brushes. Small bits

of steel may adhere to the surface causing rust.

DO NOT allow salt solutions, disinfectants, bleaches, or

cleaning compounds to remain in contact with stainless steel

for extended periods.

Many of these compounds contain chemicals which may be

harmful.

Rinse with water after exposure and wipe dry with a clean

cloth.

Painted surfaces should be cleaned with warm water and mild

detergent only.

CLEANING & MAINTENANCE

TROUBLESHOOTING

Issue Cause What to do

After installation, the unit

doesn’t work.

1. The power source is not turned ON.

2. The power line and the cable locking

connector is not connecting properly.

1. Call for service.

2. Call for service.

Light works, but motor is

not turning.

1. The blower is defective, possibly

seized.

2. Damaged capacitor.

1. Call for service.

2. Call for service.

The unit is vibrating. 1. The blower is not secure in place.

2. Damaged blower wheel.

3. The hood is not secured in place.

1. Tighten the blower in place.

2. Change the blower.

3. Check the installation of the hood.

The motor is working,

but the lights are not.

1. Defective halogen bulb. 1. Change the halogen bulb.

The hood is not venting

out properly.

1. The hood might be hanging to high from

the cook top.

2. The wind from the opened windows or

opened doors in the surrounding area

are affecting the ventilation of the hood.

3. Blockage in the duct opening or duct

work.

4. The direction of duct opening is against

the wind.

5. Using the wrong size of ducting.

1. Adjust the distance between the range

and the bottom of the hood to within

26”~34”.

2. Close all windows and doors to eliminate

the outside wind ow.

3. Remove all the blocking from the duct

work or duct opening.

4. Adjust the duct opening direction.

5. Change the ducting to at least 6” or

higher.

Metal lter is vibrating. 1. Spring clip is broken.

2. Metal lter is loose.

1. Verify spring clip is not broken.

2. Replace the metal lter.

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

First 24 Months

During the first twenty four (24) months, any functional parts of this product found to be defective, will be repaired or replaced, at

warrantor’s option, at no charge to the ORIGINAL purchaser.

To obtain

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any appliance

Service

requiring service outside the limited boundaries of “In Home Service” ,it will be the consumer’s responsibility to transport the appliance (at

their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Service” below.

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

must be performed by a qualified service technician.

If service is performed on the unit by anyone other than an authorized service depot, or the unit is used for commercial application, all

obligations of Danby under this warranty shall be void.

Boundaries of

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

In Home Service

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualified and certified for

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are the

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other contents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, made or intended by Danby or its

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditions, representations or guarantees

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall not be responsible for any damages

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or property caused by the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating conditions

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, floods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for outdoor application).

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

AUTHORIZED SERVICE DEPOT.

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

04/09

1-800-263-2629

Warranty Service

In-home

Consumable parts (ie. light bulbs, filters, glass trays, etc.) are under warranty for thirty (30) days from purchase date, with no extensions provided.
