Simarghu SIMFIRE ARB-1 Bedienungsanleitung
www.simarghu.com
Arborist Harness
Baumzüchter-Klettergurt
Harnais d’arboriste
Arnés del arborista
Imbracatura per arborista
Arborist uitrusting
UK
DE
FR
ES
IT
NL
MADE IN THE UK
2
CONTENTS 1. GENERAL INFORMATION
DESCRIPTION
This harness has been designed and manufactured specially for
arborists. It MUST NOT be used under any circumstances to
arrest a fall.
This product is manufactured and tested to conform with:
EN 813:1997 EN 358:2000
SIMARGHU®
PO BOX 412
Carlisle
CA1 9GR
T: +44 (0)1228 371 583
www.simarghu.com
PATENT PENDING
1General Information 2-3
2Use 4
2.1 Sizes 4
2.2 Part Identication – Male (FIRE) & Female (GEMINI) 4-6
2.3 How to put on Harness 7
2.4.1 Adjustment - Waste Belt 8
2.4.2 Adjustment - Leg Strap 8
2.4.3 Adjustment - Rear Straps 8
2.4.4 Adjustment - Sub Harness (Gemini Only) 9
3Floating Rope Bridge 9
3.1 Leg Riser Adjustment 9
4Lower Multi Rings 10
5Attachment Points – Male (FIRE) & Female (GEMINI) 11
5.1 Rope Bridge Set Up 12
6Suspension Trauma 12
7Harness Labelling 13
8Harness Inspection 13
9Maintenance & Storage 14
10 Service Life 14
11 Examination Form 15
12 Certicate of Conformity 16
3
UK
WARNING
Incorrect use of this harness could be fatal, so prior to
use YOU MUST:
• Read and thoroughly understand this operating manual before
using this harness.
• Be a person in t medical condition that can work at height and
do so in both normal and emergency situations. If there are any
points in this operating manual that you are unsure of, seek
advice from a trained individual.
• Be fully trained and competent in the use of the harness and
familiar with the correct actions in case of an emergency prior
to working at height.
• Carry out appropriate visual and functionality checks before
wearing this harness.
• Assess the work area to ensure adequate supporting structural
attachments are to be used.
• Understand and accept the risk involved in use of this product.
WARNING
If you are in any doubt about the condition or function
of this harness you must remove it from service
immediately and contact the seller or manufacturer.
A rescue plan should always be put in place ahead of working at
height to ensure procedures can be put into action in the event of
an accident or problem.
This product must only be serviced by a trained and competent
individual. Under no circumstances should the integrity of this
harness be undermined by making modications, repairs or
alterations.
FAILURE TO COMPLY WITH ANY OF THESE
FACTORS MAY RESULT IN SERIOUS INJURY
OR DEATH.
4
UK
WARNING
Although each harness is similar, there are important
dierences.Please ensure that you select the correct size and
fit for your build.
2. USE
2.1 SIZES 2.2 PART IDENTIFICATION
MODEL SIZE
GUIDE WAIST THIGH
SIMFIRE ARB-1 Small/
Medium
Min 27” (68cm)
/ Max 34” (86cm)
Min 17” (43cm)
/ Max 27” (68cm)
SIMFIRE ARB-2 Medium/
Large
Min 34” (86cm)
/ Max 42” (106cm)
Min 17” (43cm)
/ Max 27” (68cm)
SIMGEM ARB-3 Small/
Medium
Min 26” (66cm)
/ Max 34” (86cm)
Min 17” (43cm)
/ Max 27” (68cm)
FEATURES
1Back Pad
2Leg Loops
3Leg Strap Adjustment Buckles
4Leg Pads
5Waist Belt Adjustment Buckle
6Rope Bridge
7Rings - Side ‘D’ Rings, 7a Front ‘D’ Rings, 7b Bridge Ring
8Lower Multi Rings
9Rear Straps Adjustments Buckles
10 Shoulder Strap Attachment
11 Accessory Loops
12 Accessory Rings
13 Chainsaw Attachment Points
14 Floating Bridge Adjustment Buckles
15 Floating Bridge Strap
16 Leg Riser Adjustment Buckles
17 Label (below stretch panel)
18 Sub Harness (female GEMINI only)
19 Tool Hooks Points
5
UK
1
4
2
3
7b
16
15
8
6
7
11
7a
5 101719 19
13
15
7
9
11
14
7
12
MALE (FIRE) HARNESS - FRONT VIEW MALE (FIRE) HARNESS - BACK VIEW
6
UK
1
4
2
3
18
16
7b
15
8
6
7a
5 10
15
9
11
14
12
13
FEMALE (GEMINI) HARNESS - FRONT VIEW FEMALE (GEMINI) HARNESS - BACK VIEW
171919 19 19
7
UK
2.3 HOW TO PUT ON THE HARNESS
1. Open waist belt buckle.
2. Open leg strap buckles.
3. Hold the harness using the back
pad on each side and step in.
4. Ensure it is in the correct position,
just above the hip bones.
5. Close the waist belt buckle and
adjust to a comfortable t.
6. Close leg strap buckle and adjust.
Ensure that they are not twisted,
and the leg pads are at the back of
the thighs.
8
UK
2.4.1 ADJUSTMENT - WAIST BELT 2.4.2 ADJUSTMENT - LEG STRAP
Adjust leg strap pads by simply moving the webbing
through leg adjustment buckle, if any further
adjustments are needed release webbing from the
keeper and slide through to your required length. Any
excess webbing needs to be tucked neatly back into
the keeper.
PLEASE NOTE: The leg straps are intended to be a
relaxed fit at the thigh, as shown, however if preferred a
tighter fit can be used.
2.4.3 ADJUSTMENT - REAR STRAPS
The rear straps set the position
between the leg loop and the waist
belt. This ensures that the harness
is not slack and supports the thighs
without causing discomfort.
Adjust these straps by feeding the
webbing through the buckle to a
position which provides the best
balanced and comfort.
The waist belt should be adjusted
so that your body feels supported
and comfortable.
This adjustment is only required
once.
PLEASE NOTE: Any excess
webbing needs to be tucked neatly
back into the keeper.
9
UK
2.4.4 FEMALE (GEMINI) HARNESS ONLY
3. FLOATING BRIDGE
3.1 LEG RISER ADJUSTMENT
With a combination of adjustments
to the leg riser (16) and the oating
bridge strap (15) an optimum
position for the lower multi rings
(8), can be customised for each
user. This unique customisation
can be further enhanced by
selecting a suitable corresponding
position for the bridge rope.
The lower multi rings can be tted
with more than one rope bridge,
part number SBR125.
The female harness (GEMINI) comes with the
same benets and features but with the addition
of a sub harness.
The sub harness has been specially
designed for female anatomical support to
reduce potential injury in the event of a fall.
These straps should be pulled down and
adjusted to a ‘snug t’.
WARNING
The female harness (GEMINI) should
NOT be used by a male.The harness
has been designed to fit the female
form only.
WARNING
No more than three rope
bridges should be used
at any one time.
10
UK
4. LOWER MULTI RINGS
The two unique lower multi rings
give the exibility of three alternative
placement points allowing for a
maximum of three separate bridges.
The wearer can set the most suitable
angle by choosing either one of the
placement points. This exibility
ensures optimum balance and superior
comfort.
